Russell Hobbs Steam & Clean Pro RHDSM2001 User manual

Model Number: RHDSM2001
Steam & Clean Pro
Detergent Steam Mop
For Customer Services & Spare Parts please call0345 2097461
Opening times: Monday -Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com
PLEASE RETAIN FOR FUTURE
REFERENCE

Page(s)
Safety instructions
3-5
Steam mop feature diagram
7
Steam
mop assembly 8
Using
your steam mop 9-12
Storing
your steam mop 13-14
Cleaning and care
15
Problem solving
16-18
Guarantee
and customer services 19
Spare parts
20
Connection to the mains supply
21-22
Disposal information
24
CONTENTS
2
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com
Thank you for purchasing your Russell Hobbs Steam & Clean Pro Detergent
Steam Mop.
With a three corner mop head for flexible cleaning and an ergonomic handle
for comfort, cleaning your floors has never been so easy.
What’s more, the detergent cleaning power breaks down dirt and stains
better than steam alone, killing 99.9% of household germs.
To get the best from your new cleaner, take a few moments to read these
instructions, and keep them in a safe place for future reference.
Should you require any further assistance, our friendly Product Care team will
be happy to help.

3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to electrical parts.
•If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
•This product is intended for household use only.
Do not use outdoors.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge
IF they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play
with the appliance. Cleaning and user maintenance shall
not be made by children unless they are older than 8 and
supervised. Keep the appliance and its’ cord out of reach
of children less than 8 years.
•Do not operate this appliance for anything other than its
intended use. This product is intended for household use
only. Do not use outdoors.
•Do not immerse in water or other liquids for cleaning.

4
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Do not direct steam at people, animals, electrical outlets,
or equipment containing electrical components.
•Unplug from power outlet when not in use. Do not leave
steam mop unattended while plugged in.
•Do not use with damaged cord or plug.
•Do not use steam mop if it has been dropped, damaged,
left outdoors or dropped into water.
•Keep the steam mop away from water; do not allow it to
get wet. If unit is wet, do not plug unit into wall socket or
turn unit on.
•Do not handle steam mop with wet hands.
•Do not pull or carry by cord, use cord as a handle, close
door on cord, pull cord around sharp corners or edges, or
expose cord to heated surfaces.
•Do not unplug by pulling on cord.
•To protect against electrical shock do not immerse cord,
plug, or appliance in water or other liquid.
•Unplug from the mains outlet when not in use, before
putting on and taking off parts, and before cleaning.
•Do not let the cord hang over the edge of the worktop, or
touch hot surfaces.

5
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•The use of accessory attachments not recommended by
the appliance manufacturer may cause fire, electric shock
or injury. Only use the accessories supplied by the
manufacturer.
•Never remove parts from the appliance such as the
screws and so on.
•The filling aperture must not be opened during use.
•Do not use appliance in an enclosed space filled with
vapor given off by oil-based paint, paint thinner, some
moth proofing substances, flammable dust, or other
explosive or toxic vapors.
•Do not use on leather, wax polished furniture or floors,
synthetic fabrics, velvet or other delicate, steam-sensitive
materials.
•Do not immerse unit in water or other liquids.
•Never put descaling, aromatic or alcoholic products into
the steam mop, as this may damage the unit. Descale the
product regularly with a mixture of 50% natural white
vinegar & 50% water to maintain its performance, and
allow the mixture to steam through the product.
•Close attention is necessary when used near children.

6
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
•Do not store with a wet mop pad still attached.
•Using distilled or demineralized water will maximize the
performance of your steam mop.
•Use extra care when cleaning on stairs.
•WARNING: Detergent MUST NOT be used on carpets.
•Do not use steam for space heating purposes; household
use only.
•Use on waxed or some unwaxed floors may diminish
glossiness. Do not use on unsealed wood floors. Test in
an inconspicuous area or check the care instructions from
your flooring manufacturer.
•Quality testing during the manufacturing process may
result in water droplets remaining within the water tank.
•If you shake this product the water cut-off valve will make
a rattling noise. This is normal and is not a defect.
Symbol IEC 60417-5597 (2002-10) is used on the unit to
indicate that this unit operates with hot water vapour
(steam). To avoid scalding and burns take extra care when in
use.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com

7
STEAM MOP FEATURE DIAGRAM
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com
1 Handle 10 Detergent tank dial
2 Steam/Detergent release trigger 11 Mop head
3 Upper power cord hook 12 Microfibre cleaning pad
4 Lower power cord hook 13 Carpet glider
5 Detergent tank 14 Filler cup
6 Water tank 15 Power cord
7 On/Off button 16 Detergent
8 Hard water filter 17 Cooling tray
9 Indicator lights

8
STEAM MOP ASSEMBLY
Before using your steam mop:
Remove all packaging and lay out the separate components.
Check the steam mop after unpacking for any visual damage such as:
•Misaligned or damaged parts
•Damage to the main body and separate components
•Damage to the plug or cable.
If you can see any damage do not use the steam mop and refer to page 19.
Slot the insert on the bottom of the steam
mops body into the housing on the back of
the mop head.
Check that the mop head is the correct way
round –refer to diagram.
IMPORTANT: Ensure the stud on the insert
protrudes through the slot on the mop
heads housing.
Slot the handle into the top of the body of
the steam mop.
You may need to push the stud on the
handle inwards to fully insert the handle.
IMPORTANT: Ensure the stud on the handle
protrudes through the hole in the housing
on top of the steam mop.

9
USING: FILLING THE WATER TANK
Grip the sides of the water tank and pull
upwards to remove.
Remove the cap on the top of water tank by
turning it anti-clockwise and lifting.
Fill the tank with 500ml of water using the
filler cup. Screw the cap back onto the tank by
placing in in the bottle and turning it
clockwise.
Note: When you turn the tank upside down,
some water may drip out of the cap. Ensure
the tank is turned upside down over a sink
before transporting it to the steam mop.
Slot the tank back onto the steam mop.
Push down on the tank until it locks in place.

10
USING: FILLING THE DETERGENT TANK
Grip the sides of the detergent tank on the
front of the steam mop and pull upwards to
remove.
Remove the cap on the top of the detergent
tank by turning it anti-clockwise and lifting.
Fill the tank, using the filler cup with 30ml of
detergent & 150ml of water. Screw the cap back onto
the tank by turning it clockwise.
Again, turn the tank upside down over a sink.
IMPORTANT: Only use recommended detergent solution. Detergent must be
diluted with water as per the above instructions. Always cover food preparation
areas and remove food from all surfaces. Do not clean surfaces that come into
direct contact with food.
Slot the detergent tank back onto the steam
mop. Push down on the tank until it locks in
place.

11
USING YOUR STEAM MOP
Fasten the microfibre cleaning pad on the base.
IMPORTANT: Never use the steam mop without
the microfibre cleaning pad fitted correctly.
Plug the steam mop into a mains socket and
turn the power on.
Press the ON/OFF button on the front of the
steam mop body in to switch the mop ON.
Press the button again to switch it OFF.
When the steam mop is turned on the power
light will illuminate.
A few seconds later the steam light will
illuminate, this shows that the steam mop is
ready to use.
IMPORTANT: Always ensure the detergent dial
is set to close when not in use.
If you wish to use the detergent, turn the
detergent tank dial to open to add detergent to
the steam.

12
USING YOUR STEAM MOP
To recline the handle, place your foot over the shoe
symbol on the side of the mop head and gently pull
the handle downwards.
Cleaning hard floors
Pull trigger on the handle (1) to release the steam.
Move the steam mop backwards and forwards
across the floor (2). For stubborn dirt or stains, focus
the steam mop over the area for a few seconds.
Note: Do not leave the steam mop over one area for
more than a few seconds. This can damage the floor.
Refreshing carpets
Pads can be used for both functions but must be
washed after using detergent on hard floors, before
cleaning carpets.
Place the mop head into the carpet glider (1).
Note: The mop head does not attach to the carpet
glider but just sits in it. Pull the trigger on the handle
(2) to release the steam.
WARNING: Do not use detergent on carpets.
Detergent can stain and damage carpets.
Move the steam mop backwards and forwards
across the carpet, again paying particular attention
to well trodden and frequently used areas.
When not using the mop, place it on the cooling
tray provided.

13
STORING YOUR STEAM MOP
Place the mop head on the cooling tray that has
been provided after every use.
When you have finished cleaning your floor,
switch the steam mop off by pressing the
ON/OFF button.
Switch the power off at the plug socket and
remove the plug.
Remove the water and detergent tanks as per
pages 9 and 10.
Unscrew the caps and pour any unused liquid
down the sink.
IMPORTANT:
Always wipe up any spilled detergent.
Never store the steam mop with liquid still in
the tanks.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com

14
STORING YOUR STEAM MOP
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com
Pull the microfibre cleaning pad from the base
of the mop head.
IMPORTANT: Never store the steam mop with
the pad fitted.
Wind the power cord around the top and
bottom cord grips on the handle. Slot the end
of the power cord into the grip on the top
power cord grip.
Note: The top power cord grip can be rotated
so the power cord cable can be easily removed
when needed.

15
CLEANING AND CARE
Before you clean the appliance, disconnect the mains plug from the wall
socket.
To clean the exterior of the device, use a damp, soft cloth and mild
detergent.
NEVER IMMERSE THE STEAM MOP IN WATER
When wiping off the main body, do not allow moisture in the area
around the on/off button or indicator lights.
Wash non-electrical accessories in warm soapy water and allow to dry
thoroughly before reuse.
If the steam mop is damaged, contact the customer service helpline.
Care of your microfibre cleaning pads
Wash pads in warm water, no more than 40 degrees.
Wash separately. Do not use fabric softener and do not tumble dry.
Dry on a line.
Should there be any loose threads on the microfibre pad, carefully
cut the threads with scissors.
Do not try to pull any threads or cut any threads at the base.
If you live in a hard water area, over time the filter will become
blocked and affect the performance of the steam mop.
Check and change the filter regularly to ensure your steam
mop works to its optimum level.
As the filter becomes more blocked the colour will darken and
discolour.
The filter should be changed every 6 months.
To change the filter, remove the water tank (1) on page 9.
Grip the water filter and pull upwards (2).
Slot the new water filter into the back of the steam mops
body.
Ensure the guides on the sides of the filter are correctly fitted.
New filters are available to purchase from Product Care,
call 0345 209 7461 or visit us at www.productcareuk.com

16
PROBLEM SOLVING
PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION
Trouble
assembling/
disassembling steam
mop
1. Difficult to attach mop
head.
1. The main body of the product can be pushed down into
the nozzle of the mop head. Ensure the groove is aligned
correctly with the body. Refer to page 8 of the instruction
manual provided. Do not disassemble the heap after use.
2.
Difficult to assemble
handle.
2. Slot the handle into the top of the body of the steam
mop.
You may need to push the stud on the handle
inwards to fully insert the handle. The stud should
protrude through the hole at the top of the body for it to
be secure. To remove the handle, push in the stud whilst
lifting the handle upwards.
3. Difficult to attach mop
pad.
3.
Lay the mop pad on the floor and lift the steam mop
head, placing onto the pad. Make sure the blue microfibre
side of the pad is on the floor and attach the mop to the
other side. After use let the steam mop rest in the cooling
tray provided. To remove the mop pad hold you foot on
the edge of the pad and lift away the steam mop.
4.
Difficult to attach
carpet glider.
4.
Lift the mop and place the head into the side of the
carpet glider that has space for the mop head. The mop
head rests in the glider and does not click into place.
Filling/Emptying
water tank
1. Difficult to fill/empty
water tank.
Note: Do not
put detergent in the water
tank.
1. From above the steam mop, grip the sides of the water
tank, located on the back of the main body, and pull
upwards to remove. Unscrew the cap on the water tank in
an anticlockwise direction and remove. You could use the
tap to fill, being careful not to overfill. Replace the cap on
the water tank and turn clockwise to secure. Turn the tank
upside down over the sink to let any water from the cap
drain out. Slide the tank back into the body, ensuring the
cap goes in the correct space. To refill, unplug and follow
the same procedure as above. To empty, use the same
procedure as filling but empty rather than fill the tank.
2. Difficult
to fill/empty
detergent tank.
2. Follow the
same procedure as the water tank, but
measure approximately 30ml of detergent and 150ml
water and add to the smaller detergent tank, located on
the front of the steam mop.
Note: Ensure the detergent
dial is set to “close” when cleaning on carpets and use a
clean mop pad.

17
PROBLEM SOLVING
PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION
The mop
is not
working/steaming
1. The power button has
not been pressed.
1. Press the power button on the centre of the steam
mop. This should
illuminate the power indicator light.
Ensure you have waited 40 seconds for the water to heat
up
–this should allow the second indicator light to
illuminate green
2. Water tank may not be
filled.
2.
Make sure the water tank is filled. Refer to page 9 of
the instruction manual provided.
3.
The unit may not be
plugged in properly/the
fuse
or breaker
may not
be working.
3.
Verify the unit is plugged into an approved electrical
outlet,
is switched on and that the fuse or breaker is
functioning properly
.
4. The steam trigger has
not been pulled.
4. You will need to pull the steam trigger under the handle
for steam to begin emitting.
5. The filter had become
blocked.
5. If the filter has become blocked
you will need a
replacement filter.
Indicator lights
1. What do the indicator
lights mean?
1. The light
on the left illuminates blue when the mop is
plugged in and power button is pressed. When the blue
light has been on and the water has heated sufficiently,
after around 40 seconds, the light on the right should
illuminate green, indicating it is steam ready.
The mop is leaving the
floor streaky
1. The detergent has not
been diluted.
1. The detergent
tank needs to have 5 parts water to 1
part detergent in. The recommended amount is 30ml
Russell Hobbs detergent with 150ml water.
The
steam mop is
leaking
1. The water/detergent
tanks have not been
tipped over a sink/have
been overfilled.
1. When filling the tanks, screw the lids on securely and tip
the tanks upside over the sink to enable water from the lid
to drain. Avoid overfilling the tanks.
2. The steam mop has
been held over one area
for too long.
2. Do
not leave the steam mop concentrated over one
area for more than a couple of seconds. This could
damage your floor and may cause small puddles of water
to leak.
3. The water has not
heated sufficiently.
3. You need to let the water heat up in
the tanks for at
least 60 seconds before pulling the steam trigger. Make
sure the power is switched on.
Using
detergent
1. What can I use
detergent on?
1. You can only use detergent
on sealed hard floors. Do
not use on carpets, this can cause damage. If you are
unsure, contact the manufacturer.
2. How
do I use the
detergent?
2. Fill the tank
and
set the dial on the front of the mop to
“open” to start using the detergent on sealed hard floors.

18
PROBLEM SOLVING
PROBLEM POSSIBLE PROBLEM POSSIBLE SOLUTION
The
filter needs
replacing
1. Contact customer
services using the details on the
bottom of this page.
The
indicator lights
are
not working
1. The unit may not be
plugged in properly/the
fuse
or breaker
may not
be working.
1. Verify the unit is plugged securely into an approved
electrical outlet and that the fuse or breaker is functioning
properly.
There is a peculiar
smell coming from
the unit
1. First time using
product.
1. If
this is the first time you are using the mop, continue
using the product. The smell may be due to new parts
being heated up for the first time
.
2. This is not the first
time the product has
been used.
2. Discontinue use if problem persists and contact
Customer
Services using the details on the
bottom of this
page
.
The mop pad is not
picking up dirt
1. The mop pad is
saturated
and needs
washing.
1. Wash
the mop pad, following cleaning and care
instructions on page 15 of the instruction manual
provided.
Parts have
broken/need
replacing
1. Either the
water/detergent
tank/cap
, mop pad,
carpet glider,
filler cup,
filter, cooling tray
or
handle have broken or
been lost.
1. Call customer services or visit the website detailed at
the bottom of this page.
2. None of the above
have broken but another
part has.
2. Discontinue use and contact customer services using the
details on the bottom of this page.
I have lost the
instruction manual
provided
1. The instruction manual
has been lost or
misplaced.
1. It is important to have a copy of the instruction manual.
Visit www.productcareuk.com or contact customer
services using the details provided on the bottom of this
page.
We’re here should you need us.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com
Note: When cleaning carpets, turn off the steam mop, set the dial on the front of the body to
“close” and use a clean mop pad and the carpet glider.

19
GUARANTEE AND CUSTOMER SERVICES
At Russell Hobbs, we take all our customer feedback seriously.
Feel free to contact our Product Care Team, on 0345 209 7461
Monday –Friday: 8am-8pm & Saturday: 9am –1pm,
who will be more than happy to assist you.
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship, the faulty product must be returned to the place of
purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
•The product must be returned to the retailer with the original
proof of purchase.
•The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which are supplied.
•It must be used for domestic purposes only and for its intended
use.
•This warranty does not cover wear and tear, damage, misuse
or consumable parts.
This does not affect your statutory rights.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com

20
SPARE PARTS
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am –8pm & Saturday 9am –1pm
Or visit us at www.productcareuk.com
To check the availability of the following spare parts, simply contact
our friendly Customer Services team using the details provided at the
bottom of this page.
Part:
1. Body
2. Handle
3. Hard water filter
4. Microfibre cleaning pad
5. Mop head
6. Filler cup
7. Detergent tank
8. Water tank
9. Carpet glider
10. Detergent
11. Cooling Tray
