ROSE DISPLAYS ANOFRAME SQUARE WITH WINDOW MOUNTS User manual

35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Parts
Figure 4
split rails
AnoFrame
TM
Instructions for assembly
Incept-8.15.02
Figure 1
The AnoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSAnoFrameWindowMounts
Corner
brackets
AnoFrame rails
12AF-100
AnoFrame
split rails
Square Profile Instruction Sheet
Window Mounts
20-0038
Figure 5
Figure 3
split rails
solid rail
Figure 2
Step 1
Locate the two split rails and the
solid rail that is the same length as
the split rails.
Insert corner brackets into side
AnoFrame rails. Insert two corner
brackets into each end of the solid
side Ano rail. Insert one corner
bracket into each end of each split
side Ano rail. Fig. 1 & Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame.
Step 2
Slide the Window Mounts
into the top rail of the AnoFrame
rail. Fig. 3
Step 3
Finish assembling frame following the
sequence in Fig. 4.
Step 4
Insert poster. Fig 5
Note: For best performance when
first applied and occasionally
thereafter, press the middle of the
cup (on the cap) to “burp” extra
air out.

AnoFrame
TM
Instructions for assembly
Incept-8.15.02
Figure 1
The AnoFrame™ is a trademark of Rose Displays, Ltd. Neither the
manufacturer nor any sales agent may be held liable for injury, loss or
damage resulting from the use of these products.
Part #02INSAnoFrameWindowMounts
Corner
brackets
AnoFrame rails
12AF-100
AnoFrame
split rails
Square Profile Instruction Sheet
Window Mounts
20-0038
Figure 5
Figure 3
Parts
split rails
solid rail
Figure 2
Figure 4
split rails
Step 1
Locate the two split rails and the
solid rail that is the same length as
the split rails.
Insert corner brackets into side
AnoFrame rails. Insert two corner
brackets into each end of the solid
side Ano rail. Insert one corner
bracket into each end of each split
side Ano rail. Fig. 1 & Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame.
Step 2
Slide the Wally Window Mounts
into the top rail of the AnoFrame
rail. Fig. 3
Step 3
Finish assembling frame following the
sequence in Fig. 4.
Step 4
Insert poster. Fig 5
Note: For best performance when
first applied and occasionally
thereafter, press the middle of the
cup (on the cap) to “burp” extra
air out.
