ROSE DISPLAYS ECONOFRAME WITH CABLE CLIP AND LOOP AND... User manual

Parts
Instructions for Hanging
Instruction Sheet
Step 1
Insert corner brackets into split
rails and into rail opposite split
rail. Split rail side is made up of
two separate pieces. Fig. 1
Note: Corner bracket tension
tabs must face toward inside
of frame.
Step 2
Place cable into inner channel of
CableClip. The cable should snap
into place. Fig. 2
Step 3
Align one end of the CableClip
with the top channel of the frame.
Then insert one round end, press
down on the other round end
and slide CableClip into rail.
Fig. 3 Repeat steps 2 & 3 for
second CableClip.
Step 4
Assemble frame following steps in.
Fig. 4 sliding sides together in the
order shown.
Step 5
Insert poster. Fig 5.
Instructions for Hanging
Incept-11.13.02
The EconoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSEconoFCCLoop
Corner
brackets
EconoFrame
TM
Figure 1
Figure 2 Figure 3
solid rail w/
solid rail
split rails
34
Figure 4 Figure 5
35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
split rails
solid rail
2
1
EconoFrame rails
12EF-100
EconoFrame
split rails
Cable Clips
06-5050
Loop & Saucer
16-0018SL

Parts
Loop & Saucer
16-0018SL
Instructions for Hanging
Instruction Sheet
Step 1
Insert corner brackets into split
rails and into rail opposite split
rail. Split rail side is made up of
two separate pieces. Fig. 1
Note: Corner bracket tension
tabs must face toward inside
of frame.
Step 2
Place cable into inner channel of
CableClip. The cable should snap
into place. Fig. 2
Step 3
Align one end of the CableClip
with the top channel of the frame.
Then insert one round end, press
down on the other round end and
slide CableClip into rail. Fig. 3
Repeat steps 2 & 3 for
second CableClip.
Step 4
Assemble frame following steps in
Fig. 4 sliding sides together in the
order shown.
Step 5
Insert poster. Fig 5.
Instructions for Hanging
Incept-11.13.02
The EconoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSEconoFCCLoop
EconoFrame
TM
Figure 1
Figure 3
solid rail w/
solid rail
split rails
34
Figure 4 Figure 5
Figure 2
split rails
solid rail
2
1
Corner
brackets
EconoFrame rails
12EF-100
EconoFrame
split rails
Cable Clips
06-5050
