Quick Installation Guide
00825-0400-4101, Rev AA
March 2011
Rosemount 2051 Pressure Transmitter
with PROFIBUS PA
Rosemount 2051CF Series Flowmeter Transmitter
with PROFIBUS PA
Start
End
Step 1: Mount the Transmitter
Step 2: Consider Housing Rotation
Step 3: Set Jumpers and Switches
Step 4: Connect the Wiring and Power Up
Step 5: Basic Configuration
Step 6: Trim the Transmitter
Product Certifications
00825-0400-4101.fm Page 1 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011
Rosemount 2051
2
© 2011 Rosemount Inc. All rights reserved. All marks property of owner.
Rosemount and the Rosemount logotype are registered trademarks of Rosemount Inc.
Rosemount Inc.
8200 Market Boulevard
Chanhassen, MN USA 55317
T (US) [phone]
T (Intnl) [phone]
F [phone]
Emerson Process Management GmbH & Co. OHG
Argelsrieder Feld 3
82234 Wessling
Germany
T 49 (8153) 9390
F49 (8153) 939172
Emerson Process Management
Asia Pacific Private Limited
1 Pandan Crescent
Singapore 128461
T (65) 6777 8211
F (65) 6777 0947/65 6777 0743
Beijing Rosemount Far East Instrument Co., Limited
No. 6 North Street,
Hepingli, Dong Cheng District
Beijing 100013, China
T (86) (10) 6428 2233
F (86) (10) 6422 8586
IMPORTANT NOTICE
This installation guide provides basic guidelines for Rosemount 2051 transmitters. It does not provide
instructions for configuration, diagnostics, maintenance, service, troubleshooting, Explosion-proof,
Flame proof, or intrinsically safe (I.S.) installations. Refer to the 2051 PROFIBUS PA reference
manual (document number 00809-0300-4101) for more instruction. This manual is also available
electronically on www.emersonprocess.com/rosemount.
WARNING
Explosions could result in death or serious injury:
Installation of this transmitter in an explosive environment must be in accordance with the appropriate
local, national, and international standards, codes, and practices. Please review the approvals section
of the 2051 PROFIBUS PA reference manual for any restrictions associated with a safe installation.
• In an Explosion-proof/Flameproof installation, do not remove the transmitter covers when power is
applied to the unit.
Process leaks may cause harm or result in death.
• To avoid process leaks, only use the o-ring designed to seal with the corresponding flange
adapter.
Electrical shock can result in death or serious injury.
• Avoid contact with the leads and the terminals. High voltage that may be present on leads can
cause electrical shock.
Conduit/Cable Entries
• Unless marked, the conduit/cable entries in the transmitter housing use a 1/2-14 NPT thread form.
Only use plugs, adapters, glands, or conduit with a compatible thread form when closing these
entries.
00825-0400-4101.fm Page 2 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011 Rosemount 2051
3
STEP 1: MOUNT THE TRANSMITTER
Liquid Applications
1. Place taps to the side of the line.
2. Mount beside or below the taps.
3. Mount the transmitter so that the drain/vent
valves are oriented upward.
Gas Applications
1. Place taps in the top or
side of the line.
2. Mount beside or above the taps.
Steam Applications
1. Place taps to the side of the line.
2. Mount beside or below the taps.
3. Fill impulse lines with water.
Flow
Flow
Flow
00825-0400-4101.fm Page 3 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011
Rosemount 2051
4
STEP 1 CONTINUED...
Rosemount 2051C
Panel Mount(1)
(1) Panel bolts are customer supplied.
Pipe Mount
Coplanar Flange
Traditional Flange
Rosemount 2051T
00825-0400-4101.fm Page 4 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011 Rosemount 2051
5
STEP 1 CONTINUED...
Bolting Considerations
If the transmitter installation requires assembly of the process flanges, manifolds, or flange
adapters, follow these assembly guidelines to ensure a tight seal for optimal performance
characteristics of the transmitters. Use only bolts supplied with the transmitter or sold by
Emerson as spare parts. Figure 1 illustrates common transmitter assemblies with the bolt
length required for proper transmitter assembly.
Figure 1. Common Transmitter Assemblies
Bolts are typically carbon steel or stainless steel. Confirm the material by viewing the
markings on the head of the bolt and referencing Figure 2. If bolt material is not shown in
Figure 2, contact the local Emerson Process Management representative for more
information.
Use the following bolt installation procedure:
1. Carbon steel bolts do not require lubrication and the stainless steel bolts are coated with
a lubricant to ease installation. However, no additional lubricant should be applied when
installing either type of bolt.
2. Finger-tighten the bolts.
3. Torque the bolts to the initial torque value using a crossing pattern. See Figure 2 for
initial torque value.
4. Torque the bolts to the final torque value using the same crossing pattern. See Figure 2
for final torque value.
5. Verify that the flange bolts are protruding through the isolator plate before applying
pressure.
4 x 1.75-in. (44 mm)
4 x 2.88-in. (73 mm)
A. Transmitter with
Coplanar Flange
B. Transmitter with Coplanar
Flange and Optional
Flange Adapters
C. Transmitter with Traditional
Flange and Optional Flange
Adapters
D. Transmitter with
Coplanar Flange and
Optional Manifold and
Flange Adapters
4 x 1.75-in. (44 mm) 4 x 1.50-in. (38 mm)
4 x 1.75-in. (44 mm)
4 x 2.25-in. (57 mm)
00825-0400-4101.fm Page 5 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011
Rosemount 2051
6
STEP 1 CONTINUED...
Figure 2. Torque values for the flange and flange adapter bolts
O-rings with Flange Adapters
WARNING
Whenever the flanges or adapters are removed, visually inspect the o-rings. Replace them
if there are any signs of damage, such as nicks or cuts. If you replace the o-rings, re-torque
the flange bolts and alignment screws after installation to compensate for seating of the
PTFE o-ring.
Bolt Material Head Markings Initial Torque Final Torque
Carbon Steel (CS) 300 in.-lbs. 650 in.-lbs.
Stainless Steel (SST) 150 in.-lbs. 300 in.-lbs.
Failure to install proper flange adapter O-rings may cause process leaks, which can result in death or
serious injury. The two flange adapters are distinguished by unique O-ring grooves. Only use the O-ring
that is designed for its specific flange adapter, as shown below.
B7M
316
316
316
SW
316
STM
316
R
B8M
Rosemount 3051S / 3051 / 2051 / 3095
Rosemount 1151
Flange Adapter
O-ring
Flange Adapter
O-ring
PTFE Based
Elastomer
PTFE
Elastomer
00825-0400-4101.fm Page 6 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011 Rosemount 2051
7
Inline Gage Transmitter Orientation
The low side pressure port (atmospheric reference) on the inline gage transmitter is located
in the neck of the transmitter, behind the housing. The vent path is 360° around the
transmitter between the housing and sensor. (See Figure 3.)
Keep the vent path free of any obstruction, including but not limited to paint, dust, and
lubrication by mounting the transmitter so that the process can drain away.
Figure 3. Inline Gage Low Side Pressure Port
STEP 2: CONSIDER HOUSING ROTATION
To improve field access to wiring or to better view the optional LCD display:
1. Loosen the housing rotation set screw.
2. First rotate the housing clockwise to the desired location. If the desired location cannot
be achieved due to thread limit, rotate the housing counter clockwise to the desired
location (up to 360° from thread limit).
3. Retighten the housing rotation set screw.
Low side pressure port
(atmospheric reference)
Housing Rotation Set Screw
(5/64-inch)
00825-0400-4101.fm Page 7 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011
Rosemount 2051
8
STEP 3: SET JUMPERS AND SWITCHES
Security
After the transmitter is configured, you may want to protect the configuration data from
unwarranted changes. Each transmitter is equipped with a security jumper that can be
positioned “ON” to prevent the accidental or deliberate change of configuration data. The
jumper is labeled “Security.”
Simulate
The simulate jumper is used in conjunction with the Analog Input (AI) block. This jumper is
used to simulate the pressure measurement and is used as a lock-out feature for the AI
block. To enable the simulate feature, the jumper must be moved to the “ON” position after
power is applied. This feature prevents the transmitter from being accidently left in simulate
mode.
Figure 4. Transmitter Jumper Locations
ROSEMOUNT 2051
PROFIBUS PA OUTPUT
LOCAL OPERATOR INTERFACE
ELECTRONICS ASSEMBLY
P/N 02051-9001-2102
-USE EXTENDED COVER TO AVOID DAMAGE
-USE DISPLAY TO CONFIGURE
00825-0400-4101.fm Page 8 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011 Rosemount 2051
9
STEP 4: CONNECT WIRING AND POWER UP
Use the following steps to wire the transmitter:
1. Remove the housing cover on the FIELD TERMINALS side.
2. Connect the power leads to the terminals indicated on the terminal block label.
• Power terminals are polarity insensitive - connect positive or negative to either terminal
3. Ensure proper grounding. It is important that the instrument cable shield:
• be trimmed close and insulated from touching the transmitter housing
• be connected to the next shield if cable is routed through a junction box
• be connected to a good earth ground at the power supply end
4. Plug and seal unused conduit connections.
5. If applicable, install wiring with a drip loop. Arrange the drip loop so the bottom is lower
than the conduit connections and the transmitter housing.
6. Replace the housing cover.
Figure 5.
Figure 6.
“NC” is a No Connect terminal (do not use)
Ground
Terminal
Power
Terminals
Power
Supply DP/PA
Coupler
/Link
Terminators
6234 ft (1900 m) max
(depending upon cable
characteristics)
Integrated Power
Conditioner
and Filter
(Trunk)
(Spur)
(Spur)
Signal
Wiring
PROFIBUSPA Device
DP Network
00825-0400-4101.fm Page 9 Friday, March 25, 2011 1:34 PM

Quick Installation Guide
00825-0400-4101, Rev AA
March 2011
Rosemount 2051
10
STEP 4 CONTINUED...
Signal Wiring Grounding
Do not run signal wiring in conduit or open trays with power wiring, or near heavy electrical
equipment. Grounding terminations are provided on the outside of the electronics housing
and inside the Terminal Compartment. These grounds are used when transient protect
terminal blocks are installed or to fulfill local regulations. See Step 2 below for more
information on how the cable shield should be grounded.
1. Remove the Field Terminals housing cover.
2. Connect the wiring pair and ground as indicated in Figure 7. The cable shield should:
a. Be trimmed close and insulated from touching the transmitter housing.
b. Continuously connect to the termination point.
c. Be connected to a good earth ground at the power supply end.
Figure 7. Wiring
3. Replace the housing cover. It is recommended that the cover be tightened until there is
no gap between the cover and the housing.
4. Plug and seal unused conduit connections.
Power Supply
The dc power supply should provide power with less than two percent ripple. The
transmitter requires between 9 and 32 Vdc at the terminals to operate and provide
complete functionality.
Power Conditioner
The DP/PA Coupler / Link often includes an integrated power conditioner.
Grounding
Transmitters are electrically isolated to 500 Vac rms. Signal wiring can not be grounded.
Shield Wire Ground
Shield wire usually requires a single grounding point to avoid creating a ground loop. The
ground point is typically at the power supply.
DP
Trim shield and insulate
Connect Shield Back
to the Power Supply
Ground
Insulate Shield
