Samsung WMG160 User manual

World Wide Web
www.samsungmobile.com

11
Contents
Safety and usage information .............................................. 2
Unpack ................................................................................. 4
Layout ................................................................................... 4
Connect your gateway to a TV ............................................ 5
Turn your gateway on .......................................................... 6
Connect your gateway to a DMC
(Digital Media Controller) ..................................................... 7
Play les stored in a DMS (Digital Media Server) ............... 8
Warranty and parts replacement ....................................... 10
Correct disposal of this product ......................................... 11
English

2
Safety and usage information
Comply with the following precautions to avoid dangerous or illegal
situations and ensure peak performance of your product.
Keep your product and all accessories out of the reach of small children
or animals. Small parts may cause choking or serious injury if swallowed.
Use only Samsung-approved accessories. Using incompatible
accessories may damage your product or cause injury.
Avoid exposing your product to very cold or very hot temperatures
(below -10° C/14° F or above 40° C/104° F).
Do not allow your product to get wet—liquids can cause serious damage.
Do not handle your product with wet hands. Water damage to your
product can void your manufacturer’s warranty.
Allowing unqualied personnel to service your product may result in
damage to your product and will void your warranty.
Avoid using or storing your product in dusty, dirty areas to prevent
damage to moving parts.
Your product is a complex electronic product—protect it from impacts and
rough handling to avoid serious damage.
•
•
•
•
•
•
•

English
3
Follow these instructions to connect your Wireless Multimedia Gateway to
your TV and a DMC (Digital Media Controller) using the Wi-Fi technology.
Once connected, you can access les on a DMS (Digital Media Server)
with the DMC and view them on your TV screen, or view les stored in a
memory card.
Your gateway supports the IEEE 802.11b/g/n.

4
Unpack
Gateway • Travel adapter • HDMI cable (for digital TVs) •
Layout
Digital TV jack
Adapter jack
Multi-function button Indicator light
Memory card* slot
* Your gateway accepts microSD™ or microSDHC™ memory cards
up to 16 GB (depending on memory card manufacturer and type).

English
5
Connect your gateway to a TV
To connect to a digital TV,
1. Connect the gateway to your TV with the supplied HDMI cable.
2. Switch the TV to the appropriate HDMI mode. For further details, see
the TV user manual.

6
Turn your gateway on
1. Connect your gateway to a TV with the HDMI cable. See "Connect your
gateway to a TV."
2. Switch the TV to the appropriate HDMI mode. For further details, see
the TV user manual.
3. Plug the small end of the travel adapter into the gateway and plug the
large end of the travel adapter into a power outlet.
4. Press the Multi-function button until the indicator light becomes solid
blue to turn the gateway on.
To turn the gateway off, press and hold the Multi-function button.

English
7
Connect your gateway to a DMC (Digital Media
Controller)
Connect the gateway to your DMC using the Wi-Fi technology.
1. Turn on the Wi-Fi feature of your DMC.
2. Press the Multi-function button to show the current Ad-hoc network
WEP key.
3. When your DMC nds the WMG160_xxx Ad hoc network, connect to it
using the WEP key.
To change the WEP key,
1. Press the Multi-function button to show the current Ad-hoc network
WEP key.
2. Press and hold the Multi-function button when the current WEP key is
displayed.
For further details, see the DMC user manual.

8
Play les stored in a DMS (Digital Media Server)
1. Open the media controller program from your DMC.
2. Select a DMS.
You can also select a memory card inserted to your gateway.
3. Select les you want to view on the TV screen.
4. Select the gateway as a media renderer.
Due to the DRM (Digital Rights Management) system, some les
may not play.
During playback, buffering may happen depending on the
connected device, or the resolution or bit rate of the playing les.
•
•

English
9
Supported le format
File viewer: PPT, PPTX, DOC, DOCX, PDF, XLS, HTML, TEXT
Picture viewer: JPEG, GIF, Animated GIF, PNG, BMP, TIFF
Music player
File format: MP3, WMA, AAC (M4A), OGG, FLAC, WAV (MS-PCM
only)
Audio decoder: MP3, WMA, AAC, Vorbis, FLAC, AC3
Video player
File format: AVI, ASF, MP4, WMV, 3GP, K3G, SKM, TP, MKV, MPG
Video decoder: DivX4/5/6, Xvid, H.263, MPEG-4 SP, H.264 MP,
WMV9 (VC-1), MPEG-2, WMV7/8, DivX3.11
Audio decoder: MP3, AAC, AMR-NB/WB, AC3, WMA9 Standard
Subtitle: SMI, SRT (ASCII and Extended ASCII only)
For information about the rmware upgrade, visit http://www.
samsungmobile.com.
•
•
•
-
-
•
-
-
-
-

10
Warranty and parts replacement
Samsung warrants this product as free of defects in material, design and
workmanship for the period of one year from the original date of purchase.*
If during the period of warranty this product proves defective under normal
use and service you should return the product to the retailer from whom
it was originally purchased or qualied service centre. The liability of
Samsung and its appointed maintenance company is limited to the cost of
repair and/or replacement of the unit under warranty.
The warranty is limited to the original purchaser
A copy of your receipt or other proof of purchase is required for a proper
warranty service
The warranty is void if the serial number, date code label or product
label is removed, or if the product has been subject to physical abuse,
improper installation, modication, or repair by unauthorised third parties
Specically exempt from any warranty are limited-life consumable
components such as batteries and other accessories
Samsung will not assume any responsibility for any loss or damage
incurred in shipping. All repair work on Samsung products by
unauthorised third parties voids any warranty
* Depending on your country, the length of warranty may vary.
•
•
•
•
•

English
11
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that
it should not be disposed with other household wastes at the end
of its working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where
they purchased this product, or their local government ofce,
for details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product should not
be mixed with other commercial wastes for disposal.

Health and
safety information
Consumer Information on devices
The U.S. Food and Drug Administration (FDA) has published a series of
Questions and Answers for consumers relating to radio frequency (RF)
exposure from devices. The FDA publication includes the following
information:
What kinds of pdevices are the subject of this update?
The term device refers here to hand-held devices with built-in
antennas, often called “cell,” “mobile,” or “PCS” devices. These types of
devices can expose the user to measurable radio frequency energy
(RF) because of the short distance between the device and the user's
head. These RF exposures are limited by Federal Communications
Commission safety guidelines that were developed with the advice of
FDA and other federal health and safety agencies. When the device is
located at greater distances from the user, the exposure to RF is

drastically lower because a person's RF exposure decreases rapidly
with increasing distance from the source. The so-called “cordless
devices,” which have a base unit connected to the telephone wiring in a
house, typically operate at far lower power levels, and thus produce RF
exposures well within the FCC's compliance limits.
Do devices pose a health hazard?
The available scientific evidence does not show that any health
problems are associated with using devices. There is no proof,
however, that devices are absolutely safe. devices emit low levels of
radio frequency energy (RF) in the microwave range while being used.
They also emit very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects (by heating
tissue), exposure to low level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some studies have
suggested that some biological effects may occur, but such findings
have not been confirmed by additional research. In some cases, other
researchers have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA's role concerning the safety of devices?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as devices before they can be sold, as it does
with new drugs or medical devices. However, the agency has authority
to take action if devices are shown to emit radio frequency energy (RF)
at a level that is hazardous to the user. In such a case, FDA could
require the manufacturers of devices to notify users of the health
Health and safety information

Health and safety information
hazard and to repair, replace or recall the devices so that the hazard no
longer exists.
Although the existing scientific data do not justify FDA regulatory
actions, FDA has urged the device industry to take a number of steps,
including the following:
• “Support needed research into possible biological effects of RF of
the type emitted by devices;
• “Design devices in a way that minimizes any RF exposure to the
user that is not necessary for device function; and
• “Cooperate in providing users of devices with the best possible
information on possible effects of device use on human health.
FDA belongs to an interagency working group of the federal agencies
that have responsibility for different aspects of RF safety to ensure
coordinated efforts at the federal level. The following agencies belong
to this working group:
• “National Institute for Occupational Safety and Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information Administration
The National Institutes of Health participates in some interagency
working group activities, as well.
FDA shares regulatory responsibilities for devices with the Federal
Communications Commission (FCC). All devices that are sold in the
United States must comply with FCC safety guidelines that limit RF

exposure. FCC relies on FDA and other health agencies for safety
questions about devices.
FCC also regulates the base stations that the device networks rely
upon. While these base stations operate at higher power than do the
devices themselves, the RF exposures that people get from these base
stations are typically thousands of times lower than those they can get
from devices. Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done already?
The research done thus far has produced conflicting results, and many
studies have suffered from flaws in their research methods. Animal
experiments investigating the effects of radio frequency energy (RF)
exposures characteristic of devices have yielded conflicting results that
often cannot be repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However, many of the
studies that showed increased tumor development used animals that
had been genetically engineered or treated with cancer-causing
chemicals so as to be pre-disposed to develop cancer in absence of RF
exposure. Other studies exposed the animals to RF for up to 22 hours
per day. These conditions are not similar to the conditions under which
people use devices, so we don't know with certainty what the results of
such studies mean for human health.
Three large epidemiology studies have been published since December
2000. Between them, the studies investigated any possible association
between the use of devices and primary brain cancer, glioma,
Health and safety information

Health and safety information
meningioma, or acoustic neuroma, tumors of the brain or salivary
gland, leukemia, or other cancers. None of the studies demonstrated
the existence of any harmful health effects from devices RF exposures.
However, none of the studies can answer questions about long-term
exposures, since the average period of device use in these studies was
around three years.
What research is needed to decide whether RF exposure
from devices poses a health risk?
A combination of laboratory studies and epidemiological studies of
people actually using devices would provide some of the data that are
needed. Lifetime animal exposure studies could be completed in a few
years. However, very large numbers of animals would be needed to
provide reliable proof of a cancer promoting effect if one exists.
Epidemiological studies can provide data that is directly applicable to
human populations, but ten or more years' follow-up may be needed to
provide answers about some health effects, such as cancer. This is
because the interval between the time of exposure to a cancer-causing
agent and the time tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is hampered by
difficulties in measuring actual RF exposure during day-to-day use of
devices. Many factors affect this measurement, such as the angle at
which the device is held, or which model of device is used.
What is FDA doing to find out more about the possible
health effects of devices RF?
FDA is working with the U.S. National Toxicology Program and with
groups of investigators around the world to ensure that high priority

animal studies are conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health Organization
international Electromagnetic Fields (EMF) Project since its inception in
1996. An influential result of this work has been the development of a
detailed agenda of research needs that has driven the establishment of
new research programs around the world. The Project has also helped
develop a series of public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet Association (CTIA)
have a formal Cooperative Research and Development Agreement
(CRADA) to do research on wdevice safety. FDA provides the scientific
oversight, obtaining input from experts in government, industry, and
academic organizations. CTIA-funded research is conducted through
contracts to independent investigators. The initial research will include
both laboratory studies and studies of device users. The CRADA will
also include a broad assessment of additional research needs in the
context of the latest research developments around the world.
What steps can I take to reduce my exposure to radio
frequency energy from my device?
If there is a risk from these products - and at this point we do not know
that there is - it is probably very small. But if you are concerned about
avoiding even potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives, reducing the
amount of time spent using a device will reduce RF exposure.
• “If you must conduct extended conversations by device every day,
you could place more distance between your body and the source of

Health and safety information
the RF, since the exposure level drops off dramatically with
distance. For example, you could use a headset and carry the
device away from your body or use a device connected to a remote
antenna.
Again, the scientific data do not demonstrate that devices are harmful.
But if you are concerned about the RF exposure from these products,
you can use measures like those described above to reduce your RF
exposure from device use.
What about children using devices?
The scientific evidence does not show a danger to users of devices,
including children and teenagers. If you want to take steps to lower
exposure to radio frequency energy (RF), the measures described
above would apply to children and teenagers using devices. Reducing
the time of device use and increasing the distance between the user
and the RF source will reduce RF exposure.
Some groups sponsored by other national governments have advised
that children be discouraged from using devices at all. For example, the
government in the United Kingdom distributed leaflets containing such
a recommendation in December 2000. They noted that no evidence
exists that using a device causes brain tumors or other ill effects. Their
recommendation to limit device use by children was strictly
precautionary; it was not based on scientific evidence that any health
hazard exists.
Do hands-free kits for devices reduce risks from exposure
to RF emissions?
