SaMASZ KDF 260 User manual

Firma SaMASZ
Firma SaMASZFirma SaMASZ
Firma SaMASZ
inŜ. Antoni Stolarski
Poland, 15-161 Białystok, ul. Trawiasta 30
Rok załoŜenia – 1984
NIP PL-542-010-21-58
tel. (+48) (85) 654 45 84
654 45 82
664 70 31
fax (+48) (85) 664 70 41
e-mail: [e-mail]
www.samasz.pl
OPERATOR’S MANUAL
FRONT DISC MOWER
KDF 260 - 2,6 m – from serial number 00006
KDF 260 W - 2,6 m – from serial number 00001
KDF 260 S - 2,6 m – from serial number 00001
KDF 300 - 3,0 m – from serial number 00019
KDF 300 W - 3,0 m – from serial number 00001
KDF 300 S - 3,0 m – from serial number 00006
W – Mowers with roller conditioner IN229EN003
S – Mowers with tine conditioner 05.12.2007
EDITION NR 3

- 1 -
DO NOT
TURN THE DRIVE ON
IF THE MOWER IS NOT IN
WORKING POSITION.
DO NOT
LIFT THE MOWER
BEFORE THE MOWING
DISCS HAVE COME TO
COMPLETE STANDSTILL.
DO NOT
OPERATE WHEN ANY
PERSON REMAINS IN THE
DANGER AREA OF 50 m.
Written and translated by: Łukasz Łapiński
Technical advice: mgr inŜ. Sławomir Rabiczko
Approved by: mgr inŜ. Andrzej Łapiński
Recommended inclination 4 - 5° towards mowing
direction. It is allowed to work in horizontal position.
Different inclination may damage the mower.

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 2 -
Contents page
1. IDENTIFYING THE MACHINE............................................................................................3
2. INTRODUCTION ....................................................................................................................3
3. PROPER USE...........................................................................................................................4
3.1. Technical data.............................................................................................................................5
3.2. Design and working principle .....................................................................................................6
3.3. Standard eqipment and spare parts..............................................................................................8
4. SAFETY ADVICE....................................................................................................................9
4.1. Safety rules and regulations ........................................................................................................9
4.2. Transport ..................................................................................................................................10
4.2.1.Putting the mower onto another vehicle for transport ................................................................10
4.3. Working components................................................................................................................11
4.4. PTO shaft..................................................................................................................................11
4.5. Residual risk.............................................................................................................................11
4.6. Warning decals and their meaning ............................................................................................12
5. OPERATION..........................................................................................................................19
5.1. Attaching the mower to the tractor............................................................................................19
5.2. Adjusting the clearance between triangle’s hook and lock.........................................................20
5.3. Adjusting the length of support chains ......................................................................................20
5.4. Preparing the mower for transport.............................................................................................20
5.5. Mounting PTO shaft .................................................................................................................21
5.6. Switching from transport to working position ...........................................................................22
5.7. Preparing the mower for work...................................................................................................22
5.8. Operation (mowing)..................................................................................................................23
5.8.1.Essential information concerning mowing.................................................................................23
5.8.2.Taking turns over swaths...........................................................................................................25
6. MOUNTING AND ADJUSTMENTS ....................................................................................25
6.1. Mounting and timing of the knives............................................................................................25
6.2. Replacing the knives.................................................................................................................26
6.3. Adjusting the space between tine conditioner’s mask and its shaft ............................................27
6.4. Replacing the conditioner’s tines...............................................................................................28
6.5. Adjusting force of the pressure of roller conditioner..................................................................28
6.6. Maintenance and service...........................................................................................................29
6.6.1.Checking the knives and knife holders.......................................................................................29
6.6.2. Checking the tension of tine conditioner’s driving chain...........................................................30
6.6.3.Daily maintenance.....................................................................................................................30
6.6.4.After-season maintenance..........................................................................................................31
7. LUBRICATION......................................................................................................................31
7.1. Cutterbar...................................................................................................................................31
7.2. Intersecting axis gear. ...............................................................................................................32
7.3. Roller conditioner’s gearbox.....................................................................................................32
7.4. Bearings and joints....................................................................................................................33
8. DEFECTS AND THEIR REPAIRS.......................................................................................35
9. DISASSEMBLY AND WITHDRAWAL FROM USE..........................................................35
10. WARRANTY CARD..............................................................................................................36
11. WARRANTY TERMS............................................................................................................36
11.1. Warranty claims procedures......................................................................................................36
11.2. Warranty repairs record.............................................................................................................38

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 3 -
1. IDENTIFYING THE MACHINE
Data plate is mounted to the mower’s main frame in the place shown below (Fig.1)
Fig.1 Data plate place Fig. 2. Data plate
Data plate includes:
- name of the manufacturer, - weight,
- mower’s number, - quality management sign,
- mower’s type, - CE sign
- manufacturing date, - MADE IN POLAND sign
CAUTION:
For more detailed information concerning the mower ask your dealer
or manufacturer.
2. INTRODUCTION
 This operator’s manual should be considered as the basic mower’s equipment. If the mower is
handed over to another operator, it should be in working condition and given away along with
operator’s manual and it’s other basic equipment.
 Operator’s manual is attached to every machine in order that the operator can familiarize himself
with design, working principles, service and adjustment of the mower. The user of the mower
should be familiar with common safety rules and procedures.
 The mower is manufactured according to international safety rules.
 Compliance with the warnings in this operator’s manual will ensure safe operation.
 Please contact your dealer if you have any queries relating to the operation and service of the
mower.
 Operator’s manual remains part of mower’s equipment.
GENERAL WARNING
When operating the mower please comply with the
warnings and safety regulations shown throughout this
manual by this safety alert symbol.

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 4 -
CAUTION:
Operation of the mower before reading the operator’s manual carefully
as well as operating by the unauthorized staff, especially by children, is
strictly forbidden.
3. PROPER USE
a) mower without conditioner
SaMASZ front disc mower is designed for mowing standing grass on meadows and in stone free
fields. It is a machine for hay and green fodder production. When the high grass prevails, the first and
the second cut should be mowed at the height level - 6-7 cm, but when the grass grows low – at the
height level - 5 cm. The last cut should be mowed a little bit higher – 7-8 cm above the ground.
b) mower with tine/roller conditioner
SaMASZ front disc mower with tine/roller conditioner is designed for mowing standing grass on
meadows and in stone free fields. It particularly concerns mowers with roller conditioner, because they
tolerate stones only up to few centimeters. If a mower comes across a bigger stone, tractor-mower set
must be stopped and the stone removed, because it may lead to serious damage. It is a machine for hay
and green fodder production. Tine/roller conditioner provides effective conditioning and accelerates
drying of the forage. Roller conditioner is recommended in case of fragile crops like lucerne (alfalfa).
It reduces leaf loss to an absolute minimum. When the high grass prevails, the first and the second cut
should be mowed at the height level - 6-7 cm, but when the grass grows low – at the height level - 5
cm. The last cut should be mowed a little bit higher – 7-8 cm above the ground.
CAUTION:
Use of the mower for other purposes than the above mentioned
is forbidden. Different use than the above mentioned will be considered
as improper and may lead to revoking of the warranty. Mower should be
used, operated and repaired only by people familiarised with its detailed
specifications and with safety rules and regulations. Wilful changes of the
mower will lead to revoking of the warranty.
Mower KDF 260 works properly with tractors (class 2,0 and power from 70 HP ). Mower KDF 300
works properly with tractors (class 2,0 and power from 80 HP ). Mower KDF 260S works properly
with tractors (class 2,0 and power from 90 HP). Mower KDF 260W works properly with tractors (class
2,0 and power from 90 HP). Mower KDF 300S works properly with tractors (class 2,0 and power from
100 HP). Mower KDF 300W works properly with tractors (class 2,0 and power from 100 HP).

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 5 -
3.1. Technical data
Tab. 1. Specifications.
Model KDF 260 KDF 300
KDF 260S KDF 300S KDF
260W KDF 300W
Working width 2,6 m 3,0 m 2,6 m 3,0 m 3,0 m 3,0 m
Number of knives [pcs.] 12 (6x2) 14 (7x2) 12 (6x2) 14 (7x2) 14 (7x2) 14 (7x2)
Tractor PTO rpm 1000 rpm
Tractor power required 54 kW
(70 HP) 60 kW (80 HP) 66 kW (90 HP) 74 kW (100 HP) 66 kW (90 HP) 74 kW (100 HP)
Working capacity
V = 12 km/h ~ 2,9 ha/h ~ 3,4 ha/h
~ 2,9 ha/h ~ 3,4 ha/h ~ 2,9 ha/h ~ 3,4 ha/h
Swath width about
1,1 m about 1,2 m 0,7-1,0 m 1,0-1,4 m 0,9-1,3 m
0,9-1.5 m
Transport length 1,65 m 1,65 m 1,7 m 1,7 m 1,7 m 1,7 m
Transport width 2,5 m 2,9 m 2,65 m 3,0 m 2,65 m 3,0 m
Working width 3,15 m 3,55 m 3,25 m 3,65 m 3,25 m 3,65 m
Weight 716 kg 767 kg - 1096 kg - 1140 kg
Number of conditioner’s
tines [pcs.] - - 36 48 - -
Tine/roller conditioner shaft
rpm 818 rpm
Tractor class 2 2 2 2 2 2
Noise level L
pA
101 ± 1 dB 99,5 ± 1 dB 100,5 ± 1 dB
L
Amax
112,5 ± 1 dB 111 ± 1 dB 112 ± 1 dB
L
Cpeak
114 ± 1 dB 113,5 ± 1 dB 113,5 ± 1 dB
S – Mower with tine conditioner W – Mower with roller conditioner
L
pA
– noise level related to 8 hour working time. Averaged in time acoustic pressure level
corrected by frequency characteristic A.
L
Amax
– maximum value corrected by frequency characteristic A of acoustic pressure level.
L
Cpeak
– peak level of acoustic pressure corrected by frequency characteristic C.

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 6 -
3.2. Design and working principle
Fig. 3a. Parts of SaMASZ front disc mower.
(Decsription of Fig. 3a.)
Drive from tractor’s rpm is transmitted through PTO shaft, intersecting axis gear (4), cutterbar drive
shaft (6) and intersecting axis gear (5) to the cutterbar (3). On the cutterbar there are discs with two
knives each. The extreme discs have additional forming drums. Cutterbar is connected to the main
frame (2) along with suspension frame (1). On the suspension frame there is mower’s triangle, which
is designed to connect the mower to tractor’s front 3-point linkage. Over the cutterbar there are safety
guards (10).
Fig. 3b. Parts of SaMASZ front disc mower with tine conditioner.
1 – Suspension frame
2 – Main frame
3 – Cutterbar
4 – Intersecting axis gear
5 – Intersecting axis gear
6 – Cutterbar drive shaft
7 – Swath discs
8 – Support springs
9 – Hydraulic cylinders
10 – Safety guard
10
3
7
4
1
8
6
5
8 9 9
2
3
4
8 11
5
1
7
6
12 12
10 10
2
9

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 7 -
(Description of Fig. 3b.)
Drive from tractor’s rpm is transmitted through PTO shaft, intersecting axis gear (5), cutterbar drive
shaft (7) and intersecting axis gear (6) to the cutterbar (4). On the cutterbar there are discs with two
knives each. The extreme discs have additional forming drums. Apart from that, drive from tractor’s
rpm through intersecting axis gear (5), tine conditioner driver shaft (8) and tine conditioner gearbox
(9) is transmitted to tine conditioner (3). Cutterbar is connected to the main frame (2) along with
suspension frame (1). On the suspension frame there is mower’s triangle, which is designed to connect
the mower to tractor’s front 3-point linkage. Over the cutterbar there are safety guards (11).
Fig. 3c. Parts of SaMASZ front disc mower with roller conditioner.
(Description of Fig. 3c.)
Drive from tractor’s rpm is transmitted through PTO shaft, intersecting axis gear (5), cutterbar drive
shaft (7) and intersecting axis gear (6) to the cutterbar (4). On the cutterbar there are discs with two
knives each. The extreme discs have additional forming drums. Apart from that, drive from tractor’s
rpm through intersecting axis gear (5), tine conditioner driver shaft (8) and roller conditioner gearbox
(9) is transmitted to roller conditioner (3). Cutterbar is connected to the main frame (2) along with
suspension frame (1). On the suspension frame there is mower’s triangle, which is designed to connect
the mower to tractor’s front 3-point linkage. Over the cutterbar there are safety guards (11).
Well-proven design with thousands of machines in regular use in many countries and quality materials
ensure high durability and reliability of SaMASZ mowers.
1 – Suspension frame
2 – Main frame
3 – Tine conditioner
4 – Cutterbar
5 – Intersecting axis gear
6 – Intersecting axis gear
7 – Cutterbar drive shaft
8 – Tine conditioner drive shaft
9 – Tine conditioner gearbox
10 – Hydraulic cylinders
11 – Safety guard
12 – Support spring
1 – Suspension frame
2 – Main frame
3 – Roller conditioner
4 – Cutterbar
5 – Intersecting axis gear
6 – Intersecting axis gear
7 – Cutterbar drive shaft
8 – Roller conditioner drive shaft
9 – Roller conditioner gearbox
10 – Hydraulic cylinders
11 – Safety guard
12 – Support springs
11
8
5
1
7
6
4
3
12
12 10 10
2
9

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 8 -
3.3. Standard equipment and spare parts
The mowers are sold with the following standard equipment:
 warranty card,
 operator’s manual along with spare parts list,
 cutting knives: additional set,
 mounting lever for quick-knife changing,
 holders for warning plate and lights,
 tractor’s triangle.
Optional extra equipment:
 PTO shaft with friction clutch
 warning plate with combined lights and reflectors,
 warning triangle,
Tab.2 PTO shaft for front disc mowers.
Model Power Length Moment Symbol Clutch Manufacturer Notes
KM mm Nm
KDF260;
KDF300 S/W;
KDF260;
KDF300 S/W;
36 860-1319 540 904-00920 Friction clutch = 1250 Nm Weasler Slide lock
Fig. 4. PTO shaft lubrication points. Mounting directions.
CAUTION:
Lubricate the PTO shaft with high quality multi-purpose grease every 8
shaft operating hours. If access holes are available, lubricate fittings
through access holes. E-kits need lubrication every 50 hours. See decal
on guard if applicable.
PTO shafts of other brands with equivalent parameters could be used afer SaMASZ permission.
CAUTION:
Optional extra equipment should be ordered separately.
PTO shaft’s end without
clutch – To be mounted
on the tractor’s side.
PTO shaft’s end with friction
clutch –
To be mounted on
mower’s side
8h
8h
8h8h

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 9 -
The mower is equipped with such elements as holders and brackets used to mount warning lights and
plates. Combined lights and reflectors are mounted on the warning plates.
We congratulate you on the purchase of your new SaMASZ mower and wish you much pleasure and
the very best work results through the years to come.
4. SAFETY ADVICE
4.1 Safety rules and regulations
 Any operation with the hydraulic lift lever should be done from the operator’s seat; DO NOT
move the lever from outsider of the tractor.
In case of tractors equipped with EHR, operating with hydraul;ic lift is done by the buttons
mounted outsider the tractor’s cabin. When operating be extremely careful.
 Operation without safety guards as well as with the damaged or raised guards is not allowed
(danger of the stones, etc. being thrown out).
 Start mowing only when the tractor’s PTO reaches its normal 1000 obr/min.
 Do not exceed 1050 rpm.
 Nobody is allowed to remain within the danger area of at least 50 m. Particular caution is
necessary when operating near roads and in stoney areas.
 Any maintenance and adjustment work should only be done after the drive has been disconnected
and when the cutting discs have come to the complete standstill.
 Always check mower before starting work, in particular for damaged, missing and/or worn knives
and knife holders. Damaged or worn parts must be replaced.
 When driving on public roads always comply with local traffic regulations, especially concerning
warning lights.
CAUTION:
All service and repair operations must be done only after the tractor
engine has been stopped, all rotating parts have come to the complete
standstill and the cutterbar is on the ground.
CAUTION:
Be certain that children and animals are at a safe distance away from the
machine. Never allow anyone to ride on a machine or tractor.
 When the mower is lifted for repair on the 3-point linkage, it should be secured against
falling by a mechanical support or by chain.
 The bolts and other fasteners have to be periodically checked and, if necessary, tightened or
replaced. DO NOT work with damaged or worn fasteners.
 Never lift the mower on tractor linkage when the drive is on and the cutting discs are rotating.
 When operating the mower, the tractor should always be equipped with the cabin.
 Mower should not be operated when the tractor-mower set is not balanced.
 Never start the mower when it is lifted.
 Never start the mower, when people or animals are near the machine.
 Never lift the safety guard before the rotating parts have come to the complete standstill. Tractor’s
engine must be stopped.
 Always comply with the safety decals describing hazards, and warning signs placed on the
machine.
 Before you start the tractor make sure that every other drives are turned off and the levers steering
hydraulics are in neutral position.

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 10 -
 Never leave the tractor’s engine running without supervision. Before you leave the tractor, turn off
the engine and put off the key from tractor’s ignition switch,
 It is forbidden to operate the mower when driving backwards,
 Never get on the mower,
 Never lift the mower on tractor’s lift when the drive is on and the discs are rotating,
 Permissible inclination of the slope when working and during transport is 8°,
 Never stand between tractor and mower, before tractor-mower set is secured against moving by the
tractor’s brake,
 Every maintenance work and regulations can be done only when the mower is on the ground,
 If any maintenance work or regulation under lifted mower is needed, it must be secured against
falling,
 When the parts of the mower need replacement, use only the original spare parts according to spare
parts list,
 Pay particular attention to PTO shaft’s guards and mower’s and tractor’s spline shaft guards. Never
work with damaged guards,
 Hydraulic hoses should be peridically checked and if any damage occur or they expire, replace
with new ones. Expiry period should not exceed 5 years,
 Never use scotch tape to repair hydraulic hoses,
 When connecting hydraulic hoses to tractor’s hydraulic connectors make sure, that either tractor’s
or mower’s hydraulic system is without pressure,
 When operating hydraulic system, always wear protective gloves and glasses. Leaking under
pressure hydraulic oil (16 MPa) may permeate through the skin and cause infection. If it happens,
immediately visit a doctor,
 The mower should be stored under roofed places and in the way that it will not harm people or
animals.
4.2. Transport
 Every position change of the mower can only be done when there is nobody around (pay particular
attention to children).
 For the transport period put warning plate with combined lights and reflectors and warning triangle
on the mower.
 During transport always put the mower to transport position. See chapter 5.4.
 Before putting the mower to transport position make sure, that the tractor’s PTO is turned off and
all the rotating parts have come to complete standstill.
 Driving speed should always be adjusted to road conditions.
 Permissible speed is 25 km/h and it cannot be exceeded.
4.2.1. Putting the mower onto another vehicle for transport
The driver and the carrier are responsible for mower’s transport safety. Equipment and parts must be
secured during transport.
To put the mower onto another vehicle in a safe way, please obey the following rules:
 Seize the mower by any lifting devices only in the places indicated by the hook sign (Fig.5)

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 11 -
Fig. 5. Transport holders
 For mower lifting use only lifting devices with hoisting capacity bigger than mower’s weight
shown in data plate. It also concerns ropes and chains used for lifting.
 Collapsible parts should be blocked in transport position.
 During putting the mower onto another vehicle it is forbidden for anybody to remain in transport
area.
 On the vehicle’s trailer the machine should be secured against moving.
CAUTION:
Securing manouvering area and transport of the mower is the
responsibility of a person who does it.
4.3. Working parts
 Before operating the mower check knife’s and knife holder’s condition.
 Worn or damaged knives or knife holders should be immediately replaced with new one.
4.4. PTO shaft
 Use only PTO shafts recommended by mower’s manufacturer
4.5. Residual risk
Despite the fact, that company SaMASZ Białystok – the manufacturer of the mower takes the
responsibility for design and manufacturing of the mower, in order to eliminate dangerous situations,
certain risk during mower operation is unavoidable.
1. Danger of catching
This kind of risk occurs during changing the position of a mower, operation near rotating parts,
working without safety guards.
During operation, maintenance and reulations always wear protective gloves, shoes and clothes
without loose parts, belts and so on. Always comply with safety decals placed on the mower.
2. Danger of injury
This kind of risk occurs during replacement of working parts with sharp edges. During any
maintenance work always use safety gloves.
3. Danger of liquid ejection out of hydraulic system
During connection of hydraulic hoses to hydraulic connectors make sure, that either tractor’s or
mower’s hydraulic system is without pressure.
Transport holder

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 12 -
During operation of hydraulic system always wear protective glasses and gloves. Check regularly
hydraulic hoses.
CAUTION:
Residual risk always results from incorrect behaviour of mower’s
operator.
4. Bans
Please bear in mind the following bans during mower’s operation:
 Never unblock the mower, make any regulations or repairs of the mower while it is in motion.
 Never change the order of operation and maintenance activities described in operator’s manual.
 Never operate the mower when it is not in working order or has damaged safety guards.
 Never get your hands and legs close to rotating parts of the mower.
 During repair and maintenance of the mower always comply with the descriptions included in
operator’s manual. Always do these activities when the tractor’s drive is off.
 Before you start any activities, focus your attentionon on them.
 Never operate the mower under the influence of alcohol, drugs, or strong medicines.
 Your clothes should not be too loose, or too tight. Too loose cloth parts may be pulled in by the
rotating parts of the mower.
 The mower cannot be operated by children or by handicaped people.
When describing residual risk, the mower is treated as a machine, that up to the moment of its putting
in motion it had been designed and manufactured according to technology level actual till the day of
mower’s manufacture.
CAUTION:
Residual risk occurs in case of not complying with described instructions
and bans.
When the risk of exposing to noise cannot be avoided or eliminated by any group
protective means or organization of work, employer (farmer) must:
1) provide the operator with individual means of noise protection, if the noise level
in work place exceeds 80 dB.
2) provide the operator with individual means of noise protection and supervise the
correctness of its usage, if the noise level in work place reaches or exceeds 85 dB.
4.6. Warning decals and their meaning
CAUTION:
a) all warning decals should be clean and legible,
b) lost or damaged decals must be replaced,
c) please order new decals from your dealer or supplier.
CAUTION:
Mower’s working rpm -10 ÷+5 % i.e. 900 ÷1050 rpm.

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 13 -
Warning decals Meaning Id. Nr.
Read the operator’s manual
before putting the mower
into operation.
1
N-3
While making repairs the
machine must be stopped.
2
N-4
Operating is forbidden
when any person is within
the danger area of 50 m.
3
N-7

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 14 -
Warning decal
Meaning
Id.
Nr
Be extremely careful when
PTO shaft is rotating.
4
N-1
CAUTION: belt
transmission, be extremely
careful
5
N-5
CAUTION: pulling-in
parts
6
N-6

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 15 -
Warning decal
Meaning
Id.
Nr
CAUTION: cutting knives.
Approach during operation
is forbidden .
7
N-2
Never stand near tractor’s
3-point linkage while
steering tractor’s lift.
8
N
-
49
Do not stay in the swinging
area of mower’s parts
9
N-50; N-51

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 16 -
Warning decal
Meaning
Id.
Nr
Signs indicating transport
holders
10
N
-
40
Wear protective gloves 11
N-52
Lower side
safety guards
before turning
the drive on.
12
N-48
min = 900
1
/min
max = 1050
1
/min
1000
1
/min
13. P
-
2
14. N
-
8
WORKING WITHOUT GUARDS
IS FORBIDDEN
DANGER OF THE STONES, ETC.
BEING THROWN OUT

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 17 -
Caution: rotor
15
N-9
16. N-53
18. N-27
CAUTION:
Any spare part used for repair of the mower should have all warning
decals provided by the manufacturer.
Optimum work parameters
1. Inclination towards the front 4÷5 degrees which stands for 6÷7 cm of mowing height.
2. Operation speed ≥10 km/h.
3. PTO rpm = 900÷1000 rpm. PTO rpm > 1000 may cause stripes of uncut grass
between the discs.
4. Tractor’s rpm (max. moment – economical fuel consumption 1600÷1800 rpm).
High and inclined grass.
5. Highten the cutterbar’s inclination to – H = about 4 cm.
6. Operation without cutterbar’s inclination may cause winding of grass on the forming
drums.
7. Speed up to V ≥12 km/h. (the faster – the better)
8. Do not take turns in the mowed grass.
17. N
-
34
19. N
-
31
CLEAN THE MOWER EACH
DAY AFTER WORKING,
especially between discs and the
cutterbar, because grass with mud
may damage bearings in the disc
module.

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 18 -
1 6
3
17
18
14
2
7
13
10
10
14
9
8
11
12
17
16
4
9
7
2
17
13
5
14
3
10
8
16
4
14
10
12
19
6
11
18
11
Fig. 6a. Warning decals placed on the
mower without conditioner.
Fig. 6b. Warning decals
placed on the mower
with tine/roller conditioner.

Operator’s manual
Front disc mowers
KDF 260; KDF 300;
KDF 260 S/W; KDF 300 S/W;
- 19 -
b
3
1
2
Widok „W
1
2
a
A-A
A
block
Adjust the proper inclunation by means of
upper link and block it.
Fig.7a
5. OPERATION
5.1 Attaching the mower to the tractor
Mower KDF 260 works properly with tractors (class 2,0 and power from 70 HP ). Mower KDF 300
works properly with tractors (class 2,0 and power from 80 HP ). Mower KDF 260S works properly
with tractors (class 2,0 and power from 90 HP). Mower KDF 260W works properly with tractors (class
2,0 and power from 90 HP). Mower KDF 300S works properly with tractors (class 2,0 and power from
100 HP). Mower KDF 300W works properly with tractors (class 2,0 and power from 100 HP).
CAUTION:
Manufacturer is not responsible for mower’s damage, if it is caused by
improper mounting.
Unmounting of the mower may cause the following damages:
-bending of mower’s guards by the tractor,
-damage of PTO shaft,
-damage of the gear and other parts of the mower.
During operation check mounting of the mower.
The mower is mounted on the tractor’s triangle which is connected to the tractor’s front 3-point
linkage (the tractor’s triangle cat. II is NOT a part of standard equipment – it can be ordered from
SaMASZ as optional extra equipment).When the triangle is connected to the tractor’s 3-point linkage,
adjust it (by means of upper link) in parallel to the mower’s triangle, lift the 3-point linkage until it
locks in, check the space between 1triangle’s hook and pawl 2(Fig. 7a.), block the hook 1with cotter
pin ∅4 2(Fig. 7b.), adjust the space between the frame suspension and a rubber safety bumper to
about 150 mm (Fig. 7), regulate and mount support chains, block them with cotter pins according to
5.3.After the mower has been attached to tractor, check the balance and steerability of tractor-mower
set. To do it, weigh the set and after that drive on the weigher with only the rear axis of the tractor (the
mower must be in transport position – lifted upwards). If the pressure on the rear axis is at least 20%
of the whole set’s pressure, it means the set is stable. If not, the rear axis should be balanced.
Fig. 7.Proper mounting of the mower on tractor’s triangle cat. II. A
Shafts end with
overrunning clutch.
Adjust, mount and block the
support chain
.
Block the pins
Block the hook with
cotter pin
Adjust the space
between suspension
frameand rubber safety
bumper
to about
15 cm
.
~
15 cm
Fig.7b
