Rosin Tech Pro Touch User manual

Rosin Tech Products
Pneumatic Single Ram Touch
Owner’s Manual
All Rights Reserved. Copyright © 2018, Rosin Tech Products

At Rosin Tech Products, we work hard to bring the best
solventless extraction equipment to our customers. We
provide education to people all over the world through
our #solventless experience events, through our team of
#solventless experts, and our blog rosintech.com.
Our mission is to spread solventless extraction worldwide
by bringing to market best in class products whether you
need rosin press at home or you’re looking at our com-
mercial grade products, we have the equipment and the
expertise to achieve your goals.

Step 1: Plug In / Turn On
Step 2: Adjust Temperature
Step 3: Adjust Length of Press
Step 4: Heat Up Plates
Step 5: Speed / Pressure Control
Step 6: Engage Press
Step 7: Disengage press
Step 8: Record Yield
Step 9: Save and Recall Presets
Step 10: Set Up Session
Step 11: View Press History
Step 12: Connect to Wi
Step 13: Email results
1
2
3
4
5
6
8
9
10
11
12
13
14
Table of Contents

1. Once you’ve plugged in your press, ip on the power switch on
the back of the machine and the touch screen will activate.
2. Allow a minute for the screen to load all information.
3. Connect the air line to the press.
Step 1: Plug In / Turn On
1

1. Press temperature display in middle of screen.
2. Use + or - buttons to set desired temperature.
3. Press save button to set the temperature (right of temperature
select).
Tip: Left temperature display controls top plate, right temperature
display controls bottom plate.
Step 2: Adjust Temperature
2

1. Located above the temperature control, use + or - to set desired
press length.
2. Timer will begin when press is engaged.
Step 3: Adjust Length of Press
3

Step 4: Heat Up Plates
1. Once you have set the timer and temperature allow the press to
heat to the desired temperature.
4

1. The pressure control knob is located on the right side of the
machine, directly above the engage button.
2. The pressure control knob when closed and tightened will force
the heat plates to close slower towards one another (Fig 1).
3. When the pressure control knob is open and loose, the plates
will close faster towards one another (Fig 2).
(Fig. 1)
Step 5: Speed / Pressure Control
(Fig. 2)
5

Step 6: Engage Press
1. Two Engage buttons are located on left and right side controls
and green in color (Fig 1).
2. To begin the press, press both engage buttons at the same
time.
3. Plates will begin to close at desired speed set by pressure con-
trol.
(Fig. 1)
6

4. When press is engaged, touch screen will display the timer,
plate temperature, and a “stop button” to disengage the press.
Tip: If press will not engage, release emergency stop button.
Step 6: Engage Press cont.
7

1. Twist emergency stop button at any time or press “stop” in red
on the touch screen to release heat plates.
Step 7: Disengage press
8

1. Record the yield of the press (amount of rosin) using the - or +
buttons. Then press continue to save the amount.
Step 8: Record Yield
9

Step 9: Save and Recall Presets
1. To save the current settings, click save preset. This will allow
you to utilize the same settings over and over again, and setup the
press quickly.
2. To access these presets, press the dropdown menu on top of
touch screen and click the preset you desire.
10

1. To customize weight, material, micron bag and strain name info,
press “Edit Setup”.
2. Touch screen will display the set up session screen.
3. To adjust weight use - or + to record weight in grams.
4. To adjust material, click dropdown and input the type of material
you are using.
5. To adjust micron bag size, select from dropdown menu or enter
custom micron bag size.
6. To adjust strain name, click text box and use on screen key-
board to enter the name.
7. Click save set up to record all the information you’ve entered.
Step 10: Set Up Session
11

Step 11: View Press History
1. Click history on bottom right of the home screen.
2. Scroll down to view past information on presses.
3. Click <- History if you wish to return to the home screen.
Tip: Setting up a session will allow you to accurately record press-
es and export them to your email at a later time. The more infor-
mation you enter, the more targeted your presses can be.
12

1. On the history screen, click “wi settings”.
2. Choose your Wi network and enter the password to the net-
work.
3. Click save.
4. Status will update and show connection to wi network.
5. Click <- Connect to wi on the top right to return to history
screen.
Step 12: Connect to Wi
13

Step 13: Email Results
1. On history screen, click “export”
2. Click text box and use on screen keyboard to enter email.
3. Click send and you will receive results of press to email shortly.
Tip: If you are not receiving email, please ensure you are connect-
ed to wi (refer to step 11) or that spelling of email is correct.
For more tips and info, please visit our blog at:
www.rosintech.com
14
