Sami WS-2376 User manual

WEARABLE
User Manual
WS-2376
Thank you for purchasing the Sami wearable WS-2376. Read the instructions
carefully to obtain optimum results and preserve it for future reference.
DESCRIPTION OF THE WEARABLE.
CONTENTS.
Wearable, USB magnetic charging cable, instruction manual.
CHARGING.
Connect the device to a computer or laptop with the USB Magnetic cable for
charging. Put in contact the magnetic end of the USB cable with the charging
points positioned in the back of your device. Kindly use only the USB cable
included with the wearable. If you use a power adapter for charging, the
output of the power adapter should be 5V, 1A. Charging time: 1-2 hours approx.
Please charge the device fully before using it. Take care with the magnet side
of the cable, if you connect to the AC and you have contact with a metal
surface, you may damage the charging cable.

HOW TO POWER ON / POWER OFF?
1) To turn ON the smart band, long press the side button for a few seconds.
The side button is situated in the right of the of the screen.
2) To turn OFF the smart band, while the device is in the home screen menu,
slide on the screen from the right to the left and then from the bottom to
the top to change between the different menus of the device. Tap on the
settings icon to enter in the settings menu, slide again in the screen from
the bottom to the top until you see the shutdown icon, tap in the icon and
confirm to shutdown to make it power off.
HOW TO CONTROL?
This device is equipped with a full touch display screen, it supports full screen
touch control.
1) In the home page slide the screen as in the following diagram to enter to
the different interfaces :
TOUCH SCREEN
BUTTON PRESS

1) Short tap in the icon to select/enter in that menu. In the submenus slide
from left/right or top/bottom to go to the next/previous page. Short press
the side button to return to the previous interface.
2) In the home page, long press the screen for a few seconds until the screen
zooms out, then slide the screen up or down and select the digital clock
style you prefer to change it.
GETTING STARTED:
- For Android
1) How to obtain the BT Connection APK (VeryFit)
Search for the VeryFit APP in the Play Store; download it and install it in your
Android smartphone, or go to our website www.sami.es and download the
application.
2) Installation of the VeryFit APK.
When installing the VeryFit application on your Android, you must allow all the
Application Permissions, allow this VeryFit app auto run.
The first time you run this VeryFit app, it will ask you to Enable Notifications,
please tap OK and tap the VeryFit and confirm OK. You must tap
OK/Allow/Pair/Yes/Confirm for any pop-up request. On your Android permission
management, allow all application permissions.
3) How to make the wearable pair with your Android smart phone?
*First, turn on the Bluetooth of your Phone.
*Second, run the VeryFit app on your Phone, on the home page of VeryFit, find
the pairing request by the setting all your values requested and then select
“watch”. You must have the screen of the watch on and the APP will search for
new Bluetooth device(s), when the available Bluetooth device displays, please
select WS-2376 (the BT name of this device). Select the device on the app to
make it pair. Select “confirm tick”on the watch and the pairing will be finished
in a few seconds. When you pair for the first time, the VeryFit app will ask you to
o enable GPS and Bluetooth, and authorize VeryFit to get access to the
location service while using the app. Please accept all the requests for the
correct functioning of the device. When you finish select OK/Confirm/Allow for
any pop-up request.
4) In the case that on the watch you have the QR CODE on the screen, then in
the APP VeryFit click the icon of scan on the top left of the menu and scan the
qr code of the watch with the camera.
Important: To enable all notifications of different softwares such as WhatsAPP,
Facebook, Skype, Twitter, you will need to turn on the notifications on the APP
manually. On the VeryFit homepage, select the icon “Device” (situated on the
right bottom of the screen), select “WS-2376”select “message notification”
turn on “Allow notification”and turn on all the APP notifications you want to
active. To confirm you must click on the icon located on the top right.
- For iPhone
1) How to obtain the BT Connection APP (VeryFit)

Search for the VeryFit APP in the APP Store; download it and install it in your iOS
smartphone
2) Installation of the VeryFit APP.
When installing the VeryFit application on your iOS, you must allow all the
Application Permissions, allow this VeryFit app auto run.
The first time you run this VeryFit app, it will ask you to Enable Notifications,
please tap OK and tap the VeryFit and confirm OK. You must tap
OK/Allow/Pair/Yes/Confirm for any pop-up request. On your Android permission
management, allow all application permissions.
3) How to make the wearable pair with your Android smart phone?
*First, turn on the Bluetooth of your Phone.
*Second, run the VeryFit app on your Phone, on the home page of VeryFit, find
the pairing request by the setting all your values requested and then select
“watch”. You must have the screen of the watch on and the APP will search for
new Bluetooth device(s), when the available Bluetooth device displays, please
select WS-2376 (the BT name of this device). Select the device on the app to
make it pair. Select “confirm tick”on the watch and the pairing will be finished
in a few seconds. When you pair for the first time, the VeryFito app will ask you
to o enable GPS and Bluetooth, and authorize VeryFit to get access to the
location service while using the app. Please accept all the requests for the
correct functioning of the device. When you finish select OK/Confirm/Allow for
any pop-up request.
4) In the case that on the watch you have the QR CODE on the screen, then in
the APP VeryFit click the icon of scan on the top left of the menu and scan the
qr code of the watch with the camera.
* Now you can start using your desired functions of the smart band.
Important: To enable all notifications of different softwares such as WhatsAPP,
Facebook, Skype, Twitter, you will need to turn on the notifications on the APP
manually. On the VeryFit homepage, select the icon “Device” (situated on the
right bottom of the screen), select “WS-2376”select “message notification”
turn on “Allow notification” and turn on all the APP notifications you want to
active. To confirm you must click on the icon located on the top right
PRODUCT FEATURES
BLUETOOTH (BLE 5.0)
TOUCH SCREEN. TFT LCD 1.50" full touch screen with glass
BUILT IN VIBRATING MOTOR
BUILT IN HEART RATE SENSOR
BUILT IN GRAVITY SENSOR
GESTURE CONTROL TO LIGHT UP THE DISPLAY SCREEN
BUILT IN ALEXA
ALLUMINIUM MIDDLE FRAME
WATER PROOF 5 ATM
1) Time/Date/Battery displaying
2) Health data
3) Sports –different sport modes including Outdoor Run/Indoor Run/Outdoor
walk/Indoor walk /Hiking/Outdoor cycle/Cricket/Yoga/Indoor
cycle/Workout/Pool swim/ Open water swim/Rower/Elliptical.
Enter to the sports mode by selecting the sports icon, select

the sport type enter the sports countdown automatically.
During sports, to pause sports short press the side button, and
to restore sports short press the side button again. To end up
sports long press the icon on the screen and confirm end.
4) Amazon alexa voice function
5) Exercise record
6) Heart Rate
7) Blood oxygen
8) Stress level measure
9) Breathe Training: Helps you regulate your breathing and relax your mood.
10) Sleep
11) Weather forecast
12) Music control –control music via bt on your mobile. Watch cannot
playback or store music
13) Stopwatch
14) Alarm Clock
15) Timer
16) Find phone
17) Settings: Raise wrist to on watch/Do not disturb/Watch
face/Dimming/Power off/Restart/Reset/ About
Data can be sync from the wearable to the smart phone on the VeryFit
APK/APP.
Your smart phone will synchronize when the Bluetooth is paired with this device.
FUNCTIONS
PHONE CALL NOTIFICATION - vibrating reminder for incoming phone calls and
display on screen. This function needs to be turned on manually at the VeryFit
APK/APP.
MESSAGE NOTIFICATION - vibrating reminder for incoming messages and
display on screen, including SMS, WhatsApp, Facebook, Twitter, Skype
messages, etc. This function needs to be turned on manually at the VeryFitPro
APK/APP. Memory for 10 messages.
CLOCK SCREENS (Different home digital clocks) - In the home screen of the
smart band, long press the screen for a few seconds to change the style of the
digital clock. You can also select the cloud dials from the APK/APP
SLEEP MONITOR - supported on the watch and VeryFit APK/APP
ALARM CLOCK - supported on the watch and VeryFit APK/APP
FIND THE DEVICE (Looking for your mobile phone) supported on the VeryFit
APK/APP
SEDENTARY REMIDER (REMIND TO MOVE) –set it on the VeryFit APK/APP
Do Not Disturb Mode –set it on the VeryFit APK/APP
GESTURE CONTROL (Raise your hand to light up the screen).
GPS MAP TRACE: view it on the BT APP/APK VeryFit when you do your sports.
ALEXA: firstly on the APP/APK Veryfit you need click on amazon alexa and log in.
now on the watch once you slide towards to right, you will see the icon of alexa
and you can use the voice commands just by talking.

**** THIS IS NOT A MEDICAL INSTRUMENT, SO THE VALUES ARE APPROXIMATE
CLEANING:
In order to avoid any damage on the plating or printing of your wearable
please do not use any chemical product for cleaning such as alcohol 96º. We
recommend you to use a slightly wet cloth.
TECHNICAL SPECIFICATIONS:
Display screen: TFT LCD screen 1.50". Full colour touch screen
Screen resolution: 240x280pixels.
Internal Memory: 128Mb
CPU: Nordic NRF52840
Touch Sensor: Focaltech FT6146
Acelleration and gyroscopes:STK8321 (sitronix-sensortek)
Heart rate sensor: PPG-PAH8009 (pixart)
Charge I/O port : USB magnetic charging cable
Battery: Built in Li-Polymer 210mAh
Stand by time: 20-25 DAYS
Working time: 8-12 DAYS
Bluetooth: BLE 5.0
Water-resist Rating: 5ATM this device resists 50 meters waterproof (5ATM)
Weight: 31 g

Declaration of Conformity
Hereby we,
Name of manufacturer:
SANTOSHI SL
Address:
CALLE FELIPE ASENJO N.56
Zip code & City:
28947 - FUENLABRADA ( MADRID )
Country:
SPAIN
declare that this DoC is issued under our sole responsibility and that this product:
Product description:
Smart Band
Type designation(s):
WS-2376
Trademark:
SAMI WEARABLE
is in conformity with the relevant Union harmonization legislation:
DIRECTIVE EMC 2014/30/EU
DIRECTIVE LVD 2014/35/EU
Standard CE (RED): DIRECTIVE 2014/53/EU
Standard RoHS: 2011/65/EU: (RoHS) Restriction of Hazardous Substance.
with reference to the following standards applied:
EN 60950-1: 2006+A11:2009+A1:2010+A12:2011+A2:2013
EN 62479:2010
EN 301 489-1 V2.1.1 (2017-02)
EN 301 489-17 V3.1.1 (2017-02)
EN 300 328 V2.1.1 (2016-11)
Signature
Full name: VISHAL MIRPURI
Position: ADMINISTRATOR
Date: 08/05/2023
