RiverRidge X-FRAME BATH WALL SHELF-WHITE User manual

ASSEMBLY INSTRUCTIONS
X-FRAME BATH WALL SHELF-WHITE
X-FRAME BATH WALL SHELF-ESPRESSO
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of the small parts. Care should be
taken in unpacking and assembling this item to keep the small parts away from children.
WARNING
Young children can be seriously injured or killed, if furniture tips over.
Don’t use this item for a TV stand.
Use angle-braces or anchors to secure furniture to the wall.
- 1 -

- 2 -
THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 50 POUNDS.
DO NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS AND A TOTAL OF 50 POUNDS TOTAL
WEIGHT. IF OVERLOADED WITH MORE THAN 25 POUNDS PER SHELF AND 50 POUNDS TOTAL
WEIGHT THE SHELF MAY FALL FROM THE WALL AND CAUSE SERIOUS INJURY OR DEATH.

- 3 -
PARTS LIST
NO PARTS QTY DESCRIPTION
1 1PC TOP BOARD
2 2PCS SIDE FRAME
3 1PC BOTTOM BOARD
4 1PC BACK BOARD
5 1PC LEFT SIDE PANEL
6 1PC RIGHT SIDE PANEL
7 1PC BACK CROSS BAR
8 1PC FRONT CROSS BAR
A 4PCS WOOD DOWEL
B 8PCS LONG WOOD SCREW 5x45mm
C 12PCS WOOD SCREW 4x35mm
D 6PCS SMALL WOOD SCREW 3x12mm
E 3PCS HOOK
F 4PCS PLASTIC CAP
G 2PCS WOOD SCREW 4x40mm
H 2PCS PLASTIC ANCHOR
I 1PC ALLEN WRENCH
TOOLS NEEDED FOR ASSEMBLY: PHILIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF POWER SCREWDRIVER IS NOT RECOMMENDED

- 4 -
STEP 1
STEP 1
1. Put the top board (1) upside down on a soft padded surface.
2. Attach the back apron (7) to the top board (1) by inserting 3 wood screws (C) through the holes
on the back apron (7) then tighten to the top board (1) by using a Philips screw driver.
3. Repeat the above step to assemble the front apron (8).
STEP 2
STEP 2
1. Attach 1 side frame (2) to the top board (1) by inserting 2 long wood screws (B) through the holes
on the side frame (2) then tighten to the back cross bar (7) and front cross bar (8) by using the
Allen wrench (I).

- 5 -
STEP 3
STEP 3
1. Attach another side frame (2) to the top board (1) by inserting 2 long wood screws (B) through
the holes on the side frame (2) then tighten to the back cross bar (7) and front cross bar (8) by
using the Allen wrench (I).
STEP 4
STEP 4
1. Attach the bottom board (3) to the bottom side of 2 side frames (2) by inserting 4 long wood
screws (B) through the holes on the bottom board (3) then tighten to the 2 side frames (2) by
using the Allen wrench (I).

- 6 -
STEP 5
STEP 5
1. Attach 1 hook (E) to the back board (4) by inserting 2 small wood screws (D) through the holes
on the hook (E) then tighten to the back board (4).
2. Repeat the above step to assemble the other 2 hooks (E).
3. Insert 2 wood dowels (A) into the holes on the left side panel (5).
4. Attach the left side panel (5) to the back board (4) by inserting the 2 wood dowels (A) into the
holes on the back board (4).
5. Insert 1 wood screw (C) through the hole on the left side panel (5) and tighten to the back board
(4).
6. Repeat the above steps 3- 6 to assemble the right side panel (6).
STEP 6
STEP 6
1. Attached the assembled back board (4) to the bottom board (3).
2. Insert 2 wood screws (C) through the holes on the bottom board (3) then tighten to the left side
panel (5) by using a Philips screwdriver.
3. Insert 2 wood screws (C) through the holes on the bottom board (3) then tighten to the right side
panel (6) by using a Philips screwdriver.

- 7 -
STEP 7
STEP 7
1. Press 4 plastic caps (F) into the wood screw holes on the 2 side frames (2).
2. If added pressure is needed to keep the plastic cap in place – cover the cap with a piece of paper
and tap lightly with a hammer to secure the cap.
STEP 8
STEP 8
1. Drill 2 holes on the wall by using the template drawing(included) w/hole positions as a guideline.
2. Insert 2 plastic anchors (H) into the holes on the wall.
3. Insert 2 wood screws (G) through the holes on the back cross bar (7) then tighten to the 2 plastic
anchors (H) with a Philips screwdriver.

- 8 -
Attention Adults: The cabinet should be checked periodically for damage or loose screws/parts.
Take appropriate action necessary to correct the hazard such as tightening of screws and taking
any damaged parts away from children.
ENJOY YOUR NEW CABINET NOW !
Thank you for purchasing this item. We hope you enjoy it, and consider purchasing other
items.
