Rosen AV7700 Reference guide

AV7700 Quick Reference Card
PLAY A DVD OR CD
a. Press and release the MODE button
on the front control panel or the
SOURCE button on the remote control
until "DVD PLAYER" appears.
b. Press on the bottom of the display to pivot
and access the DVD/CD slot.
c. With the label facing away from you, insert
a disc into the disc slot. Do not force disc
into slot. If a DVD/CD menu appears on
the screen, press PLAY or ENTER
as instructed on the screen. Most discs
will load and play automaticaltely.
d. To obtain the best viewing angle adjust the
display angle as needed.
USE THE HEADPHONES
a. Turn on by pressing the OFF/ON button,
located on the ear piece. The power
LED on the ear piece should illuminate -
if not, check that the batteries have a
charge and are inserted properly.
b. The headphones each have a two-position
slide switch labeled “CH.A/CH.B.” They
must have a clear line of sight to the
headrest monitor and must be switched
to the designated A/B channel to operate
properly.
c. To adjust the volume use the knob on the ear
piece.
Adjust Size Here
Volume
FIG 4
TURN ON THE SYSTEM
a. Turn vehicle ignition to ON or ACC.
b. Press POWER on the front display
or wireless remote to turn on
each system.
FRONT CONTROL PANEL
Power Play
Speaker
Speaker
Mode
Enter
Power
Stop
Play
Speaker
Pause
Day/
Night
Source
On/off
Batteries

LISTEN OVER VEHICLE SPEAKERS
a. Press the SPEAKER on the
remote or on the front control
panel."SPEAKER SOUND ON
FM __._ PRESS LEFT OR RIGHT
TO ADJUST" will appear on the
screen as shown at right.
b. Turn vehicle's radio on, and tune
to the FM frequency displayed
on screen. If radio interference is heard,
try another frequency (see pages 13 & 15
in your Owner’s Manual for more information).
PLAY INTERNAL VIDEO GAMES
a. Press the MODE button on the front
control panel (or SOURCE on the
remote control) until “INTERNAL GAME”
appears on the screen.
b. Turn ON and set the game controller to
channel “A” or channel “B” depending on
which unit you will play on.
c. Use the game controller's left and right
arrow keys to choose a game.
d. Press the START button on the game
controller to choose the game.
e. Use the "A & B" buttons for fire, jump
or other action.
f. Press RESET to return to the main menu.
Note: If the flashing LED stays illuminated,
replace the batteries.
Start
Reset
Directional
Control
Joystick
Flashing LED
A/Off/B
Switch
AV7700 Quick Reference Card
PN: AP2002
