Rosemount 708 Wireless Acoustic
Transmitter

Reference Manual
00809-0100-4708, Rev AA
June 2010 Rosemount 708
Rosemount 708 Wireless
Acoustic Transmitter
Rosemount 708 Hardware Revision
HART®Device Revision
Field Communicator Field Device Revision
1
1
Dev vX, DD vX
NOTICE
Read this manual before working with the product. For personal and system safety, and for
optimum product performance, make sure to thoroughly understand the contents before
installing, using, or maintaining this product.
The United States has two toll-free assistance numbers and one international number.
Customer Central
1 800 999 9307 (7:00 a.m. to 7:00 p.m. CST)
National Response Center
1 800 654 7768 (24 hours a day)
Equipment service needs
International
1 952 906 8888
The products described in this document are NOT designed for nuclear-qualified
applications.
Using non-nuclear qualified products in applications that require nuclear-qualified hardware
or products may cause inaccurate readings.
For information on Rosemount nuclear-qualified products, contact an Emerson Process
Management Sales Representative.

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
The power module with the wireless unit contains one "D” size primary lithium/thionyl chloride
batteries. Each battery contains approximately X.X grams of lithium. Under normal conditions,
the battery materials are self-contained and are not reactive as long as the batteries and the pack
integrity are maintained. Care should be taken to prevent thermal, electrical or mechanical
damage. Contacts should be protected to prevent premature discharge.
Battery hazards remain when cells are discharged.
Power modules should be stored in a clean and dry area. For maximum battery life, storage
temperature should not exceed 30° C.
The power module has surface resistivity greater than one gigaohm and must be properly
installed in the wireless device enclosure. Care must be taken during transportation to and from
the point of installation to prevent electrostatic charge build-up.
Explosions could result in death or serious injury:
Installation of this transmitter in an explosive environment must be in accordance
with the appropriate local, national, and international standards, codes, and
practices. Please review the approvals section of the 708 Reference Manual for any
restrictions associated with a safe installation.
• Before connecting a Field Communicator in an explosive atmosphere, ensure the
instruments are installed in accordance with intrinsically safe or non-incendive
field wiring practices
Process leaks may cause harm or result in death:
• Install and tighten process connectors before applying pressure
Electrical shock can result in death or serious injury:
• Avoid contact with the leads and terminals. High voltage that may be present on
leads can cause electrical shock
NOTICE
The Rosemount 708 and all other wireless devices should be installed only after the
Smart Wireless Gateway has been installed and is functioning properly. Wireless
devices should also be powered up in order of proximity from the Smart Wireless
Gateway, beginning with the closest. This will result in a simpler and faster network
installation.
NOTICE
Shipping considerations for wireless products:
The unit was shipped to you without the power module installed. Please remove the power
module prior to shipping.
Each power module contains one “D” size primary lithium battery. Primary lithium batteries
are regulated in transportation by the U. S. Department of Transportation, and are also
covered by IATA (International Air Transport Association), ICAO (International Civil Aviation
Organization), and ARD (European Ground Transportation of Dangerous Goods). It is the
responsibility of the shipper to ensure compliance with these or any other local
requirements. Please consult current regulations and requirements before shipping.

Reference Manual
00809-0100-4708, Rev AA
June 2010
TOC-1
Rosemount 708
SECTION 1
Overview Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Service Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Product Recycling/Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
SECTION 2
Configuration Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Device Sensor Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Device Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Remove Power Module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-5
SECTION 3
Mounting Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
SECTION 4
Commissioning Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Verify Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
SECTION 5
Operation and
Maintenance
Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Power Module Replacement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
APPENDIX A
Specifications and
Reference Data
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Ordering Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-4
APPENDIX B
Product
Certifications
Table of Contents

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
TOC-2

Reference Manual
00809-0100-4708, Rev AA
June 2010
1-1
Rosemount 708
Section 1 Overview
Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 1-1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 1-2
Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 1-3
Service Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 1-4
Product Recycling/Disposal . . . . . . . . . . . . . . . . . . . . . . .page 1-5
SAFETY MESSAGES Instructions and procedures in this section may require special precautions to
ensure the safety of the personnel performing the operations. Information that
potentially raises safety issues is indicated by a warning symbol ( ). Please
refer to the following safety messages before performing an operation
preceded by this symbol.
Warnings
Failure to follow these installation guidelines could result in death or serious injury:
• Only qualified personnel should perform the installation
Explosions could result in death or serious injury.
• Before connecting a Field Communicator in an explosive atmosphere, make
sure that the instruments are installed in accordance with intrinsically safe or
non-incendive field wiring practices
• Verify that the operating atmosphere of the transmitter is consistent with the
appropriate hazardous locations certifications
Electrical shock could cause death or serious injury.
• Use extreme caution when making contact with the leads and terminals

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
1-2
OVERVIEW
Manual This manual is designed to assist in the installation, operation, and
maintenance of the Rosemount 702.
Section 1: Overview
• Overview
• Considerations
• Service Support
• Product Recycling/Disposal
Section 2: Configuration
• Device Sensor Configuration
• Device Network Configuration
• Remove Power Module
Section 3: Mounting
• Mounting
- Direct Mount
• Ground the Transmitter
Section 4: Commissioning
• Verify Operation
•AMS
®Wireless Configurator
Section 5: Operation and Maintenance
• Power Module Replacement
Section A: Specifications and Reference Data
• Specifications
• Dimensional Drawings
• Ordering Information
Section B: Product Certifications
• Approved Manufacturing Locations
• Telecommunication Compliance
• FCC and IC
• European Union Directive Information
• Ordinary Location Certification for FM
• Hazardous Locations Certificates
Transmitter Features of the Rosemount 708 include:
• An installation-ready solution that provides acoustic noise detection.
• Acoustic levels to verify the state of steam traps, pressure relief valves,
condensers, and many others.
• Wireless output with >99% data reliability delivers rich HART®data,
protected by industry leading security
• Simple and easy installation practices currently being used for robust
installations

Reference Manual
00809-0100-4708, Rev AA
June 2010
1-3
Rosemount 708
CONSIDERATIONS
General The acoustic transmitter detects either a noise or no noise along with a
temperature. By using simple HART configuration, the Rosemount 708
converts the noise and temperature status to a device status.
Wireless Considerations Power Up Sequence
The power module should not be installed on any wireless device until the
Smart Wireless Gateway (“Gateway”) is installed and functioning properly.
Wireless devices should also be powered up in order of proximity from the
Gateway, beginning with the closest. This will result in a simpler and faster
network installation. Enable Active Advertising on the Gateway to ensure that
new devices join the network faster. For more information see the Smart
Wireless Gateway Manual (Document Number 00809-0200-4420).
Antenna Position
The antenna is internal to the acoustic transmitter. If best practices are
followed, the antenna position will not matter in the wireless functionality.
Field Communicator Connections
The Power Module needs to be connected for the Field Communicator to
interface with the 708.
Figure 1-1.
Mechanical Location
When choosing an installation location and position, take into account access
to the transmitter.

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
1-4
Electrical Power Module
The Rosemount 708 Wireless transmitter is self-powered. The included power
module contains one “D” size primary lithium/thionyl chloride battery. Each
battery contains approximately X.X grams of lithium. Under normal conditions,
the battery materials are self-contained and are not reactive as long as the
batteries and the power module are maintained. Care should be taken to
prevent thermal, electrical, or mechanical damage. Contacts should be
protected to prevent premature discharge.
Use caution when handling the power module, it may be damaged if dropped
from heights in excess of 20 feet (6.10 m).
Environmental Verify that the operating atmosphere of the transmitter is consistent with the
appropriate hazardous locations certifications.
Temperature Effects
The transmitter will operate within specifications for ambient temperatures
between -40 and 185 °F (-40 and 85 °C). Heat from the process is transferred
from the switch to the transmitter housing. If the expected process
temperature is near or beyond specification limits, ...add recommendation
Temperature Limits
SERVICE SUPPORT To expedite the return process outside of North America, contact your
Emerson Process Management representative,
Within the United States, call the Emerson Process Management Response
Center toll-free number 1 800 654 7768. The center, which is available 24
hours a day, will assist you with any needed information or materials.
The center will ask for product model and serial numbers, and will provide a
Return Material Authorization (RMA) number. The center will also ask for the
process material to which the product was last exposed.
SHIPPING CONSIDERATIONS FOR WIRELESS PRODUCTS (LITHIUM
BATTERIES):
The unit was shipped with the Power Module not installed. Please remove the
Power Module from the unit before shipping.
Primary lithium batteries (charged or discharged) are regulated during
transportation by the U.S. Department of Transportation. They are also
Operating Limit Storage Limit
-40 to 185 °F
-40 to 85° C -40 to 185 °F -40 to 85 °C
Individuals who handle products exposed to a hazardous substance can avoid injury if they
are informed of, and understand, the hazard. If the product being returned was exposed to a
hazardous substance as defined by OSHA, a copy of the required Material Safety Data
Sheet (MSDS) for each hazardous substance identified must be included with the returned
goods.

Reference Manual
00809-0100-4708, Rev AA
June 2010
1-5
Rosemount 708
covered by IATA (International Air Transport Association), ICAO (International
Civil Aviation Organization), and ARD (European Ground Transportation of
Dangerous Goods). It is the responsibility of the shipper to ensure compliance
with these or any other local requirements. Consult current regulations and
requirements before shipping.
PRODUCT
RECYCLING/DISPOSAL Recycling of equipment and packaging should be taken into consideration
and disposed of in accordance with local and national legislation/regulations.

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
1-6

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
1-7

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
1-8

Reference Manual
00809-0100-4708, Rev AA
June 2010
2-1
Rosemount 708
Section 2 Configuration
Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 2-1
Device Sensor Configuration . . . . . . . . . . . . . . . . . . . . . .page 2-1
Device Network Configuration . . . . . . . . . . . . . . . . . . . . .page 2-2
Remove Power Module . . . . . . . . . . . . . . . . . . . . . . . . . . .page 2-5
SAFETY MESSAGES Instructions and procedures in this section may require special precautions to
ensure the safety of the personnel performing the operations. Information that
potentially raises safety issues is indicated by a warning symbol ( ). Please
refer to the following safety messages before performing an operation
preceded by this symbol.
Warnings
DEVICE SENSOR
CONFIGURATION Remove the power module housing then connect to the HART
communication terminals for configuration.
The Rosemount 708 will receive any HART communication from a handheld
Field Communicator, or AMS®. When using a Field Communicator, any
configuration changes must be sent to the transmitter using the Send key
(F2). AMS configuration changes are implemented when the Apply button is
clicked.
AMS® Wireless Configurator
AMS is capable of connecting to devices directly, using a HART modem, or
with the Gateway. When configuring on the bench with a HART modem,
double click the device icon, then choose the Configure/Setup tab (or right
click and select Configure/Setup). Configure the device settings using the
Direct Connection menu. When configuring with the Gateway, double click the
device icon then choose the Configure/Setup tab (or right click and select
Configure/Setup). Configure the device settings using the Wireless
Connection menu.
To check or change sensor configuration using a 475 Field Communicator,
enter the following Fast Key Sequence: X, X, X.
Failure to follow these installation guidelines could result in death or serious injury:
• Only qualified personnel should perform the installation
Explosions could result in death or serious injury.
• Before connecting a Field Communicator in an explosive atmosphere, make
sure that the instruments are installed in accordance with intrinsically safe or
non-incendive field wiring practices
• Verify that the operating atmosphere of the transmitter is consistent with the
appropriate hazardous locations certifications
Electrical shock could cause death or serious injury.
• Use extreme caution when making contact with the leads and terminals

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
2-2
DEVICE NETWORK
CONFIGURATION To communicate with the Gateway, and ultimately the Information System, the
transmitter must be configured to communicate with the wireless network.
Using a Field Communicator or AMS, enter the Network ID and Join Key so
they match the Network ID and Join Key of the Gateway and the other
devices in the network. If the Network ID and Join Key are not identical, the
transmitter will not communicate with the network. The Network ID and Join
Key may be obtained from the Gateway on the Setup>Network>Settings
page on the web server. Using a 475 Field Communicator, the Network ID can
be configured by entering the Fast Key Sequence: X, X, X, X. The Join Key
can also be configured using a 475 Field Communicator with the Fast Key
Sequence: X, X, X, X.
The final device network configuration piece is the Update Rate which, by
default, is 1 minute. It can be changed at commissioning, or at any time, by
using AMS or the Gateway’s web server. The Update Rate should be
between 4 seconds and 60 minutes. To change the Update Rate with a Field
Communicator, use the Fast Key Sequence: X, X, X.
If doing a bench top initial configuration, after completion remove the power
module until installation. When the device is installed, insert he power module
and close the housing cover securely. Always ensure a proper seal so that
polymer touches polymer, but do not over tighten.
Figure 2-1. 708 Power Module
Connect the HART communication leads to the COMM terminals on the
power module.

Reference Manual
00809-0100-4708, Rev AA
June 2010
2-3
Rosemount 708
Figure 2-2. 475 Field
Communicator Connections
For HART communication, a 708 DD is required.

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
2-4
HART Menu Tree For ease of operation, changing setup, such as switch type, can be completed
in several locations.
Figure 2-3. Field Communicator Menu Tree
1. Overview
2. Configure
3. Service Tools
1. Active Alerts
2. Communication Status
3. Sensor
4. Sensor Status
5. Last Update Time
1. Guided Setup
2. Manual Setup
1. Alerts
2. Variables
3. Communications
4. Routine Maintenance
5. Simulate
1. Join Device to Network
2. Configure Update Rate
3. Configure Discrete Application
4. Configure Device Display
1. Wireless
2. Discrete Sensors
3. Electronics Temperature
4. Device Information
5. Device Display
6. Other
1. Active Alerts
2. History
1. Discrete Input 1
2. Discrete Input 2
3. Electronics Temperature
4. Electronics temperature Status
5. Supply Voltage
6. Supply Voltage Status
7. Last Update Time
1. Join Status
2. Communication Status
3. Join Mode
4. Number of Available Neighbors
5. Number of Advertisements Heard
6. Number of Join Attempts
1. Sensor Calibration
2. Other
1. Discrete Input 1
2. Discrete Input 2
3. Electronics Temperature
4. Supply Voltage
1. Clear Alert History
1. Discrete Input 1 Sensor Wiring Offset
2. Discrete Input 2 Sensor Wiring Offset
1. Perform Master Reset
2. Measurement History
3. Advertise to New Devices
1. Network ID
2. Join Device to Network Broadcast Rates
3. Configure Broadcast Power Level
4. Power Mode
5. Power Source
1. Configure Discrete Application
2. Discrete Input 1
3. Discrete Input 2
1. Electronics Temperature
2. Electronics Temperature Status
3. Unit
4. Maximum
5. Minimum
1. Tag
2. Long Tag
3. Device
4. Discrete Input 1
5. Discrete Input 2
6. Wireless
1. Mode
1. Write Protect
2. AC Power Filter
3. Measurement and Status Log
1. Configure Update Rate
2. Message 1
3. Message 2
1. Discrete State
2. Invert Option
3. Sensor Serial Number
1. Discrete State
2. Invert Option
3. Sensor Serial Number
1. Manufacturer
2. Model
3. Final Assembly Number
4. Universal
5. Field Device
6. Software
7. Hardware
8. Descriptor
9. Message
10 Date
11 Model Number I
12 Model Number II
13 Model Number III
14 SI Unit Restriction
15 Country
16 Device ID
1. Sensor Serial Number
1. Sensor Serial Number
1. Manufacturer
2. Device Type
3. Device Revision
4. Software Revision
5. Hardware Revision

Reference Manual
00809-0100-4708, Rev AA
June 2010
2-5
Rosemount 708
Fast Key Sequence Table 2-1 lists the fast key sequence for common transmitter functions.
NOTE:
The fast key sequences assume that DD Dev v1, DD v4 is being used.
Table 2-1. 702 Fast Key
Sequence
Calibration
REMOVE POWER
MODULE After the sensor and network have been configured, remove the power
module and replace the power module cover. The power module should be
inserted only when the device is ready for commissioning
Function Key Sequence Menu Items
Device Information 2, 2, 5, 3 Manufacturer, Model, Final Assembly Number,
Universal, Field Device, Software, Hardware
Descriptor, Message, Date, Model Number, I, II,
III, SI Unit Restriction, Country
Guided Setup 2, 1 Join Device to Network, Configure Update Rate,
Configure Sensor, Calibrate Sensor, Configure
Display, Configure Process Alarms
Manual Setup 2, 2 Wireless, Process Sensor, Percent of Range,
Device Temperature, Device Information,
Device Configure, Other
Wireless 2, 2, 1 Network ID, Join Device to Network, Configure
Update Rate, Configure Broadcast Power Level,
Power Mode, Power Source
Discrete Input
Configuration 3, 4, 1 Output Configuration, Discrete Input Configuration

Reference Manual
00809-0100-4708, Rev AA
June 2010
Rosemount 708
2-6
