Ruby Tech GS-5116C User manual

GS-5116C:
16-Port Unmanaged Gigabit Ethernet Switch
Key FeaturesKey Features
16-Port 10/100/1000 Mbps GbE Switch
Provides two Gigabit Ethernet Modules
options: 1000Mbps RJ-45/1000Mbps
Fiber SFP (single-mode/multi-mode) for
remote uplink
Conforms to IEEE 802.3 10BASE-T,
IEEE802.3u 100BASE-TX, IEEE
802.3ab 1000BASE-T and IEEE 802.3x
flow control standards
Supports 10/100Mbps auto-detect half/
full duplex and 1000Mbps at full duplex
Supports TP interface auto MDI/MDI-X
function for auto TX/RX swap
Supports 802.3x flow control pause
packet for full duplex
LEDs to indicate: 10/100/1000Mbps,
Link/Act. and Power Status
Slim & Compact design
RoHS Compliance
Overview
GS-5116C is a cost-effective switch that
meets all IEEE 802.3/u/x/z Gigabit, Fast
Ethernet specifications. With 32 Gbps
switch fabric, the switch improves your
network performance. You can connect to
backbone or make Gigabit to the PC to
perform high speed transfer. The switch
has a 8K MAC Address Table and provides
a 272K on-chip buffer. It is suitable for
workgroups or WAN edge application. The
versatile and compact 1RU height design
of the GS-5116C enables the device to be
rackmounted in a standard 19 inch rack,
while conserving valuable rack space.
Easy Installation and Configuration
GS-5116C conforms to plug and play for
easy installation and use. With diagnostic
LEDs, network and port status can be
easily monitoring and trouble-shooting.
GS-5116C also build in wiring crossover on
all ports allows connection to server or PC
without worrying about cabling.
GS-5116C
RUB
TECHTECH
Unmanaged Switch
Technical SpecificationsTechnical Specifications
Standard compliance:
IEEE 802.3 10Base-T Ethernet(twisted-pair copper)
IEEE 802.3u 100Base-TX Ethernet(twisted-pair copper)
IEEE 802.3ab 1000Base-T Ethernet(twisted-pair copper)
IEEE 802.3Z 1000Base-T Ethernet(Gigabit Fiber)
ANSI/IEEE 802.3 Auto-negotiation
MAC Address: 8K
Network Interface: 16 10/100/1000Mbps RJ-45 ports
Flow control:
IEEE802.3x compliant for full-duplex
Back pressure flow control for half-duplex
Media :
10BASE-T: UTP Cat. 3, 4, 5 or up
100BASE-TX: UTP Cat. 5 or up
1000BASE-T: UTP Cat. 5 or up
Transmission Mode: 10/100Mbps, full/half-duplex (Auto-sensing)
Transfer Rate:
10Mbps: 14880pps (64 Bytes Package)
100Mbps: 148800pps (64 Bytes Package)
1000Mbps: 1488000pps (64 Bytes Package)
Buffer Memory: 272KB on chip frame buffer
Switching Method: Store & forward
LED Description
LED Color Function
Global POWER Green Lit when +5Vpower is comingup
Global CPU/ Green Blinks when CPUis activity
ACT
Port LINK/ Green Lit when connectionwith remote device
1-16 ACT is good
Blinks when anytraffic is present
Port 1000/ Green/ Lit Green whenTP link on 1000Mbps
1-16 100Mbps Amber speed
Lit Amberwhen TP link on 100Mbps
speed
Off when 10Mbps or nolink occur
Gigabit Switch
Gigabit Switch

RUB
TECHTECH
Unmanaged Switch
Hardware Spec.
Packing InformationPacking Information
Ordering InformationOrdering Information
Weight 3kg
Feature Detailed Description
Voltage 100~240 V
Frequency 50~60 Hz
Consumption 30W
Ambient Temperature 0 to 40 C
Humidity 5% to 90%
Dimensions 44(H) x 442(W)x 209(D) mm
Safety UL
Comply with FCCPart 15 ClassA& CE MarkApproval
Gigabit Switch
Gigabit Switch
Carton Dimensions (mm) pcs/Carton N.W (KG) G.W (KG)
530x512x345 5 20 21
Note:
We recommend the SFP transceiver from the following vendors:
1. Ruby Tech Corporation
2. Agilient Technologies
3. AVAGO Technologies
4. Finisar Corporation
Ruby Tech Corp.
3F, No.1, Lane 50, Nan Kang Road, Sec.3, Taipei, Taiwan http://www.rubytech.com.tw
TEL:[phone] FAX:[phone] E-mail [email protected]
2008-07.25 Version A
Technicalinformation listed issubject to changewithout prior notice. All brand names and trademarks are property of their respective owners.
Copyright c 2008 Ruby Tech Corp. All rights reserved.
GS-5116C 16-Port Unmanaged Gigabit Ethernet Switch with 2 SFP Dual Media Port
Optional SFP Module
SFP.LC 1000Base-SX GE SFPFiber Module, LC Multi-Mode 850nm
SFP.LC.M2 1000Base-SX GE SFPFiber Module, LC Multi-Mode 1310nm 2km
