ROSE DISPLAYS ANOFRAME ROUND WITH MULTICLIPS User manual

Parts
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Step 1
Insert corner brackets into vertical
AnoFrame sides. Fig. 1 & Fig. 2. Note:
Assembly brackets tension tabs face
towards outside of frames. Split rail side
is made up of 2 separate pieces.
Step 2
Squeeze sides of MultiClip together. Fig. 3
Step 3
Align the bottom rail of the MultiClip
with the top channel of the aluminum
holder. Slide MultiClip into rail. Fig. 4
Repeat steps 2 & 3 for second MultiClip.
Step 4
Assemble frame following steps in. Fig. 5
sliding sides together in the order shown.
Step 5
Insert poster. Fig 6.
AnoFrame
TM
Instructions for assembly
Incept-7.31.02
The AnoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSAnoFrameMC
Corner
brackets
MultiClips
1UP-0101
AnoFrame rails
12AF-100
AnoFrame
split rails
Instruction Sheet
Figure 1
Figure 3 Figure 4
Figure 5
Figure 2
solid rail w/
solid rail
split rails
