roblight FI 1050 B-2 3000KCRI 90+ User manual

User manual
FL 1050 B-2

The RobLight FL 1050 B-2 light generator is designed for indoor use in dry locations
with glass and PMMA fibre harness Ø9/Ø28 mm. It can be used in all installations set
-ups, including closed compartments if limits for max ambient temperature are
followed.
Introduction
Product overview/unboxing
1 FL 1050 B-2
1 User manual
Installation instructions
Follow the installation instructions to ensure
• Safe operation
• Full functionality
• Stated expected lifetime
• Uninterrupted illumination
Applies to :
0132 0018 Fl 1050 B-2 3000K CRI 90+
0132 0019 Fl 1050 B-2 3000K CRI 95+
0132 5019 Fl 1050 B-2 3000K CRI 95+ AUS
0132 0028 Fl 1050 B-2 4000K CRI 90+
0132 1719 Fl 1050 B-2M 3000K CRI 95+
0132 1740 Fl 1050 B-2M 3000K CRI 95+ Ø40

This device has a built in high power phosphor converted blue led. The light source
is grouped in Risk Group 2.
Warning
Do not look into the light port when lit.
Beware of placing highly light absorbing material directly in front (Distance 0-1cm)
of the port or a fibre. The extremely high intensity will increase the temperature in
the material.
Using non RobLight harnesses in this light generator is at its own risk.
Ensure that the polyconnector is undamaged and clean before using the light gener-
ator in retrofit RobLight installations.
Beware that when the or a light generator is operated at max ambient temperature
the surface temperature can exceed 75°C.
The light generator is only tested with RobLight standard polyconnector end.
The warranty label is not to be broken under ANY circumstances. If broken the
warranty is terminated.
Warranty label
Risk group 2
CAUTION.
Possibly hazardous optical radiation emitted from this
product. Do not stare at operating lamp. May be harmful
to the eye.

General
Light port Ø28 mm
Fibre type PMMA or glass
Material Aluminium, POM and other
Dimensions (L x H x W) 268 x 73 x 86mm
Weight (total) 1120g
Safety CE, RoHS, WEEE
Environmental
Protection rating IP 20
Thermal protection Automatic resettable
Cooling Ebmpapst cooling solution [7 dB(A)]
Ambient temperature -10°C to 45°C
Driver/electrical
Driver LED driver constant current
Supply voltage (mains) 220-240V 50/60Hz
Driver expected lifetime 50.000 hours (@TC = 65°C)
Total power consumption 42W
Dimmer systems applicable DALI 1-10V, PWM and PUSH (mains) and (DMX on
request
Light source
Applied LED Cree
LED expected lifetime >50.000 hours @Ta = 25°C
Typical CCT 3000K or 4000K, 3SDMC
Typical Ra (CRI1-8) 93 (min. 90)
Technical data

Installation instructions
a) Remove cap from the light port
b) For use with Ø9 harness, mount the Ø28->Ø9 harness adaptor on the common
end Tighten the screw with the Allen key
c) Insert the common end, fully in the light port
d) Tighten the screw on the light port
e) Ensure all installation and ventilation requirements are met
f) Connect the supply cord to the mains

Surface mounting
Attach to surface using two screws (not supplied) in the baseplate holes
Vertical mounting
This light generator should not be mounted with light port up. At high ambient tem-
perature the operational lifetime of the internal components will be reduced.

MAX AMBIENT TEMPERATURE 45°C.
Recommendations: (should always be tested in a mock up)
Secure enough space to allow natural heat transmission through surfaces.
Surfaces should not be insulated.
Cooling air for the polyconnector can not be obstructed in any way, as it is essential
to avoid damage to the harness.
General minimum distance from the light generator to any enclosing surface 10 cm
(excluded mounting surface).
Ventilation holes per light generator with min. 20 cm² air inlet and min. 20 cm² air
outlet.
Beware of inlet and outlet ventilation holes
opposite each other as shown on the drawing.
Keep free from dust and polluted air.
Installing adjacent light generators
Recommendation:
Minimum 10 cm distance between adjacent light generators to ensure enough free
cooling air.
If multiple rows, use offset to avoid vertical rows. Minimal free distance between
rows 15 cm.
Max temperature has to be observed for all light generators measured at air inlet
for each light generator.
MAX AMBIENT TEMPERATURE 45°C.
Closed compartments

Installing accessories
The 1-10V dimmer potentiometer can be installed following this procedure.
Remove lid and wire fasternes from the
driver
Place dimmer in 1-10V, brown wire in +
Place fasternes and lid again
Network line
Wire from Dimmer 1-10V
Potentiometer
Wire from Light Generator

Accessories / Spare part
Part name Description Item no.
CCT Filter A –500KWill make the ligth warmer. Will not fade.
No tools needed 0126 1000
CCT Filter A –900KWill make the light warmer. Will
not fade.
No tools needed 0126 1002
CCT Filter A –1200KWill make the light warmer. Will
not fade.
No tools needed 0126 1001
Colour Filter,
FL1000, yellow Yellow colour filter. Glass. Will not fade. No tools needed 0126 1004
Colour Filter,
FL1000, green Green colour filter. Glass. Will not fade. No tools needed 0126 1005
Colour Filter,
FL1000, blue Blue colour filter. Glass. Will not fade. No tools needed 0126 1006
Colour Filter,
FL1000, red Red colour filter. Glass. Will not fade. No tools needed. 0126 1007
Colour Wheel kit User attachable kit for make your
fibres light in sparkling colours. 0126 6105
Twinkling Wheel
kit User attachable kit to make your fibres twinkle. 0126 6205
Dimmer 1-10V
(potentiometer) Attach it to the driver and the product can be dimmed 0126 5110
Adapter Ø28/Ø9 If you want to change the light port
from Ø28 to Ø9 mm. 7800 0130

The effectiveness of the active cooling device is greatly diminished if the cooling
fins and the air intake is blocked or polluted with dust. This will reduce the ex-
pected lifetime of the product.
The dust must be removed on a regular basis. Interval depending on the environ-
ment.
A fine brush, vacuum cleaning or light compressed air can be used for the cleaning.
This light source is not supposed to be otherwise serviced, if used as recommended.
The fan can be replaced using standard tools. A replacement kit with guide is avail-
able.
If the product is not performing as specified, use the troubleshooting guide. If you
need further assistance, please contact RobLight.
Maintenance, spare parts and repairs

Application notes
The light generator is an electronic device and must be handled accordingly. The
different components will have different factors influencing the practical lifetime.
The most important factor for this system is the condition of the surrounding air
(temperature and cleanliness). The data we have stated about or and the expected
lifetime of the key components, are at the temperatures that the suppliers have
performed during their standardized tests in clean environments.
The light generator is designed to run at max ambient temperature, but the longest
usable operation is achieved with lower temperatures.
Although there is thermal protection built into this device, it is only a safety device
and should not be used as a measurement device to test if the light generator is
running at a tolerable surrounding temperature.
The polyconnector is the most stressed part of this system.
Care should be taken to ensure that the fibre ends are 100% clean and free from
dust and grease (fingerprint will do damage.). See www.rob-light.com for recom-
mendations to clean fibre ends.
Running the light generator at too high temperatures will not only risk damage to
the light source but also to the fibre harness.
CLEAN AIR
KEEP COOL

Troubleshooting
If problems are not solved using this guide, please contact RobLight A/S.
Problem Trace the problem Solution
No light
Check the power Connect the power cord properly/ Turn
on the device
Check the tempera-
ture.
Check it is installed according to the
instructions.
Check the dimming Unplug. Unplug the dimmer system
from the driver. Turn on the power.
Light switches
on and off
Check the operating
conditions of the
light generator
Check it is installed according to the
instructions.
Check active cool-
ing system.
Remove dirt and dust from light gene-
rator.
Problem Trace the problem Solution
No light
Check the power Connect the power cord properly
Turn on the device
Check the tempera-
ture
Check if it is installed according to the
instructions
Check the dimming
Unplug the light generator. Unplug the
dimmer system from the driver. Turn
on the power
Light switches
on and off
Check the operating
conditions of the
light generator
Check if it is installed according to the
instructions
Check the active
cooling system
Remove dirt and dust from the light
generator
RobLight accepts no responsibility for possible errors in catalogues, brochures and other printed material.
RobLight reserves the right to alter or discontinue its products without notice. © 2019 RobLight A/S
RobLight A/S, Nordhavnsvej 1A, DK-9900 Frederikshavn
T: [phone], E: [e-mail]
www.rob-light.com
99082127, 01-09-2020, Rev. 1.1
