ring Contact Sensor 2nd Generation Z-Wave User manual

1
Contact Sensor 2nd Generation
Z-Wave™ Technical Manual

2
Ring Contact Sensor
Introduction
Ring Alarm Contact Sensor is a wireless sensor for the Ring Alarm system which provides users the
ability to know when a door or window is open or closed. After installing the sensor on a door or
window and setting up the sensor in the Ring app, monitor and receive notifications when the door or
window opens or closes. The Ring Alarm Base Station is required to enable Contact Sensor features
and functions within the Ring app.
Notes:
1. This product can be operated in any Z-Wave™ network with other Z-Wave certified devices
from other manufacturers. All mains operated nodes within the network will act as repeaters
regardless of vendor to increase reliability of the network.
2 SmartStart enabled products can be added into a Z-Wave network by scanning the Z-Wave
QR Code present on the product with a controller providing SmartStart inclusion. No further
action is required and the SmartStart product will be added automatically within 10 minutes of being
switched on in the network vicinity.

3
Installation & Set Up
Ring Alarm Contact Sensor – Basic Setup & Installation
In-app Setup
1. Ensure your Ring Alarm system is disarmed.
2. In the Ring app, tap Set Up a Device and find the Contact Sensor in the Security Devices menu.
3. Follow the in-app instructions to complete setup.
a. Pull the battery tab (or reinsert the batteries) to trigger setup mode.
b. Tap the button on the front to retry setup mode.
Installation
1. Choose a door or window for installing your Contact Sensor and companion magnet.
2. Ensure the surfaces where you plan to install your sensor and magnet are clean and free
from dust or dirt.
3. Using the provided double-sided tape, peel the backing and attach the sensor to the
mounting location.
4. Follow the same steps for the companion magnet ensuring the magnet is aligned with the sensor
and no more than 1 inch from sensor for the “closed” position.
Note
Leave ~ ½ in. of space on the side opposite the magnet to ensure you can slide open the case when
it’s time to change the batteries.
This product can be operated in any Z-Wave network with other Z-Wave certified devices from other
manufacturers. All mains operated nodes within the network will act as repeaters regardless of vendor
to increase reliability of the network.
This is a SmartStart enabled product which can be added into a Z-Wave network by scanning the
Z-Wave QR Code present on the product with a controller providing SmartStart inclusion. No further
action is required and the SmartStart product will be added automatically within 10 minutes of being
switched on in the network vicinity. This product can also be operated in any Z-Wave network with other
Z-Wave certified devices from other manufacturers.
Z-Wave Instructions
Z-Wave Device Type: Notification Sensor
Role Type: Reporting Sleeping Slave (RSS)
GENERIC_TYPE_SENSOR_NOTIFICATION (0x07)
SPECIFIC_TYPE_NOTIFICATION_SENSOR (0x01)

4

5
Ring Alarm Contact Sensor – Inclusion
Adding Ring Alarm Contact Sensor to a Z-Wave Network
Ring Alarm Contact Sensor can be added via SmartStart or Classic inclusion mode.
Note
When prompted for the QR Code or PIN, you may find them on the device, on the box, or on a card
inside the box. Keep the device nearby. You’ll be prompted to pull the battery tab to power on the
device and enter setup mode.
SmartStart Inclusion Steps:
1. Initiate the add flow for Security Devices in the Ring mobile application – Follow the guided add flow
instructions provided in the Ring mobile application.
2. When prompted by the mobile application, scan the QR code found on the package of the
Contact Sensor. The QR code can also be found on the device itself.
3. Pull the pull-tab or insert batteries, and the device will go into SmartStart inclusion mode. While in
this mode, Contact Sensor can be added to a Z-Wave controller that supports SmartStart. When in
SmartStart inclusion mode, SmartStart can be restarted by tapping the button on the front of
the device.
Classic Inclusion Steps:
Classic Inclusion should be used if the controller does not support SmartStart.
1. Initiate add flow for Security Devices in the Ring mobile application – Follow the guided add flow
instructions provided in theRing mobile application.
2. Select add manually and enter the 5-digit DSK PIN found on the package of the Ring Alarm Contact
Sensor or the 5-digit DSK PIN found under the QR code on the device.
3. After powering on the device, press and hold the button on the front of the device for ~3 seconds.
Release the button and the device will enter Classic inclusion mode which implements both classic
inclusion with a Node Information Frame, and Network Wide Inclusion. During Classic Inclusion
mode, the green LED will blink three times followed by a brief pause, repeatedly. When Classic
inclusion times-out, the device will blink alternating red and green a few times.
LED Behabior for Inclusion Blink Pattern
SmartStart Started Green LED three times, repeated after a brief pause
Classic Inclusion Started Green LED three times, repeated after a brief pause
Classic Inclusion Timed-Out Alternate red and green a few times
Inclusion Successful (Authenticated S2) Green LED on solid
Inclusion Not Successful (Self-Destruct) Red LED on solid

6
Ring Alarm Contact Sensor – Exclusion
Removing Ring Alarm Contact Sensor from a Z-Wave Network
Ring Alarm Contact Sensor can be added via SmartStart or Classic inclusion mode.
Exclusion Instructions:
1. Initiate remove “Ring Alarm Contact Sensor” flow in the Ring Alarm mobile application – Select the
settings icon from device details page and choose “Remove Device” to remove the device. This will
place the controller into Remove or “Z-Wave Exclusion” mode.
2. With the controller in Remove (Z-Wave Exclusion) mode, use a paper clip or similar object and tap
the pinhole button. The device’s red LED turns on solid to indicate the device was removed from
the network.
Ring Alarm Contact Sensor – Factory Reset
Factory Default Instructions
1. To restore Ring Alarm Contact Sensor to factory default settings, locate the pinhole reset button on
the device. This is found inside the battery compartment on the back of the device after removing
the back bracket.
2. Select add manually and enter the 5-digit DSK PIN found on the package of the Ring Alarm Contact
Using a paperclip or similar object, insert it into the pinhole, press and hold the button down for
10 seconds.
3. The device will rapidly blink green continuously for 10 seconds. After about 10 seconds, when the
green blinking stops, release the button. The red LED will turn on solid to indicate the device was
removed from the network.
Note
Use this procedure only in the event that the network primary controller is missing or
otherwise inoperable.
Wake-Up Notification
The sensor will wake up every so often to send a Wake-Up Notification to allow the life line master node
controller that the sensor is now available for any queued messages that the controller may have for
the sensor. The time between Wake-Up Notifications can be configured with the Wake-Up Notification
command class according to the following configurable values:
• Min Value 1 hr
• Max Value 24 hr
• Default Value 12 hours (12 * 60 * 60 seconds)
• Wake Up Interval Step Seconds 1 hour (3600 seconds)

7
Z-Wave Command Classes
Command Class Version Required Security Class
Association 2 Highest granted
Association Group Information 3 Highest granted
Device Reset Locally 1 Highest granted
Firmware Update Meta Data 5 Highest granted
Indicator 3 Highest granted
Manufacturer Specific 2 Highest granted
Multi-Channel Association 3 Highest granted
Powerlevel 1 Highest granted
Security 2 1 none
Supervision 1 none
Transport Service 2 none
Version 3 Highest granted
Z-Wave Plus™ Info 2 none
Notification 8 Highest granted
Wake Up 2 Highest granted
Configuration 4 Highest granted
Battery 2 Highest granted
Association Command Class
Group Identifier Max Nodes Description
1 (Lifeline) 0x05
1. Notification Report
a. See notification CC section for notifications that are sent
2. Battery Report
3. Device Reset Locally Notification

8
Parameter
Number Description
Number
of
Bytes
Default Min Max Format
1
Heartbeats:
This parameter is the number min-
utes between heartbeats. Heart-
beats are automatic battery reports
on a timer after the last event.
1 70 (0x46) 1 (0x01) 70 (0x46) 0x01
Unsigned
2
Number of application level retries
attempted for messages either not
ACKed or messages encapsulated
via supervision get that did not
receive a report.
1 1 (0x01) 0 (0x00) 5 (0x05) 0x01
Unsigned
3
Application Level Retry Base Wait
Time Period: The number base
seconds used in the calculation for
sleeping between retry messages.
1 5 (0x05) 1 (0x01) 60 (0x3C) 0x01
Unsigned
4
This parameter allows a user, via
software, to configure the various
LED indications on the device.
0 == Don’t show green
1 == Show green after Supervision
Report Intrusion (Fault)
2 == Show green after Supervision
Report both Intrusion and Intrusion
clear
1 1 (0x01) 0 (0x00) 2 (0x01) enum
5
One shot timer: Writing to this
parameter prompts the sensor to
send a wakeup notification one
time after this parameter’s number
of seconds. After which it is reset
back to 0.
2 0 (0x00) 5 (0x05) 65535
(0xFFFF)
0x01
Unsigned
6
The number of milliseconds
waiting for a Supervisory Report
response to a Supervisory Get
encapsulated command from the
sensor before attempting a retry.
21500
(0x5DC) 500 (0x1F4) 5000 (0x1388)
0x01
Unsigned
Configuration Command Class
The sensor has the following supported configuration parameters.

9
Notification Command Class, V8
Sensor Condition Command Class and Value Association Group
Door/Window Open
Notification Report
Type: Home Security 0x07
State: Intrusion 0x02
1 (Lifeline)
Door/Window Close
Notification Report
Type: Home Security 0x07 State:
Previous Events Cleared 0x00 Event parameter: 0x02
1 (Lifeline)
Sensor Case Removed
Notification Report
Type: Home Security 0x07
State: Tampering Product Covering Removed 0x03
1 (Lifeline)
Sensor Case Fastened
Notification Report
Type: Home Security 0x07
State: Previous Events Cleared 0x00
Event Parameter: 0x03
1 (Lifeline)
Comm Test Button Pressed
Notification Report
Type: System 0x09
Event: Heartbeat 0x05
1 (Lifeline)
Watchdog Notification
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0x55
1 (Lifeline)
Magnetic Tamper
Notification Report
Type: Home Security 0x07
State: 0x0B (Magnetic field interference detected)
1 (Lifeline)
Magnetic Tamper Clear
Notification Report
Type: Home Security 0x07
State: Previous Events Cleared 0x00
Event Parameter: 0x0B
1 (Lifeline)
Software Fault (Ring)
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAA (Ring Value for Soft Fault)
1 (Lifeline)
Software Fault (SDK)
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xA9 (SDK Value for Soft Fault)
1 (Lifeline)
Pin Reset (soft reset)
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAB
1 (Lifeline)
Software Reset
(Not triggered by failure)
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAC
1 (Lifeline)
Power On Reset
Notification Report
Type: 0x08 Power Management
Event Parameter: 0x01 Power has been applied
1 (Lifeline)
Brownout
Notification Report
Type: 0x08 Power Management
Event: 0x05 Voltage Drop/Drift
1 (Lifeline)
Dropped Frame
Notification Report
Type: System 0x09
State Value: 0x04 System Software Failure
State Parameter Value = 0xAD
1 (Lifeline)

10
Supplier’s Declaration of Conformity – Compliance Information Statement
Unique Identifier: Ring Contact Sensor
Responsible Party and Party issuing Supplier’s Declaration of Conformity
Ring LLC dba Ring
1523 26th Street
Santa Monica, CA 90404 U.S.A.
www.ring.com / [email protected]om
FCC Compliance Statement (for products subject to Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Innovation, Science and Economic Development Canada (ISED) Compliance
This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired operation
of the device.
Conformité Innovation Sciences et Développement Économique Canada (ISDE) L’émetteur/récepteur
exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage.

11
To review your warranty coverage, please visit www.ring.com/warranty.
© 2020 Ring LLC or its affiliates.
Ring, Always Home, and all related logos are trademarks of Ring LLC or its affiliates.
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible
d’en compromettre le fonctionnement.
CAN ICES-3 (B)/NMB-3(B)
In accordance with FCC requirements of human exposure to radio frequency fields, the radiating
element shall be installed such that a minimum separation distance of 20 cm is maintained from the
general population.
Conformément aux exigences d’Industrie Canada
en matière d’exposition humaine aux champs de radiofréquences, l’élément rayonnant doit être
installé de telle sorte qu’une distance minimale de 20 cm soit maintenue par rapport à la population
générale.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
AVERTISSEMENT : Tout changement ou modification à cet appareil qui n’a pas fait l’objet d’une
autorisation expresse par la partie responsable de sa conformité pourrait annuler le droit pour
l’utilisateur d’opérer l’équipement.
CAUTION: To reduce the risk of electrical shock, DO NOT open the unit. There are no user serviceable
parts inside the unit. Refer to customer support for any repairs.
ATTENTION : Pour réduire le risque d’électrocution, NE PAS ouvrir l’appareil. Aucune pièce interne n’est
réparable par l’utilisateur. Veuillez vous référer au service à la clientèle pour toute réparation.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Dispose of the used batteries according to the
manufacturer’s instructions.
ATTENTION : Danger d’explosion si la pile n’est pas remplacée correctement. Remplacez la pile
uniquement par une pile identique ou par une pile du même type que celle recommandée par le
fabricant. Suivez les instructions du fabricant pour jeter les piles usées.
