Samsung MIM-B17 User manual

BACnet Gateway
MIM-B17
Air Conditioner
installation manual
DB98-32390A(3)
E
imagine the possibilities
Thank you for purchasing this Samsung product.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 65 2011-04-04 오후 3:44:31

E-2
Safety Precautions
 Read carefully this installation manual before
installation and check if the BACnet Gateway is installed
correctly after installation.
 Do not attempt to install or repair this BACnet Gateway
by yourself.
 This BACnet Gateway contains no user-serviceable parts.
Always consult authorized service personnel for repairs.
 When moving, consult authorized service personnel for
disconnection and installation of the BACnet Gateway.
 Ensure that the wall is strong enough to support the
weight of the BACnet Gateway.
 Must install the BACnet Gateway with rated power
supply.
 The BACnet Gateway must be installed according to
the national electrical rules by an installation specialist.
 If you wish to uninstall the BACnet Gateway, consult an
authorized installation center.
WARNING
CAUTION  Do not use inflammable gases near the BACnet
Gateway.
 Do not install the BACnet Gateway in a location where
it will come into contact with combustible gases,
machine oil, sulphide gas, etc.
 Avoid locations where acid/alkali solution or special
spray is used.
 Choose a location that is dry and sunny, but not exposed
to direct sunlight. Suitable temperature is between
0°C(32°F) and 39°C(102.2°F).
 Do not spill water into the BACnet Gateway.
 Do not apply tensile strength to the cable to avoid cable
damage.
 Do not press the buttons with a sharp object.
 Do not connect the power cable to the control terminal.
 If the BACnet Gateway is installed in a hospital or other
special places, it should not affect other electronic
devices.
This installation manual describes how to install the BACnet Gateway. For installation
of other optional accessories, refer to the appropriate installation manual.
 BACnet is a registered trademark of American Society of Heating,
Refrigerating and Air-Conditioning Engineers (ASHRAE).
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 2 2011-04-04 오후 3:44:20

E-3
Contents

Safety PrecautionS
.......................................................... 2

Before inStalling the Bacnet gateway
............................. 4

acceSSorieS
...................................................................... 5

Viewing the PartS
............................................................ 6

Product dimenSionS
......................................................... 8

SyStem architecture
........................................................ 9

comPatiBle deViceS
....................................................... 10

inStalling the Bacnet gateway
..................................... 12

Setting the Bacnet gateway
......................................... 17

reading ehP watt-hour meter
..................................... 22

SyStem Setting initialization
.......................................... 27

SyStem SettingS
............................................................ 28

tracking
....................................................................... 37

deVice configuration
.................................................... 43

Bacnet Protocol imPlementation conformance Statement
... 51

Standard oBject tyPeS SuPPorted
................................. 55

detail deScriPtion of oBject
.......................................... 56

Bacnet Point liSt
......................................................... 57

other information
....................................................... 61
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 3 2011-04-04 오후 3:44:21

E-4
Checks before installation
1BACnet Gateway IP
A public IP is needed to access the BACnet Gateway
over the internet.
(One public IP is needed for each BACnet Gateway)
A private IP may be used if the BACnet Gateway need
not be accessed over the internet.
2Network related equipments
3Installation connection wire
The LAN cable and the communication cables from
centralized controllers/interface modules must be
installed in such a way that the wires can be connected
to the BACnet Gateway with ease.
Note  The BACnet Gateway is a server and supports static IP.
To access the BACnet Gateway through the internet or
with BMS System, the BACnet Gateway address, which
is the IP address, must be known.
 A static IP service from an internet service provider
must be used if xDSL (ADSL, VDSL) is being used for
internet connection. (Static IP costs more than dynamic
IP.)
 BACnet Gateway should be situated in the same sub-
net as BMS system.
Before Installing the BACnet Gateway
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 4 2011-04-04 오후 3:44:21

E-5
Item BACnet
Gateway
Quantity 1
Shape
Adapter Power cable M4x16 Screw
1 1 6
User’s manual Installation
manual Cable tie
111
Make sure you have each item. Supplied items may vary depending on your
country or service provider.
Accessories

The BACnet Gateway must be installed by a trained
installer.

Ensure the main power is turned o before installing
the BACnet Gateway.
Be sure to use adapter and power cable we provide.
The power cable and the communication cable must
be installed according to the national electrical wiring
regulations.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 5 2011-04-04 오후 3:44:21

E-6
BACnet Gateway Exterior
LCD Display
Shows current time and IP address. Various
messages will be displayed depending on
button input.
LCD operation button
There are 4 buttons(Menu, (Down), (Up),
Set) and you can access to menu and move,
check the menu.
LED Indicator
Check 15 LED status such as Power, CPU-Alive,
Ethernet-Linked/Active, COM1~5-TX/RX and
Check
BACnet Gateway Bottom cover
Unfasten 2 screws on the bottom and
separate the bottom cover from BACnet
Gateway. Then check cable connection part.
Item Name Status
Power Power indicator Turns blue when the
power is supplied.
CPU Alive CPU operation indicator
Blinks in orange with
1 second intervals during
normal operation.
Ethernet–Linked Internet connection indicator Turns green during
normal connection.
Ethernet–Active Internet data transmission/reception indicator
Blinks in orange during
normal transmission/
reception.
COM1~5 – TX Channel 1~5 Centralized controller/Interface module
Data transmission Indicator
Blinks in green during
normal transmission.
COM1~5 – RX Channel 1~5 Centralized controller/Interface module
Data reception Indicator
Blinks in green during
normal reception,
Check Indoor/Outdoor unit/Communication check Indicator Turns green when notice
occurs.
LED Indicator
Viewing the Parts
Main Parts
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 6 2011-04-04 오후 3:44:21

E-7
Name Description
DI Terminal1 Digital Input connection terminal, Channel1~Channel5
DI Terminal2 Digital Input connection terminal, Channel6~Channel10
DO Terminal3 Digital Output connection terminal, Channel1~Channel5
DO Terminal4 Digital Output connection terminal, Channel6~Channel8
Reset Button Reset BACnet Gateway
Power Terminal Connect BACnet Gateway adapter
Serial Terminal Service agent checks BACnet Gateway error status using this terminal
SD card socket Sub memory (for program update and set information saving) socket
RS485
Communication
Terminal
Connect for RS485 communication with devices such as centralized
controller/Interface module
-COM1 ~ COM5
Ethernet Terminal Connect LAN cable
Cable tie groove Groove for arranging cables
Cable tie groove
SD Card Socket
Serial Terminal
Power Terminal
Reset Button
DI Terminal1 DI Terminal2 DO Terminal3 DO Terminal4
Ethernet Terminal
RS485 Communication Terminal
Viewing the Parts
BACnet Gateway Cable Connection Part
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 7 2011-04-04 오후 3:44:21

E-8
240
255
64.80 (Unit : mm)
Display Board
40-pin Cable
20-pin Cable
Main Board
Sub Board
BACnet Gateway Interior
Main Parts
Viewing the Parts (Continued)
Note If you need external circuit configuration, consult with the manufacturer.
Product Dimensions
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 8 2011-04-04 오후 3:44:23

E-9
 Connecting centralized controller and BACnet Gateway ( type)
- You can control up to 16 centralized controllers and 256 indoor units using BACnet Gateway.
 Connecting interface module and BACnet Gateway( type)
- You can control up to 80 interface modules and 256 indoor units using BACnet Gateway.
*MAX.16 interface module can be connected to each of the RS485 communication channels of
the BACnet Gateway.
- The more interface modules are connected, the longer time takes for tracking.
System Architecture
Centralized
controller
BACnet Gateway
Internet
BMS system
BMS Engineering
SAMSUNG Engineering
Interface module Interface module Interface module

When connecting centralized controller and interface module to the BACnet Gateway
of same communication channel, only one of them will communicate according to the
communication channel mode setting of [System Settings]-[Tracking]. Therefore,
do not connect the centralized controller and interface module to the same
communication channel.

If you set the communication channel mode as interface module, virtual centralized
controller address will be assigned. Therefore please aware of that if you set the
centralized controller address as virtual centralized controller address when you
connect interface module and centralized controller at the same, it may cause trouble
for bringing device information.
Channel 0: Virtual centralized controller 11, Channel 1: Virtual centralized controller 12,
Channel 2: Virtual centralized controller 13, Channel 4: Virtual centralized controller 14,
Channel 5: Virtual centralized controller 15
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 9 2011-04-04 오후 3:44:23

E-10
Compatible Devices
No Devices Model Note
1
Indoor Unit
Outdoor Unit
All System indoor/outdoor units
such as: DVM, DVM PLUS,
DVM PLUS II, DVM PLUS III,
DVM PLUS IV, mini DVM, CAC Series
-
2
Centralized
Controller
MCM-A202, MCM-A202A,
MCM-A202B, MCM-A202D -
3
SIM MIM-B12 Needed for EHP power distribution
4
PIM MIM-B16 Needed for EHP power distribution
5
Interface
module
MIM-B04A (DVM, DVM PLUS, etc.)
MIM-B13 (DVM PLUS II,etc.)
MIM-B13A (DVM PLUS II/
DVM PLUS III, DVM PLUS IVetc.)
MIM-B13B, MIM-B13D, MIM-B13E
-
6*
Watt-hour
Meter
RS485 comm. type
Connected with SIM
Needed for power distribution
( Please consult Samsung for compatible
power meters)
Pulse type
Connected with PIM
Pulse Width : 20~400(ms)
Pulse : 1~10000(Wh/Pulse)
Products with ‘* ’ are not Samsung products and must be purchased separately.
(Only selected power meters may be used for protocol compatibility issues.)
Samsung is not responsible for BMS engineering which creates each device and objects.
For further directions regarding on BMS engineering, consult with specialized BMS related vendor.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 10 2011-04-04 오후 3:44:23

E-11
Compatible Devices
Devices Max. Note
Indoor Unit 256 Tracking error occurs if exceeded
Centralized
Controller 16 Must not exceed 16 units
Interface
module 80
16 units per 1 channel, total 80 units are connectable
when connecting i nterface module to BACnet Gate-
way directly
(256 units are connectable when using centralized
controller)
SIM/PIM 8 Up to 8 units are connectable
Watt-hour
Meter 64 8 units are connectable per 1 SIM/PIM
Maximum Devices Attachable
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 11 2011-04-04 오후 3:44:23

E-12
Installation
plate
Installing the BACnet Gateway
1Separate the installation plate on the rear side of BACnet
Gateway.
2Fix the installation plate on the wall using 4 screws.
3Hang the BACnet Gateway on the groove which is on the
top of the installation plate.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 12 2011-04-04 오후 3:44:24

E-13
Assistant hole
wiring groove
Installing the BACnet Gateway
4Fix the installation plate and BACnet Gateway using 2 screws.
Depending on the installation environment, fix BACnet
Gateway using assistant holes.
(Screws for assistant hole are not provided by our
company.)
5If you install BACnet Gateway inside of the wall or wiring
from the rear side is needed, use wiring groove on the
bottom of BACnet Gateway.
To prevent breakdown and damage of BACnet Gateway, and
for safe usage, it is recommended to install BACnet Gateway on
the wall.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 13 2011-04-04 오후 3:44:24

E-14
Cable tie
LAN cable
Connect
communication
cable
Adapter
Installing the BACnet Gateway (Continued)
Connecting Centralized Controller
1Unfasten the 2 screws on the bottom of the BACnet
Gateway front cover. Hold the bottom 2 sides of the
BACnet Gateway and push downwards to slide open the
cover.
2Connect the adapter to the power terminal.
Arrange the adapter as the right figure.
3Separate 1 terminal block from 5 terminal blocks which
are attached to RS485 communication terminal.
Then, connect interface communication cable (C1, C2) to
the terminal block.(C1A, C2B)
4Connect LAN cable to the Ethernet terminal of BACnet
Gateway. Then arrange it using cable tie.
5Fasten the bottom cover of BACnet Gateway and fix it
using 2 screws.
Maximum 16 centralized controllers can be connected
to one BACnet Gateway.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 14 2011-04-04 오후 3:44:25

E-15
Cable tie
LAN cable
Connect
communication
cable
Adapter
Installing the BACnet Gateway (Continued)
Connecting Interface Module
1Unfasten the 2 screws on the bottom of the BACnet
Gateway front cover. Hold the bottom 2 sides of the
BACnet Gateway and push downwards to slide open the
cover.
2Connect the adapter to the power terminal.
Arrange the adapter as the right figure.
3Separate 1 terminal block from 5 terminal blocks which
are attached to RS485 communication terminal.
Then, connect interface module communication cable(R1,
R2) to the terminal block.(R1A, R2B)
4Connect LAN cable to the Ethernet terminal of BACnet
Gateway. Then arrange it using cable tie.
5Fasten the bottom cover of BACnet Gateway and fix it
using 2 screws.
Maximum 80 i nterface modules can be connected to one
BACnet Gateway.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 15 2011-04-04 오후 3:44:25

E-16
Cable tie
LAN cable
Connect
communication
cable
Adapter
Connecting SIM/PIM
1Unfasten the 2 screws on the bottom of the BACnet
Gateway front cover. Hold the bottom 2 sides of the
BACnet Gateway and push downwards to slide open the
cover.
2Connect the adapter to the power terminal.
Arrange the adapter as the right figure.
3Separate 1 terminal block from 5 terminal blocks which
are attached to RS485 communication terminal.
Then, connect SIM/PIM communication cable (C1, C2) to
the terminal block. (C1A, C2B)
4Connect LAN cable to the Ethernet terminal of BACnet
Gateway. Then arrange it using cable tie.
5Fasten the bottom cover of BACnet Gateway and fix it
using 2 screws.
Maximum 8 SIM/PIM units can be connected to one BACnet
Gateway.
Installing the BACnet Gateway (Continued)
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 16 2011-04-04 오후 3:44:26

E-17
Address bar
Setting the BACnet Gateway
BACnet Gateway Connection and Login
1Click internet explorer icon( ) twice on your computer.
2When internet explorer window appears, enter IP address
(http://192.168.0.100) on the address bar then press
[ENTER].
3If it is the first time to access BACnet Gateway, “ Install
Microsoft Silverlight” message will appear.
If Microsoft Silverlight have already installed, the screen
will not appear.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 17 2011-04-04 오후 3:44:26

E-18
Setting the BACnet Gateway (Continued)
4Click [Run] button and continue installation.
After installation, access to BACnet Gateway again.
Silverlight operates normally with Windows XP SP2 or later
version. It may not operate normally with previous version
of Windows.
4
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 18 2011-04-04 오후 3:44:26

E-19
Setting the BACnet Gateway (Continued)
5
5
Enter ID and password when BACnet Gateway main web page appears, Then click
[LOGIN]. If you click [Connect], you will be logged in with general user’s authority level.
If you use accounts with general authorization level to login, you cannot use
the BACnet Gateway settings.
Depending on authorization level set by the administrator, access to some
functions may be restricted.
You can change authorization level settings from System settings 
User authorization management.
To use the BACnet Gateway functions, you must login with the ID that is
included in administration group. Factory default BACnet Gateway ID is ‘admin’
and password is ‘1234’.
Note  Only authorized users can access to web page.
 Connection speed may slow down. Fewer than 5 concurrent users are
recommended.
 BACnet Gateway manager should change ID and password for security and
management.
 Logout: If you want to logout, click [LOGOUT] on the top of the menu. BACnet
Gateway will be ended.
If you use accounts with authorization level lower than management group or accounts
with general authorization level, you cannot access BACnet Gateway settings.
If you cannot access BACnet Gateway, consult the manager.
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 19 2011-04-04 오후 3:44:27

E-20
Setting the BACnet Gateway (Continued)
6If you login successfully, 'Control and Monitoring' screen
will appear.
Click [System Setting]➔[BACnet configuration] menu to
switch to BACnet Gateway.
If you use accounts with authorization level lower
than management group or accounts with general
authorization level, BACnet conguration will not be
displayed on the menu.
If the BACnet conguration menu does not appear,
consult the manager.
6
MIM-B17_BACnet Gateway_IM_E 32390-3.indd 20 2011-04-04 오후 3:44:27
