Ruckus Wireless ZF7761CM User manual

Ruckus Wireless™
ZoneFlex™7761CM Dual Band 802.11n
Outdoor Access Point
with Integrated Cable Modem
Installation Guide
Part Number 800-70290-001
Published March 2010
www.ruckuswireless.com

i
1About This Installation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Using ZoneDirector to Manage the CMAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Terms Used in This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2Unpacking the CMAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3Preparing for Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Preconfiguring the Access Point (Standalone Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Step 1: Prepare the Administrative Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 2: Supply Power to the CMAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Step 3: Log Into the Access Point’s Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Step 4: Configure the Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Step 5: Disconnect the CMAP from the Administrative Computer . . . . . . . . . . . . . . 14
Step 6: Restore the Administrative Computer’s Network Settings . . . . . . . . . . . . . . 14
Pointing the CMAP to ZoneDirector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Use SSH to Set the ZoneDirector IP Address on the CMAP . . . . . . . . . . . . . . . . . . . . 15
Configure Option 43 on the DHCP Server (ZoneDirector Management Only) . . . . . 16
4Hardware Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Weight and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Ethernet/PoE-Out Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Supported Power Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Heaters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Prepare the Required Hardware and Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Perform a Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Contents

ii
6Powering the CMAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using DC Power (Staging or Debugging Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Using Power Over Cable (Actual Deployment) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7Verifying Access Point Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8Switching LEDs to Cable Modem Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Using the AP’s Web Interface to Switch to CM Mode . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using SNMP to Switch to CM Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9Resetting the Access Point to Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Using the Reset Switch on the DC Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Using SNMP to Reset the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
10 Resetting the CM to Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
11 Mounting the CMAP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
12 Installing the Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
13 What to Do Next. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Change the Administrative Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Read Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
14 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Retrieving the CM’s MAC Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
How Radio Frequency Scanning Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Contacting Ruckus Wireless Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

1
1About This Installation Guide
This Installation Guide provides information on how to set up the Cable Modem Access
Point (CMAP) on your network. Topics covered in this guide include installation, basic
configuration, operation, and device mounting.
This guide is intended for use by those responsible for installing and setting up network
equipment. Consequently, it assumes a basic working knowledge of local area networking,
cable modem setup and configuration, wireless networking, and wireless devices.
NOTE: The cable modem and access point each have its own independent firmware load
that are updated independently.
Related Documentation
In addition to this guide, each Cable Modem Access Point documentation set includes
the following:
■User Guide: Provides detailed information on how to configure the functions of the
unit. The User Guide is available for download on the Ruckus Wireless Support Web
site at:
http://support.ruckuswireless.com/documents
■Release Notes: Provides late-breaking information about the current software release,
including new features, enhancements, and known issues. If the information in the
Release Notes differs from the information in this guide, follow the instructions in the
Release Notes.
■Online Help: Accessible from the CMAP’s Web interface, the Online Help provides
information that helps you configure the device from the Web interface.
Using ZoneDirector to Manage the CMAP
If you are planning to use a Ruckus Wireless ZoneDirector to manage the CMAP, this guide
describes the required steps that will enable the access point to report to and
communicate with ZoneDirector successfully. Refer to “Configure Option 43 on the DHCP
Server (ZoneDirector Management Only)” on page 16.
Terms Used in This Guide
Before continuing, Ruckus Wireless recommends that you become familiar with the
following terms:
■Access Point (AP): The Wi-Fi component of the Cable Modem Access Point (CMAP).

2
Unpacking the CMAP
Package Contents
■Cable Modem (or CM): The cable modem component of the Cable Modem Access
Point (CMAP).
■Cable Modem Access Point (or ZF7761CM): The whole unit, which includes the CM
and AP, as well as the power supply.
2Unpacking the CMAP
1. Open the CMAP package, and then carefully remove the contents.
2. Return all packing materials to the shipping box, and put the box away in a dry location.
3. Verify that all items listed in Package Contents below are included in the package.
Check each item for damage. If any item is damaged or missing, notify your authorized
Ruckus Wireless sales representative.
Package Contents
A complete ZoneFlex 7761CM package contains all of the items listed below:
■ZoneFlex 7761CM unit
■Three N-type 5GHz external antennas
■Service Level Agreement / Limited Warranty Statement
■Regulatory Statement
■This Installation Guide
NOTE: The CMAP comes preinstalled with the cable strand interface, which you will use
to mount the assembly onto the cable strand. You only need to attach the three external
antennas to the cable strand interface (after mounting the CMAP on the strand) to
complete the assembly. See “Installing the Antennas” on page 45 for more information.

3
Unpacking the CMAP
Package Contents
Figure 1. The CMAP comes preassembled with the cable strand interface
Cable Strand
Interface
Access Point

4
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
3Preparing for Installation
This section describes the tasks that you need to perform before proceeding with the
installation. The required tasks depend on whether you are deploying the access point as
a standalone device or as a ZoneDirector-managed device.
■Preconfiguring the Access Point (Standalone Only)
■Configure Option 43 on the DHCP Server (ZoneDirector Management Only)
NOTE: A standalone access point refers to a device that is not managed by Ruckus
Wireless ZoneDirector or Ruckus Wireless FlexMaster.
Preconfiguring the Access Point (Standalone Only)
If you are deploying the access point as a standalone device, Ruckus Wireless strongly
recommends that you preconfigure (or “stage”) the unit before mounting it. It is more
convenient to connect the administrative computer to the access point and configure the
device in the lab than when the device is already mounted on the cable strand.
Preconfiguring the access point requires the following tasks to be completed:
■Step 1: Prepare the Administrative Computer
■Step 2: Supply Power to the CMAP
■Step 3: Log Into the Access Point’s Web Interface
■Step 4: Configure the Wireless Settings
■Step 5: Disconnect the CMAP from the Administrative Computer
■Step 6: Restore the Administrative Computer’s Network Settings
Before starting, prepare the following requirements:
■DC power supply (see DC Power Supply in “Connectors” on page 31)
■One Ethernet cable
■An administrative computer (any computer running Windows that you will use to
preconfigure the access point)

5
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
Step 1: Prepare the Administrative Computer
NOTE: The following procedures are applicable if the administrative computer is running
on Windows XP. If you are using a different operating system, refer to the documentation
that was shipped with your operating system for information on how to modify the
computer’s IP address settings.
On Microsoft Windows 7
1. Click the orb, and then click Control Panel.
2. Double-click Network and Sharing Center.
3. On the left menu, click Change Adapter Settings. The Network Connections page
appears and displays the available network interfaces on the computer.
4. Look for the network connection icon labeled Local Area Connection.
5. Right-click Local Area Connection, and then click Properties. The Local Connection
Properties dialog box appears.
6. Under This connection uses the following items, look for Internet Protocol Version 4
(TCP/IPv4), and then double-click the item. The Internet Protocol Version 4 (TCP/IPv4)
Properties dialog box appears.
7. Write down all of the currently active network settings. You will need this information
later when you restore your computer to its current network configuration.
8. On the General tab, Click Use the following IP address, and then configure the IP
address settings with the values listed in Table 2 . For a sample configuration, refer to
Figure 3.
9. Click OK to save your changes and close the Internet Protocol Version 4 (TCP/IPv4)
Properties dialog box.
10. Click OK again to close the Local Area Connection Properties dialog box.
Windows saves the IP address settings that you configured.
Table 1. Configure your computer’s IP address settings
IP address 192.168.100.77 (or any address in the
192.168.100.x network — with the exception of
192.168.100.2, which is already used by the access
point)
Subnet mask 255.255.255.0

6
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
Figure 2. Sample configuration in the Internet Protocol Version 4 (TCP/IPv4)
Properties dialog box
On Microsoft Windows XP
1. Click Start > Control Panel > Network Connections.
2. When the Network Connections window appears, right-click the icon for Local Area
Connection, and then click Properties.
NOTE: Make sure that you configure the Local Area Connection properties, not the
Wireless Network Connection properties.
3. When the Local Area Connection Properties dialog box appears, select Internet
Protocol (TCP/IP) from the list, and then click Properties. The Internet Protocol (TCP/
IP) Properties dialog box appears.
4. Write down all of the currently active network settings. You will need this information
later when you restore your computer to its current network configuration.

7
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
5. Click Use the following IP address, and then configure the IP address settings with
the values listed in Tab le 2. For a sample configuration, refer to Figure 3.
6. Click OK to save your changes and close the Internet Protocol (TCP/IP) Properties
dialog box.
7. Click OK again to close the Local Area Connection Properties dialog box.
Windows saves the IP address settings that you configured.
Figure 3. Sample configuration in the Internet Protocol (TCP/IP) Properties dialog box
Table 2. Configure your computer’s IP address settings
IP address 192.168.100.77 (or any address in the
192.168.100.x network — with the exception of
192.168.100.2, which is already used by the access
point)
Subnet mask 255.255.255.0

8
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
Step 2: Supply Power to the CMAP
In this step, you will connect the CMAP to the administrative computer, and then you will
power it on using 12 VDC power.
NOTE: Before starting this procedure, you must have already obtained a DC power
supply, such as 705-60224-002 shown in Figure 4.
To supply DC power to the CMAP
1. Connect one end of an Ethernet cable to the Ethernet port (labeled PoE OUT) on the
CMAP, and then connect the other end to the administrative computer’s Ethernet port.
2. Remove the protective cap from the DC connector on the CMAP.
3. Connect the DC adapter (labeled 2 in Figure 4) to the DC connector on the CMAP.
Figure 4. DC switching adapter
Tabl e 3 identifies the numbered components in Figure 4.
Table 3. DC switching adapter components
Number Description
1Power Supply: 100 to 240 VAC input. Connects with a standard IEC
C13 style power cord.

9
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
Step 3: Log Into the Access Point’s Web Interface
1. On the administrative computer, open a Web browser window.
2. In the address or location bar, type the following address:
https://192.168.100.2
3. Press <Enter> on the keyboard to connect to the access point’s Web interface. A
security alert message appears.
4. Click Yes or OK (depending on the browser) to continue. The access point’s login page
appears.
Figure 5. The ZoneFlex Access Point login page
5. In User name, type super.
6. In Password, type sp-admin.
7. Click Log In. The Web interface appears, displaying the Device page.
8. Continue to “Step 4: Configure the Wireless Settings” below.
2 Connector for the 12VDC connector on the CMAP
3 Reset switch
Table 3. DC switching adapter components
Number Description

10
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
Step 4: Configure the Wireless Settings
To complete this step, you will need to configure the settings on the Common tab and at
least one Wireless # tab. These are the essential wireless settings that will enable wireless
devices on the network to associate with the access point.
NOTE: ZoneFlex 7762 has one 2.4GHz radio and one 5GHz radio. The wireless settings
for each radio need to be configured separately on the Web interface (except for the
country code setting, see note in Ta bl e 4). To configure the 2.4GHz radio settings, click
Configuration > Radio 2.4G. To configure the 5GHz radio settings, click Configuration
>Radio 5G.
For your reference, the default wireless settings on the access point are listed in Tabl e 4.
Configure Common Wireless Settings
1. On the left menu of the Web interface, click Configuration > Radio {2.5/5} G. The
Common page appears.
2. Verify that the common wireless settings are configured as listed in Table 8.
Table 4. Default wireless settings
Setting Default Value
SSID (network name) Wireless 1 to Wireless 8 (8 WLANs)
Encryption (security) Disabled on all WLANs
Default management IP address 192.168.100.2
Table 5. Common wireless configuration
Setting Recommended Value
Wireless Mode Auto-select
Channel SmartSelect
Channel Width 20MHz or 40MHz

11
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
3. If you made any changes to the Common tab that you want to save, click Update
Settings.
4. Continue to “Step 4: Configure the Wireless Settings” below.
Figure 6. The Configuration > Radio 2.4 > Common tab
Configure Wireless # Settings
1. Click one of the Wireless # tabs.
2. In Wireless Availability, click Enabled.
3. In Broadcast SSID, click Enabled.
Country Code • If you purchased the access point in the United States,
this value is fixed to United States at the factory and is
not user-configurable.
• If you purchased the access point outside of the United
States, verify that the value is set to your country or
region. Selecting the correct country code ensures that
the access point uses only the radio channels allowed in
your country or region.
NOTE: The two radios on ZoneFlex 7762 Access Point are
always configured with the same country code setting. If
you change the country code for Radio 2.4G, for example,
the same change will be automatically applied to Radio 5G.
Table 5. Common wireless configuration
Setting Recommended Value

12
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
4. Clear the SSID box, and then type a unique and descriptive name that you want to call
this wireless network.
For example, you can type Ruckus Wireless AP. This SSID is the name that will
help users identify this wireless network in their wireless network connection
application.
NOTE: You may also configure other wireless settings on this and other Wireless # tabs
(in addition to the settings described above), although it is not necessary for completing
the access point installation.
5. Click Update Settings.
You have completed configuring the basic wireless settings of the access point.
Figure 7. The Configuration > Radio 2.4 > Wireless 1 tab

13
Preparing for Installation
Preconfiguring the Access Point (Standalone Only)
Figure 8. Type the FlexMaster server URL

14
Preparing for Installation
Pointing the CMAP to ZoneDirector
Step 5: Disconnect the CMAP from the Administrative
Computer
1. Disconnect the CMAP from the DC power source.
2. Verify that all LEDs are off.
3. Disconnect the Ethernet cable from the administrative computer’s Ethernet port.
Step 6: Restore the Administrative Computer’s Network
Settings
1. On your Windows XP or Windows 2000 computer, open the Network Connections (or
Network and Dial-up Connections) control panel according to how the Start menu is
set up:
• On Windows XP, click Start > Control Panel > Network Connections.
• On Windows 2000, click Start > Settings > Network Connections.
2. When the Network Connections window appears, right-click the icon for Local Area
Connection, and then click Properties.
3. When the Local Area Connection Properties dialog box appears, select Internet
Protocol (TCP/IP) from the scrolling list, and then click Properties. The TCP/IP
Properties dialog box appears.
4. Restore the computer’s network settings by typing the original IP address settings in
the TCP/IP Properties dialog box.
5. On the TCP/IP Properties dialog box, click OK to close it.
6. Click OK again to close the Local Area Connection Properties dialog box.
You are now ready to connect the CMAP to your network.
Pointing the CMAP to ZoneDirector
If you are deploying the access point to be managed by ZoneDirector, you must ensure
that the CMAP can report to its parent ZoneDirector device on the network. There are two
ways you can do this:
■Use SSH to Set the ZoneDirector IP Address on the CMAP
■Configure Option 43 on the DHCP Server (ZoneDirector Management Only)

15
Preparing for Installation
Pointing the CMAP to ZoneDirector
Use SSH to Set the ZoneDirector IP Address on the CMAP
You can use SSH to set the IP address of the ZoneDirector device that you want to use to
manage the CMAP. Before starting this procedure, you must obtain the IP address of the
ZoneDirector device to which you want to assign the CMAP.
To perform this procedure, you will need the following:
■An administrative computer
■An Ethernet cable
■A Telnet or SSH (secure shell) client program
To set the ZoneDirector IP Address on the CMAP via SSH
1. Connect one end of the Ethernet cable to the administrative computer’s Ethernet port,
and then connect the other end to the CMAP’s Ethernet port.
2. Change the administrative computer’s IP address to the same subnet as the CMAP.
The AP’s default IP address is 192.168.100.2.
3. Start the Telnet or SSH client program on the administrative computer.
4. Log onto to the AP via Telnet or SSH using the following logon details:
•Username:super
•Password:sp-admin
5. When command prompt appears, enter the following command:
set director ip {ip-address}
where {ip-address} is the IP address of the ZoneDirector to which you want to
assign the CMAP.
The following message appears, which indicates that you have assigned the
ZoneDirector IP address:
Please reboot for this change to take effect.
6. Reboot the CMAP.
7. Log onto the command prompt again, and then enter the following command:
get director info
The command prompt displays the IP address of the ZoneDirector device that is
managing the CMAP.
8. Verify that this IP address is the same IP address that you set in Step 5.
You have completed the setting the ZoneDirector IP address via SSH.

16
Preparing for Installation
Pointing the CMAP to ZoneDirector
Configure Option 43 on the DHCP Server (ZoneDirector
Management Only)
You can configure the DHCP server on your CMTS backbone to ensure that the CMAP will
successfully discover its parent ZoneDirector on the network.
To customize your DHCP server, you need to configure DHCP Option 43 (043 Vendor
Specific Info) with the IP address of the ZoneDirector device on the network. When an
access point requests an IP address, the DHCP server will send a list of ZoneDirector IP
addresses to the access point. If there are multiple ZoneDirector devices on the network,
the access point will automatically select a ZoneDirector to register with from this list of IP
addresses.
NOTE: The following procedure describes how to customize a DHCP server running on
Microsoft Windows. If your DHCP server is running on a different operating system, the
procedure may be different.
The procedure for configuring Option 43 on your DHCP server depends on whether both
ZoneDirector and FlexMaster exist on the network, and whether you want to add the DHCP
subcode for ZoneDirector.
If Only ZoneDirector Exists on the Network (No ZoneDirector Subcode)
1. From Control Panel > Windows Administrative Tools, open DHCP, and then select the
DHCP server you want to configure.
2. If the Scope folder is collapsed, click the plus (+) sign to expand it.
3. Right-click Scope Options, and then click Configure Options. The General tab of the
Scope Options dialog box appears.
4. Under Available Options, look for the 43 Vendor Specific Info check box, and then
select it.
5. Under Data Entry, position the cursor in the ASCII text area, and then type the IP
address of the ZoneDirector device. In the figure below, the IP address of the
ZoneDirector device is 192.168.100.2.
