ROSE DISPLAYS ANOFRAME SQUARE WITH 4 WALL MOUNTS User manual

Parts
35 Congress Street, Salem MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Instructions For Hanging
Square Profile Instruction Sheet
AnoFrame™
Step 1
Locate the two split rails and the solid rail that is
the same length as the split rails.
Insert corner brackets into side AnoFrame rails.
Insert two corner brackets into each end of the
solid side Ano rail. Insert one corner bracket into
each end of each split side Ano rail. Fig. 1 & Fig.
2
Note: Tension tabs on corner brackets face
towards outside of frame.
Step 2
Finish assembling frame by following sequence in
Fig. 3.
Step 3
Install wall mounting hangers using a Phillips head
screwdriver. Make sure that the wall mounting
hangers are level.. A plastic expansion anchor is
suggested for drywall installations.
Fig. 4
Step 4
Slide AnoFrame onto wall mounting hangers.
Fig 5.
Step 5
Install bottom mounting hangers. This secures
frame in place. Fig 6
Step 6
Insert poster. Fig 7
Note: The AnoFrame shown here is a square
profile. It is available in either square or round
profile.
split rails
solid rail
Figure 2
Figure 1
Incept-8.15.02
Figure 4
The AnoFrame is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSAnoFrameSQWallHangers
Figure 3
Wall Mounting
Hangers
06-6067
AnoFrame Rails
12AF-100
AnoFrame
Split Rails
Corner
Assembly Clips
solid rail
solid rail
split rails
Figure 5 Figure 6 Figure 7
