ROSE DISPLAYS ANOSKYBOX-TOP LOADING 4 WAY User manual

The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #03INAnoSkyboxTopLoad4Way
Incept-2.07.03
Top Load 4-Way Instruction Sheet
Page 1 of 2
Note:
We recommended that two people
assemble this AnoSkybox.
Step 1a
Slide spine into vertical rail.
Step 1b
Slide another vertical rail onto the
other edge of spine. Repeat for all
vertical rails and spines.
Step 2
Carefully insert corner brackets into
ends of bottom rails, using thumb as
shown in illustration. Two brackets
per end of each rail. Bracket can
bend if forced.
Detail- It is important that the corner
bracket tension tab faces toward
outside of frame. (2b)
Step 3
Lay out the bottom rails on the floor as
they will be configured.
AnoSkybox™
Instructions for Assembly
Corner brackets
Parts
Single rails Split rails
(Continued on other side)
2a 2b
1a 1b
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
2
3
4-Way
Spines with
pre-drilled holes

The AnoSkybox™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #03INAnoSkyboxTopLoad4Way
Incept-2.07.03
Instructions for Assembly continued
7
Step 4
Assemble the vertical rail assemblies
onto the upward facing corner brackets
already inserted into the bottom rails.
All four brackets should go into the
vertical rails at one time.
Note: The last vertical rail will be
tensioned. This is normal.
Note: Insert end of spine without the
predrilled holes. Holes should
remain at the top of the AnoSkybox
for hanging.
Step 5
Insert corner brackets into ends
of split rails, 1 per end. Use thumb
as shown in illustration.
Step 6
Assemble split rails onto top ends
of vertical rails, one inside and one
outside of each side of the AnoSkybox.
Step 7
Insert and change signs through top
of each side.
Step 8
Assemble hanging hardware by
inserting hooks through holes on the
spines.
Step 9
Hang the completed assembly.
Note: Steps 7-9 illustrate a 3-Way
AnoSkybox. Assembly is the same for
a 4-Way
AnoSkybox™
4 5
6
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
89
Top Load 3-Way Instruction Sheet
Page 2 of 2
