Ryobi R18RT User manual

ORIGINAL INSTRUCTIONS
Rotary Tool
R18RT

Important!
It is essential that you read the instructions in this manual before assembling,
operating and maintaining the product.
Subject to technical modification.

1
Safety, performance, and dependability have been given
top priority in the design of your rotary tool.
INTENDED USE
The rotary tool is intended to be used only by adults who
have read and understood the instructions and warnings in
this manual, and can be considered responsible for their
actions.
With appropriate accessories tted, the product is designed
to perform cutting, grinding, sanding, sculpting, polishing,
bufng, etching, engraving and drilling.
The product is intended for consumer use only.
Do not use the product for any other purpose. Use of the
product for operations different from intended could result
in a hazardous situation.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool’’ in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
WORK AREA SAFETY
■Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
■Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
■Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
ELECTRICAL SAFETY
■Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
■Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
■Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
■Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
■When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
■If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
■Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personal injury.
■Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat or hearing
protection used for appropriate conditions will reduce
personal injuries.
■Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch
on invites accidents.
■Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
■Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
■Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can
be caught in moving parts.
■If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
■Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
severe injury within a fraction of a second.
POWER TOOL USE AND CARE
■Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
■Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
■Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting
the power tool accidentally.

2
■Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
■Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused
by poorly maintained power tools.
■Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
■Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
■Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another battery pack.
■Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
■When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
■Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
■Do not use a battery pack or tool that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or
risk of injury.
■Do not expose a battery pack or tool to fire
or excessive temperature. Exposure to fire or
temperature above 130°C may cause explosion.
■Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified
range may damage the battery and increase the risk
of fire.
SERVICE
■Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
■Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
ROTARY TOOL SAFETY WARNINGS
Safety warnings common for grinding, sanding, wire
brushing, polishing, carving or abrasive cutting-off
operations
■This power tool is intended to function as a grinder,
sander, wire brush, polisher, carving or cut-off tool.
Read all safety warnings, instructions, illustrations
and specifications provided with this power tool.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
■Do not use accessories which are not specifically
designed and recommended by the tool
manufacturer. Just because the accessory can be
attached to your power tool, it does not assure safe
operation.
■The rated speed of the grinding accessories must
be at least equal to the maximum speed marked on
the power tool. Grinding accessories running faster
than their rated speed can break and fly apart.
■The outside diameter and the thickness of your
accessory must be within the capacity rating of
your power tool. Incorrectly sized accessories cannot
be adequately controlled.
■The arbour size of wheels, sanding drums or any
other accessory must properly fit the spindle or
collet of the power tool. Accessories that do not
match the mounting hardware of the power tool will run
out of balance, vibrate excessively and may cause loss
of control.
■Mandrel mounted wheels, sanding drums, cutters
or other accessories must be fully inserted into
the collet or chuck. If the mandrel is insufficiently
held and/or the overhang of the wheel is too long, the
mounted wheel may become loose and be ejected at
high velocity.
■Do not use a damaged accessory. Before each use
inspect the accessory such as abrasive wheels for
chips and cracks, sanding drum for cracks, tear or
excess wear, wire brush for loose or cracked wires.
If power tool or accessory is dropped, inspect for
damage or install an undamaged accessory. After
inspecting and installing an accessory, position
yourself and bystanders away from the plane of
the rotating accessory and run the power tool at
maximum no-load speed for one minute. Damaged
accessories will normally break apart during this test
time.
■Wear personal protective equipment. Depending
on application, use face shield, safety goggles or
safety glasses. As appropriate wear dust mask,

3
hearing protectors, gloves and workshop apron
capable of stopping small abrasive or workpiece
fragments. The eye protection must be capable of
stopping flying debris generated by various operations.
The dust mask or respirator must be capable of filtrating
particles generated by your operation. Prolonged
exposure to high intensity noise may cause hearing
loss.
■Keep bystanders a safe distance away from work
area. Anyone entering the work area must wear
personal protective equipment. Fragments of
workpiece or of a broken accessory may fly away and
cause injury beyond immediate area of operation.
■Hold power tool by insulated gripping surfaces
only, when performing an operation where the
cutting accessory may contact hidden wiring.
Cutting accessory contacting a “live” wire may make
exposed metal parts of the power tool “live” and could
give the operator an electric shock.
■Always hold the tool firmly in your hand(s) during
the start-up. The reaction torque of the motor, as it
accelerates to full speed, can cause the tool to twist.
■Use clamps to support workpiece whenever
practical. Never hold a small workpiece in one hand
and the tool in the other hand while in use. Clamping
a small workpiece allows you to use your hand(s) to
control the tool. Round material such as dowel rods,
pipes or tubing have a tendency to roll while being cut,
and may cause the bit to bind or jump toward you.
■Position the cord clear of the spinning accessory.
If you lose control, the cord may be cut or snagged
and your hand or arm may be pulled into the spinning
accessory.
■Never lay the power tool down until the accessory
has come to a complete stop. The spinning accessory
may grab the surface and pull the power tool out of your
control.
■After changing the bits or making any adjustments,
make sure the collet nut, chuck or any other
adjustment devices are securely tightened. Loose
adjustment devices can unexpectedly shift, causing
loss of control, loose rotating components will be
violently thrown.
■Do not run the power tool while carrying it at your
side. Accidental contact with the spinning accessory
could snag your clothing, pulling the accessory into
your body.
■Regularly clean the power tool’s air vents. The
motor’s fan will draw the dust inside the housing and
excessive accumulation of powdered metal may cause
electrical hazards.
■Do not operate the power tool near flammable
materials. Sparks could ignite these materials.
■Do not use accessories that require liquid coolants.
Using water or other liquid coolants may result in
electrocution or shock.
KICKBACK AND RELATED WARNINGS
Kickback is a sudden reaction to a pinched or snagged
rotating wheel, sanding band, brush or any other accessory.
Pinching or snagging causes rapid stalling of the rotating
accessory which in turn causes the uncontrolled power tool
to be forced in the direction opposite of the accessory’s
rotation.
For example, if an abrasive wheel is snagged or pinched
by the workpiece, the edge of the wheel that is entering
into the pinch point can dig into the surface of the material
causing the wheel to climb out or kick out. The wheel may
either jump toward or away from the operator, depending on
direction of the wheel’s movement at the point of pinching.
Abrasive wheels may also break under these conditions.
Kickback is the result of power tool misuse and/or incorrect
operating procedures or conditions and can be avoided by
taking proper precautions as given below.
■Maintain a firm grip on the power tool and position
your body and arm to allow you to resist kickback
forces. The operator can control kickback forces, if
proper precautions are taken.
■Use special care when working corners, sharp
edges etc. Avoid bouncing and snagging the
accessory. Corners, sharp edges or bouncing have a
tendency to snag the rotating accessory and cause loss
of control or kickback.
■Do not attach a toothed saw blade. Such blades
create frequent kickback and loss of control.
■Always feed the bit into the material in the same
direction as the cutting edge is exiting from the
material (which is the same direction as the chips
are thrown). Feeding the tool in the wrong direction
causes the cutting edge of the bit to climb out of the
work and pull the tool in the direction of this feed.
■When using rotary files, cut-off wheels, high-speed
cutters or tungsten carbide cutters, always have
the work securely clamped. These wheels will grab
if they become slightly canted in the groove, and can
kickback. When a cut-off wheel grabs, the wheel itself
usually breaks. When a rotary file, high-speed cutter
or tungsten carbide cutter grabs, it may jump from the
groove and you could lose control of the tool.
Safety warnings specic for grinding and abrasive
cutting-off operations
■Use only wheel types that are recommended
for your power tool and only for recommended
applications. For example: do not grind with the
side of a cut-off wheel. Abrasive cut-off wheels are
intended for peripheral grinding, side forces applied to
these wheels may cause them to shatter.
■For threaded abrasive cones and plugs use only
undamaged wheel mandrels with an unrelieved
shoulder flange that are of correct size and length.
Proper mandrels will reduce the possibility of breakage.
■Do not “jam” a cut-off wheel or apply excessive
pressure. Do not attempt to make an excessive
depth of cut. Overstressing the wheel increases the
loading and susceptibility to twisting or snagging of the
wheel in the cut and the possibility of kickback or wheel
breakage.
■Do not position your hand in line with and behind
the rotating wheel. When the wheel, at the point of
operation, is moving away from your hand, the possible

4
kickback may propel the spinning wheel and the power
tool directly at you.
■When wheel is pinched, snagged or when
interrupting a cut for any reason, switch off the
power tool and hold the power tool motionless until
the wheel comes to a complete stop. Never attempt
to remove the cut-off wheel from the cut while the
wheel is in motion otherwise kickback may occur.
Investigate and take corrective action to eliminate the
cause of wheel pinching or snagging.
■Do not restart the cutting operation in the workpiece.
Let the wheel reach full speed and carefully re-enter
the cut. The wheel may bind, walk up or kickback if the
power tool is restarted in the workpiece.
■Support panels or any oversized workpiece to
minimize the risk of wheel pinching and kickback.
Large workpieces tend to sag under their own weight.
Supports must be placed under the workpiece near the
line of cut and near the edge of the workpiece on both
sides of the wheel.
■Use extra caution when making a “pocket cut” into
existing walls or other blind areas. The protruding
wheel may cut gas or water pipes, electrical wiring or
objects that can cause kickback.
Safety warnings specic for wire brushing operations
■Be aware that wire bristles are thrown by the brush
even during ordinary operation. Do not overstress
the wires by applying excessive load to the brush.
The wire bristles can easily penetrate light clothing and/
or skin.
■Allow brushes to run at operating speed for at least
one minute before using them. During this time no
one is to stand in front or in line with the brush.
Loose bristles or wires will be discharged during the
run-in time.
■Direct the discharge of the spinning wire brush
away from you. Small particles and tiny wire fragments
may be discharged at high velocity during the use of
these brushes and may become imbedded in your skin.
ADDITIONAL SAFETY WARNINGS
■Inspect for and remove all nails from the workpiece
before using the product. Following this rule will
reduce the risk of serious personal injury.
■Do not reach in the area of the spinning bit. The
proximity of the spinning bit to your hand may not
always be obvious.
■The product is not intended for use as a dental drill
or in human or veterinary medical applications.
Serious injury may result.
■Do not grind or sand heat flammable materials.
Sparks from the wheel could ignite these materials.
■Do not bend the flex shaft with a radius less than
13 mm. The risk of overheating will increase
substantially.
■Ambient temperature range for tool during operation is
between 0°C and 40°C.
■Ambient temperature range for tool storage is between
0°C and 40°C.
■The recommended ambient temperature range for the
charging system during charging is between 10°C and
38°C.
ADDITIONAL SAFETY WARNINGS
WARNING
The product is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the product by a person responsible
for their safety.
Children should be supervised to ensure that they do not
play with the product.
ADDITIONAL BATTERY SAFETY WARNINGS
WARNING
To reduce the risk of re, personal injury, and product
damage due to a short circuit, never immerse your
tool, battery pack or charger in uid or allow a uid to
ow inside them. Corrosive or conductive uids, such
as seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a short
circuit.
■Ambient temperature range for battery during use is
between 0°C and 40°C.
■Ambient temperature range for battery storage is
between 0°C and 20°C.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps
or tape. Do not transport batteries that are cracked or
leaking. Check with the forwarding company for further
advice.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still
impossible to completely eliminate certain residual risk
factors. The following hazards may arise and the operator
should pay special attention to avoid the following:
■Injury caused by thrown-off particles
–Metal or abrasive particles may enter the eyes and
cause severe permanent damage. Wear goggles
approved for grinding operations whenever you use
the product.
■Injury caused by vibration
–Limit exposure. See “Risk Reduction”.

5
■Injury caused by dust
–Wear appropriate dust control mask with filters
suitable for protecting against particles from the
material being worked on and abrasive particles
from the accessories. Do not eat, drink, or smoke in
the work area. Ensure adequate ventilation.
■Injury from contact with the attachments
–The attachment and workpiece will become hot
during use. Wear gloves when changing discs or
touching workpiece. Keep hands away from the
working area at all times. Clamp the workpiece
whenever possible.
■Injury caused by noise
–Prolonged exposure to noise will increase the risk
of hearing damage, and the effects are cumulative.
When using power tools for any extended period of
time, wear hearing protection.
RISK REDUCTION
It has been reported that vibrations from hand-held tools
may contribute to a condition called Raynaud’s Syndrome
in certain individuals. Symptoms may include tingling,
numbness and blanching of the ngers, usually apparent
upon exposure to cold environments. Hereditary factors,
exposure to cold and dampness, diet, smoking and work
practices are all thought to contribute to the development
of the these symptoms. There are measures that can be
taken by the operator to possibly reduce the effects of
vibration:
■Keep your body warm in cold weather. When operating
the unit wear gloves to keep the hands and wrists
warm. It is reported that cold weather is a major factor
contributing to Raynaud’s Syndrome.
■After each period of operation, exercise to increase
blood circulation.
■Take frequent work breaks. Limit the amount of
exposure per day.
If you experience any of the symptoms of this condition,
immediately discontinue use and see your doctor.
WARNING
Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
OPERATING TIPS
INSTALLING ACCESSORIES
Insert the shank of the accessory into the collet until
the shank bottoms out, then pull it out 2 mm to allow for
expansion when the accessory gets hot.
BALANCING ACCESSORIES
For precision work, it is important that all accessories
be properly balanced. To balance an accessory, slightly
loosen the collet nut and give the accessory or collet a 1/4
turn. You should be able to tell by the sound and feel if
the accessory is running in balance. Continue adjusting
in this fashion until the best balance is achieved. Replace
accessories if they become damaged or unbalanced.
LEARNING TO USE THE ROTARY TOOL
Hold the pen in your hand and get used to its weight,
balance, and the taper of the housing. This taper permits
the pen to be grasped like a pencil.
MAINTENANCE
WARNING
The product should never be connected to a power supply
when you are assembling parts, making adjustments,
cleaning, performing maintenance, or when the product
is not in use. Disconnecting the product will prevent
accidental starting that could cause serious injury.
WARNING
When servicing, use only original manufacturer’s
replacement parts, accessories and attachments. Use of
any other parts may create a hazard or cause product
damage.
■Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloths to remove dirt, carbon dust, etc.
WARNING
Do not at any time let brake uids, gasoline, petroleum-
based products, penetrating oils, etc., come in contact
with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.
WARNING
For greater safety and reliability, all repairs should be
performed by an authorised service centre.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing
of as waste. The machine, accessories and
packaging should be sorted for environment-
friendly recycling.
SYMBOLS ON THE PRODUCT
Safety alert
No-load speed
Rated speed
VVolts
Direct current

6
Please read the instructions carefully
before starting the machine.
Regulatory Compliance Mark (RCM).
Product meets applicable regulatory
requirements.
Failure to keep long hair away from air
inlet could result in personal injury.
Wear eye protection
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or retailer
for recycling advice.
SPEED DIAL SETTINGS
Type of accessory Application Speed
Aluminum oxide grinding
bits Grinding metal High
Fiberglass cut-off wheel Cut bolts, screws, nails, thin wood High
Sanding drums Sanding wood High
Felt polishing wheels Polishing steel, aluminum, brass, stone, ceramic, glass Medium
Drill bit Drilling holes into wood, leather High
Wire brush Brushing metal Medium
Engraving bit Engraving soft metals and wood High speeds for woods, low
speeds for metals
High-speed cutter Shaping curved surfaces and engraving soft metals and
wood High
Conical grinding stone Grinding metal High
SYMBOLS IN THIS MANUAL
Note
Parts or accessories sold separately
The following signal words and meanings are intended to
explain the levels of risk associated with this product:
DANGER
Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
(Without Safety Alert Symbol) Indicates a situation that
may result in property damage.

7
ACCESSORY
Figure Accessory Accessory number Application
Drum sander mandrel (Ø 6.4 mm)
(Ø 3.2 mm shank/collet) A1
Attaching to sanding
drums
Drum sander mandrel (Ø 12.7 mm)
(Ø 3.2 mm shank/collet) A2
Wrench A3
Removing and
inserting accessory
bits
15.9 mm. x 9.5 mm orange 120-grit aluminum oxide
grinding wheel bits A4
Grinding metal
9.5 mm x 12.7 mm orange 120-grit aluminum oxide
grinding wheel bits A5
32 mm berglass cut-off wheel
used with [A18] mandrel A6 Cutting bolts, screws, nails, and thin wood
6.4 mm screw mandrel A7 Attaching to polishing
wheels
6.4 mm x 12.7 mm sanding drums,
used with [A1] mandrel
A8 (60 grit)
A9 (12 grit)
A12 (240 grit) Sanding wood
12.7 mm x 12.7 mm sanding drums,
used with [A2] mandrel
A10 (60 grit)
A11 (12 grit)
A13 (240 grit)
Felt polishing wheels
used with [A7] mandrel A14
Polishing and bufng
metals, stone, glass
and ceramics
Polishing compound vial A15
Polishing and
brightening metals
and plastics.
3.2 mm high speed steel drill bit A16 Drilling
Wire brush wheel A17 Brushing metal
Cut-off wheel mandrel,
3.2 mm shank A18 Attaching to berglass cut-off wheels
0.8 mm engraving bit A19 Engraving soft metals
High-speed cutter A20
Shaping curved
surfaces and
engraving soft metals
and wood
Conical grinding stone A21 Grinding metal

8
......

9
5
6
7
8
1
4
2
3
127 mm(5”)
9
KNOW YOUR PRODUCT
1. Battery port
2. Accessory storage slots
3. Speed control dial
4. On/off switch
5. Collet nut
6. Pen holder
7. Spindle lock lever
8. Flex shaft
9. Key hole hanger

10
2
3
1
4
2
3
11
2
45
2
1
1 2

11
2
3
4
5
3
1
2
3
4
2

12
229 mm127 mm(5”)
1
2
20190117v1_d5

PRODUCT SPECIFICATIONS
Rotary tool
Model R18RT
Voltage 18 V
Collet 3.2 mm(1/8“)
Flexshaft length 91.5 cm
Maximum allowable overhang 14 mm
Maximum mandrel length 40 mm
Rated speed 4000 - 35000 min-1
Weight - not incl. battery pack 1.3 kg
Measured sound values determined according to EN 60745:
A-weighted sound pressure level Lp= 84.0 dB(A)
Uncertainty K 3 dB(A)
Measured values determined according to EN 60745
A-weighted sound power level LW= 95.0 dB(A)
Uncertainty K 3 dB(A)
Measured sound values determined according to EN 60745:
Vibration emission value ah= 23.0 m/s2
Uncertainty K 1.5 m/s2
REPLACEMENT PARTS
Flex shaft 5131042169
VIBRATION LEVEL
WARNING
The vibration emission level given in this information sheet has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of
exposure. The declared vibration emission level represents the main applications of the tool. However if the tool is used
for different applications, with different accessories or poorly maintained, the vibration emission may differ. This may
signicantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may signicantly reduce the exposure level over the total working
period. Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool
and the accessories, keep the hands warm, and organisation of work patterns.
BATTERY AND CHARGER
Model Compatible battery pack
(not included)
Compatible charger
(not included)
Lithium-Ion
RB18L13
RB18L15
RB18L20
RB18L25
RB18L30A
RB18L40
RB18L50
RB18L60A
RB18L90A
BCS618G
BCL14181H
BCL14183H
BCL1418IV*
RC18150
RC18150U
RC18627U
RC18115
RC18120
*for vehicles with 12V DC outlets

Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley, VIC 3149
Melbourne, Australia
Techtronic Industries N.Z. Limited
2 Landing Drive, Mangere
Auckland, 2022, New Zealand
Imported by:
RYOBI is a trademark of Ryobi Limited,
and is used under license.
961075460-01
