Ricoh Aficio MP 1600 Owner's manual

PostScript 3 Supplement
Read this manual carefully before you use this machine and keep it handy for future reference. For safe and correct use, be sure to read the
Safety Information in "About This Machine" before using the machine.
Windows Configuration
MacOS Configuration
Using PostScript 3
Printer Utility for Mac
1
2
3
4

Introduction
This manual contains detailed instructions and notes on the operation and use of this machine. For your
safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy
place for quick reference.
Important
Contents of this manual are subject to change without prior notice. In no event will the company be li-
able for direct, indirect, special, incidental, or consequential damages as a result of handling or oper-
ating the machine.
Notes:
Some illustrations in this manual might be slightly different from the machine.
Certain options might not be available in some countries. For details, please contact your local dealer.

i
Manuals for This Machine
Refer to the manuals that are relevant to what you want to do with the machine.
Important
❒Media differ according to manual.
❒The printed and electronic versions of a manual have the same contents.
❒Adobe Acrobat Reader/Adobe Reader must be installed in order to view the
manuals as PDF files.
❒Depending on which country you are in, there may also be html manuals. To
view these manuals, a Web browser must be installed.
❖About This Machine
Be sure to read the Safety Information in this manual before using the ma-
chine.
This manual provides an introduction to the functions of the machine. It also
explains the control panel, preparation procedures for using the machine,
how to enter text, and how to install the CD-ROMs provided.
❖General Settings Guide
Explains User Tools settings, and Address Book procedures such as register-
ing fax numbers, e-mail addresses, and user codes. Also refer to this manual
for explanations on how to connect the machine.
❖Trouble Shooting
Provides a guide to solving common problems, and explains how to replace
paper, toner, and other consumables.
❖Security Reference
This manual is for administrators of the machine. It explains security func-
tions that the administrators can use to protect data from being tampered
with, or prevent the machine from unauthorized use.
Also refer to this manual for the procedures for registering administrators, as
well as setting user and administrator authentication.
❖Copy Reference
Explains Copier functions and operations. Also refer to this manual for expla-
nations on how to place originals.
❖Facsimile Reference
Explains Facsimile functions and operations.
❖Printer Reference
Explains Printer functions and operations.
❖Scanner Reference
Explains Scanner functions and operations.

ii
❖Network Guide
Explains how to configure and operate the machine in a network environ-
ment, and use the software provided.
This manual covers all models, and includes descriptions of functions and
settings that might not be available on this machine. Images, illustrations, and
information about operating systems that are supported might also differ
slightly from those of this machine.
❖Other manuals
• Manuals for This Machine
•SafetyInformation
• Quick Reference Copy Guide
• Quick Reference Fax Guide
• Quick Reference Printer Guide
• Quick Reference Scanner Guide
• PostScript 3 Supplement
•UNIXSupplement
• Manuals for DeskTopBinder Lite
• DeskTopBinder Lite Setup Guide
• DeskTopBinder Introduction Guide
•AutoDocumentLinkGuide
Note
❒Manuals provided are specific to machine types.
❒Adobe Acrobat Reader/Adobe Reader must be installed in order to view the
manuals as PDF files.
❒For “UNIX Supplement”, please visit our Web site or consult an authorized
dealer.
❒“PostScript3 Supplement” and “UNIX Supplement” include descriptions of
functions and settings that might not be available on this machine.

iii
TABLE OF CONTENTS
Manuals for This Machine ......................................................................................i
How to Read This Manual .....................................................................................1
Symbols .....................................................................................................................1
1. Windows Configuration
Using the DeskTopBinder - SmartDeviceMonitor for Client Port......................3
Installing DeskTopBinder - SmartDeviceMonitor for Client ........................................3
Installing the PostScript 3 Printer Driver (Windows 95 / 98 / Me - TCP/IP)................4
Installing the PostScript 3 Printer Driver (Windows 95 / 98 / Me - IPP) .....................5
Installing the PostScript 3 Printer Driver (Windows 2000 - TCP/IP)...........................7
Installing the PostScript 3 Printer Driver (Windows 2000 - IPP) ................................8
Installing the PostScript 3 Printer Driver (Windows XP, Windows Server 2003 - TCP/IP) ...9
Installing the PostScript 3 Printer Driver (Windows XP, Windows Server 2003 - IPP) ...11
Installing the PostScript 3 Printer Driver (Windows NT 4.0 - TCP/IP)......................12
Installing the PostScript 3 Printer Driver (Windows NT 4.0 - IPP)............................13
Changing the Port Settings for DeskTopBinder - SmartDeviceMonitor for Client ....15
Using the Standard TCP/IP Port .........................................................................17
Installing the PostScript 3 Printer Driver (Windows 2000) .......................................17
Installing the PostScript 3 Printer Driver (Windows XP, Windows Server 2003) .....18
Using the LPR Port ..............................................................................................20
Installing the PostScript 3 Printer Driver (Windows 2000) .......................................20
Installing the PostScript 3 Printer Driver (Windows XP, Windows Server 2003) .....21
Installing the PostScript 3 Printer Driver (Windows NT 4.0).....................................22
Using as the Windows Network Printer .............................................................24
Installing the PostScript 3 Printer Driver (Windows 95 / 98 / Me) ............................24
Installing the PostScript 3 Printer Driver (Windows 2000) .......................................25
Installing the PostScript 3 Printer Driver (Windows XP, Windows Server 2003) .....26
Installing the PostScript 3 Printer Driver (Windows NT 4.0).....................................27
Using as the NetWare Print Server / Remote Printer........................................28
When using the PostScript 3 Printer Driver..............................................................28
Installing the Printer Driver Using USB .............................................................29
Windows 98 SE / Me - USB .....................................................................................29
Windows 2000 - USB ...............................................................................................31
Windows XP, Windows Server 2003 - USB .............................................................32
Troubleshooting for using USB ................................................................................33
Printing with Parallel Connection.......................................................................34
Installing the PostScript 3 Printer Driver (Windows 95 / 98 / Me) ............................34
Installing the PostScript 3 printer driver (Windows 2000) ........................................35
Installing the PostScript 3 Printer Driver (Windows XP, Windows Server 2003) .....36
Installing the PostScript 3 Printer Driver (Windows NT 4.0).....................................37
Printing with Bluetooth Connection...................................................................38
Supported Profiles....................................................................................................38
Printing with Bluetooth Connection ..........................................................................38
If a Message Appears during Installation..........................................................41
Making Option Settings for the Printer ..............................................................42

iv
Setting Up the Printer Driver...............................................................................43
Windows 95 / 98 / Me - Accessing the Printer Properties ........................................43
Windows 2000 - Accessing the Printer Properties ...................................................44
Windows XP, Windows Server 2003 - Accessing the Printer Properties .................46
Windows NT 4.0 - Accessing the Printer Properties ................................................48
2. MacOS Configuration
MacOS...................................................................................................................51
Installing the PostScript 3 Printer Driver and PPD File ............................................51
Setting Up PPD Files ...............................................................................................52
Setting Up Options ...................................................................................................53
Installing Adobe Type Manager ...............................................................................53
Installing Screen fonts..............................................................................................54
Changing to EtherTalk .............................................................................................55
Mac OS X ..............................................................................................................56
Installing the PPD Files ............................................................................................56
Setting Up the PPD File ...........................................................................................57
Setting Up Options ...................................................................................................57
Using USB Interface.................................................................................................58
Using Bonjour (Rendezvous) ...................................................................................58
Changing to EtherTalk .............................................................................................59
Configuring the Printer........................................................................................60
3. Using PostScript 3
Setting Up Options ..............................................................................................61
Printing a Document............................................................................................63
Job Type ..................................................................................................................63
User Code ................................................................................................................64
Paper Selection........................................................................................................64
Paper Size................................................................................................................65
Fit to Paper...............................................................................................................65
Input Slot ..................................................................................................................66
Resolution ................................................................................................................66
Orientation Override.................................................................................................67
Print Mode................................................................................................................67
Duplex Printing.........................................................................................................68
Collate ......................................................................................................................70
Paper Type...............................................................................................................70
Destination ...............................................................................................................71
Watermark................................................................................................................71
Watermark Text........................................................................................................72
Watermark Font .......................................................................................................72
Watermark Size........................................................................................................72
Watermark Angle .....................................................................................................73
Watermark Style.......................................................................................................73
Dithering...................................................................................................................74
Image Smoothing .....................................................................................................75

v
4. Printer Utility for Mac
Installing Printer Utility for Mac..........................................................................77
Starting Printer Utility for Mac............................................................................78
Mac OS ....................................................................................................................78
Mac OS X.................................................................................................................78
Printer Utility for Mac Functions ........................................................................79
Downloading PS Fonts.............................................................................................80
Displaying Printer's Fonts.........................................................................................81
Deleting Fonts ..........................................................................................................81
Page Setup ..............................................................................................................81
Printing Fonts Catalog..............................................................................................82
Printing Fonts Sample..............................................................................................82
Renaming the Printer ...............................................................................................82
Restarting the Printer ...............................................................................................83
Downloading PostScript Files ..................................................................................83
Selecting the Zone ...................................................................................................84
Displaying the Printer Status....................................................................................85
Launching the Dialogue Console .............................................................................85
INDEX......................................................................................................... 86

vi

1
How to Read This Manual
Symbols
This manual uses the following symbols:
Indicates important safety notes.
Ignoring these notes could result in serious injury or death. Be sure to read these
notes. They can be found in the “Safety Information” section of About This Ma-
chine.
Indicates important safety notes.
Ignoring these notes could result in moderate or minor injury, or damage to the
machine or to property. Be sure to read these notes. They can be found in the
“Safety Information” section of About This Machine.
Indicates points to pay attention to when using the machine, and explanations
of likely causes of paper misfeeds, damage to originals, or loss of data. Be sure
to read these explanations.
Indicates supplementary explanations of the machine’s functions, and instruc-
tions on resolving user errors.
This symbol is located at the end of sections. It indicates where you can find fur-
ther relevant information.
[]
Indicates the names of keys that appear on the machine’s display panel.
{}
Indicates the names of keys on the machine’s control panel.

2

3
1. Windows Configuration
Using the DeskTopBinder -
SmartDeviceMonitor for Client Port
Installing DeskTopBinder - SmartDeviceMonitor for Client
Important
❒ To install DeskTopBinder - SmartDeviceMonitor for Client under Windows 2000
/ XP Professional, Windows Server 2003, and Windows NT 4.0, you must have
an account that has Manage Printers permission. Log on as an Administrator.
❒Install DeskTopBinder - SmartDeviceMonitor for Client before installing the
printer driver when using the DeskTopBinder - SmartDeviceMonitor for Cli-
ent port.
AQuit all applications currently running.
BInsert the CD-ROM into the CD-ROM drive.
The installer starts.
CSelect an interface language, and then click [OK].
The default interface language is English.
DClick [DeskTopBinder - SmartDeviceMonitor for Client].
ESelect an interface language, and then click [OK].
The default interface language is English.
FThe message to quit all other applications appears. Quit all applications,
and then click [Next >].
GThe software license agreement appears in the [License Agreement]dialog
box. After reading through its contents, click [Yes].
H Follow the instructions on the display and click [ Next > ] to proceed next step.
IAfter the installation is completed, select one of the options to restart the
computer either now or later, and click [Complete].
Restart the computer to complete installation.
Note
❒To stop installation of the selected software, click [Cancel]before installa-
tion is complete.
❒Auto Run may not work with certain operating system settings. In that
case, launch “Setup.exe” on the CD-ROM root directory.

Windows Configuration
4
1
Installing the PostScript 3 Printer Driver (Windows 95 / 98 / Me -
TCP/IP)
AQuit all applications currently running.
BInsert the CD-ROM into the CD-ROM drive.
The installer starts.
CSelect an interface language, and then click [OK].
The default interface language is English.
The printer driver with the selected language will be installed. The English
printer driver is installed when the following language is selected: Cestina,
Magyar, Polski, Portugues, Suomi.
DClick [PostScript 3 Printer Driver].
Add Printer Wizard starts.
EClick [Next >].
FClick [Local Printer], and then click [Next >].
A dialog box for selecting the printer manufacturer and model name appears.
GSelect the name of the machine whose driver you want to install, and then
click [Next >].
HIn the [Available ports:]box, click [Printer Port], and then click [Next >].
IChange the printer name if you want, and then click [Next >].
Select the [Yes]check box to configure the printer as default.
JSpecify whether or not to print a test page, and then click [Finish].
KOn the [Start]menu, point to [Settings], and then click [Printers].
The [Printers]window appears.
LClick the icon of the printer you want to use. On the [File]menu, click [Prop-
erties].
MOn the [Details]tab, click [Add Port…].
NClick [DeskTop Binder-SmartDeviceMonitor]in the [Other]list, and then click
[OK].
OClick [TCP/IP], and then click [Search].
A list of printers using TCP/IP appears.

Using the DeskTopBinder - SmartDeviceMonitor for Client Port
5
1
PSelect the printer you want to use, and then click [OK].
Only printers that respond to a broadcast from the computer appear. To use
a machine not listed here, click [Specify Address], enter the IP address or host
name of the machine, and then click [OK].
You cannot add an IP address partially similar to the one already used. For
example, if “192.168.0.2” is in use, “192.168.0.2xx” cannot be used. Similarly,
if “192.168.0.20” is in use, “192.168.0.2” cannot be used.
QCheck that the selected port is highlighted in [Print to the following port], and
then click [OK].
RRestart the computer to complete installation.
Note
❒A user code can be set after the printer driver installation. For information
about user code, see the printer driver Help.
❒Auto Run may not work with certain operating system settings. In that
case, launch “Setup.exe” on the CD-ROM root directory.
Installing the PostScript 3 Printer Driver (Windows 95 / 98 / Me - IPP)
AQuit all applications currently running.
BInsert the CD-ROM into the CD-ROM drive.
The installer starts.
CSelect an interface language, and then click [OK].
The default interface language is English.
The printer driver with the selected language will be installed. The English
printer driver is installed when the following language is selected: Cestina,
Magyar, Polski, Portugues, Suomi.
DClick [PostScript 3 Printer Driver].
Add Printer Wizard starts.
EClick [Next >].
FClick [Local Printer], and then click [Next >].
A dialog box for selecting the printer manufacturer and model name appears.
GSelect the name of the machine whose driver you want to install, and then
click [Next >].
HIn the [Available ports:]box, click [Printer Port], and then click [Next >].
IChange the printer name if you want, and then click [Next >].
Select the [Yes]check box to configure the printer as default.

Windows Configuration
6
1
JSpecify whether or not to print a test page, and then click [Finish].
KOn the [Start]menu, point to [Settings], and then click [Printers].
The [Printers]window appears.
LClick the icon of the printer you want to use. On the [File]menu, click [Prop-
erties].
MOn the [Details]tab, click [Add Port…].
NClick [DeskTop Binder-SmartDeviceMonitor]in the [Other]list, and then click
[OK].
OClick [IPP].
PIn the [Printer URL]box, enter “http://(printer's address)/printer” as the print-
er's address.
If the server authentification is issued, to enable SSL ( a protocol for encrypted
communication), enter “https://(printer's address)/printer” (Internet Ex-
plorer 5.01, or a higher version must be installed).
(example IP address: 192.168.15.16)
http://192.168.15.16/printer
https://192.168.15.16/printer
You can enter "http://printer's address/ipp" as the printer's address.
QEnter a name for identifying the printer in [IPP Port Name]. Use a name dif-
ferent from the one of any existing port.
If a name is not specified here, the address entered in the [Printer URL]box be-
comes the IPP port name.
RClick [Detailed Settings]to configure proxy server, IPP user name, and other
settings. Make these settings, and then click [OK].
You can enter "http://printer's address/ipp" as the printer's address.
SClick [OK].
TCheck that the selected port is highlighted in [Print to the following port], and
then click [OK].
URestart the computer to complete installation.
Note
❒A user code can be set after the printer driver installation. For information
about user code, see the printer driver Help.
❒Auto Run may not work with certain operating system settings. In that
case, launch “Setup.exe” on the CD-ROM root directory.

Using the DeskTopBinder - SmartDeviceMonitor for Client Port
7
1
Installing the PostScript 3 Printer Driver (Windows 2000 - TCP/IP)
Important
❒Installing this printer driver requires Administrators permission. Log on us-
ing an account that has Administrators permission.
AQuit all applications currently running.
BInsert the CD-ROM into the CD-ROM drive.
The installer starts.
CSelect an interface language, and then click [OK].
The default interface language is English.
The printer driver with the selected language will be installed. The English
printer driver is installed when the following language is selected: Cestina,
Magyar, Polski, Portugues, Suomi.
DClick [PostScript 3 Printer Driver].
Add Printer Wizard starts.
EClick [Next >].
FClick [Local printer], and then click [Next >].
GClick [Create a new port:].
HClick [DeskTop Binder-SmartDeviceMonitor], and then click [Next >].
IClick [TCP/IP], and then click [Search].
A list of printers using TCP/IP appears.
JSelect the printer you want to use, and then click [OK].
Only printers that respond to a broadcast from the computer appear. To use
a machine not listed here, click [Specify Address], and then enter the IP address
or host name of the machine.
KCheck that the name of the machine whose driver you want to install is se-
lected, and then click [Next >].
LChange the printer name if you want, and then click [Next >].
Select the [Yes]check box to configure the printer as default.
MSpecify whether or not to share the printer, and then click [Next >].
NSpecify whether or not to print a test page, and then click [Next >].
OClick [Finish].
The printer driver installation starts.

Windows Configuration
8
1
Note
❒A user code can be set after the printer driver installation. For information
about user code, see the printer driver Help.
❒Auto Run may not work with certain operating system settings. In that
case, launch “Setup.exe” on the CD-ROM root directory.
Installing the PostScript 3 Printer Driver (Windows 2000 - IPP)
Important
❒Installing this printer driver requires Administrators permission. Log on us-
ing an account that has Administrators permission.
AQuit all applications currently running.
BInsert the CD-ROM into the CD-ROM drive.
The installer starts.
CSelect an interface language, and then click [OK].
The default interface language is English.
The printer driver with the selected language will be installed. The English
printer driver is installed when the following language is selected: Cestina,
Magyar, Polski, Portugues, Suomi.
DClick [PostScript 3 Printer Driver].
Add Printer Wizard starts.
EClick [Next >].
FClick [Local printer attached to this computer], and then click [Next >].
GClick [Create a new port:].
HClick [DeskTop Binder-SmartDeviceMonitor], and then click [Next >].
IClick [IPP].
JIn the [Printer URL]box, enter “http://(printer's address)/printer” as the print-
er's address.
If the server authentification is issued, to enable SSL (a protocol for encrypted
communication), enter “https://(printer's address)/printer” (Internet Ex-
plorer 5.01, or a higher version must be installed).
(example IP address: 192.168.15.16)
http://192.168.15.16/printer
https://192.168.15.16/printer
You can enter "http://printer's address/ipp" as the printer's address.

Using the DeskTopBinder - SmartDeviceMonitor for Client Port
9
1
KEnter a name for identifying the printer in [IPP Port Name]. Use a name dif-
ferent from the name of any existing port.
If a name is not specified here, the address entered in the [Printer URL]box be-
comes the IPP port name.
LClick [Detailed Settings]to configure proxy server, the IPP user name and oth-
er settings. Specify the necessary settings, and then click [OK].
For information about the settings, see DeskTopBinder - SmartDeviceMoni-
tor for Client Help.
MClick [OK].
NCheck that the name of the machine whose driver you want to install is se-
lected, and then click [Next >].
OChange the printer name if you want, and then click [Next >].
PSpecify whether or not to print a test page, and then click [Next >].
QClick [Finish].
The printer driver installation starts.
Note
❒A user code can be set after the printer driver installation. For information
about user code, see the printer driver Help.
❒Auto Run may not work with certain operating system settings. In that
case, launch “Setup.exe” on the CD-ROM root directory.
Installing the PostScript 3 Printer Driver (Windows XP, Windows
Server 2003 - TCP/IP)
Important
❒Installing this printer driver requires Administrators permission. Log on us-
ing an account that has Administrators permission.
AQuit all applications currently running.
BInsert the CD-ROM into the CD-ROM drive.
The installer starts.
CSelect an interface language, and then click [OK].
The default interface language is English.
The printer driver with the selected language will be installed. The English
printer driver is installed when the following language is selected: Cestina,
Magyar, Polski, Portugues, Suomi.

Windows Configuration
10
1
DClick [PostScript 3 Printer Driver].
Add Printer Wizard starts.
EClick [Next >].
FClick [Local printer attached to this computer.], and then click [Next >].
GClick [Create a new port:].
HClick [DeskTop Binder-SmartDeviceMonitor], and then click [Next >].
IClick [TCP/IP], and then click [Search].
A list of printers using TCP/IP appears.
JSelect the printer you want to use, and then click [OK].
Only printers that respond to a broadcast from the computer appear. To use
a machine not listed here, click [Specify Address], and then enter the IP address
or host name of the machine.
KCheck that the name of the machine whose driver you want to install is se-
lected, and then click [Next >].
LChange the printer name if you want, and then click [Next >].
Select the [Yes]check box to configure the printer as default.
MSpecify whether or not to print a test page, and then click [Next >].
NClick [Finish].
The printer driver installation starts.
Note
❒A user code can be set after the printer driver installation. For information
about user code, see the printer driver Help.
❒Auto Run may not work with certain operating system settings. In that
case, launch “Setup.exe”on the CD-ROM root directory.

Using the DeskTopBinder - SmartDeviceMonitor for Client Port
11
1
Installing the PostScript 3 Printer Driver (Windows XP, Windows
Server 2003 - IPP)
Important
❒Installing this printer driver requires Administrators permission. Log on us-
ing an account that has Administrators permission.
AQuit all applications currently running.
BInsert the CD-ROM into the CD-ROM drive.
The installer starts.
CSelect an interface language, and then click [OK].
The default interface language is English.
The printer driver with the selected language will be installed. The English
printer driver is installed when the following language is selected: Cestina,
Magyar, Polski, Portugues, Suomi.
DClick [PostScript 3 Printer Driver].
Add Printer Wizard starts.
EClick [Next >].
FClick [Local printer attached to this computer.], and then click [Next >].
GClick [Create a new port:].
HClick [DeskTop Binder-SmartDeviceMonitor], and then click [Next >].
IClick [IPP].
JIn the [Printer URL]box, enter “http://(printer's address)/printer” as the print-
er's address.
If the server authentification is issued, to enable SSL (a protocol for encrypted
communication), enter “https://(printer's address)/printer” (Internet Ex-
plorer 5.01, or a higher version must be installed).
(example IP address: 192.168.15.16)
http://192.168.15.16/printer
https://192.168.15.16/printer
You can enter "http://printer's address/ipp" as the printer's address.
KEnter a name for identifying the printer in [IPP Port Name]. Use a name dif-
ferent from the one of any existing port.
If a name is not specified here, the address entered in the [Printer URL]box be-
comes the IPP port name.

Windows Configuration
12
1
LClick [Detailed Settings]to make necessary settings.
For information about the settings, see DeskTopBinder - SmartDeviceMoni-
tor for Client Help.
MClick [OK].
NCheck that the name of the printer driver you want to install is selected, and
then click [Next >].
OChange the name of the printer if you want, and then click [Next >].
Select the [Yes]check box to configure the printer as default.
PSpecify whether or not to print a test page, and then click [Next >].
QClick [Finish].
The printer driver installation starts.
Note
❒A user code can be set after the printer driver installation. For information
about user code, see the printer driver Help.
❒Auto Run may not work with certain operating system settings. In that
case, launch “Setup.exe” on the CD-ROM root directory.
Installing the PostScript 3 Printer Driver (Windows NT 4.0 - TCP/IP)
Important
❒Installing this printer driver requires Administrators permission. Log on us-
ing an account that has Administrators permission.
❒If your operating system is Windows NT4.0, download printer driver for
Windows NT4.0 from the supplier's Web site.
ADouble-click on "SETUP.EXE" in the downloaded folder.
Add Printer Wizard starts.
BSelect [My Computer], and then click [Next >].
CClick [Add Port...].
DClick [DeskTop Binder-SmartDeviceMonitor], and then click [New Port...].
EClick [TCP/IP], and then click [Search].
A list of printers using [TCP/IP]appears.
FSelect the printer you want to use, and then click [OK].
Only printers that respond to a broadcast from the computer appear. To use
a machine not listed here, click [Specify Address], and then enter the IP address
or host name of the machine.
