Samsung SmartThings ADT Carbon Monoxide Alarm User manual

ADT Carbon
Monoxide Alarm
Setup Guide
PRINTER’S INSTRUCTIONS:
MANUAL,QUICK START,NOVA,CO - NORTEK P/N: 10015712B- INK: BLACK PLUS PMS 286C - MATERIAL: 105G COATED PAPER - SIZE: 105MM X 105MM - SCALE:
1-1 - BINDING: TRIM, FOLD AND SADDLE STITCHED - PAGE 1 OF 32

Setup
A
• Make sure that your ADT Security Hub is disarmed
before connecting a new device.
Take the ADT Carbon Monoxide Alarm to where you
intend to mount it after setup.
1. 2.
• Make sure you are within 350 feet from the
ADT Security Hub. (Exact range depends on
your home’s construction, the environment, the
position of the ADT Security Hub, and the position
and number of other connected devices.)
• Make sure that you only setup one new device
at a time.
3.
• Do not remove the battery tab until you are ready
to set up the detector.

Setup Setup
• Make sure that your ADT Security Hub is disarmed
before connecting a new device.
Take the ADT Carbon Monoxide Alarm to where you
intend to mount it after setup.
2. Use the SmartThings app on your smartphone to
select the “My Home” tab. Select "Things", and then
“Add a Thing".
• Make sure you are within 350 feet from the
ADT Security Hub. (Exact range depends on
your home’s construction, the environment, the
position of the ADT Security Hub, and the position
and number of other connected devices.)
• Make sure that you only setup one new device
at a time.
3. Use the SmartThings app to scan the QR code on
the front of the alarm and then follow the on-screen
instructions to complete setup.
QR Code
Carbon Monoxide Alarm (Front)
• Do not remove the battery tab until you are ready
to set up the detector.

Install the ADT Carbon Monoxide Alarm in a place where
the alarm can be heard easily. Ideally, a carbon monoxide
alarm should be installed in:
WARNING: This product is intended for use in ordinary
indoor locations of family living units. It is not designed
to measure compliance with Occupational Safety and
Health Administration (OSHA) commercial or industrial
standards.
• Every room containing a fuel burning appliance.
• Within 10 feet of a sleeping area.
• On every oor of the building.
B
Setup
5. Remove the QR code from the front of the alarm and
attach it inside the ADT Security Hub User Guide for
future reference.
4. Remove the tab on the carbon monoxide alarm
marked “Pull This Tab”.
Carbon Monoxide Alarm (Back)
Battery Tab

Install the ADT Carbon Monoxide Alarm in a place where
the alarm can be heard easily. Ideally, a carbon monoxide
alarm should be installed in:
WARNING: This product is intended for use in ordinary
indoor locations of family living units. It is not designed
to measure compliance with Occupational Safety and
Health Administration (OSHA) commercial or industrial
standards.
• Every room containing a fuel burning appliance.
• Within 10 feet of a sleeping area.
• On every oor of the building.
Placement
B
Remove the QR code from the front of the alarm and
attach it inside the ADT Security Hub User Guide for
future reference.
Remove the tab on the carbon monoxide alarm
marked “Pull This Tab”.

Do not place the ADT Carbon Monoxide Alarm in any
of the following areas:
• In the immediate vicinity of a cooking appliance
(keep it at least 5 feet away from it).
• Outside the building.
• In an enclosed space, e. g. in or below a cupboard.
• In a damp or humid area.
• Directly above a sink or cooker.
• Next to a door, window, airvent, or anywhere it could
be affected by drafts.
• Next to an extractor fan.
Placement
Carbon monoxide alarm suggested Locations:
Attic
Bedroom
Kitchen
Basement Garage
Master Bedroom
Family Room
Hallway

Do not place the ADT Carbon Monoxide Alarm in any
of the following areas:
• In the immediate vicinity of a cooking appliance
(keep it at least 5 feet away from it).
• Outside the building.
• In an enclosed space, e. g. in or below a cupboard.
• In a damp or humid area.
• Directly above a sink or cooker.
• Next to a door, window, airvent, or anywhere it could
be affected by drafts.
• Next to an extractor fan.
Placement
Carbon monoxide alarm suggested Locations:

• If mounted on a wall, it should be located at a
height greater than the height of any door or window
but still be at least 5.9 inches from the ceiling.
If locating the ADT Carbon Monoxide Alarm in a room
with a fuel burning appliance:
• If mounted on the ceiling, it should be at least
12 inches from any wall or light tting.
• The alarm should be a horizontal distance of
between 3.28 and 9.84 feet from the potential
carbon monoxide source.
• In rooms with sloped ceilings, the alarm should be
located on the high side of the room.
• Near paint, thinners, solvent fumes, or air fresheners.
• Where dirt or dust could block the detector.
• In a bathroom or other areas where it may be exposed
to water splashes, dripping or condensation, e.g.
above an electric kettle.
• Where it would be obstructed, e.g. by curtains or
furniture.
• In an area where the temperature could be below
-50°F or above 104°F.
• Where it could be easily knocked or damaged, or
accidentally turned off or removed.
• Over heat sources such as radiators or hot air vents.
Placement

• If mounted on a wall, it should be located at a
height greater than the height of any door or window
but still be at least 5.9 inches from the ceiling.
If locating the ADT Carbon Monoxide Alarm in a room
with a fuel burning appliance:
• If mounted on the ceiling, it should be at least
12 inches from any wall or light tting.
• The alarm should be a horizontal distance of
between 3.28 and 9.84 feet from the potential
carbon monoxide source.
• In rooms with sloped ceilings, the alarm should be
located on the high side of the room.
• Near paint, thinners, solvent fumes, or air fresheners.
• Where dirt or dust could block the detector.
• In a bathroom or other areas where it may be exposed
to water splashes, dripping or condensation, e.g.
above an electric kettle.
• Where it would be obstructed, e.g. by curtains or
furniture.
• In an area where the temperature could be below
-50°F or above 104°F.
• Where it could be easily knocked or damaged, or
accidentally turned off or removed.
• Over heat sources such as radiators or hot air vents.
Placement

Carbon Monoxide Alarm Ceiling Placement:
If locating the ADT Carbon Monoxide Alarm in a bedroom
or in rooms remote from a fuel burning appliance:
• Mount the alarm within 10 feet of the occupants.
• Always make sure it is possible to view the three
light indicators when in the vicinity of the alarm.
Carbon Monoxide Alarms should face out in this position:
• If there is a partition in the room, the alarm should
be located on the same side of the partition as the
potential source.
Placement

Carbon Monoxide Alarm Ceiling Placement:
If locating the ADT Carbon Monoxide Alarm in a bedroom
or in rooms remote from a fuel burning appliance:
• Mount the alarm within 10 feet of the occupants.
• Always make sure it is possible to view the three
light indicators when in the vicinity of the alarm.
Carbon Monoxide Alarms should face out in this position:
Wall Behind Alarm
4 Inches (10cm)
3 Feet
(0.9m)
3 Feet
(0.9m)
Anywhere In This Area
Not This Area
• If there is a partition in the room, the alarm should
be located on the same side of the partition as the
potential source.
Placement
Carbon Monoxide Alarm (Front)

Install the mounting base using the two screws
and anchors provided.
12 inches
from wall
12 inches
from wall
1.
Mounting
C
Ceiling
Mounting Base
2.
3.
Carbon Monoxide Alarm (Front)

Install the mounting base using the two screws
and anchors provided.
Mounting
Fit the alarm inside the base by aligning it over the
base, then turn the alarm in a clockwise direction
until it clicks into place. The three LEDs will ash
while the alarm powers up.
Test the alarm after completing the installation.
2.
3.
ALARM
CARBON
MONOXIDE
ALARM
FAULT
POWER
Mounting

Test the ADT Carbon Monoxide Alarm weekly by pressing
and holding the test button for a few seconds while the
ADT Security Hub is in Walk Test Mode. See the ADT
Security Hub User Guide for more details.
practitioner. Individuals with medical problems may
consider using warning devices which provide audible
and visual signals for carbon monoxide concentrations
under 30 ppm.
Replace the alarm when the “Replace unit by” date has
been reached (check label on the side of the device).
Important: This carbon monoxide alarm must be tested
and maintained weekly. This device is designed to protect
individuals from the acute effects of carbon monoxide
exposure. It will not fully safeguard individuals with
specic medical conditions. If in doubt, consult a medical
DTesting
Note: If you have an ADT professional monitoring service
activated, additional testing is required when you connect
new devices. Follow the on-screen instructions in the
SmartThings app to complete testing.

Test the ADT Carbon Monoxide Alarm weekly by pressing
and holding the test button for a few seconds while the
ADT Security Hub is in Walk Test Mode. See the ADT
Security Hub User Guide for more details.
practitioner. Individuals with medical problems may
consider using warning devices which provide audible
and visual signals for carbon monoxide concentrations
under 30 ppm.
Replace the alarm when the “Replace unit by” date has
been reached (check label on the side of the device).
Important: This carbon monoxide alarm must be tested
and maintained weekly. This device is designed to protect
individuals from the acute effects of carbon monoxide
exposure. It will not fully safeguard individuals with
specic medical conditions. If in doubt, consult a medical
Testing
Note: If you have an ADT professional monitoring service
activated, additional testing is required when you connect
new devices. Follow the on-screen instructions in the
SmartThings app to complete testing.
Testing

Make sure the batteries are properly inserted and
then wait 15 seconds.
If the alarm does not sound when you press the test
button:
Hold button down rmly for at least 5 seconds.
Check the alarm is secured correctly on the mounting
plate.
Replace batteries.
1.
2.
3.
4.
Troubleshooting
ETo reset the alarm:
If the alarm did not pair successfully with the ADT
Security Hub, follow these instructions to reset it:
1.
2.
3.
4.
5.
If you're still having trouble connecting the ADT Carbon
Monoxide Alarm, please visit SmartThings.com
Support-ADT for assistance.

Troubleshooting
Make sure the batteries are properly inserted and
then wait 15 seconds.
If the alarm does not sound when you press the test
button:
Hold button down rmly for at least 5 seconds.
Check the alarm is secured correctly on the mounting
plate.
Replace batteries.
Troubleshooting To reset the alarm:
If the alarm did not pair successfully with the ADT
Security Hub, follow these instructions to reset it:
1.
2.
3.
4.
5.
Press and hold the button until the red LED starts
blinking quickly.
Continue to press and hold the button until the red
LED turns solid.
Release the button and after 5 seconds the red LED
will begin to blink slowly.
Use the SmartThings app to complete setup.
If you're still having trouble connecting the ADT Carbon
Monoxide Alarm, please visit SmartThings.com
Support-ADT for assistance.
Press and release the test button twice.

Reset Button
Troubleshooting
When the ADT Carbon Monoxide Alarm detects potentially
dangerous levels of carbon monoxide, it ashes the red
light immediately and then sounds a loud alarm if the
carbon monoxide persists.
Alarm - Red LED
Power- Green LED
Fault - Amber LED
The below table shows how the alarm reacts to
different levels of carbon monoxide gas and exposure
time. At higher levels of carbon monoxide, the alarm
turns on sooner.
F

When the ADT Carbon Monoxide Alarm detects potentially
dangerous levels of carbon monoxide, it ashes the red
light immediately and then sounds a loud alarm if the
carbon monoxide persists.
Alarm - Red LED
Power- Green LED
Fault - Amber LED
The below table shows how the alarm reacts to
different levels of carbon monoxide gas and exposure
time. At higher levels of carbon monoxide, the alarm
turns on sooner.
FUse

The rate of ashing of the red light indicates the level
of carbon monoxide. If your alarm sounds, follow the
instructions in the “What To Do” column.
Caution: The alarm only indicates the presence of carbon
monoxide gas in the area where the ADT Carbon Monoxide
Alarm is located. Carbon monoxide gas may be present in
other areas.
This carbon monoxide alarm is designed to detect carbon
monoxide gas from ANY source of combustion. It is not
designed to detect smoke, re or any other gas.
WARNING: Actuation of your carbon monoxide alarm
indicates the presence of carbon monoxide (CO) which can
KILL YOU.
Use
The following symptoms are related to CARBON
MONOXIDE POISONING and are to be discussed with
ALL members of the household:
Many cases of reported CARBON MONOXIDE POISONING
indicate that while victims are aware they are not well,
they become so disoriented they are unable to save
themselves by either exiting the building or calling for
assistance. Young children and household pets are
typically the rst affected.
• Medium Exposure: Severe throbbing headache,
drowsiness, confusion, fast heart rate.
• Mild Exposure: Slight headache, nausea, vomiting,
fatigue (often described as u-like symptoms).
• Extreme Exposure: Unconsciousness, convulsions,
cardiorespiratory failure, death.
