Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 1
SL135
Capacity: 3500 kg
Model Serial Number
SL135RA
SL135HP
SL135HMP
Initial operation:
This operation and maintenance manual has to be handed over to the owner/user after putting the
lift into operation.
© July 2005 by Rotary Lift. PBxxxxx
Rev.C 01/07/05
O
P
E
R
A
T
I
O
N
&
M
A
I
N
T
E
N
A
N
C
E
M
A
N
U
A
L

Operation and maintenance manual • ROTARY inground lifts SmartLift • Rev. B • Release: 08/2004 2
Content
1 Important remarks......................................................................................2
2 Control box.................................................................................................3
3 Certificate for initial operation by an expert................................................4
4 Certificate for power connection by an electro-technician..........................5
5 Indications for regular maintenance...........................................................6
6 Results of the regular maintenance ...........................................................7
7 Technical data sheet..................................................................................8
8 Complete user instructions.........................................................................9
9 EC-conformity declaration........................................................................15
1. Important remarks
This Lift is only for lifting vehicles without persons.
Note the short user instructions at the control box!
Only persons with an age of 18 and more, which are instructed in
operating the lift, are allowed to operate them independently.
They have to be engaged by the person responsible expressly
to operate the lifting platform.
Display this manual in a conspicuous location in the area
convenient to the operator.

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 3
2. Control box
Description of the control elements
1. Turning the key from position ´0´ to position ´I´ supplies the motor with power.
2. The use of the lift is mechanically with a one-hand lever (dead man´s control), which
works using a micro switch directly to the valve. To lift press the lever UP (from the
body). To lower press the lever DOWN (towards the body).
3. Immediately after release of the lever the lift stops lifting or lowering movement..
4. Turning the key from position ´I´ to position ´0´ immediately interrupts the power supply
of the motor and stops every movement (emergency stop function).
5. There is no pneumatic lowering system in case of power failure.
6. Lifting or lowering is limited mechanically by an upper and lower stop. You have to
release the level immediately at the upper or lower mechanical stop.

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 4
3. Certificate for initial operation by an expert
The lift of model __________________ with the serial number ________________
was subjected to the examination of an operational status on ______________ .
No faults have been discovered and the lift can be put into operation.
The operator was taught and introduced by the expert about the proper handling.
Place, Date Signature of the expert
Name of the expert
Adress of the expert
ATTENTION: Please send the clompeted certificate for initial operation by an expert
back to the manufacturer for the validity of the rights to claim under warranty.
Without this certificate no warranty!
Please cut here and send or fax to BlitzRotary GmbH, Hüfinger Str. 55, D-78199 Bräunlingen, Fax-Nr. ++49-(0)-771/9233-99
"------------------------------------------------------------------------------------------------------------------------------------------
CERTIFICATE FOR INITIAL OPERATION BY AN EXPERT FOR
LIFT WITH SERIAL NUMBER _________________.
Place, Date Signature of the expert
Name and adress of the expert
Adress of the owner (stamp):
By fax to ++49-(0)-771/9233-99
BlitzRotary GmbH
Hüfinger Str. 55
78199 Bräunlingen
GERMANY

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 5
4. Certificate for power connection by an electro-technician
For the lift with the serial number _________
_
_____________ the power connection
was performed by an electro-technician on _______________ .
The grounding contact was tested with an current of 10 Ampere [max. 0,1 Ohm] and
the high voltage test with 1000 Volts.
The tests have been performed without any complaints.
The electro-technician confirms to the owner that the power connection was performed
regularly and the test have been without complaints.
Place, Date Signature of the electro-technician
Name of the electro-technician
Adress / Stamp of the electro-technician´s company
Please note: Only the owner is responsible for the regular power connection!

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 6
5. Indications for the regular maintenance
Technical data of the lift
Check the manufacturer plate, inscription and abridged operating instructions if its readable and still
fastened.
Operating status and security devices
Check the lift with and without load in all functions, especially check the end stops at hydraulic
cylinders and supports of effectiveness and secure fastening.
Test the load construction and the supports for distortion.
Test the welding seams for cracks.
Check the wear and tear on all movable parts.
Control parts
Check the lever (dead man´s control) for functioning and fastening.
Check the master switch.
Check the security against unauthorized use.
Check all electrical wires for damage and fastening.
Lifting cylinders and hydraulic unit
Check the lifting cylinders and the hydraulic unit especially at the connections for tightness.
Check the loss of oil in the tank.
Check the hydraulic hoses for the proper position and state.
Indications for maintenance
1. Clean the cylinder exit!
2. Tighten all screws!
3. Check all fixation screws according to torque (see installation instructions)
4. Grease all bearings and lubricating nipples!
5. Check level of hydraulic oil! If necessary fill in hydraulic oil HLP22.
6. Clean the hydraulic oil using filter machine!
7. Change all hydraulic hoses every 6 years!
8. Tighten up the hydraulic hoses and the electric wires at the connections!
9. Check all electrical connections for corrosion!
10. Clean and protect the hydraulic unit and all electric parts!
11. Remove water and humidity from the cassette!
12. Check the valve plugs for humidity! If necessary protect with a hydrophobic grease.
13. Renew damaged rubber profile! Use silicone at the contacts of two profiles!
14. Inform the responsible person about special observations!
15. Complete the maintenance manual!

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 7
6. Results of the regular maintenance
A regular yearly check by an expert is laid down for the lift. We recommend the carrying out of this
check together with a maintenance of an ROTARY-authorised service-technician.
You will find some tips for the carrying out of this yearly check and maintenance at chapter 5.
Necessary repairs can be carried out against separate charge.
Date Results of check Name and adress of the expert

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 8
7. Technical data sheet SL135 series
Manufacturer:
BlitzRotary GmbH
Hüfinger Str. 55
78199 Bräunlingen, Germany
Description: Vehicle lift model ______________________
Serial number: _________________ Year of manufact.:
_________________
Date of delivery: _________________ Initial operation: _________________
Lift model SL135RA SL135HP SL135HMP
Capacity in kg 3500 3500 3500
Allowed load distribution 2:1 2:1 2:1
Max. lifting velocity cm/sec 4,5 4,5 4,5
Max. lowering velocity cm/sec 5,0 5,0 5,0
Operating pressure in bar 180 180 180
Pressure limitation in bar 200 200 200
Operating voltage in Volt 400 400 400
Control voltage of valves in Volt by hand by hand by hand
Control voltage of control (DC) 24 24 24
Noise level dB (A) 70 70 70
Lifting limitation no no no
Audible protection system no no no
Pneumatic emergency lowering no no no
Suitable for use in:
in wet and damp rooms yes yes yes
in rooms with danger of explosion no no no
Not for staying below the load-carrier. Not for staying on the load-carrier.
Not for use as a lift bridge.

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 9
8. Complete user instructions
8.1 Range of use
The lift is only to be used for the lifting of motor vehicles. The maximum load capacity has
not to be exceeded.
8.2 Initial operation
The "Initial Operation" has to be carried out by an expert after the installation of the lifting
platform. Then the introduction of the operator into the proper handling and operation has to
take place.
Rights to claim under guarantee can only be given after the receipt of the initial sheeth (see
form "Initial operation by an expert") by the manufacturer.
8.3 Rights of handling
Only persons with an age of 18 and more, which are instructed in operating the lift, are
allowed to operate them independently. They have to be engaged by the person responsible
(business employer, workshop master or security representative) expressly to operate the
lifting platform. The tips of the abridged operating instructions at the control box are to
observe.

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 10
8.4 Lifting vehicle (principles)
a) Before you can drive on, off or over the lifting platform, it has to be lowered up to the
ground level. The driving on is allowed only in the planned direction.
b) Speeding up and braking of the vehicle rapidly is not allowed over the lift supports.
c) Vehicles with a low distance between underside and ground or with special fittings have to
be checked first if damages can happen.
d) The lifting of the vehicles is allowed only at the support points given by the car
manufacturers. If necessary use suitable additional support carriers.
e) Take care that the vehicles are lifted secure! The support points at the vehicles and the lift
have to be clean and free of oil and grease.
f) Pay attention to the allowed load distribution of 2:1.
g) After lifting the wheels from the ground the secure position of the vehicle is to check! This
means: Inspect and check if all four suppoet points are lifted up proper and secure and a
slipping of the vehicle is not possible. Further the locking systems must be in function. If
this is not: Lower down the lift and try again.
h) Possible shifts of center of gravity by a disassembly of heavy parts have to be taken into
account.
i) The vehicle is to be taken up by the lift as centric as possible.
j) It is not allowed to set the lift and the vehicle swinging intentionally.
k) During lifting and lowering of the lift no persons are allowed to stay in the danger spot of
the lift.

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 11
8.4.1 SL135RA
In ground position the swivel arms are pushed together and orientated parallely to the driving
direction. The screw-in cups are removed. The vehicle has to be placed in middle position.
Normally the vehicle is placed correctly, if the middle of the vehicle is over the support arms.
At ground position the locking device unlocks automatically and the swivel arms can be
turned using a hook until the holes for the screw-in cups are not more covered by the
vehicle. Now screw in the cups in their lowest possible position.
To reach the support points exactly, you can extend the swivel arms longitudinally. The
position is correct if the screw-in cups are exactly below the support points. If necessary
adjust the screw-in cups to the right height. Please note that the distance between cups and
vehicle is about equal at all four cups to lift the vehicle in level.
At vehicles with low clearance height of the vehicles´s bottom please note not to damage the
vehicle when driving on or lifting by the support plate. Probably it is necessary to use
different screw-in cups or cup elongations to avoid this.

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 12
8.4.2 SL135HP / SL135HMP
The support plates of the model SL135HP are adjustable longitudinally. You can choose the
following pre-settings as a rule:
Pushed together: very small cars
Half extended: small and normal cars
Totally extended: large cars
Recommendation:
At the half extended position you can lift about 70% of all cars without further adjustement.
To lift a car please perform the steps listed below:
- pre-adjustement of the support plates
- drive on in middle position
- adjust the additional rubber supports
- check the safe support of the plates
- lifting
To adjust the longitudinal position of the support plates push up the plate and move it until it
is fixed at the next position. Please note that both plates of one side are extended about to
the same position. Please avoid that one plate is extended completely and the other one not.
Because of the centre of gravity normally it is correct to extend at first the behind plate.
Support plates and additional rubber supports have to be kept free of oil and mud to
guarantee a safe support of the car.
Model SL135HMP is equiped with support which are adjustable longitudinally and
crossways. Please use them analogous to the normal supports. Aditionally you have to
adjust the cross plate.
For driving over you have to push in the cross plate of the supports!

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 13
8.5 Operation
Turn on the lift by moving the main switch to position ´I´. The use of the lift is according to
move on the one-hand lever:
Pushing the lever up: lifting
Pushing the lever down: lowering
If you release the lever the lift immediately stops.
The operator has to observe the lifting platform during the whole lifting and lowering time and
to pay attention that no persons get endangered or hindrances get under the lifting platform.
Arising faults or irregularities during lifting or lowering the lifting platform, immediately
realease the lever and protect the lift against commissioning. A putting into operation again
is only to be done by an expert.
8.6 Maintenance, care and examination
The lifting platform is in general maintenance-free for the operator provided that the regular
annual examination of an authorized ROTARY service technician is carried out together with
a maintenance. Otherwise we refer to maintenance instructions (see capter 5.)!
The following indications are to be considered:
Piston escapes and supports are to be held clean and are to be freed from polluting so that
moveability of the support plates and swivel arms remains guaranteed.
The pressure hoses between cylinder and hydraulic pump are to be exchanged at the latest
after 6 years. The replacement is to be recorded in this maintenance manual.
The annual maintenance is to be recorded in this maintenance manual.
Handle floor cleaners and water economically in the field of the lift! Only employ mild, non-
polluting cleaners. Do not use steam jet cleaners and high pressure cleaners in the direct
field of piston escape and sealings of the inground cassette. The seals may be damaged.
Keep the area around the lift dry. In the area around the built-in cassette, no floor cleaner
and after that no water or "water pools" may gather but the moisture must pour away from
the lift.
Don't let supports lie on wet workshop floor overnight but drive it slightly up.

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 14
8.7 Behavior in case of malfunction
In case of malfunction, in particular with leakiness in the oil system, the lift is to be shut down
immediately and secured against unauthorized use by taking out key of the main power
switch.
Before repairing the failure, a further use is forbidden. Repairs may only be carried out by a
competent and trained personnel.
For elimination of simple failures, ROTARY service hotline ++49-(0)-771-9233-0 is available
for you.
8.8 Pneumatic emergency lowering
During power failure or at defective lowering valve, the lift can be lowered without energy. At
the control a pneumatic emergency lowering is included on the bottom. Simply blow with a
blow gun into the opening and the lift lowers slowly down.
8.9 Spare parts
For repairs, only original ROTARY spare parts are allowed. These can be bought over
ROTARY service technicians or in case of smaller self repairs directly from ROTARY.

Operation and maintenance manual ROTARY SL135-series • Rev. C • Release: 07/2005 15
9. EC conformity declaration
Manufacturer: BlitzRotary GmbH
Manufacturer´s adress: Hüfinger Str. 55, 78199 Bräunlingen,
Germany
Product decription: 1-piston hydraulic inground lifts
Models: SL135RA
SL135HP
SL135HMP
EC guidelines: 98/37/EC, 73/23/EEC, 89/336/EC
Seriennummer:
Applied harmonized and national
standards: EN 1493, VBG 14, DIN EN 292-1, DIN
EN 292-2, DIN EN 294, DIN EN 60 204-1
Institute of approval: RW TÜV Anlagentechnik GmbH,
Postfach 10 32 61, D-45032 Essen
Certificate No:
Hereby we declare that this lift as designed, manufactured and put by us on the
market meets relevant basic safety and health requirements as set forth in the
relevant EC guidelines for machines and electromagnetic compatibility as specified
hereafter (in their latest versions). Further we declare that the machine, described in
appendix IV of the guideline 89/392, was tested at the arroval institute and this lift
corresponds to the tested model.
This declaration will become invalid if the machine is not used as set forth under
"Scope of application" of this operation manual or if any modifications or changes
whatever are made to the machine without prior approval from our end.
Bräunlingen, 01th of July 2005
F. Scherer
General Manager
