SAFAVIEH COUTURE Onyx Mid Century SFV4724 User manual

CARE AND MAINTENANCE
NOTICE
B󰾡 2X
Part List and Hardware List
PIECE DESCRIPTION PICTURE QUANTITY
SAFAVIEH
A 1X
Spot clean using a mild water-free solvent. Only a professional cleaner should
undertake a complete overall cleaning.
The use of steam or water-based cleaners may cause excessive shrinking or
staining.
* Please make sure that you have all parts indicated before you begin assembly of
this item
* This item should be assembled on a soft surface to prevent scratching the finish
during assembly
* This item may require periodic tightening SFV4724
Dimensions:
C O U T U R E
Front Leg
Seat
HW3 Split Lock Washer(M8)
HW4 Flat Washer(M8)
The legs and hardware are located underneath the
Chair
in the zipper compartment
SocketScrews 8*1.25*65MM
4X
HW5 Allen Key 1X
WARNING: DO NOT STAND ON CHAIR
WARNING: DO NOT OVER TORQUE BOLTS/SCREWS
HW2 Socket Screws 8*1.25*40MM
12X
12X
C
2
X
8X
43.31''W*34.25''D*28.94''H
Back Leg
HW1
Weight Capacity: 275 lbs

PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contentslist and hardware contents list.
If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 10 minutes.
Tools Required for Assembly(included): Allen key
STEP1
OPEN THE ZIPPER ON THE UNDERSIDE
OF THE
SEAT AND TAKE OUT LEGS AND
HARDWARE
HW1
HW2
HW4 HW3
HW1
HW1
HW1
HW2
HW2
HW2
BL
BL
BR
BR
BR
CL
CR
HW5
HW5
HW5
HW5
HW5
STEP2 PUT THE WASHERS ON THE SCREW
IN THE ORDER SHOWN IN THE PICTURE
STEP3 ATTACH 1 PIECE OF FRONT LEG(BR) TO THE BOTTOM
OF SEAT(A) BY USING 2 PIECES OF SCREWS(HW1) AND 1
PIECE OF SCREW(HW2) WITH 3 PIECES OF SPLIT LOACK
WASHER(HW3) AND 3 PIECES OF FLAT WASHER(HW4) AS
SHOWN. TIGHTEN ALL SCREWS BY USING ALLEN
WRENCH(HW5) AS SHOWN.
A
STEP4 REPEAT THE SAME STEPS FOR
ANOTHER 1 PIECE OF FRONT LEG(BL). TIGHTEN
ALL SCREWS BY USING ALLEN WRENCH(HW5)
AS SHOWN
STEP5 ATTACH 1 PIECE OF BACK LEG(CR) TO THE BOTTOM OF
SEAT(A) BY USING 2 PIECES OF SCREW(HW1) AND 1 PIECE OF
SCREW(HW2) WITH 3 PIECES OF SPLIT LOACK WASHER(HW3) AND 3
PIECES OF FLAT WASHER(HW4) AS SHOWN. REPEAT THE SAME
STEPS FOR OTHER 1 PIECE OD BACK LEG(CL). TIGHTEN ALL SCREWS
BY USING ALLEN WRENCH(HW5) AS SHOWN.
STEP6 CLOSE THE VELCRO STRIP ON THE
BOTTOM OF THE SEAT(A). ASSEMBLY IS
COMPLETE.
The legs and hardware are located underneath the Chair
in the zipper compartment
