Rockler Miter-Tight Picture Frame Clamp User manual

Miter Tight Picture Frame
Clamp™Instructions
Review full instruction manual prior to use for important safety information.
Always check Rockler.com to conrm that you are using the most recent manual version for your product.

2
> Always confirm that you are using the most recent version
of the Instructions and safety warnings for your product. To
find the most recent version, find the product page on
Rockler.com and click on the link to the Instructions.
> For any tool used in conjunction with this product,
always read, understand and follow the instructions
and safety warnings in the owner’s manual for that tool.
If you do not have the owner’s manual, obtain one from
the tool’s manufacturer before using it with this product.
> Before using this product, review and verify that all
tools to be used with it have safety equipment
installed and are in proper working order as
defined by the tools’ owner’s manuals.
> Do not use this product until you have read and
are confident you understand:
• Parts List (pp. 3);
• Picture Frame Stock (pp. 4).
> Do not use this product in any manner other than
what is described in these instructions. Use only
recommended accessories.
> Remain alert and use good judgment when using
this tool. Do not use this tool if you are in any way
impaired by medications, alcohol, drugs or fatigue.
> Dress appropriately and remove all jewelry, secure
loose clothing and tie up long hair before using
this tool.
> It is the sole responsibility of the purchaser of this
product to ensure that any third party whom you
allow to use this product reads and complies with all the
instructions and safety precautions outlined in this
manual prior to use.
> Maintain these instructions and warnings as long as
you own the product. Keep this booklet in a place where
it will be readily available for reference.
> The user assumes all risk and responsibility for the
proper use of this product and for ensuring product
suitability for intended application.
> Always wear safety glasses in compliance with ANSI
safety standards and hearing protection and follow all
standard shop safety practices, including:
• Keep your work area well lit and clean;
• Unplug all power tools before making any
adjustments or changing accessories;
• Use dust collection tools and dust face masks to
reduce exposure to dust;
• Use accessory safety equipment such as
featherboards, push sticks and push blocks
whenever appropriate;
• Do not use power tools in explosive
environments (e.g., in the presence of
flammable liquids, fumes or dust);
• Keep children and bystanders away from
the tool operating area;
• Maintain proper footing at all times and
do not overreach;
•Do not force the tool.
> These warnings and instructions do not represent the
total of all information available regarding tool safety,
use and technique. Please read the full manual before
using this product and always seek out opportunities to
learn more and improve your skills and knowledge.
This product is designed for specific applications as defined in the instructions and should not be modified and/or used for
any other applications. Before using the Miter Tight Picture Frame Clamp™, read, understand and follow all instructions and safety
information provided. KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
GENERAL SAFETY WARNINGS
Drilling, sawing, sanding or machining wood
products can expose you to wood dust, a substance known
ot the State of California to cause cancer. Avoid inhaling
wood dust or use a dust mask or other safeguards for
personal protection. For more information go to
www.P65Warnings.ca.gov/wood.
BP0617
Danger indicates a hazardous situation that, if not avoided, will result in death or serious injury.
Warning indicates a hazardous situation that, if not avoided, could result in death or serious injury.
Caution indicates a hazardous situation that, if not avoided, may result in minor or moderate injury
or property damage.
Notice indicates important or helpful information and/or user tips.

3
Quantity
A Spring-loaded Jaws 2
B Auxiliary Jaws (one pair attached) 2 pr
C Angle Adjustment Knobs 2
D Large Clamp Knob 1
E Hex Wrench (not shown) 1
PARTS LIST
B
A
C
D

4Distributed by Rockler Companies, Inc.
©2017 Rockler Woodworking and Hardware
30108
Rev 06/17
Check Rockler.com for updates to these instructions. If you have
further questions, please contact our Technical Support Department
at 1-800-260-9663 or [e-mail]
Picture Frame Stock
When clamping square stock, auxiliary jaws are not used. Only
Spring-Loaded Jaws (A) are needed. Proceed to Step 3.
1. Choose the Auxiliary Jaw (B) set that best fits your
frame stock. Fig. 1.
2. If necessary for your application, remove the attached
Auxiliary Jaws and replace with other jaws using two hex
screws and hex wrench provided for assembly.
3. Support the end of long frame stock with a piece of 3/4"
thick scrap. Fig. 2.
4. Position the Angle Adjustment Knobs to the 90° position.
Fig. 3.
5. Insert both pieces of the frame stock against the back jaws and
slide them together to close the joint. The clamp is not
engaged at this point. Only hand pressure against the back
jaws is used.
Note: If the two frame pieces are cut accurately and form a
tight joint, proceed to Step 7.
6. If the miters are not cut to a perfect 45° and there is a gap
between the toe or heel of the joint, slightly rotate both
Angle Adjustment Knobs (C) to adjust the angle of the back
jaws until the joint is tight. Both Angle Adjustment Knobs
should be adjusted simultaneously for best results. Fig. 4.
It’s natural to over-adjust the Angle
Adjustment Knobs. In most situations, the knobs should be
left in the 90° position. Adjust only in very small increments.
7. Once the joint has been dry clamped and is tight, loosen the
clamp and apply glue on the joint.
8. Reposition the frame stock in the clamp and engage the clamp
by turning Large Clamp Knob (D) until the joint is tight.
Do NOT overtighten.
9. The miter can be fastened with glue, brads or specialty
picture frame fasteners.
Fig. 4
Fig. 3
Fig. 2
Fig. 1
3/4" Scrap
AB
C
C
