Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 1 -
Ring Contact Sensor – 2nd Generation
Introduction
Ring Alarm Contact Sensor is a wireless sensor for the Ring Alarm system which provides users the
ability to know when a door or window is open or closed. After installing the sensor on a door or
window and setting up the sensor in the Ring app, monitor and receive notifications when the door
or window opens or closes. The Ring Alarm Base Station is required to enable Contact Sensor
features and functions within the Ring app.
Notes:
1. This product can be operated in any Z-WaveTM network with other Z-Wave certified devices
from other manufacturers. All mains operated nodes within the network will act as repeaters
regardless of vendor to increase reliability of the network.
2. SmartStart enabled products can be added into a Z-Wave network by scanning the Z-Wave
QR Code present on the product with a controller providing SmartStart inclusion. No further action is required and the
SmartStart product will be added automatically within 10 minutes of being switched on in the network vicinity.
Installation & Set Up
Ring Alarm Contact Sensor – Basic Setup & Installation
In-app Setup
1. Ensure your Ring Alarm system is disarmed.
2. In the Ring app, tap Set Up a Device and find the Contact Sensor in the Security Devices menu.
3. Follow the in-app instructions to complete setup.
a. Pull the battery tab (or reinsert the batteries) to trigger setup mode.
b. Tap the button on the front to retry setup mode.

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 2 -

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 3 -
Installation
1. Choose a door or window for installing your Contact Sensor and companion magnet.
2. Ensure the surfaces where you plan to install your sensor and magnet are clean and free from dust or dirt.
3. Using the provided double-sided tape, peel the backing and attach the sensor to the mounting location.
4. Follow the same steps for the companion magnet ensuring the magnet is aligned with the sensor and no more than 1 inch
from sensor for the "closed" position.
Note: Leave ~ ½ in. of space on the side opposite the magnet to ensure you can slide open the case when it's time to change the
batteries.
Note:
• This product can be operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers. All mains
operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.
• This is a SmartStart enabled product which can be added into a Z-Wave network by scanning the Z-Wave QR Code present
on the product with a controller providing SmartStart inclusion. No further action is required and the SmartStart product will be
added automatically within 10 minutes of being switched on in the network vicinity. This product can also be operated in any
Z-Wave network with other Z-Wave certified devices from other manufacturers.
Z-Wave Instructions
Z-Wave Device Type: Notification Sensor
Role Type: Reporting Sleeping Slave (RSS)
• GENERIC_TYPE_SENSOR_NOTIFICATION (0x07)
• SPECIFIC_TYPE_NOTIFICATION_SENSOR (0x01)
Ring Alarm Contact Sensor Inclusion
Adding Ring Alarm Contact Sensor to a Z-Wave Network
Ring Alarm Contact Sensor can be added via SmartStart or Classic inclusion mode.

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 4 -
Note: When prompted for the QR Code or PIN, you may find them on the device, on the box, or on a card inside the box. Keep the
device nearby. You’ll be prompted to pull the battery tab to power on the device and enter setup mode.
SmartStart Inclusion Steps:
1. Initiate the add flow for Security Devices in the Ring mobile application – Follow the guided add flow instructions provided in
the Ring mobile application.
2. When prompted by the mobile application, scan the QR code found on the package of the Contact Sensor. The QR code can
also be found on the device itself.
3. Pull the pull-tab or insert batteries, and the device will go into SmartStart inclusion mode. While in this mode, Contact Sensor
can be added to a Z-Wave controller that supports SmartStart. When in SmartStart inclusion mode, SmartStart can be
restarted by tapping the button on the front of the device.
Classic Inclusion Steps:
1. Initiate add flow for Security Devices in the Ring mobile application – Follow the guided add flow instructions provided in the
Ring mobile application.
2. Select add manually and enter the 5-digit DSK PIN found on the package of the Ring Alarm Contact Sensor or the 5-digit
DSK PIN found under the QR code on the device.
3. After powering on the device, press and hold the button on the front of the device for ~3 seconds. Release the button and the
device will enter Classic inclusion mode which implements both classic inclusion with a Node Information Frame, and
Network Wide Inclusion. During Classic Inclusion mode, the green LED will blink three times followed by a brief pause,
repeatedly. When Classic inclusion times-out, the device will blink alternating red and green a few times.
Note: Classic Inclusion should be used if the controller does not support SmartStart.
LED Behavior for Inclusion
Blink Pattern
SmartStart Started
Green LED three times, repeated after a brief
pause
Classic Inclusion Started
Green LED three times, repeated after a brief
pause
Classic Inclusion Timed-Out
Alternate red and green a few times
Inclusion Successful (Authenticated S2)
Green LED on solid

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 5 -
Inclusion Not Successful (Self-Destruct)
Red LED on solid
Ring Alarm Contact Sensor – Exclusion
Removing Ring Alarm Contact Sensor from a Z-Wave Network
Exclusion Instructions:
1. Initiate remove “Ring Alarm Contact Sensor” flow in the Ring Alarm mobile application – Select the settings icon from device
details page and choose “Remove Device” to remove the device. This will place the controller into Remove or “Z-Wave
Exclusion” mode.
2. With the controller in Remove (Z-Wave Exclusion) mode, use a paper clip or similar object and tap the pinhole button. The
device’s red LED turns on solid to indicate the device was removed from the network.
Ring Alarm Contact Sensor – Factory Reset
Factory Default Instructions
1. To restore Ring Alarm Contact Sensor to factory default settings, locate the pinhole reset button on the device. This is found
inside the battery compartment on the back of the device after removing the back bracket.
2. Using a paperclip or similar object, insert it into the pinhole, press and hold the button down for 10 seconds.
3. The device will rapidly blink green continuously for 10 seconds. After about 10 seconds, when the green blinking stops,
release the button. The red LED will turn on solid to indicate the device was removed from the network.
Note: Use this procedure only in the event that the network primary controller is missing or otherwise inoperable.
Wake-Up Notification
The sensor will wake up every so often to send a Wake-Up Notification to allow the life line master node controller that the sensor is
now available for any queued messages that the controller may have for the sensor. The time between Wake-Up Notifications can be
configured with the Wake-Up Notification command class according to the following configurable values:
• Min Value 1 hr
• Max Value 24 hr
• Default Value 12 hours (12 * 60 * 60 seconds)
• Wake Up Interval Step Seconds 1 hour (3600 seconds)

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 6 -
Z-Wave Command Classes
Command Class
Version
Required
Security Class
Association
2
Highest granted
Association Group Information
3
Highest granted
Device Reset Locally
1
Highest granted
Firmware Update Meta Data
5
Highest granted
Indicator
3
Highest granted
Manufacturer Specific
2
Highest granted
Multi-Channel Association
3
Highest granted
Powerlevel
1
Highest granted
Security 2
1
none
Supervision
1
none
Transport Service
2
none
Version
3
Highest granted
Z-Wave PlusTM Info
2
none
Notification
8
Highest granted
Wake Up
2
Highest granted
Configuration
4
Highest granted
Battery
2
Highest granted
Association Command Class
Group Identifier
Max Nodes
Description
1 (Lifeline)
0x05
1. Notification Report
a. See notification CC section for notifications that are sent
2. Battery Report

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 7 -
Group Identifier
Max Nodes
Description
3. Device Reset Locally Notification
Configuration Command Class
The sensor has the following supported configuration parameters.
Parameter
Number
Description
Number
of
Bytes
Default
Min
Max
Format
1
Heartbeats:
This parameter is the number minutes
between heartbeats. Heartbeats are
automatic battery reports on a timer after
the last event.
1
70 (0x46)
1 (0x01)
70 (0x46)
0x01
Unsigned
2
Number of application level retries
attempted for messages either not ACKed
or messages encapsulated via supervision
get that did not receive a report.
1
1 (0x01)
0 (0x00)
5 (0x05)
0x01
Unsigned
3
Application Level Retry Base Wait Time
Period:
The number base seconds used in the
calculation for sleeping between retry
messages.
1
5 (0x05)
1 (0x01)
60 (0x3C)
0x01
Unsigned
4
This parameter allows a user, via software,
to configure the various LED indications on
the device.
0 == Don't show green
1 == Show green after Supervision Report
Intrusion (Fault)
2 == Show green after Supervision Report
both Intrusion and Intrusion clear
1
1 (0x01)
0 (0x00)
2 (0x01)
enum

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 8 -
Parameter
Number
Description
Number
of
Bytes
Default
Min
Max
Format
5
One shot timer:
Writing to this parameter prompts the
sensor to send a wakeup notification one
time after this parameter's number of
seconds. After which it is reset back to 0.
2
0 (0x00)
5 (0x05)
65535
(0xFFFF)
0x01
Unsigned
6
The number of milliseconds waiting for a
Supervisory Report response to a
Supervisory Get encapsulated command
from the sensor before attempting a retry.
2
1500
(0x5DC)
500 (0x1F4)
5000
(0x1388)
0x01
Unsigned
Notification Command Class, V8
Sensor Condition
Command Class and Value
Association Group
Door/Window Open
Notification Report
Type: Home Security 0x07
State: Intrusion 0x02
1 (Lifeline)
Door/Window Close
Notification Report
Type: Home Security 0x07
State: Previous Events Cleared 0x00
Event parameter: 0x02
1 (Lifeline)
Sensor Case Removed
Notification Report
Type: Home Security 0x07
State: Tampering Product Covering Removed 0x03
1 (Lifeline)

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 9 -
Sensor Condition
Command Class and Value
Association Group
Sensor Case Fastened
Notification Report
Type: Home Security 0x07
State: Previous Events Cleared 0x00
Event Parameter: 0x03
1 (Lifeline)
Comm Test Button Pressed
Notification Report
Type: System 0x09
Event: Heartbeat 0x05
1 (Lifeline)
Watchdog Notification
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0x55
1 (Lifeline)
Magnetic Tamper
Notification Report
Type: Home Security 0x07
State: 0x0B (Magnetic field interference detected)
1 (Lifeline)
Magnetic Tamper Clear
Notification Report
Type: Home Security 0x07
State: Previous Events Cleared 0x00
Event Parameter: 0x0B
1 (Lifeline)
Software Fault (Ring)
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAA (Ring Value for Soft Fault)
1 (Lifeline)
Software Fault (SDK)
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xA9 (SDK Value for Soft Fault)
1 (Lifeline)
Pin Reset (soft reset)
Notification Report
1 (Lifeline)

Ring Alarm Contact Sensor User Manual
Date:
Version: 0.1
Page: - 10 -
Sensor Condition
Command Class and Value
Association Group
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAB
Software Reset (Not triggered by failure)
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAC
1 (Lifeline)
Power On Reset
Notification Report
Type: 0x08 Power Management
Event Parameter: 0x01 Power has been applied
1 (Lifeline)
Brownout
Notification Report
Type: 0x08 Power Management
Event: 0x05 Voltage Drop/Drift
1 (Lifeline)
Dropped Frame
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAD
1 (Lifeline)
