ASSEMBLY INSTRUCTIONS
RiverRidge® Somerset 2-Door Floor Cabinet
ITEM #: 06-038 White
ITEM #: 06-077 Gray
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
WARNING SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don’t use
this item for a TV stand or place heavy objects on top of item. Always use
angle-braces or anchors to secure furniture to the wall.

THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF AND 10 POUNDS PER
DRAWER OR A TOTAL OF 85 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 25
POUNDS AND 10 POUNDS PER DRAWER OR A TOTAL OF 85 POUNDS TOTAL WEIGHT. IF
OVERLOADED WITH MORE THAN 25 POUNDS PER SHELF AND 10 POUNDS PER DRAWER
OR 85 POUNDS TOTAL WEIGHT, SHELF MAY TIP FROM WALL AND CAUSE SERIOUS
INJURY OR DEATH.

PARTS LIST
NO
QTY
DESCRIPTION
1
1 PC
Left Side Panel
2
1 PC
Right Side Panel
3
1 PC
Right Support Board
4
1 PC
Cross Bar
5
1 PC
Bottom Board
6
1 PC
Left Support Board
7
1 PC
Top Board
8
2 PCS
Back Board
9
2 PCS
Shelf
10
1 PC
Drawer Front Board
11
1 PC
Drawer Right Side Panel
12
1 PC
Drawer Left Side Panel
13
1 PC
Drawer Bottom Board
14
1 PC
Drawer Back Board
15
1 PC
Left Door
16
1 PC
Right Door

NO
PARTS
QTY
DESCRIPTION
A
18PCS
Wood Dowel
B
18PCS
Cam Bolt
C
18PCS
Cam Lock
D
18PCS
Screw (3x12mm)
E
4PCS
Hinge
F
2PCS
Magnet Plate
G
18PCS
Wood Screw (2.5x12mm)
H
1 SET
Magnet With 2 Screws
I
8PCS
Shelf Holder
J
6PCS
Machine Screw (4x12mm)
K
3PCS
Handle
L
8PCS
Screw (3.5x12mm)
M
4PCS
Screw (4x35mm)
P
1PC
Plastic Connection Strip
Q
2PCS
Plastic Anchor
R
2PCS
Screw (4x30mm)
S
2PCS
Adjustable Anchor Bracket
U
2PCS
Screw (4x14mm)
V
1 SET
Drawer Slides (Attach to Side Panel)
W
1 SET
Drawer Slides (Attach to Drawer)
TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY
DO NOT USE IF ANY PARTS ARE MISSING OR DAMAGED
To order replacement parts at no cost to you, email [e-mail], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
For purchases outside of the United States, please contact retailer where purchased.

STEP 1
1. Attach drawer left side panel (12) to drawer back board (14) by inserting 2 long wood
screws (M) through holes on drawer left side panel (12), then tighten to drawer back
board (14).
2. Attach drawer right side panel (11) to drawer back board (14) by inserting 2 long wood
screws (M) through holes on drawer right side panel (11), then tighten to drawer back
board (14).
3. Slide drawer bottom board (13) into grooves on drawer left side panel (12), drawer right
side panel (11) and drawer back side panel (14).
STEP 2
1. Screw 2 cam bolts (B) into cam bolt holes on drawer front board (10).
2. Insert 4 wood dowels (A) into dowel holes on drawer front board (10).
3. Attach drawer front board (10) to drawer left side panel (12), drawer right side panel (11)
and drawer bottom board (13) by inserting dowels (A) into dowel holes and inserting cam
bolts (B) into cam lock holes on drawer left side panel (12), drawer right side panel (11)
and inserting drawer bottom board (13) into groove on drawer front board (10).
4. Insert 2 cam locks (C) into cam lock holes on drawer left side panel (12) and drawer right
side panel (11), then rotate clockwise to secure cam bolts (B) in place.
5. Attach 1 handle (K) to drawer front board (10) by inserting 2 machine screws (J) through
holes on drawer front board (10), then tighten to handle (K).

STEP 3
1. Turn assembled drawer upside down.
2. Attach drawer slides (W) to drawer right side panel (11) by inserting 2 wood screws (L)
through holes on drawer slides (W), then tighten to drawer right side panel (11).
3. Attach drawer slides (W) to drawer left side panel (12) by inserting 2 wood screws (L)
through holes on drawer slides (W), then tighten to drawer left side panel (12).
STEP 4
1. Screw 3 cam bolts (B) into cam bolt holes on left support board (6).
2. Insert 2 wood dowels (A) into dowel holes on left support board (6).
3. Attach left support board (6) to left side panel (1) by inserting wood dowels (A) into dowel
holes and inserting cam bolts (B) into cam lock holes on left side panel (1).
4. Insert 3 cam locks (C) into cam lock holes on left side panel (1), then rotate clockwise to
secure cam bolts (B) in place.

STEP 5
1. Screw 3 cam bolts (B) into cam bolt holes on right support board (3).
2. Insert 2 wood dowels (A) into dowel holes on right support board (3).
3. Attach right support board (3) to right side panel (2) by inserting wood dowels (A) into
dowel holes and inserting cam bolts (B) into cam lock holes on right side panel (2).
4. Insert 3 cam locks (C) into cam lock holes on right side panel (2), then rotate clockwise
to secure cam bolts (B) in place.
STEP 6
1. Attach drawer slides (V) to left side panel (1) by inserting 2 wood screws (L) through holes
on drawer slides (V), then tighten to left side panel (1).
2. Attach 2 hinges (E) to left support board (6) by inserting 4 wood screws (D) through holes
on hinges (E), then tighten to left support board (6).

STEP 7
1. Attach drawer slides (V) to right side panel (2) by inserting 2 wood screws (L) through
holes on drawer slides (V), then tighten to right side panel (2).
2. Attach 2 hinges (E) to right support board (3) by inserting 4 wood screws (D) through holes
on hinges (E), then tighten to right support board (3).
STEP 8
1. Screw 6 cam bolts (B) into cam bolt holes on left side panel (1) and right side panel (2).
2. Insert 6 wood dowels (A) into dowel holes on left side panel (1) and right side panel (2).
3. Attach cross bar (4) to left side panel (1) by inserting wood dowel (A) and cam bolt (B) into
holes on cross bar (4), then insert 1 cam lock (C) into cam lock hole on cross bar (4), then
rotate clockwise to secure cam bolt (B) in place.
4. Attach bottom board (5) to left side panel (1) by inserting wood dowels (A) and cam bolts
(B) into holes on bottom board (5), then insert 2 cam locks (C) into cam lock holes on
bottom board (5) and rotate clockwise to secure cam bolts (B) in place.
5. Repeat above steps to attach right side panel (2) to cross bar (4) and bottom board (5).
6. Attach magnet (H) to cross bar (4) by inserting 2 wood screws (H) through holes on
magnet (H), then tighten to cross bar (4).

STEP 9
1. Insert 2 screws (U) through sliding brackets (S) into holes on top board (7).
2. Insert 4 wood dowels (A) into dowel holes on top of left side panel (1) and right side panel (2).
3. Screw 4 cam bolts (B) into cam bolt holes on top board (7).
4. Attach top board (7) to left side panel (1) and right side panel (2) by inserting 4 wood dowels
(A) into dowel holes on top board (7), then insert 4 cam bolts (B) into cam lock holes on left
side panel (1) and right side panel (2).
5. Insert 2 cam locks (C) into cam lock holes on left side panel (1), then rotate clockwise to
secure 2 cam bolts (B) in place.
6. Insert 2 cam locks (C) into cam lock holes on right side panel (2), then rotate clockwise to
secure 2 cam bolts (B) in place.
STEP 10
1. Attach 2 back boards (8) together by sliding into plastic connection strip (P).
2. Attach 2 back boards (8) to pre-assembled cabinet by inserting 18 wood screws (G) through
holes on back boards (8), then tighten into cabinet.

STEP 11
1. Attach left door (15) to left side panel (1) by inserting 4 wood screws (D) through holes on
hinges (E), then tighten to left door (15).
2. Attach handle (K) to left door (15) by inserting 2 machine screws (J) through holes on left
door (15), then tighten to handle (K).
3. Attach 1 magnet plate (F) to left door (15) by inserting 1 wood screw (D) through hole on
magnet plate (F), then tighten to left door (15).
4. Repeat above 3 steps to assemble right door (16) to right side panel (2) and assemble
handle (K), magnet plate (F) to right door (16).
STEP 12
Option #1: Securing to Drywall
1. Position cabinet against wall in desired location. Using a pencil, make two small marks on wall
through holes on brackets (S). Move cabinet away from wall and screw 2 plastic anchors (Q)
into wall on pencil marks.
2. Place cabinet against wall, insert 2 screws (R) through holes on brackets (S), then tighten
to plastic anchors (Q).
Option #2: Securing to Drywall and Wood Stud
1. Position cabinet against wall in desired location. Insert 2 screws (R) through holes on brackets
(S), then tighten through drywall and into wood stud.
*Tip: Anchor bracket (S) can be adjusted to correct distance from wall to cabinet as needed. Once adjusted,
be sure to re-tighten bracket inside cabinet for stability.

STEP 13
1. Place drawer in cabinet by inserting drawer slides with wheels into drawer slides in cabinet.
2. Insert 8 shelf holders (I) into holes on left side panel (1) and right side panel (2) at desired
shelf heights.
3. Place shelves (9) onto shelf holders (I).
IMPORTANT:
Keep assembly instructions for future reference.
ATTENTION ADULTS: Cabinet should be checked periodically for damage or
loose screws/parts. Take appropriate action necessary to correct hazards such as
tightening of screws and taking any damaged parts away from children.
WARNING Please make sure your item is
secured to the wall, per assembly instructions.
CARE INSTRUCTIONS:
Wipe clean with a water dampened cloth. Wipe dry with clean cloth.

Enjoy your new RiverRidge® Cabinet!
Thank you for purchasing this RiverRidge® Home item. We hope you
enjoy it and consider purchasing other RiverRidge® items.
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI 54016
