RINGFEDER TNZ ZCA User manual

Partner for Performance www.ringfeder.com
08.2019
TNZ ZCA / TNZ ZCB
TNZ ZCAUU / TNZ ZCBUU
TNZ ZCAU / TNZ ZCBU
Gear Couplings
RINGFEDER®TNZ ZCA / TNZ ZCB,
TNZ ZCAU / TNZ ZCBU, TNZ ZCAUU /
TNZ ZCBUU
Assembly, Disassembly
EN

08.2019
TA!
2EN
Cleaning Drilling
Disassembly Align shafts
(axial, radial and angular)
Warning!
Always work with gloves to
protect yourself from burns
from hot coupling parts!
Even warming of the shaft
hub at 80 °C to 120 °C is
harmless in order to simplify
assembly.
Recycling/disposal
Used grease must be disposed
of appropriately.
Grease gun Clamping site
Legend
Assembly
Valid data on the required
tightening torques on the
relevant screw connections
can be found in the following
tables. The tightening torque is
to be applied by tightening
the hexagon nut.
Assembly, Disassembly
Safety instructions
Rotating machine parts may injure operators and service staff!
Therefore:
Switch off the drive before assembly work.
Safeguard the machine against accidental switch-on.
Mount all covers and protection devices before switching on
the machine.
RINGFEDER®products may only be mounted by specialist staff
and for suitable applications.
Attention
Please read these instructions through carefully.
In the event of infringement of these notes all claims of
liability will become void.
RINGFEDER POWER TRANSMISSION reserves the right
to technical changes to improve the product.
RINGFEDER®Gear Couplings are accepted state of
the art.
If you experience problems or have any questions, our
technical and service staff will be happy to assist you. See
the reverse of these instructions for the corresponding
contact information.
Gear Couplings
RINGFEDER®TNZ

08.2019
1 2
4
1
2
3
H7/m6
TNZ ZCA / TNZ ZCB, TNZ ZCAU / TNZ ZCBU,
TNZ ZCAUU / TNZ ZCBUU
3EN
The coupling is generally delivered assembled. The coupling
must be disassembled and checked for completeness prior
to assembly.
The gear hub must be clamped at the marked areas for
drilling.
If the customer carries out the hub bore then the hub must
be aligned carefully with the outer diameter in order to
adhere to the required concentricity
The maximum values for the drilling diameter Ø dmax must
be adhered to in all events.
The hubs must be secured against axial displacement on
the shaft ends using an adjusting screw, shaft locking plate
or suitable oversize element.
Attention: The adjusting screw should never be under
the O-ring in the casing.

08.2019
7
C2
1
3
2
8
1
2
2
E
5
1
2
6
TNZ ZCA / TNZ ZCB, TNZ ZCAU / TNZ ZCBU,
TNZ ZCAUU / TNZ ZCBUU
9ZCB
1
3
2
C1
4EN
table 3, page 6
B-design:
Simply slide the separate O-ring covers,
including the O-ring, onto the ends of
the shaft.

08.2019
∆Kr
∆Kw
180°
180°
TNZ ZCA / TNZ ZCB, TNZ ZCAU / TNZ ZCBU,
TNZ ZCAUU / TNZ ZCBUU
5EN
The maximum permitted displacements must always be taken into account!
The valid data can be found in the following table (Table 1).
Attention: the coupling may never be adjusted ‘to zero’!
A small offset is necessary in order to achieve lubrication of the gearing.
Heat expansion that is to be expected during operation must be taken into account
when adjusting the cold system, so that the maximum permitted displacement values
are not exceeded during operation.
Displacement values are maximum values that may not occur simultaneously.
The values must be reduced if there is simultaneous radial and angular displacement.
Aligning the coupling
Table 1: Displacement values
An angular displacement of Kw= 0.1° is necessary at all times in order to guarantee lubrication of the gearing.
Size Max. axial
displacement
Max. radial
displacement Max. angular displacement
∆Ka[mm] ∆Kr[mm]
recommended
∆Kr[mm]
maximum
∆Kw[mm]
recommended
∆Kw[mm]
maximum
∆Kw[°]
recommended
∆Kw[°]
maximum
69 1 0,11 0,42 0,15 0,60
0,125° per hub 0,5° per hub
85 1 0,13 0,51 0,19 0,74
107 1 0,17 0,66 0,23 0,933
133 1,5 0,19 0,77 0,29 1,16
152 1,5 0,25 1,00 0,33 1,32
179 2 0,29 1,15 0,39 1,56
209 20,33 1,33 0,46 1,82
234 30,38 1,50 0,51 2,04
254 30,44 1,75 0,56 2,21
279 30,50 2,00 0,61 2,43
305 30,54 2,16 0,67 2,66
355 4 0,64 2,55 0,77 3,10

08.2019
10 11
TA!
TA!
TNZ ZCA / TNZ ZCB, TNZ ZCAU / TNZ ZCBU,
TNZ ZCAUU / TNZ ZCBUU
6EN
Please note the required tightening torques!
Table 2: Tightening torques for flange screws
Table 3: Tightening torques for cover screws, version B
Size 69 85 107 133 152 179 209 234 254 279 305 355
MA[Nm] 33,5 66 112 277 277 537 537 537 537 537 795 795
z x Thread M 6 x M8 8 x M10 6 x M12 6 x M16 8 x M16 8 x M20 8 x M20 10 x M20 10 x M20 14 x M20 14 x M24 16 x M24
Opening width 10 12 14 19 19 24 24 24 24 24 30 30
Tool 1/4“ 3/8“ 3/8“ 1/2“ 1/2“ 1/2“ 1/2“ 1/2“ 1/2“ 1/2“ 1“ 1“
Valid data can be found in the tables (2 and 3) below.
Only use fitting screws and nuts in the condition as delivered. The fastening elements may
not be cleaned or additionally lubricated.
Secure the fitting screws against twisting and tighten the nuts with the given torque.
Any adjusting screws must be secured against unwanted loosening and flying off during
tightening using a suitable adhesive such as e.g.: Loctite 222.
Size 69 85 107 133 152 179 209 234 254 279 305 355
MA[Nm] - - 1,3 3 3 3 8 13 13 33 33 33
Thread - - M3 M4 M4 M4 M5 M6 M6 M8 M8 M8

08.2019
12
TNZ ZCA / TNZ ZCB, TNZ ZCAU / TNZ ZCBU,
TNZ ZCAUU / TNZ ZCBUU
7EN
Place the filling openings horizontally.
Open the screw plug on the opposite side before filling.
Fill lubricant into each half of a coupling, for example
using a grease press, until it comes out of the opposite drill
hole.
Select a suitable lubricating grease from Table 5.
Conventional roller bearing grease is not suitable for use
in Gear Couplings.
Table 4: Lubricant quantities for the entire coupling
Table 5: Recommended lubricants
Ver-
sion Size 69 85 107 133 152 179 209 234 254 279 305 355
E
Quantity
[dm³] 0,067 0,08 0,13 0,22 0,38 0,58 0,75 1,25 1,92 2,67 3,34 5,00
EI1
Quantity
[dm³] 0,07 0,09 0,17 0,27 0,56 0,85 1,20 1,88 2,98 4,05 5,16 8,09
EI2
Quantity
[dm²] 0,078 0,12 0,27 0,36 0,90 1,38 2,09 3,12 5,11 6,80 8,82 14,21
Normal speed and load High speed and load
Manufacturer Variety Manufacturer Variety
Agip Agip GR MU/EP1
Caltex Coupling grease Caltex Coupling grease
Castrol Impervia MDX
Chevron Polyurea grease EP 0
Esso Fibrax 370
Fina Marson EPL 1
Lical EPL 1
Gulf Gulfcrown EP 0
Klüber Klüberplex GE 11-680
Grafloscon C-SG 500 Plus Klüber Klüberplex GE 11-680
Mobil Mobilgrease XTC Mobil Mobilgrease XTC
Pennzoil Multi-Purpose 705
Shell Alvania grease EP R-0 / EP 1 Shell Albida GC1
Texaco Coupling grease Texaco Coupling grease
Total Specis EPG

08.2019
Grünen Gehäuseansch
gestrichelt darstellen
1
2
3
1
2
4
1
1
1
2
2
5
TNZ ZCA / TNZ ZCB, TNZ ZCAU / TNZ ZCBU,
TNZ ZCAUU / TNZ ZCBUU
8EN

08.2019 9EN
Maintenance
The torsionally stiff Gear Coupling RINGFEDER®TNZ must be
maintained and lubricated regularly!
Please check the following points during
routine maintenance work on the system:
Lubricant quantity in the coupling
Leak tightness of the coupling
Adjustment of the coupling
A tight fit on all fastening elements
Remove dust and dirt deposits on the coupling parts
Inspection and maintenance
The coupling must be re-lubricated after every 1,000 hours of
operation.
After every 5,000 hours of operation or at least once every two
years the grease must be changed, gears and seals inspected
for damage and the adjustment checked.
The position of the gear hub and the sprocket sleeve to one
another must be marked before opening the coupling.
Place the geared parts back together in their original position
after the inspection. The same gears must always interlock as
before.
It is recommended to exchange the seal elements as well as the
screws and nuts as part of the maintenance.
General information on operation
Please note the identification data when using the coup-
ling (see product Product Paper & Tech Paper ”Gear Cou-
plings“). They may never be exceeded without the written
authorisation of RINGFEDER POWER TRANSMISSION.
In order to ensure the failure-free, long-term operation of
the coupling it must be adjusted in accordance with the
design specification in the Product Paper & Tech Paper ”Gear
Couplings“ with an operating factor that is suitable for the
operating conditions. Any modification to the conditions
of use or the operating parameters necessitates an inspec-
tion of the coupling configuration.
At the start and during operation please pay attention to:
changes in running sounds,
vibrations,
leaks,
other unusual occurrences.
Attention!
If you discover irregularities at the start or during operation
then please switch the drive off immediately!
Determine the cause of the fault and resolve it.
All the machine components and operating circumstances
must be taken into account when searching for the fault.
Coupling operating temperature:
-10 °C to +80 °C
Further information
Gear Couplings
RINGFEDER®TNZ
