Ryobi P610 Quick setup guide

RYOBI
18 VOLT PLANER
MODEL NO. P610
REPAIR SHEET

47
40
59
57
58
56
17
11
13
15
14
12
22
38
10
60
7
8
663
5
4
3
2
55
54
25
28
27
1
62
30
24
23
35
31
32
34
51
50
49
53
52
36
61
11
16
18
64
19
20
21
25
26
29
37
41
43
44
45 46
47
48
2
9
9
33
33
42
1
39
RYOBI 18 VOLT PLANER – MODEL NUMBER P610
2

RYOBI 18 VOLT PLANER – MODEL NUMBER P610
3
1 6620606 * SCREW (M3.5 X 16 mm) ................................... 4
2 200392002 MOTOR COVER AND BELT COVER ................. 1
3 513570002 CHIP EJECTMENT ............................................ 1
4 660206018 * SCREW (M3.5 X 15 mm PAN HD.) .................... 1
5 514506001 DEPTH ADJUST KNOB .................................... 1
6 690541001 COPPER CAP ................................................... 1
7 690542001 SPRING ............................................................. 1
8 513702001 WASHER ........................................................... 1
9 200078027 HOUSING ASSEMBLY ...................................... 1
10 670970001 NUT (M5) ........................................................... 2
11 6620805 * SCREW (M4 X 16 mm PAN HD.) ..................... 17
12 631501001 WASHER (ID7.2 mm) ........................................ 1
13 620416001 DEPTH ADJUST SHAFT ................................... 1
14 671799001 SPRING ............................................................. 1
15 641133001 FRONT SHOE .................................................. 1
16 6990301 WAVY WASHER ................................................ 1
17 660811001 * SCREW (M8 X 9 mm HEX SOC.) ...................... 1
18 660279007 * SCREW (M4 X 16 mm) ...................................... 6
19 631423001 REAR SHOE ..................................................... 1
20 513575002 KICK STAND ..................................................... 1
21 671889001 SPRING (Ø0.5 mm) ........................................... 1
22 671888001 HINGE PIN (Ø0.5 mm) ...................................... 1
23 513679001 FOAM RUBBER ................................................ 2
24 513572002 CHIP GUIDE ..................................................... 1
25 660206025 * SCREW (M3.5 X 10 mm) ................................... 3
26 680727001 BEARING NEEDLE ........................................... 1
27 300132026 BLADE ASSEMBLY ........................................... 1
28 6807001 BALL BEARING (6000ZZ) ................................. 1
29 610497001 DRIVEN PULLEY ............................................... 1
30 570279002 BELT .................................................................. 1
31 230130001 MOTOR ASSEMBLY ......................................... 1
32 513571002 WIND COVER ................................................... 1
33 200073013 HANDLE ASSEMBLY ........................................ 1
34 513678001 SAFETY BUTTON ............................................. 1
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
PLANER or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY

RYOBI 18 VOLT PLANER – MODEL NUMBER P610
4
KEY PART
NO. NUMBER DESCRIPTION QTY
PARTS LIST
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
PLANER or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
35 6749901 SPRING ............................................................. 1
36 6620812 * SCREW (M4 X 25 mm PAN HD.) ....................... 1
37 270017086 SWITCH ASSEMBLY ........................................ 1
38 300869008 EDGE GUIDE ASSEMBLY ................................. 1
39 940230148 WARNING LABEL ............................................. 1
40 690214004 * HEX KEY (5/32 in.) ............................................ 1
41 300027057 DUST BAG ASSEMBLY .................................... 1
42 200292003 PLUG IN LANYARD .......................................... 1
43 660852001 * SCREW (M4 PAN HD.) ...................................... 4
44 641114001 BLADE BODY ................................................... 1
45 641113001 BLADE CLAMP ................................................. 2
46 660169058 * SCREW (M6 X 16 mm HEX SOC. HD.) ............. 4
47 671798001 STRAIGHT PLANER BLADE ............................. 4
48 672001001 SPRING ............................................................. 4
49 610496001 DRIVE PULLEY ................................................. 1
50 6872601 BALL BEARING (688Z) ..................................... 1
51 513600001 FAN W/SHAFT .................................................. 1
52 660212023 * SCREW (M4 X 7.0 mm PAN HD.) ...................... 2
53 631509001 MOTOR MOUTING PLATE ............................... 1
54 740795001 MOTOR ............................................................. 1
55 660142001 * CARRIAGE BOLT .............................................. 1
56 690865003 ADJUSTING STEEL PLATE ............................... 1
57 690866004 EDGE GUIDE PLATE ......................................... 1
58 5228001 FLAT WASHER .................................................. 1
59 540510007 KNOB NUT ....................................................... 1
60 540511008 KNOB BOLT ...................................................... 1
61 940115118 DATA LABEL ..................................................... 1
62 940114135 LOGO LABEL .................................................... 1
63 940700005 SCALE LABEL .................................................. 1
64 940230147 WARNING LABEL (ON BASE) .......................... 1
983000936 OPERATOR’S MANUAL (960223929)
983000936R REPAIR SHEET (REV:00)
03-13-06

RYOBI 18 VOLT PLANER – MODEL NUMBER P610
5
WIRING DIAGRAM
RED LEAD
MOTOR SWITCH
RED LEAD
BLACK LEAD
CONTACT
PLATE HOLDER
