JCROffroad UNI-FPF-PC Configuration guide

FAIRLEAD LICENSE
PLATE FLIP
Please read the mounting instructions below carefully before attempting to install.
Thank you for purchasing from JcrOroad! Checkout our website, www.jcroroad.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-353-1184!
INSTALL INSTRUCTIONS

INCLUDED HARDWARE
4x
4x
1x
6x
6x
5/16"-18 x 3/4"
Button Head
5/16"-18
Lock Nut
Adjustable
Hinge
1/4"-20
Serr. Flange Nut
1/4"-20 x 3/4"
Button Head

INCLUDED PARTS
1x
1x
1x

1The bracket will bolt together as shown below. The small angled bracket
highlighted in red will only be used on bumpers with completely vertical
fairleads. If your bumper has an angled fairlead, the hinge will bolt directly
to the fairlead-side bracket. The bracket will then slide over the winch line
and bolt behind the fairlead. The hinge will use 5/16" bolts and lock nuts.
NOTE:
The license plate bracket can be flipped to mount the plate higher if needed.
The fairlead and angled brackets are slotted to allow for front to back adjustment of the
license plate.
