Hardware Installation and Reference Guide Product Overview
1
1 Product Overview
The RG-S5750-E series switches are the next generation Layer 3 switches introduced by Ruijie Networks. Featuring high
performance, reliable security, and multiple services, the RG-S5750-E series switches are mainly applicable to the
convergence layer of large-scale networks to provide full wire-speed exchanging and complete QoS services, classify
different services according to different business needs and ensure the prompt transmission of key data. The
RG-S5750-E series switches can provide various medium interfaces to meet the requirement for interfaces in network
constructions.
RG-S5750-E series switches
Model
10/100/1000Base-T
adaptive Ethernet
port
1000Base-X
SFP port
Console
Port
USB
Port
Extension
Module
Slot
Redundant
Power
Supply
RG-S5750-24GT/8SFP-E
V1.XX
24
8 (Combo)
1
0
2
RPS
RG-S5750-48GT/4SFP-E
V1.XX
48
4 (Combo)
1
0
2
RPS
RG-S5750-24GT/8SFP-E
V2.XX
24
8 (Combo)
1
1
2
RPS
RG-S5750-48GT/4SFP-E
V2.XX
48
4 (Combo)
1
1
2
RPS
RG-S5750-24GT/8SFP-P
24 (PoE+
supported)
8 (Combo)
1
0
2
Dual power
supplies
RG-S5750-48GT/4SFP-P
48 (PoE+
supported)
4 (Combo)
1
0
2
Dual power
supplies
RG-S5750-24SFP/8GT-E
8(Combo)
24
1
1
2
Dual power
supplies
1.1 RG-S5750-24GT/8SFP-E
Technical Specifications
Model
RG-S5750-24GT/8SFP-E
Optical Module
Type
Ethernet 100M:
FE-SFP-LX-MM1310
FE-SFP-LH15-SM1310
FE-SFP-LX20-SM1310-BIDI
FE-SFP-LX20-SM1550-BIDI
FE-SFP-LH40-SM1310-BIDI
FE-SFP-LH40-SM1550-BIDI

Hardware Installation and Reference Guide Product Overview
2
Ethernet 1000M:
MINI-GBIC-SX
MINI-GBIC-LX
MINI-GBIC-LH40
MINI-GBIC-ZX50
MINI-GBIC-ZX80
MINI-GBIC-ZX100
GE-SFP-LX20-SM1310-BIDI
GE-SFP-LX20-SM1550-BIDI
GE-SFP-LH40-SM1310-BIDI
GE-SFP-LH40-SM1550-BIDI
1000Base-T:
Mini-GBIC-GT
The supported module type may change at any time. For the detailed change information,
consult the Ruijie Networks.
BIDI optic module must be used in pairs. For example, FE-SFP-LX20-SM1310-BIDI is
used at one end, then FE-SFP-LX20-SM1550-BIDI must be applied to the other end.
Please refer to Appendix B for BIDI optic module details.
Extended Module
Type
M5000E-02SFP/GT
M5000E-01XS
M5000E-02XS
SFP Port
100Base-X
1000Base-X
RPS Type
RG-RPS150
Power Supply
AC input:
Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264 V AC
Frequency: 50/60 Hz
Rated current: 2 A
HVDC input:
Voltage range: 192 V DC to 290 V DC
Current range: 0.5 A to 0.24 A
Input Leakage
Current
≤2.5mA
Max. Power
Consumption
60 W (with extension modules); 43 W (without extension modules)
Temperature
Working temperature: 0ºC to 50ºC
Storage temperature: -40ºC to 70ºC
Humidity
Working humidity: 10% to 90% RH
Storage humidity: 5% to 90% RH
Fan
Support adjustment of fan speed and warning of fan trouble.

Hardware Installation and Reference Guide Product Overview
3
Temperature
Warning
Support
EMC
GB9254/GB17625 CLASS A
Security
Compliance
GB4943/IEC60950/UL/CE
Dimensions (W x
D x H)
440 mm x 260 mm x 44 mm
Weight
4.9 kg (with extension modules) ; 3.9 kg (without extension modules)
RG-S5750-24GT/8SFP-E switch is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
Product Appearance
The front panel of the RG-S5750-24GT/8SFP-E Ethernet switch provides twenty four 10/100/1000Base-T Ethernet ports,
eight 1000M SFP fiber/copper combo ports, one Console port and one USB port. The back panel provides AC power input
ports, RPS input ports and two extension module slots.
Figure 1-1 Appearance of the RG-S5750-24GT/8SFP-E
Front Panel
Figure 1-2 RG-S5750-24GT/8SFP-E Front Panel
Note:
1. Switch status indicator
2. Extension module 1 status indicator
3. Extension module 2 status indicator
4. RPS status indicator
5. Console port
6. 10/100/1000Base-T adaptive Ethernet port
7. Port status indicator
8. 100/1000Base-X SFP port
9. USB port (supported only by V2.XX)

Hardware Installation and Reference Guide Product Overview
4
Back Panel
Figure 1-3 RG-S5750-24GT/8SFP-E Back Panel
Note:
1. Grounding pole
2. 3-core AC power port
3. Power defense shedding plug
4. RPS input port
5. Slot for extension module 1
6. slot for Extension module 2
Power Supply System
The RG-S5750-24GT/8SFP-E adopts the AC power input and RPS input.
AC input:
Rated voltage range: Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264V AC
Frequency: 50/60 Hz
Rated current: 2 A
Power cable: 10 A power cable
HVDC input:
Voltage range: 192 V DC to 290 V DC
Current range: 0.5 A to 0.24 A
RPS input:
The switch power can be supplied by the redundant power input or both the AC input and redundant power input.
When both the AC input and the redundant power input are available, the switch power is supplied by the AC power
input;
When the AC input is unavailable, the switch power supply switches to the redundant power input seamlessly.
At present, the redundant power supply interface can be used together with the RPS150 that are manufactured by
Ruijie Networks. Unless otherwise stated, other power supply modules cannot be used for power input; otherwise,
an abnormality may occur or damage the switch.
Heat Dissipation
The RG-S5750-24GT/8SFP-E is designed with left and right fans for heat dissipation purposes, thereby ensuring the
device's functioning in the specified environment. Sufficient space (10 cm distance from both sides and the backplane of
the cabinet) should be reserved to allow air circulation. Dust the device every three months to avoid blocking the
ventilation openings.
Figure 1-4 Flow Scheme of Heat Dissipation

Hardware Installation and Reference Guide Product Overview
5
LED Indicators
Indicator
Panel Identification
Status
Meaning
Status indicator
Status
Off
The switch is powered down.
Blinking green
The switch is being initialized. If the blinking
persists, however, it indicates that an
abnormality occurs.
Solid green
The switch is working properly.
Solid yellow
It indicates a warning on the switch temperature.
Check the working environment of the switch
immediately.
Solid red
Indicates a fault on the switch. For details, refer
to Section 5.2 Troubleshooting Common Faults.
Extension module
indicator
M1 / M2
Off
There is no extension module or the extension
module is not correctly installed.
Solid green
The extension module is correctly installed.
RPS status indicator
RPS
Off
The redundant power is not connected to a link.
Solid green
The redundant power is connected and can
supply power.
Solid yellow
The redundant power is supplying power.
Solid red
The redundant power is connected but cannot
supply power.
1000Mbps SFP port
indicator
21F-24F
Off
The port is link down.
Solid green
The 1000 M link that the port connects to is Up.
Blinking green
Data at a rate of 1000 M are being transceived at
the port.
Solid yellow
The 100 M link that the port connects to is Up.
Blinking yellow
Data at a rate of 100 M are being transceived at
the port.
1000Mbps RJ-45
1-24
Off
The port is link down.

Hardware Installation and Reference Guide Product Overview
6
Indicator
Panel Identification
Status
Meaning
port indicator
Solid green
The 1000 M link that the port connects to is Up.
Blinking green
Data at a rate of 1000 M are being transceived at
the port.
Solid yellow
The 100 or 10 M link that the port connects to is
Up.
Blinking yellow
Data at a rate of 100 or 10 M are being
transceived at the port.
1.2 RG-S5750-48GT/4SFP-E
Technical Specifications
Model
RG-S5750-48GT/4SFP-E
Optical Module
Type
Ethernet 100 MB:
FE-SFP-LX-MM1310
FE-SFP-LH15-SM1310
FE-SFP-LX20-SM1310-BIDI
FE-SFP-LX20-SM1550-BIDI
FE-SFP-LH40-SM1310-BIDI
FE-SFP-LH40-SM1550-BIDI
Ethernet 1000 MB:
MINI-GBIC-SX
MINI-GBIC-LX
MINI-GBIC-LH40
MINI-GBIC-ZX50
MINI-GBIC-ZX80
MINI-GBIC-ZX100
GE-SFP-LX20-SM1310-BIDI
GE-SFP-LX20-SM1550-BIDI
GE-SFP-LH40-SM1310-BIDI
GE-SFP-LH40-SM1550-BIDI
1000Base-T:
Mini-GBIC-GT
The supported module type may change at any time. For the detailed change information,
consult the Ruijie Networks.
BIDI optical module must be used in pairs. For example, FE-SFP-LX20-SM1310-BIDI is
used at one end, then FE-SFP-LX20-SM1550-BIDI must be applied to the other end.
Please refer to Appendix B for BIDI optic module details.
Extended Module
M5000E-02SFP/GT

Hardware Installation and Reference Guide Product Overview
7
Type
M5000E-01XS
M5000E-02XS
SFP Port
100Base-X
1000Base-X
RPS Type
RG-RPS150
Power Supply
AC input:
Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264 V AC
Frequency: 50/60 Hz
Rated current: 2 A
HVDC input:
Voltage range: 192 V DC to 290 V DC
Current range: 0.7 A to 0.5 A
Input Leakage
Current
≤3.5mA
Max. Power
Consumption
90 W (with extension modules); 72 W (without extension modules)
Temperature
Working temperature: 0ºC to 50ºC
Storage temperature: -40ºC to 70ºC
Humidity
Working humidity: 10% to 90% RH
Storage humidity: 5% to 90% RH
Fan
Support fan speed adjustment and the fault warning function
Temperature
Warning
Support
EMC
GB9254/GB17625 CLASS A
Security
Compliance
GB4943 /IEC60950/UL/CE
Dimensions (W x
D x H)
440 mm x 300 mm x 44 mm
Weight
5.4 kg (with extension modules); 4.4 kg (without extension modules)
RG-S5750-48GT/4SFP-E switch is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
Product Appearance
The front panel of the RG-S5750-48GT/4SFP-E Ethernet switch provides 48 10/100/1000Base-T Ethernet ports, four
1000M SFP fiber/copper combo ports, one Console port and one USB port. The back panel provides AC power input
ports, RPS input ports and two extension module slots.

Hardware Installation and Reference Guide Product Overview
8
Figure 1-5 Appearance of the RG-S5750-48GT/4SFP-E
Front Panel
Figure 1-6 Schematic Diagram of the RG-S5750-48GT/4SFP-E Front Panel
Note:
1. Switch status indicator
2. Extension port 1 status indicator
3. Extension port 2 status indicator
4. RPS status indicator
5. Console port
6. 10/100/1000Base-T adaptive Ethernet port
indicator
7. Port status indicator
8. 100/1000Base-X SFP port
9. USB port (supported only by V2.XX)
Back Panel
Figure 1-7 Schematic Diagram of the RG-S5750-48GT/4SFP-E Back Panel
Note:
1. Grounding pole
2. 3-core AC power port
3. Power defense shedding plug
4. RPS input port
5. Slot for extension module 1
6. Slot for extension module 2
Power Supply System
The RG-S5750-48GT/4SFP-E adopts the AC power input and redundant power input.
AC input:
Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264 V AC

Hardware Installation and Reference Guide Product Overview
9
Frequency: 50/60 Hz
Rated current: 2 A
Power cable: 10 A power cable
HVDC input:
Voltage range: 192 V DC to 290 V DC
Current range: 0.7 A to 0.5 A
RPS input:
The switch power can be supplied by the redundant power input or both the AC input and redundant power input.
When both the AC input and the redundant power input are available, the switch power is supplied by the AC power
input.
When the AC input is unavailable, the switch power supply switches to the redundant power input seamlessly.
At present, the redundant power supply interface can be used together with the RPS150 that are manufactured by
Ruijie Networks. Unless otherwise stated, other power supply modules cannot be used for power input; otherwise,
an abnormality may occur or damage the switch.
Heat Dissipation
The RG-S5750-48GT/4SFP-E adopts left and right fans for heat dissipation purposes, thereby ensuring the device's
functioning in the specified environment. Sufficient space (10 cm distance from both sides and the backplane of the
cabinet) should be reserved around the cabinet to allow air circulation. Dust the device every three months to avoid
blocking the ventilation openings.
Figure 1-8 Flow Scheme of Heat Dissipation
LED Indicators
Indicator
Panel Identification
Status
Meaning
Status indicator
Status
Off
The switch is powered down.

Hardware Installation and Reference Guide Product Overview
10
Indicator
Panel Identification
Status
Meaning
Blinking green
The switch is being initialized. If the blinking
persists, however, it indicates that an abnormality
occurs.
Solid green
The switch is working properly.
Solid yellow
It indicates a warning on the switch temperature.
Check the working environment of the switch
immediately.
Solid red
Indicates a fault on the switch. For details, refer
to Section 5.2 Troubleshooting Common Faults.
Extension module
indicator
M1 / M2
Off
There is no extension module or the extension
module is not correctly installed.
Solid green
The extension module is correctly installed.
RPS status indicator
RPS
Off
The redundant power is not connected to a link.
Solid green
The redundant power is connected and can
supply power.
Solid yellow
The redundant power is supplying power.
Solid red
The redundant power is connected but cannot
supply power.
1000Mbps SFP port
indicator
45F-48F
Off
The port is link down.
Solid green
The 1000 M link that the port connects to is Up.
Blinking green
Data at a rate of 1000 M are being transceived at
the port.
Solid yellow
The 100 M link that the port connects to is Up.
Blinking yellow
Data at a rate of 100 M are being transceived at
the port.
1000Mbps RJ-45
port indicator
1-48
Off
The port is link down.
Solid green
The 1000 M link that the port connects to is Up.
Blinking green
Data at a rate of 1000 M are being transceived at
the port.
Solid yellow
The 100 or 10 M link that the port connects to is
Up.
Blinking yellow
Data at a rate of 100 or 10 M are being
transceived at the port.
1.3 RG-S5750-24GT/8SFP-P
Technical Specifications
Model
RG-S5750-24GT/8SFP-P
Optical Module
Type
Ethernet 100 MB:
FE-SFP-LX-MM1310
FE-SFP-LH15-SM1310

Hardware Installation and Reference Guide Product Overview
11
FE-SFP-LX20-SM1310-BIDI
FE-SFP-LX20-SM1550-BIDI
FE-SFP-LH40-SM1310-BIDI
FE-SFP-LH40-SM1550-BIDI
Ethernet 1000 MB:
MINI-GBIC-SX
MINI-GBIC-LX
MINI-GBIC-LH40
MINI-GBIC-ZX50
MINI-GBIC-ZX80
MINI-GBIC-ZX100
GE-SFP-LX20-SM1310-BIDI
GE-SFP-LX20-SM1550-BIDI
GE-SFP-LH40-SM1310-BIDI
GE-SFP-LH40-SM1550-BIDI
1000Base-T :
Mini-GBIC-GT
The supported module type may change at any time. For the detailed change information,
consult the Ruijie Networks.
BIDI optical module must be used in pairs. For example, one port use
FE-SFP-LX20-SM1310-BIDI is used at one end, then FE-SFP-LX20-SM1550-BIDI must
be applied to the other end. Please refer to Appendix B for BIDI optic module details.
Extended Module
Type
M5000E-02SFP/GT
M5000E-01XS
M5000E-02XS
SFP Port
100Base-X
1000Base-X
RPS Type
Dual power supplies
Power Supply
AC input (M5000E-AC500P):
Rated voltage range: 100 V AC to 240 V AC
Frequency: 50/60 Hz
Rated current: 7 A to 3.5 A
HVDC input:
Voltage range: 192 V DC to 290 V DC
Current range: 3.5 A to 2.5 A
DC input (M5000E-DC500P):
Rated voltage range: -36 V DC to -72 V DC
Rated current: 16.5 A
Input Leakage
Current
≤3.5mA
PoE Function
All the RJ45 ports support the PoE function, and each port supports a maximum of 30 W PoE

Hardware Installation and Reference Guide Product Overview
12
power supply. The maximum power supported depends on the configured power supply.
Max. Power
Consumption
Without extension modules or PD load
50 W
Without extension modules but with 24-port PD
load
900 W
With extension modules but without PD load
65 W
With extension cards and 24-port PD load
915 W
Temperature
Working temperature: 0ºC to 50ºC
Storage temperature: -40ºC to 70ºC
Humidity
Working humidity: 10% to 90% RH
Storage humidity: 5% to 90% RH
Fan
Support fan speed adjustment and the fault warning function.
Temperature
Warning
Support
EMC
GB9254-1998
Security
Compliance
GB4943-2001
Dimensions (W x
D x H)
440 mm x 400 mm x 44 mm
Weight
With extension modules and power supplies 8.3 kg ;
Without extension modules or power supplies 7.3 kg
RG-S5750-24GT/8SFP-P switch is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
Product Appearance
The front panel of the RG-S5750-24GT/8SFP-P Ethernet switch provides 24 10/100/1000Base-T Ethernet ports, eight
1000M SFP fiber/copper combo ports and one Console port. The back panel provides two slots for the power supply, and
two slots for extension modules.
Figure 1-9 Appearance of the RG-S5750-24GT/8SFP-P

Hardware Installation and Reference Guide Product Overview
13
Front Panel
Figure 1-10 Schematic Diagram of the RG-S5750-24GT/8SFP-P Front Panel
Note:
1. PoE mode indicator
2. Switch status indicator
3. Extension module 1 status indicator
4. Extension module 2 status indicator
5. Button for switching the PoE mode
6. Console port
7. 10/100/1000Base-T adaptive Ethernet port
8. Port status indicator
9. 100/1000Base-X SFP port
Back Panel
Figure 1-11 Schematic Diagram of the RG-S5750-24GT/8SFP-P Back Panel
Note:
1. Slot for the power supply module 1
2. Slot for the power supply module 2
3. Slot for extension module 1
4. Slot for extension module 2
5. Grounding pole
Power Supply System
The RG-S5750-24GT/8SFP-P supports two power supplies, and supports AC and DC input. See the following table for
the detailed power specifications.

Hardware Installation and Reference Guide Product Overview
14
Table 1-8 Technical Specifications of RG-M5000E-AC500P
Model
RG-M5000E-AC500P (AC Input)
RG-M5000E-AC500P (HVDC Input)
Applicable Models
RG-S5750-24GT/8SFP-P
RG-S5750-48GT/4SFP-P
RG-S5750-24GT/8SFP-P
RG-S5750-48GT/4SFP-P
Rated Input Voltage
Range
100 V AC to 240 V AC, 50/60 Hz
240 V DC
Maximum Input
Voltage Range
90 V AC to 264 V AC, 50/60 Hz
192 V DC to 290 V DC
Power
500 W, of which 370 W for PoE. When dual power supplies are adopted, the power for PoE will
increase to 740 W.
Power Supply
Hot-Plug
Support
Power Supply
Redundancy
1+1 redundancy
Over-Voltage
Protection
54 V: -57 V to -60 V
12 V: 13.4 V to 16 V
Over-Current
Protection
54 V: 8A to 10 A
12 V: 12A to 16 A
Over-Heat
Protection
Support
Flow Equalization
Support
Mixed Power
Supply
Support RG-M5000E-DC500P
Power Cable
10 A power cable
Dimensions
195.4 mm x 90 mm x 40 mm (excluding connecting finger and handle)
224.5 mm x 90 mm x 40 mm (including connecting finger and handle)
Weight
1.6 kg
Table 1-9 Technical Specifications of RG-M5000E-DC500P
Model
RG-M5000E-DC500P
Applicable Models
RG-S5750-24GT/8SFP-P
RG-S5750-48GT/4SFP-P
Rated DC Input
Voltage Range
-32 VDC to -72 VDC
Power
500 W, of which 370 W for PoE. When dual power supplies are adopted, the power for PoE will
increase to 740 W.
Power Supply
Support

Hardware Installation and Reference Guide Product Overview
15
Hot-Plug
Power Supply
Redundancy
1+1 redundancy
Over-Voltage
Protection
54 V: -58 V to -66 V
12 V: 13.2 V to 15.6 V
Over-Current
Protection
54 V: 7.8 A to 10 A
12 V: 11 A to 14 A
Over-Heat
Protection
Support
Flow Equalization
Support
Mixed Power
Supply
Support RG-M5000E-AC500P
Power Cable
3m/12A DC power cable
Dimensions
195.4 mm x 90 mm x 43.2 mm (excluding connecting finger and handle)
224.5 mm x 90 mm x 43.2 mm (including connecting finger and handle)
Weight
1.6 kg
Dual power supplies mean that the switch can use either one power supply or two power supplies at the same time. When
the two power supply modules are adopted concurrently, the switch is powered by the equalizing current.
When the dual power supplies are used, the power supply redundancy does not work if the system consumption is
larger than the maximum consumption provided by single power supply. In this case, the system function is affected
when one of the power supplies fails.
RG-M5000E-DC500Pis used in the network equipment room, and can be operated by only professional engineers.
Heat Dissipation
The S5750-24GT/8SFP-P is designed with left and right fans, and backward heat dissipation of power supply, thereby
ensuring the device's functioning in the specified environment. Sufficient space (10 cm distance from both sides and the
backplane of the cabinet) should be reserved to allow air circulation. Dust the device every threemonths to avoid blocking
the ventilation openings.
Figure 1-12 Flow Scheme of Heat Dissipation

Hardware Installation and Reference Guide Product Overview
16
LED Indicators
Indicator
Panel Identification
Status
Meaning
PoE indicator
PoE
Solid green
Indicates the switching mode.
Solid yellow
Indicates the PoE working mode.
Status indicator
Status
Off
The switch is powered down.
Blinking green
The switch is being initialized. If the blinking
persists, however, it indicates that an
abnormality occurs.
Solid green
The switch is working properly.
Solid yellow
It indicates a warning on the switch temperature.
Check the working environment of the switch
immediately.
Solid red
Indicates a fault on the switch. For details, refer
to Section 5.2 Troubleshooting Common Faults.
Extension module
indicator
M1 / M2
Off
There is no extension module or the extension
module is not correctly installed.
Solid green
The extension module is correctly installed.
RJ45 port PoE
status indicator
1-24
Off
The port PoE is not powered on.
Solid green
The port PoE has the normal power supply.
Solid yellow
The port PoE overloads.
Solid red
The port PoE power supply is faulty.
1000Mbps SFP port
21F-24F
Off
The port is link down.

Hardware Installation and Reference Guide Product Overview
17
Indicator
Panel Identification
Status
Meaning
indicator
Solid green
The 1000 M link that the port connects to is Up.
Blinking green
Data at a rate of 1000 M are being transceived at
the port.
Solid yellow
The 100 M link that the port connects to is Up.
Blinking yellow
Data at a rate of 100 M are being transceived at
the port.
1000Mbps RJ-45
port indicator
1-24
Off
The port is link down.
Solid green
The 1000 M link that the port connects to is Up.
Blinking green
Data at a rate of 1000 M are being transceived at
the port.
Solid yellow
The 100 or 10 M link that the port connects to is
Up.
Blinking yellow
Data at a rate of 100/10M are being tranceived at
the port.
1.4 RG-S5750-48GT/4SFP-P
Model
RG-S5750-48GT/4SFP-P
