OWNER’S MANUAL
R.C750
R.C750 HT
R.X750
R.X750 HT
R.E750
R.T750

3
Contents........................................................ 3
Introduction.................................................. 5
Requirements for riders .................................. 6
Safety............................................................ 7
Safety information in the instruction
manual ........................................................... 7
Symbols on the product .................................. 7
Current regulations......................................... 8
Type plate ....................................................... 8
General information ..................................... 9
Version of the product and edition
of the manual ................................................. 9
Manufacturer:................................................. 9
ONLINE REGISTRATION.................................... 9
Copyright ........................................................ 9
Language........................................................ 9
Target group/users ......................................... 9
Product and type designation ......................... 9
Emergency stop............................................ 10
Power.............................................................. 10
Pushing aid mode........................................... 10
Detailed information..................................... 11
Important information.................................. 12
Proper use of the e-MTB .............................. 14
Safety information .......................................... 14
Problems while using the e-MTB..................... 15
Categories of use ......................................... 16
Using the e-MTB ............................................. 16
Remote 14d operating system ..................... 17
Display screen................................................. 17
Description of the functions............................ 17
On/off button (1)............................................. 17
Light button (2)............................................... 17
Set button (3).................................................. 17
Rocker switch (+/-)......................................... 17
Pushing aid mode........................................... 17
Marquardt Remote 4311 operating
system........................................................... 18
Display screen................................................. 18
Description of the functions............................ 18
On/off button (1)............................................. 18
Rocker switch (︿/﹀) (2) .............................. 18
Joystick (3)...................................................... 18
Light button (4)............................................... 18
Pushing aid mode........................................... 18
Technical data .............................................. 19
First use and before every ride.................... 25
Connecting the charger cable ......................... 25
Charging the drive battery .............................. 25
Drive battery in the down tube ........................ 25
Quick release levers ........................................ 26
Wheels and tyres............................................. 26
Brake system .................................................. 27
Pedals............................................................. 27
Handlebars, stem and suspension fork ........... 28
Saddle height and position ............................. 28
Switching the drive system on and off ............ 28
Checking the bolts .......................................... 29
Riding on public roads.................................... 30
What to check after a crash......................... 31
Wheels and tyres............................................. 31
Handlebars and stem...................................... 31
Frame.............................................................. 31
Drive train....................................................... 32
Other checks ................................................... 32
Brake system ................................................ 33
Checking the brake system ............................. 33
Bedding in the brakes..................................... 33
Grip width ....................................................... 33
Brake chafing ................................................. 34
Contents

4
Drive system ................................................. 35
Electric drive................................................... 35
Motor .............................................................. 35
Mechanical drive ............................................ 35
Cranks ............................................................ 36
Chain.............................................................. 36
Gear system .................................................. 38
Changing gear................................................ 38
Adjusting the gear system .............................. 38
Drive battery ................................................. 40
IPU.................................................................. 40
Charging the IPU ............................................ 42
Removing the IPU ........................................... 43
Installing the IPU............................................ 44
Adjusting the tension on the drive battery ...... 44
Charger ......................................................... 46
Storing the e-MTB........................................... 47
Handlebars, stem and headset..................... 48
Adjusting the handlebars ............................... 48
Headset .......................................................... 48
Stem ............................................................... 48
Adjusting the saddle....................................... 49
Adjusting the Eightpins seat post................... 50
Adjusting the seat post with
a quick release lever ....................................... 51
Lowering the saddle........................................ 51
Running gear - suspension fork ................... 52
Adjusting the suspension fork......................... 52
Shock compression damping .......................... 52
Shock rebound damping ................................. 53
Running gear - rear triangle......................... 54
Adjusting the damping ................................... 54
Shock compression damping .......................... 54
Shock rebound damping ................................. 55
Testing the fork and shock settings ................ 55
Wheels and tyres........................................... 56
Checks before every ride ................................. 56
Quick test........................................................ 56
Front wheel ..................................................... 57
Rear wheel ...................................................... 58
Tyres ............................................................... 58
Checking the tyres .......................................... 58
Checking the spokes ....................................... 59
Checking that the rims run true...................... 59
Transporting the ROTWILD e-MTB................. 60
Transporting the e-MTB by car........................ 60
Transporting the e-MTB by air......................... 61
Troubleshooting ............................................ 62
Warranty, wear and brake pads ................... 63
Wear parts excluded from the warranty........... 63
Normal wear and tear...................................... 63
Brake pads...................................................... 63
Cleaning.......................................................... 64
Cleaning, packaging and disposal................ 64
Recycling and disposal ................................... 65
Packaging material......................................... 65
Service record .............................................. 66
List of tables.................................................. 69
Recommended tightening torques................... 69
EU declaration of conformity........................ 70
List of figures ................................................ 71

5
Dear customer,
Thank you for buying this ROTWILD e-MTB.
You have chosen a high-quality product.
This instruction manual contains information
about the safe use and maintenance of your
ROTWILD e-MTB. Please read the instruction
manual carefully before you go for your first ride,
so that you can find out about the risks
associated with the incorrect use of your e-MTB.
In this instruction manual it is not possible to
describe in detail all the maintenance that your
ROTWILD e-MTB needs. Therefore, you should also
refer to the enclosed instructions provided by our
component manufacturers and visit their
websites.
It is important that you care for and maintain
your ROTWILD e-MTB correctly. This will help
to ensure that it runs without problems and
performs at its best. This manual cannot teach
you the skills you need to be a bike mechanic.
In addition, special tools are needed for some
jobs.
Therefore, you should have maintenance and
repairs carried out by the ROTWILD authorised
dealer who supplied your bike. You will find the
dealer’s contact details and company stamp on
the back page of this original instruction manual.
If you are not able to contact this dealer, you will
find a list of other ROTWILD authorised dealers on
our website at www.rotwild.de.
ROTWILD is constantly developing and improving
its cycles and reserves the right to make changes
to the design, equipment and technology. For this
reason, you cannot make any legal claims on the
basis of the information, illustrations and
descriptions in this instruction manual.
The ROTWILD e-MTB is supplied almost
completely pre-assembled. Nevertheless we
recommend that you check the bike’s functions
before riding it. Always wear suitable safety
clothing, including a helmet, gloves and glasses.
Before you ride the bike on public roads, you
should check the regulations that apply in your
country and ensure that your e-MTB meets the
necessary requirements. You should also follow
the road traffic regulations and behave
considerately to avoid putting yourself and
other road users in danger.
The standard equipment required on bicycles in
other countries may differ from that in Germany.
In particular, the road traffic regulations relating
to lighting, reflectors and other components may
be different.
Before you use your bike, find out about the
regulations that apply to cyclists and bikes on
the roads in your country.
When you use your ROTWILD e-MTB off road,
you should comply with the law in your country.
We would also ask you to respect nature and the
environment.
Introduction

6
Requirements for riders
Please follow the national regulations in your
country.
Where no other legal requirements apply to riders
of electrically assisted bikes, we recommend that
the rider should be a minimum of 15 years old
and have experience of riding pedal-powered
bikes.
In addition, the rider must have the physical and
mental capability to ride a pedal-powered e-MTB.
You should only use your ROTWILD e-MTB for its
intended purpose (see the section “Proper use of
the e-MTB”). This will ensure that the bike is
always ridden in accordance with the specified
category of use.
If the ROTWILD e-MTB is not used properly, this
will invalidate the warranty.
Make sure that you understand the technical
terms that are explained in this instruction
manual on the page where there is an overview
of your bike.
Please note that this instruction manual does not
describe how to build a ROTWILD e-MTB from
parts or how to turn a partially assembled e-MTB
into a roadworthy bike.
Keep this manual in a safe place so that you
can carry out the function checks correctly at any
time. Parents should explain the contents of the
manual to their children if they do not understand
it.
Your ROTWILD authorised dealer will help you
to choose the right frame size for your height.
The ROTWILD e-MTB comes in different frame
sizes for people of the following heights:
Frame size [S] Height: 1.60 - 1.70 m Frame size
[M] Height: 1.71 - 1.84 m Frame size [L] Height:
1.85 - 1.95 m
Frame size [XL] Height: 1.96 - 2.05 m

7
Safety information in the instruction
manual
The following types of safety instructions are
provided in this instruction manual:
DANGER
Serious injuries or death. If you do not follow the
safety instructions in the “Danger” category, you
will suffer serious injuries or death.
WARNING
Serious injuries or death possible. If you do not
follow the safety instructions in the “Warning”
category, you could risk serious injuries or death.
CAUTION
Moderate or minor injuries possible. If you do
not follow the safety instructions in the “Caution”
category, you could suffer moderate or minor
injuries.
NOTICE
Damage to property possible. If you do not follow
the safety instructions in the “Note” category, you
could cause damage to the ROTWILD e-MTB.
Additional information, tips and notes come
under the heading “Information”. Please read
and follow them carefully.
We at ROTWILD hope that you enjoy riding your
new ROTWILD e-MTB.
Symbols on the product
Symbol
General warning. Refer to the owner’s manual.
Meaning
Separate disposal of electrical and electronic
equipment and batteries.
Device in protection class II.
Fuse (device fuse).
Only for indoor use.
Do not burn.
(Do not burn). Do not open battery. Device in protection class II.
Read instructions.
Keep at temperatures below 50°C and out of direct sunlight.
Recyclable material.
Safety

8
Current regulations
The ROTWILD e-MTB models described in this
instruction manual are electrically assisted. They
meet the requirements of the EN 15194 standard,
among others.
This instruction manual complies with the
standards listed in the EU declaration of
conformity
that can be found at the end of the instruction
manual.
You should use only original spare parts and
accessories on your e-MTB. ROTWILD cannot be
held liable for any damage caused if other spare
parts and accessories are used.
NOTICE
Your ROTWILD authorised dealer will have an up-
to-date list of approved accessories.
Before you fit accessories to your e-MTB, please
check with your dealer that they are permitted
and approved for road use.
Type plate
Fig. 1: Sample type plate for ROTWILD electric power
assisted cycles (EPACs)
You will find the latest version of the instruction
manual for your ROTWILD e-MTB at:
www.rotwild.com/Download

9
Version of the product and edition of
the manual
This original instruction manual relates to the
2020 model year, which runs from August 2019
to August 2020.
The manual was published in August 2019.
Manufacturer:
The manufacturer of the e-MTBs is:
ADP ENGINEERING GMBH
Am Bauhof 5
64807 Dieburg, Germany
Tel.: [phone]
Fax: [phone] - 25
E-mail: [email protected]
Website: www.rotwild.de
ONLINE REGISTRATION
Please register your ROTWILD e-MTB online at
www.rotwild.de. We will confirm immediately that
your warranty has started. Once you have
registered your product, you can request an
extended manufacturer’s warranty.
You will find more information in the ROTWILD
warranty terms at www.rotwild.de.
Copyright
© ADP ENGINEERING GMBH, 2019
This original instruction manual must not be
reproduced or distributed and its content must
not be used or communicated, unless specific
permission has been given. If you breach these
regulations, you will be liable for damages.
All rights reserved in the event of the registration
of a patent, utility model or industrial design.
Language
The original instruction manual is written
in German. Other language versions are
translations and are not valid without the
German original instruction manual.
Target group/users
This original instruction manual is intended
for the rider and operator of the ROTWILD e-MTB
described here.
The operator generally has the right of disposal
over the ROTWILD e-MTB and makes it available
for the rider to use and for the specialist dealer
to maintain and repair. If the e-MTB is being test
ridden, hired out or loaned, for example, the
operator and the rider may be different people.
ROTWILD authorised dealers have trained staff
who are able to identify and prevent the risks that
can occur when maintaining and repairing the
ROTWILD e-MTB.
Product and type designation
This original instruction manual applies to the
following ROTWILD e-MTBs:
RC750HT20 / RC75020 / RX750HT20 / RX75020 /
RE75020 / RT75020
CAUTION
The e-MTB does not have a separate emergency
stop or shut-off button.
General information

10
The bike can be shut down by removing the
battery or taking the connector out of the drive
system.
Power
The power is switched off as soon as the rider
stops pedalling. The e-MTB can be stopped
mechanically using the brakes. The brake system
is not connected to the drive system.
CAUTION
When support mode is switched on, the drive
system responds to the smallest pressure on the
pedals.
When you get off the bike, you should apply the
brakes to prevent it from rolling away and to
reduce the risk of an accident.
Pushing aid mode
When the pushing aid mode is switched on, the
drive train will disconnect as soon as you release
the walk-assist button.
The drive system does not switch off when you
apply the brakes, which means that it is always
available.
Fig. 2: Applying the brakes/pulling away
CAUTION
The e-MTB must only be switched on if the rider
is ready to apply the brakes, in other words, if he
or she can reach at least one of the brakes.
Fig. 3: ON/OFF switch
CAUTION
The e-MTB must be switched off as soon as the
rider is no longer able to apply the brakes.
Emergency stop

11
Fig. 4: Detailed information about the ROTWILD e-MTB
1 Suspension fork
2 Handlebars
3Stem
4Frame
5 Saddle clamp
6 Saddle
7 Seat post
8 Rear triangle/swing arm
9 Cassette
10 Rear dérailleur
11 Spoke
12 Rim
13 Tyres
14 Chain
15 Chain ring
16 Crank
17 Pedals
18 Motor
19 Down tube with drive battery
20 Disc brake
21 Shock
22 Linkage
* Please refer to the parts list for your
model to find out whether your eMTB has
the components listed here.
1
2
3
4
6
7
5
13
12
11
8
20
21
22
19
17
15 16
14
18
910
Detailed information

12
The frame of the ROTWILD e-MTB is made by hand
from high-quality aluminium alloy or carbon fibre
composite and is designed to be robust enough
for the intended category of use of the e-MTB
(see the section “Proper use of the e-MTB”).
WARNING
Damage to the frame caused by excessive
stresses, accidents or crashes. A damaged
frame can suddenly fail and cause a crash.
If your frame is damaged or if you have had
an accident or a crash, contact your ROTWILD
authorised dealer.
The ROTWILD e-MTB has a modern, lightweight
design and its components have a limited life
span. Different materials and components react
in different ways to wear and fatigue caused by
stress. If a component exceeds its design service
life, it can suddenly fail. This may result in the
rider being injured.
NOTICE
Specific information about carbon. Please
note that carbon and aluminium behave in
a fundamentally different way when damaged.
Unlike aluminium, when carbon is overstressed
it does not become dented or deformed.
The effects of damage to carbon are generally
internal (cracks). After a crash, the frame and
front wheel fork must be checked by a dealer and
replaced if the carbon structure has been
damaged. Carbon components can suddenly fail
as a result of damage.
CAUTION
If the fine carbon fibres have broken, take care
when handling the material as they can cause
injuries.
Components made from carbon must never be
straightened after they have been damaged.
They must be replaced immediately. Paint
damage must be repaired to prevent the material
from absorbing moisture, which could have
a negative impact on its properties. Please note
that carbon fibre is highly sensitive to pressure
when clamped (for example the saddle and
dérailleur clamps).
Important information

13
NOTICE
Always use a torque wrench and note the
recommended tightening torques (seethe section
“Recommended tightening torques”).
Keep the contact surfaces of the carbon free
of grease. Use special carbon assembly paste
(available from bike dealers). Never clamp
a carbon frame in a stand (when maintaining
the bike) or in a roof rack. Only use the seat post
for this purpose, providing that it is not made
from carbon fibre.
Make sure that carbon components do not get too
hot, for example if exposed to sunlight in a car.
We recommend that you do not paint or powder
coat your frame or front wheel fork. These
processes can involve high temperatures which
could damage or destroy the components.
If you have had the frame or fork partially
repainted, you must ask your ROTWILD authorised
dealer to check them.
WARNING
Material fatigue in carbon components. Carbon
components that are exposed to high levels of
stress, such as handlebars, stems and seat
posts, can suffer from material fatigue in the
same way as metal parts.
Have your bike serviced regularly at the
recommended intervals so that these
components can be checked.
WARNING
Using damaged carbon components. If carbon
frames, carbon forks or other carbon components
make cracking noises or if you can see cracks,
nicks, dents or discolouration, you must stop
using them. Damaged carbon components can
suddenly fail and cause a crash.
The damaged carbon components must be
replaced immediately.
Your ROTWILD authorised dealer will clean the
e-MTB thoroughly and check it for signs of
material fatigue.
CAUTION
If you notice any signs of material fatigue while
you are using the bike, you must stop using it
immediately and ask your ROTWILD authorised
dealer to check it.

14
Using the e-MTB properly includes following
the instructions on operating, maintaining and
servicing the bike in this instruction manual.
The instruction manual has been written
specifically for your ROTWILD e-MTB, but
cannot describe it down to the smallest detail.
The ROTWILD e-MTB is an electric mountain bike.
The models described here – RC750HT20 /
RC75020 / RX750HT20 / RX75020 / RE75020 /
RT75020 – are designed for private use on paved
roads and paths and for off-road riding in
accordance with the specified category of
use They are designed to transport one person.
See the section “Categories of use”.
Safety information
If you do not follow the safety instructions in this
instruction manual, you run the risk of the e-MTB
breaking down. ROTWILD will not be liable for the
resulting damage.
NOTICE
The total permitted weight of the ROTWILD e-
MTB, including the rider and any luggage, is
120 kg.
WARNING
Using child seats and child trailers. ROTWILD e-
MTBs are not approved for child seats or for
towing child trailers. Do not use child seats or
child trailers.
Your ROTWILD authorised dealer will have an up-
to-date list of approved accessories.
WARNING
If the drive system is switched on, bags or loads
can activate the pushing aid mode. They can also
interfere with other functions, such as braking.
You must not use the e-MTB if it is damaged or
incomplete, for example if the drive battery has
been removed.
WARNING
Overloading the e-MTB. Overloading the e-MTB
can cause safety-related components to break or
fail (for example the frame, front wheel fork,
handlebars, stem, seat post etc.). Do not exceed
the total permitted weight of 120 kg. Never take
a second person on the bike.
WARNING
Uncontrolled riding. By failing to fasten loads
properly and riding carelessly you can put
yourself and other road users at risk. You can lose
control of the e-MTB. Do not transport bags or
other loads on the handlebars. Do not ride with
your hands off the handlebars. Only ride on
suitable surfaces that have sufficient grip.
Kickstands/centre stands. Fitting a kickstand to
the ROTWILD models with the type designation
specified on the cover is not permitted unless the
ROTWILD stand adapter is used to fit the
kickstand (available from ROTWILD authorised
dealers).
Proper use of the e-MTB

15
WARNING
Using the e-MTB in any other way does not
constitute proper use. ROTWILD will not accept
liability if the e-MTB is not used properly. This will
also invalidate the warranty. This includes
lending the e-MTB to a rider who is not familiar
with it, transporting more than one person, riding
with excessive luggage, riding with your hands
off the handlebars, riding on unsuitable surfaces
(ice or snow) and incorrect maintenance or
repairs.
You must not hang shopping bags or similar
loads on the handlebars.
Problems while using the e-MTB
If you notice unusual noises, vibrations, smells,
discolouration, deformed components, friction or
wear while riding or maintaining the e-MTB or
while charging the drive battery, you must stop
using it and take it to your ROTWILD authorised
dealer. The same applies if the bike feels
different, for example during braking, pedalling
or steering.
NOTICE
Please follow the instructions for use and
assembly provided by the component
manufacturers which are included with your
e-MTB, together with the instruction manual for
use on the component manufacturers’ websites.
Your ROTWILD authorised dealer will be happy
to answer any further questions you may have.

16
The various ROTWILD models are suitable/
designed for different categories of use:
Category 1
This is a set of conditions for the
operation of a bicycle on a regular
paved surface where the tires are
intended to maintain ground
contact.
Category 2
TYPE RC750HT20 / RT75020
This is a set of conditions for the
operation of a bicycle that includes
Condition 1 as well as unpaved and
gravel roads and trails with moderate grades.
In this set of conditions, contact with irregular
terrain and loss of tire contact with the ground
may occur. Drops are intended to be limited to
15 cm (6 in.) or less. The tyres may briefly lose
contact with the ground. Jumps and drops are
restricted to a maximum height of 15 cm.
Category 3
TYPE RC75020 / RX750HT20
This is a set of conditions for
operation of a bicycle that includes
Condition 1 and Condition 2 as well
as rough trails, rough unpaved roads, and
rough terrain and unimproved trails that require
technical skills. Jumps and drops are intended
to be less than 61 cm (24 in.). A good riding
technique is needed. Jumps and drops are
restricted to a maximum height of 61 cm.
Category 4
TYPE RX75020 / RE75020
This is a set of conditions for
operation of a bicycle that includes
Conditions 1 - 3, and downhill
grades on rough trails at speeds of up to
40 km/h (25 mph). Jumps and drops are
restricted to a maximum height of 122 cm.
Using the e-MTB
WARNING
Only use the ROTWILD e-MTB in the manner
described in this instruction manual. Any other
type of use constitutes improper use and can lead
to accidents, injuries or damage to property.
The ROTWILD e-MTB is not a toy.
NOTICE
The manufacturer and the dealer accept no
liability for damage caused by improper or
incorrect use.
Categories of use

17
The display of the Remote 14d operating system
is on the left of the handlebars when you are
sitting on the bike. Please check the parts list for
your model to see which type of display it is fitted
with.
Display screen
Fig. 5: Overview of the fields on the display.
Description of the functions
The operating system has three buttons and
a rocker switch. The functions are as follows:
On/off button (1)
The button located in the e-MTB’s direction of
travel is used to switch it on and off. If the bike
is not being used for several minutes, the system
switches off automatically to save energy.
Light button (2)
When you press the light button, the background
lighting in the display and the e-MTB lights are
switched on, if your bike has this option.
Set button (3)
By pressing the set button you can toggle the
display between total kilometres (T), trip counter
(TRP) and remaining range (R).
If you press and hold the set button, the system
switches between metric and imperial units.
Rocker switch (+/-)
The rocker switch is used to select the different
levels of support. If you press the top half of the
display (+), you increase the level of support.
To reduce the level of support, you press the
bottom half (-).
By pressing and holding the bottom half of the
display (-), you reset the trip counter (TRP).
Pushing aid mode
You switch on the pushing aid mode by pressing
and holding the top half of the display (+).
WARNING
Using pushing aid mode. You must steer the
e-MTB using both hands in the pushing aid
mode.
Please note that because of the design of the
bike, the pedals may turn, so you should leave
enough space for them to move. The power and
speed of pushing aid mode can be adjusted
by selecting a different gear.
Remote 14d operating system

18
The display of the Marquardt Remote 4311
operating system is on the left of the handlebars
when you are sitting on the bike. Please check
the parts list for your model to see which type
of display it is fitted with.
Display screen
Fig. 6: Overview of the fields on the display.
Description of the functions
The operating system has two buttons, a rocker
switch and a joystick. The functions are as
follows:
On/off button (1)
The button located in the e-MTB’s direction of
travel is used to switch it on and off. If the bike is
not being used for several minutes, the system
switches off automatically to save energy.
Rocker switch (︿/﹀) (2)
The rocker switch is used to select the different
levels of support.
If you press the top half of the rocker arm (︿),
you increase the level of support.
To reduce the level of support, you press the
bottom half of the rocker arm (﹀).
Joystick (3)
By pushing the joystick to the right or left, you can
toggle the display between the speed, remaining
range, power in watts, TOUR menu, TOTAL menu
and general settings.
By pushing the joystick downwards, you can
display additional information in the TOUR menu
and the TOTAL menu and under general settings.
Light button (4)
When you press the light button, the light symbol
appears on the display and the e-MTB lights
are switched on, if your bike has this option.
Pushing aid mode
You switch on pushing aid mode by pressing and
holding the top half of the rocker arm (︿) .
WARNING
Using pushing aid mode. You must steer the
e-MTB using both hands in the pushing aid
mode.
Please note that because of the design of the
bike, the pedals may turn, so you should leave
enough space for them to move. The power and
speed of pushing aid mode can be adjusted
by selecting a different gear.
Marquardt Remote 4311 operating system

19
R.C750 HT (type RC750HT20)
EQUIPMENT PRO
HEADSET ACROS RW750 1.5 HEADSET W/ BLOCK LOCK
FORK DT SWISS F535 ONE 120 APT
1.5 TAPERED LINEAIR / COILPAIR / INCONTROL / PLUSHPORT
HANDLEBARS (S/M/L/XL) B35 AL7075 (15-740/740/780/780)
STEM (S/M/L/XL) S35 AL6061 / ML READY (50/50/70/70)
DISPLAY MARQUARDT 4311 / CONNECT C
SEAT POST CRANKBROTHERS HIGHLINE 20
Ø34.9 OFFSET 34.9x125(S)150(M/L/XL) TRAVEL
SADDLE ERGON SM COMP
HANDLEBAR GRIPS ERGON GD10 SLIM FACTORY FROZEN
DRIVE TRAIN BROSE DRIVE S MAG AIR COOLER
BATTERY IPU750 REMOVABLE
4.5A CHARGER
CRANK E13 PLUS 165(S/M)/170(L/XL), E13 DM 36T
CHAIN GUIDEROTWILD SL750
SHIFTING LEVER SHIMANO XT I-SPEC EV
REAR DERAILLEUR SHIMANO XT 8100 SGS STANDARD PLUS
CHAIN SHIMANO HG 7100 12-SPEED
CASSETTE SHIMANO CS 7100 10-51T. 12-SPEED
BRAKES SHIMANO XT 8120/8100 FIN PAD
DISC ROTOR SHIMANO RT800 SENSOR ICE 203/203
WHEELS DT SWISS H1900 SPLINE (30) 110-15/148-12 TAS CL
TYRES CONTINENTAL TRAIL KING PROTECTION 29x2.40
COLOUR COOL GREY
Technical data

20
R.C750 (Type RC75020)
EQUIPMENT ULTRA PRO CORE
SUSPENSION ELEMENT DT SWISS R535 ONE LINEAIR / INCONTROL DT SWISS R535 ONE LINEAIR / INCONTROL DT SWISS R535 ONE LINEAIR / INCONTROL
HEADSET ACROS RW750 1.5 HEADSET W/ BLOCK LOCK ACROS RW750 1.5 HEADSET W/ BLOCK LOCK ACROS RW750 1.5 HEADSET W/ BLOCK LOCK
FORK DT SWISS F535 ONE 150 APT DT SWISS F535 ONE 150 APT DT SWISS F535 ONE 150 APT
1.5 TAPERED LINEAIR / COILPAIR / INCONTROL / PLUSHPORT LINEAIR / COILPAIR / INCONTROL / PLUSHPORT LINEAIR / COILPAIR / INCONTROL / PLUSHPORT
HANDLEBARS (S/M/L/XL) B35 AL7075 (15-740/740/780/780) B35 AL7075 (15-740/740/780/780) B35 AL7075 (15-740/740/780/780)
STEM (S/M/L/XL) S35 AL6061 / ML READY (50/50/70/70) S35 AL6061 / ML READY (50/50/70/70) S35 AL6061 / ML READY (50/50/70/70)
DISPLAY MARQUARDT 4311 / CONNECT C MARQUARDT 4311 / CONNECT C MARQUARDT 4311 / CONNECT C READY
SEAT POST 8PINS PIN LOCK CRANKBROTHERS HIGHLINE 20 P35
Ø34.9 OFFSET 34.9x125(S)/150(M/L/XL) TRAVEL 34.9x350(S)/400(M/L/XL)
SADDLE ERGON SM COMP ERGON SM COMP ERGON SM COMP
HANDLEBAR GRIPS ERGON GD10 SLIM FACTORY FROZEN ERGON GD10 SLIM FACTORY FROZEN ERGON GD10 SLIM FACTORY FROZEN
DRIVE TRAIN BROSE DRIVE S MAG AIR COOLER BROSE DRIVE S MAG AIR COOLER BROSE DRIVE S MAG AIR COOLER
BATTERY IPU750 REMOVABLE IPU750 REMOVABLE IPU750 REMOVABLE
4.5A CHARGER 4.5A CHARGER 4.5A CHARGER
CRANK E13 PLUS 165(S/M)/170(L/XL), E13 DM 36T E13 PLUS 165(S/M)/170(L/XL), E13 DM 36T E13 PLUS 165(S/M)/170(L/XL), E13 DM 36T
CHAIN GUIDE ROTWILD SL750 ROTWILD SL750 ROTWILD SL750
SHIFTING LEVERSHIMANO XTR I-SPEC EV SHIMANO XT I-SPEC EV SHIMANO XT
REAR DERAILLEUR SHIMANO XTR 9100 SGS STANDARD PLUS SHIMANO XT 8100 SGS STANDARD PLUS SHIMANO XT 8100 SGS STANDARD PLUS
CHAIN SHIMANO HG 7100 12-SPEED SHIMANO HG 7100 12-SPEED SHIMANO HG 7100 12-SPEED
CASSETTE SHIMANO CS 8100 10-51T. 12-SPEED SHIMANO CS 7100 10-51T. 12-SPEED SHIMANO CS 7100 10-51T. 12-SPEED
BRAKES SHIMANO XTR 9120 FIN PAD SHIMANO XT 8120/8100 FIN PAD SHIMANO 520/500
DISC ROTOR SHIMANO RT800 SENSOR ICE 203/203 SHIMANO RT800 SENSOR ICE 203/203 SHIMANO RT64/600 SENSOR 203/203
WHEELS DT SWISS HX1501 SPLINE ONE (30) DT SWISS H1900 SPLINE (30) DT SWISS H1900 SPLINE (30)
110-15/148-12 TAS CL 110-15/148-12 TAS CL 110-15/148-12 TAS CL
TYRES CONTINENTAL TRAIL KING PROTECTION 29x2.40 CONTINENTAL TRAIL KING PROTECTION 29x2.40 CONTINENTAL TRAIL KING PERFORMANCE 29x2.40
COLOUR BLACK COOL GREY COOL GREY

21
R.X750 HT (type RX750HT20)
EQUIPMENT PRO
HEADSET ACROS RW750 1.5 HEADSET W/ BLOCK LOCK
FORK FOX 36 FLOAT 120 3-POS GRIP
1.5 TAPERED PERFORMANCE E-BIKE+
HANDLEBARS (S/M/L/XL) B35 AL7075 (15-780)
STEM (S/M/L/XL) S35 AL6061 / ML READY (50/50/50/70)
DISPLAY BLOKS 14D / CONNECT C
SEAT POST 8PINS
Ø34.9 OFFSET
SADDLE ERGON SM-E MOUNTAIN SPORT
HANDLEBAR GRIPS ERGON GD10 SLIM FACTORY FROZEN
DRIVE TRAIN BROSE DRIVE S MAG AIR COOLER
BATTERY IPU750 REMOVABLE
4.5A CHARGER
CRANK E13 PLUS 160(S)/165(M/L)/170(XL), E13 DM 36T
CHAIN GUIDEROTWILD SL750
SHIFTING LEVER SHIMANO XT I-SPEC EV
REAR DERAILLEUR SHIMANO XT 8100 SGS STANDARD PLUS
CHAIN SHIMANO HG 7100 12-SPEED
CASSETTE SHIMANO CS 7100 10-51T. 12-SPEED
BRAKES SHIMANO XT 8120 FIN PAD
DISC ROTOR SHIMANO RT800 SENSOR ICE 203/203
WHEELS DT SWISS HX1501 SPLINE ONE (30) 110-15/148-12 TAS CL
TYRES CONTINENTAL BARON PROJEKT PROTECTION 29x2.40 / 27.5x2.60
COLOUR RED
