Russell Hobbs RHSM1001 User manual

Model Number: RHSM1001
Steam & Clean
Steam Mop
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
PLEASE RETAIN
FOR FUTURE REFERENCE

Page(s)
Safety instructions
3-6
Steam mop feature diagram
7
Steam
mop assembly 8-9
Filling the water tank
10
Using your
steam mop 11
Storing your steam
mop 12
Cleaning and care
13
Problem solving
14-15
Guarantee and customer services
16
Notes
17
Connection to the mains supply
18-19
Disposal information
20
CONTENTS
2
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
Thank you for purchasing your Russell Hobbs Steam & Clean Steam Mop.
To get the best from your new cleaner, take a few moments to read these
instructions, and keep them in a safe place for future reference.
Should you require any further assistance, our friendly Product Care team will
be happy to help.

3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to electrical parts.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•This product is intended for household use only.
Do not use outdoors.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
IF they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children unless they are older than 8 and
supervised. Keep the appliance and its’ cord out of reach
of children less than 8 years.
•Do not operate this appliance for anything other than its
intended use. This product is intended for household use
only. Do not use outdoors.
•Do not immerse in water or other liquids for cleaning.

4
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Do not direct steam at people, animals, electrical outlets,
or equipment containing electrical components.
•Unplug from power outlet when not in use. Do not leave
steam mop unattended while plugged in.
•Do not use with damaged cord or plug.
•Do not use steam mop if it has been dropped, damaged,
left outdoors or dropped into water.
•Keep the steam mop away from water; do not allow it to
get wet. If unit is wet, do not plug unit into wall socket or
turn unit on.
•Do not handle steam mop with wet hands.
•Do not pull or carry by cord, use cord as a handle, close
door on cord, pull cord around sharp corners or edges, or
expose cord to heated surfaces.
•Do not unplug by pulling on cord.
•To protect against electrical shock do not immerse cord,
plug, or appliance in water or other liquid.
•Unplug from the mains outlet when not in use, before
putting on and taking off parts, and before cleaning.

5
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•The use of accessory attachments not recommended by
the appliance manufacturer may cause fire, electric shock
or injury. Only use the accessories supplied by the
manufacturer.
•Do not let the cord hang over the edge of the worktop, or
touch hot surfaces.
•Never remove parts from the appliance such as the
screws and so on.
•The filling aperture must not be opened during use.
•Do not use appliance in an enclosed space filled with
vapor given off by oil-based paint, paint thinner, some
moth proofing substances, flammable dust, or other
explosive or toxic vapors.
•Do not use on leather, wax polished furniture or floors,
synthetic fabrics, velvet or other delicate, steam-sensitive
materials.
•Do not immerse unit in water or other liquids.
•Never put descaling, aromatic or alcoholic products into
the steam mop, as this may damage the unit. Descale the
product regularly with a mixture of 50% natural white
vinegar & 50% water to maintain its performance, and
allow the mixture to steam through the product.

Symbol IEC 60417-5597 (2002-10) is used on the unit to
indicate that this unit operates with hot water vapour
(steam). To avoid scalding and burns take extra care when in
use.
6
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Close attention is necessary when used near children.
•Do not store with a wet mop pad still attached.
•Using distilled or demineralized water will maximize the
performance of your steam mop.
•Use extra care when cleaning on stairs.
•Do not use steam for space heating purposes; household
use only.
•Use on waxed or some unwaxed floors may diminish
glossiness. Do not use on unsealed wood floors. Test in
an inconspicuous area or check the care instructions from
your flooring manufacturer.
•Quality testing during the manufacturing process may
result in water droplets remaining within the water tank.
•If you shake this product the water cut-off valve will make
a rattling noise. This is normal and is not a defect.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk

1
Power
cord
2
Power indicator
light
3
Power dial
4
Water tank and cap
5
Mop head
6
Handle top release button
7
Quick cord release and
hook
8
Handle tube
9
Handle assembly release
button
10
Measuring jug
11
Microfibre
mop pad
12
Carpet glider
7
STEAM MOP FEATURE DIAGRAM
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcare.co.uk
1
2
3
4
5
6 7
8
9
11 12
10

8
STEAM MOP ASSEMBLY
Before using your steam mop:
Remove all packaging and lay out the separate components.
Check the steam mop after unpacking for any visual damage such as:
•Misaligned or damaged parts
•Damage to the main body and separate components
•Damage to the plug or cable.
If you can see any damage do not use the steam mop and refer page 16.
Handle assembly
Note: Before assembling/disassembling any parts of the product make sure
the unit is unplugged and has cooled sufficiently.
The handle comes in 2 parts:
•Handle top
•Handle tube
1. Fit the handle top onto the handle tube, applying a small amount of
pressure until you hear it ‘click’ into place.
2. Once this is secure, put the assembly into the top of the main unit with
the cord hook parallel to the back of the unit. Push the tab on the base to
allow the handle to fully insert and secure. This should ‘click’ into place.
3. If you wish to remove the handle, simply push the release button on the
back of the unit and lift the assembly upwards. The release button on the
handle top allows you to disassemble the handle parts if required.
1 2 3

9
STEAM MOP ASSEMBLY
Microfibre mop pad attachment
The steam mop should never be operated
without the mop pad attached.
To attach the pad, place it on the floor with the
velcro facing upwards and removal lip to the
back. Lift the mop above the pad and align the
head with the mop pad. Lower the pad and rest
the mop on it to secure the velcro to the head.
To remove the pad, secure your foot on the
protruding piece of cloth and lift the mop away.
Carpet glider attachment
The mop can be used with the carpet glider
attachment to refresh carpets and rugs.
To attach the carpet glider, lift the mop over the
glider and lower the front of the mop head
under the two plastic ribs. Next, lower the back
end of the head. This should secure the head in
place.
To remove the glider, place your foot on the
protruding plastic and lift the mop upwards.

10
FILLING THE WATER TANK
Note: Before filling/re-filling the water tank, unplug the steam mop.
Do not touch any hot parts before allowing them to cool sufficiently.
1. Lay the steam mop horizontally.
2. Pull open the cap on the water tank.
3. Fill the provided measuring jug with water, being careful not to spill any
liquid.
Note: It is recommended to use treated water in your steam mop, especially in
hard water areas. Water can be treated using water filters. Using untreated
hard water can reduce the performance and life span of your product. Never
use boiled water in your steam appliance. This is harmful as the boiled water
that has not turned to steam contains solely the hard water minerals that
should be avoided.
4. Use the jug to fill the tank to the ‘MAX’ fill line.
5. Close the cap on the tank so that it is secure. Lift the mop upright.
A full tank should provide approximately 15 minutes steam time. The mop will
not steam if you do not turn on the power and wait sufficient time for the
water to heat.
