Ross OpenGear DSS-8224 User manual

DSS-8224 User Guide

Thank You for Choosing Ross
You've made a great choice. We expect you will be very happy with your purchase of Ross Technology.
Our mission is to:
1. Provide a Superior Customer Experience
• offer the best product quality and support
2. Make Cool Practical Technology
• develop great products that customers love
Ross has become well known for the Ross Video Code of Ethics. It guides our interactions and
empowers our employees. I hope you enjoy reading it below.
If anything at all with your Ross experience does not live up to your expectations be sure to reach out to
us at [email protected].
David Ross
CEO, Ross Video
[email protected]
Ross Video Code of Ethics
Any company is the sum total of the people that make things happen. At Ross, our employees are a
special group. Our employees truly care about doing a great job and delivering a high quality customer
experience every day. This code of ethics hangs on the wall of all Ross Video locations to guide our
behavior:
1. We will always act in our customers’ best interest.
2. We will do our best to understand our customers’ requirements.
3. We will not ship crap.
4. We will be great to work with.
5. We will do something extra for our customers, as an apology, when something big goes wrong and
it's our fault.
6. We will keep our promises.
7. We will treat the competition with respect.
8. We will cooperate with and help other friendly companies.
9. We will go above and beyond in times of crisis. If there's no one to authorize the required action in
times of company or customer crisis - do what you know in your heart is right. (You may rent
helicopters if necessary.)

DSS-8224 · User Guide
• Ross Part Number: 8224DR-004-06
• Release Date: August 21, 2019.
The information contained in this Guide is subject to change without notice or obligation.
Copyright
©2019 Ross Video Limited, Ross®, and any related marks are trademarks or registered trademarks of Ross Video
Limited. All other trademarks are the property of their respective companies. PATENTS ISSUED and PENDING.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any
form or by any means, mechanical, photocopying, recording or otherwise, without the prior written permission of
Ross Video. While every precaution has been taken in the preparation of this document, Ross Video assumes no
responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the
information contained herein.
Patents
Patent numbers US 7,034,886; US 7,508,455; US 7,602,446; US 7,802,802 B2; US 7,834,886; US 7,914,332; US
8,307,284; US 8,407,374 B2; US 8,499,019 B2; US 8,519,949 B2; US 8,743,292 B2; GB 2,419,119 B; GB
2,447,380 B; and other patents pending.
Notice
The material in this manual is furnished for informational use only. It is subject to change without notice and should
not be construed as commitment by Ross Video Limited. Ross Video Limited assumes no responsibility or liability
for errors or inaccuracies that may appear in this manual.
Safety Notices
Refer to the “Important Regulatory and Safety Notices” document that accompanied your product.
Statement of Compliance
This product has been determined to be compliant with the applicable standards, regulations, and directives for the
countries where the product is marketed.
Compliance documentation, such as certification or Declaration of Compliance for the product is available upon
request by contacting [email protected]. Please include the product; model number identifiers and serial
number and country that compliance information is needed in request.
EMC Notices
US FCC Part 15
This equipment has been tested and found to comply with the limits for a class A Digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a Commercial environment. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
Canada
This Class “A” digital apparatus complies with Canadian ICES-003 and part 15 of the FCC Rules.
Cet appareil numerique de la classe “A” est conforme a la norme NMB-003 du Canada.
European Union
This equipment is in compliance with the essential requirements and other relevant provisions established under
regulation (EC) No 765/2008 and Decision No 768/2008/EC referred to as the “New Legislative Framework”.
Australia/New Zealand
This equipment is in compliance with the provisions established under the Radiocommunications Act 1992 and
Radiocommunications Labeling (Electromagnetic Compatibility) Notice 2008.
Korea
This equipment is in compliance with the provisions established under the Radio Waves Act.
Class A equipment (Broadcasting and communications service for business use)
This device is a business-use (Class A) EMC-compliant device. The seller and user are advised to be aware of this
fact. This device is intended for use in areas outside home.
International
This equipment has been tested under the requirements of CISPR 22:2008 or CISPR 32:2015 and found to comply
with the limits for a Class A Digital device.
Maintenance/User Serviceable Parts
Routine maintenance to this openGear product is not required. This product contains no user serviceable parts. If
the module does not appear to be working properly, please contact Technical Support using the numbers listed
under the “Contact Us” section of this manual. All openGear products are covered by a generous 5-year warranty
Notice — Changes or modifications to this equipment not expressly approved by Ross Video Ltd. could
void the user’s authority to operate this equipment.
Warning — This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
Notice — This is a Class A product. In domestic environments, this product may cause radio
interference, in which case the user may have to take adequate measures.
Type of Equipment User’s Guide
A
(߶הࡈ ؏ܞݦ࢕ࢢ)
Class A Equipment
(Industrial Broadcasting &
Communication Equipment)
ࢇ Е ߶הࡈ(A)ࢷ࢕ળࢶଢԻ۰ શ
֐࢕ ӖЕ یࡈ࢕Е ࢇ ࢺࡶ ࣯ࢂଜݤ ؂Ԃ
ֲ,ɼࢽ࠹ࢂ ࠇ߾۰ یࡈଜЕ ʨࡶ ּࢶࡳԻ
ଢТЬ.
This equipment is Industrial (Class A)
electromagnetic wave suitability equipment and
seller or user should take notice of it, and this
equipment is to be used in the places except for home.

and will be repaired without charge for materials or labor within this period. See the “Warranty and Repair
Policy” section in this manual for details.
Environmental Information
The equipment may contain hazardous substances that could impact health and the environment.
To avoid the potential release of those substances into the environment and to diminish the need for the extraction
of natural resources, Ross Video encourages you to use the appropriate take-back systems. These systems will reuse
or recycle most of the materials from your end-of-life equipment in an environmentally friendly and health
conscious manner.
The crossed-out wheeled bin symbol invites you to use these systems.
If you need more information on the collection, reuse, and recycling systems, please contact your local or regional
waste administration. You can also contact Ross Video for more information on the environmental performances of
our products.
Company Address
Ross Video Limited Ross Video Incorporated
8 John Street P.O. Box 880
Iroquois, Ontario, K0E 1K0 Ogdensburg, New York
Canada USA 13669-0880
General Business Office: (+1) 613 • 652 • 4886
Fax: (+1) 613 • 652 • 4425
Technical Support: (+1) 613 • 652 • 4886
After Hours Emergency: (+1) 613 • 349 • 0006
E-mail (Technical Support): [email protected]
E-mail (General Information): solu[email protected]
Website: http://www.rossvideo.com

DSS-8224 Series User Guide (v6.0) Contents • i
Contents
Introduction 9
Related Publications .................................................................................................................................................9
Documentation Conventions .................................................................................................................................... 9
Interface Elements ................................................................................................................................................. 9
User Entered Text .................................................................................................................................................9
Referenced Guides ................................................................................................................................................9
Menu Sequences .................................................................................................................................................. 10
Important Instructions .........................................................................................................................................10
Contacting Technical Support ................................................................................................................................ 10
Before You Begin 11
Overview ................................................................................................................................................................11
Features ...............................................................................................................................................................11
Functional Block Diagrams ...................................................................................................................................12
User Interfaces .......................................................................................................................................................13
DashBoard Control System ................................................................................................................................. 13
Card-edge Control and Monitoring ..................................................................................................................... 13
SNMP Monitoring and Control ........................................................................................................................... 13
Hardware Overview 15
Card Overview .......................................................................................................................................................15
Control and Monitoring Features ...........................................................................................................................16
Status and Selection LEDs on the DSS-8224 .....................................................................................................17
Physical Installation 19
Before You Begin .................................................................................................................................................. 19
Static Discharge .................................................................................................................................................. 19
Unpacking ........................................................................................................................................................... 19
Installing the DSS-8224 .........................................................................................................................................19
Rear Modules for the DSS-8224 .........................................................................................................................19
Installing a Rear Module .....................................................................................................................................19
Installing the DSS-8224 ...................................................................................................................................... 20
Cabling for the DSS-8224 ......................................................................................................................................21
DFR-8310 Series Frame Cabling ........................................................................................................................21
DFR-8321, OG3-FR, and OGX-FR Series Frame Cabling ................................................................................21
Configuration 23
Control Modes ....................................................................................................................................................... 23
Configuring Card Control ...................................................................................................................................23
Selecting the Control Mode ................................................................................................................................ 23
Operation Modes ....................................................................................................................................................23
Configuring the Operating Mode ........................................................................................................................ 24
Configuring SW1 and SW2 ................................................................................................................................24
Auto Change Over (ACO) Mode ........................................................................................................................ 25
7x1 Mode Setup ..................................................................................................................................................25
Selecting the Timing .............................................................................................................................................. 25
Selecting the Reclocking Mode .............................................................................................................................26

ii • Contents DSS-8224 Series User Guide (v6.0)
Operation 27
Overview ................................................................................................................................................................27
Cable Length Requirements ...................................................................................................................................28
Operating Modes with the RCM-8120 Control Module ........................................................................................29
7x1 Mode .............................................................................................................................................................30
Multiple Remote Module Operation ......................................................................................................................30
GPI Operation ........................................................................................................................................................30
GPI Switch Operation .........................................................................................................................................31
GPI Level Operating Modes ................................................................................................................................31
Software Upgrades 33
DashBoard Menus 35
Status Tabs .............................................................................................................................................................35
Signal Tab ............................................................................................................................................................35
Hardware Tab ......................................................................................................................................................36
Product Tab .........................................................................................................................................................36
Setup Tab ................................................................................................................................................................36
Remote Control Tab ...............................................................................................................................................37
4x2 Mode .............................................................................................................................................................37
4x1 Mode .............................................................................................................................................................37
Dual 2x1 Mode ....................................................................................................................................................38
Dual 2x1 with Tracking Mode ............................................................................................................................39
Alarms Tab .............................................................................................................................................................40
Jumpers Tab ...........................................................................................................................................................40
Technical Specifications 43
Service Information 45
Troubleshooting Checklist .....................................................................................................................................45
Bootload Button ..................................................................................................................................................45
Warranty and Repair Policy ...................................................................................................................................45
Glossary 47

DSS-8224 User Guide (v6.0) Introduction • 9
Introduction
This guide covers the installation, configuration, and use of the DSS-8224. The following chapters are included:
•“Introduction” summarizes the guide and provides important terms, and conventions.
•“Before You Begin” provides general information to keep in mind before installing and configuring your card.
•“Hardware Overview” provides a basic introduction to the hardware features including the cabling and
monitoring features of the rear module.
•“Physical Installation” provides instructions for the physical installation of the card and its rear module, and
provides an overview of connecting input and output devices to the rear module.
•“Configuration” provides a general overview of the configuring the DSS-8224.
•“Software Upgrades” provides instructions for upgrading the software for your DSS-8224 using DashBoard.
•“DashBoard Menus” summarizes the DSS-8224 menus, items, and parameters in DashBoard.
•“Technical Specifications” provides technical specification details on the DSS-8224.
•“Service Information” provides information on the warranty and repair policy for your card.
•“Glossary” provides a list of terms used throughout this guide.
Related Publications
It is recommended to consult the following Ross documentation before installing and configuring your DSS-8224
card:
•DashBoard User Manual, Ross Part Number: 8351DR-004
•MFC-OG3-N and MFC-8322-S User Manual, Ross Part Number: 8322DR-004
•OG3-FR Series User Manual, Ross Part Number: 8322DR-005
•OGX-FR Series User Manual, Ross Part Number: 8322DR-204
Documentation Conventions
Special text formats are used in this guide to identify parts of the user interface, text that a user must enter, or a
sequence of menus and sub-menus that must be followed to reach a particular command.
Interface Elements
Bold text is used to identify a user interface element such as a dialog box, menu item, or button. For example:
In the Network tab, click Apply.
User Entered Text
Courier text is used to identify text that a user must enter. For example:
In the Language box, enter English.
Referenced Guides
Text set in bold and italic represent the titles of referenced guides, manuals, or documents. For example:
For more information, refer to the DashBoard User Manual.

10 • Introduction DSS-8224 User Guide (v6.0)
Menu Sequences
Menu arrows are used in procedures to identify a sequence of menu items that you must follow. For example, if a
step reads “File > Save As,” you would click the File menu and then click Save As.
Important Instructions
Star icons are used to identify important instructions or features. For example:
Contact your IT department before connecting to your facility network to ensure that there are no conflicts. They
will provide you with an appropriate value for the IP Address, Subnet Mask, and Gateway for your device.
Contacting Technical Support
At Ross Video, we take pride in the quality of our products, but if problems occur, help is as close as the nearest
telephone.
Our 24-hour Hot Line service ensures you have access to technical expertise around the clock. After-sales service
and technical support is provided directly by Ross Video personnel. During business hours (Eastern Time),
technical support personnel are available by telephone. After hours and on weekends, a direct emergency technical
support phone line is available. If the technical support person who is on call does not answer this line immediately,
a voice message can be left and the call will be returned shortly. This team of highly trained staff is available to
react to any problem and to do whatever is necessary to ensure customer satisfaction.
•Technical Support: ([phone]
•After Hours Emergency: ([phone]
•E-mail: [email protected]
•Website: http://www.rossvideo.com

DSS-8224 User Guide (v6.0) Before You Begin • 11
Before You Begin
Overview
The DSS-8224 is a dual serial switch designed for broadcast use in a multi-definition broadcast environment. This
card supports both standard definition 270Mbps and high definition 1.485Gbps SDI video, as well as other common
serial digital signals at 143Mbps, 360Mbps, and 540Mbps.
Each DSS-8224 has four inputs and two outputs. Each output is available on two BNCs. The DSS-8224 can be
configured for 7x1, 4x2, 4x1, Dual 2x1, or 2x1 operation.
Each switch is controlled by an optional control module (RMC-8120 or RMC-8120-1), by GPI contact, or by logic
level. All switching is done in the vertical interval, and timed to an external analog reference. The DSS-8224 can
use either of the two frame references that are distributed to all cards in the openGear frame. The appropriate
switching line is automatically determined by the reference frame rate (50Hz or 59.94Hz), and the SDI data rate.
The last input selected for each output is stored in non-volatile memory for power failure protection.
The DSS-8224 equalizes the incoming SDI signal, which compensates for up to 300m of cable at 270Mbps, and
over 120m of cable at 1.485Gbps. The serial data rate is determined automatically, and the signal is optionally
reclocked on output.
LEDs are provided to indicate input and reference signal presence, and to show which input source is selected for
each output.
The DSS-8224 is fully compliant with all openGear technical specifications and supports remote monitoring via
DashBoard Control System software.
Features
The following features make the DSS-8224 the best solution for multi-definition SDI video switching:
• Switches SD and HD serial digital video (270Mbps or 1.485Gbps)
• 4 inputs
• 4 outputs (2 per switch)
• Can be configured as a 7x11, 4x2, 4x1, 2x1, or Dual 2x1 switch
• Controllable by the RCM-8120 module or GPIs
• Switch selections are saved to non-volatile memory
• Vertical interval switching compliant with SMPTE RP168-2002
• Economical cost per switch
• Indicators for input signal presence and reference
• Reports status and configuration remotely via DashBoard Control System
• Fits openGear frames
• Fully compliant with openGear specifications
• 5-year transferable warranty
1. Requires two DSS-8224 cards.

12 • Before You Begin DSS-8224 User Guide (v6.0)
Functional Block Diagrams
This section provides the functional block diagrams that outline the work-flow of the DSS-8224.
Figure 2.1 DSS-8224 4x2 Mode — Simplified Block Diagram
Figure 2.2 DSS-8224 Dual 2x1 Mode — Simplified Block Diagram
Input and EQ
Input and EQ
Input and EQ
Input and EQ
Control
Optional
Reclocker
Optional
Reclocker
Frame Ref 1
* Not available in 2x2 mode with split rear module.
Frame Ref 2
OUT 1A
OUT 1B*
OUT 2A
OUT 2B*
IN 1
IN 2
IN 3*
IN 4*
CTRL Module 1/GPI 1
CTRL Module 2/GPI 2*
Input and EQ
Input and EQ
Input and EQ
Input and EQ
OUT 1A
OUT 1B
IN 1
IN 2
IN 1/IN 3
IN 2/IN 4
Control
OUT 2A
OUT 2B
Optional
Reclocker
Optional
Reclocker
Frame Ref 1
Frame Ref 2
CTRL Module 1/GPI 1
CTRL Module 2/GPI 2
1 & 2
3 & 4
JP10

DSS-8224 User Guide (v6.0) Before You Begin • 13
User Interfaces
The following interfaces are available for control and monitoring of your DSS-8224.
DashBoard Control System
DashBoard Control System enables you to monitor and control openGear frames and cards from a computer.
DashBoard communicates with other cards in the frame through the Network Controller card.
For More Information on...
• the menus in DashBoard, refer to the chapter “DashBoard Menus” on page 35.
• installing and using DashBoard, refer to the DashBoard User Manual.
Card-edge Control and Monitoring
The card-edge provides jumpers for configuring DSS-8224 and LEDs for monitoring the status of the input and
output signals.
For More Information on...
• the DSS-8224 control modes, refer to the section “Control Modes” on page 4.
• the DSS-8224 operation modes, refer to the section “Operation Modes” on page 5.
• configuring the switch timing of the DSS-8224, refer to the section “Selecting the Timing” on page 7.
• selecting the reclocking mode of the DSS-8224, refer to the section “Selecting the Reclocking Mode” on
page 8.
• the card-edge LEDs, refer to the section “Control and Monitoring Features” on page 9.
SNMP Monitoring and Control
The Network Controller card in the openGear frame provides optional support for remote monitoring and control of
your frame and openGear cards using Simple Network Management Protocol (SNMP), which is compatible with
many third-party monitoring and control tools.
For More Information on...
• SNMP controls on your card, refer to your DSS-8224 Management Information Base (MIB) file.
• SNMP Monitoring and Control, refer to your MFC-8300 Series or MFC-OG3 Series User Manual.

14 • Before You Begin DSS-8224 User Guide (v6.0)

DSS-8224 User Guide (v6.0) Hardware Overview • 15
Hardware Overview
This chapter provides a general overview of the DSS-8224 components, supported rear modules, and cabling
designations.
Wait 30 seconds after the last setting change to ensure all changes are saved to the non-volatile memory of the
card.
Card Overview
This section provides a general overview of the DSS-8224 components.
Figure 3.1 DSS-8224 — Components
1. Board Mode Jumper (JP1)
Use JP1 in conjunction with JP3 to configure the DSS-8224 as a Master or Slave card. One RCM-8120 can
control up to ten cards by using one Master and nine Slave cards. The communication between the RCM-8120
and the card is controlled by the DSS-8224 that is configured as the Master card.
2. HD Type Jumper (JP2)
Use JP2 to enable the DSS-8224 to automatically detect the input type, SD or HD, and switch on the appropriate
switching line as defined by SMPTE RP-168-2002. However, the specific HD format cannot be detected
automatically. JP2 allows you to select the HD input format to determine the correct switching line for HD.
3. Control Jumper (JP3)
Use JP3 to select the type of input control that is connect to the card on BNC 7 and BNC 8.
4. Xpoint Mode Jumper (JP4)
Use JP4 to select the control mode of the DSS-8224.
5. Panel Type Jumper (JP5)
Use JP5 in conjunction with JP3 to select the type of RCM-810 remote control module connected to the
DSS-8224.
6. Reference Select Jumper (JP6)
Use JP6 to select the frame reference used on the DSS-8224.
1) Board Mode Jumper (JP1) 6) Reference Select Jumper (JP6) 11) GPI Type Jumper (JP11)
2) HD Type Jumper (JP2) 7) Reclock Mode Jumper (JP7) 12) Output 1 Select Button (SW1)
3) Control Jumper (JP3) 8) Card Control Jumper (JP8) 13)Output 2 Select Button (SW2)
4) Xpoint Mode Jumper (JP4) 9) Output 2 Control Mode Jumper (JP9) 14) Bootload Button (SW3)
5) Panel Type Jumper (JP5) 10) 2x1 Mode Jumper (JP10)

16 • Hardware Overview DSS-8224 User Guide (v6.0)
7. Reclock Mode Jumper (JP7)
Use JP7 to enable or disable the reclocking feature of the DSS-8224. This jumper also impacts the ACO feature of
the card. Refer to “Auto Change Over (ACO) Mode” on page 25 for more information.
8. Card Control Jumper (JP8)
Use JP8 to select whether the DSS-8224 is remotely configured using DashBoard or SNMP, or using the
card-edge controls.
9. Output 2 Control Mode Jumper (JP9)
Use JP9 to configure the control mode for Output 2.
10.2x1 Mode Jumper (JP10)
Use JP10 to configure which two inputs are available on Output 2, when operating in 2x1 Mode
11.GPI Type Jumper (JP11)
Use JP11 in conjunction with JP3 to select the type of GPI control used by the DSS-8224.
12.Output 1 Select Button (SW1)
SW1 selects the next input on Output 1.
13.Output 2 Select Button (SW2)
SW2 selects the next input on Output 2.
14.Bootload Button (SW3)
This button is used for factory service in the unlikely event of a complete card failure. Do not press this button
unless instructed to do so by Ross Technical Support.
For More Information on...
• the operating modes for the DSS-8224, refer to the section “Operation Modes” on page 23.
• the switch timing of the DSS-8224, refer to the section “Selecting the Timing” on page 25.
Control and Monitoring Features
This section provides information on the jumpers, buttons and LEDs for the DSS-8224. (Figure 3.1)
Figure 3.2 DSS-8224 Card-edge Controls

DSS-8224 User Guide (v6.0) Hardware Overview • 17
Status and Selection LEDs on the DSS-8224
The front-edge of the DSS-8224 has LED indicators for card power, and communication activity. Basic LED
displays and descriptions are provided in Ta ble 3. 1 .
Table 3.1 LEDs on the DSS-8224
LED Color Display and Description
PWR Green When lit green, this LED indicates that the card is functioning correctly.
Flashing Green When flashing green, this LED indicates that the card does not have a
valid software load.
Amber When lit amber, this LED indicates a hardware failure.
Red When lit red, this LED indicates that the card is powering on.
Off When unlit, this LED indicates a lack of power to the card.
SW1 IN # Yellow The four LEDs present in this area report which input is selected for
Output 1. The LED for the selected input is illuminated yellow when
selected.
This input is routed to Outputs 1A and 1B.
Flashing Yellow When flashing, these LEDs indicate the ACO Mode is enabled.
SW2 IN # Yellow The four LEDs present in this area report which input is selected for
Output 2. The LED for the selected input is illuminated yellow when
selected. This input is routed to outputs 2A and 2B.
Flashing Yellow When flashing, these LEDs indicate the ACO Mode is enabled.
INPUT # Green When lit green, this LED indicates that an SDI signal is present on the
specified input.
Off When unlit, this LED indicates that no SDI signal is detected on the
specified input.
REF OK Green When lit green, this LED indicates than an analog reference is present
and locked.
Off When unlit, this LED indicates that the analog reference is not present,
or not locked.

18 • Hardware Overview DSS-8224 User Guide (v6.0)

DSS-8224 User Guide (v6.0) Physical Installation • 19
Physical Installation
This chapter provides instructions for installing the Rear Module(s) for the DSS-8224, installing the card into the
frame, cabling details, and updating the card software.
Before You Begin
Before proceeding with the instructions in this chapter, ensure that your openGear frame is properly installed
according to the instructions in its manual.
Static Discharge
Throughout this chapter, please heed the following cautionary note:
Unpacking
Unpack each DSS-8224 you received from the shipping container and ensure that all items are included. If any
items are missing or damaged, contact your sales representative or Ross Video directly.
Installing the DSS-8224
This section outlines how to install a Rear Module in an openGear frame. The same procedure applies regardless of
the frame or card type. However, the specific Rear Module you need to install depends on the frame you are using.
Rear Modules for the DSS-8224
The Rear Module for the DSS-8224 depends on the openGear frame you are installing the card into.
•DFR-8310 series frame — The 8310AR-030 Rear Module is required. The DSS-8224 is also compatible with
the DFR-8310-BNC frame.
•DFR-8320, OG3-FR, or OGX-FR series frame — The 8320AR-030 Full Rear Module or the 8320AR-031
Split Rear Module can be used. Note that the available cable designations differ between the type of rear module
used. Refer to the section Refer to the section “DFR-8321, OG3-FR, and OGX-FR Series Frame Cabling” on
page 21 for details.
Installing a Rear Module
If you are installing the DSS-8224 in a DFR-8310-BNC frame, or the Rear Module is already installed, proceed to
the section Refer to the section “Installing the DSS-8224” on page 20.
To install a Rear Module in your openGear frame
1. Locate the card frame slots on the rear of the frame.
2. Remove the Blank Plate from the slot you have chosen for the DSS-8224 installation.
3. Install the bottom of the Rear Module in the Module Seating Slot at the base of the frame’s back plane.
ESD Susceptibility — Static discharge can cause serious damage to sensitive semiconductor
devices. Avoid handling circuit boards in high static environments such as carpeted areas and when
synthetic fiber clothing is worn. Always exercise proper grounding precautions when working on circuit
boards and related equipment.

20 • Physical Installation DSS-8224 User Guide (v6.0)
4. Align the top hole of the Rear Module with the screw on the top-edge of the frame back plane.
5. Using a Phillips screwdriver and the supplied screw, fasten the Rear Module to the back plane of the frame. Do
not over tighten.
6. Ensure proper frame cooling and ventilation by having all rear frame slots covered with Rear Modules or Blank
Plates.
Installing the DSS-8224
This section outlines how to install the DSS-8224 in an openGear frame. If the DSS-8224 is to be installed in any
compatible frame other than a Ross Video product, refer to the frame manufacturer’s manual for specific
instructions.
To install the DSS-8224 in an openGear frame
1. Locate the Rear Module you installed in the procedure Refer to the section “Installing a Rear Module” on
page 19.
2. Hold the DSS-8224 by the edges and carefully align the card-edges with the slots in the frame.
3. Fully insert the card into the frame until the rear connection plus is properly seated in the Rear Module.
4. Verify whether your Rear Module Label is self-adhesive by checking the back of the label for a thin wax sheet.
You must remove the wax sheet before affixing the label.
5. Affix the supplied Rear Module Label to the rear module face.
Caution — Heat and power distribution requirements within a frame may dictate specific slot
placements of cards. Cards with many heat-producing components should be arranged to avoid areas of
excess heat build-up, particularly in frames using convectional cooling.
Screw Hole
Module Seating Slots
