Sangoma S205 User manual

s205 IP Desk Phone
We reserve the right to improve or change the product and the user guide without notice.
Copyright © 2017 SANGOMA TECHNOLOGIES.
Completed with FCC Part 15 Standards
FCC Part 15 Class B
FCC Statement:
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired
operation.
2. Changes or modications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
*RF warning for Mobile device:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
IC Caution
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two
conditions: (1) This device may not cause interference, and (2)
This device must accept any interference, including interference
that may cause undesired operation of the device.
This device is compliant with Power over Ethernet (PoE) 802.3af Class 3 and can therefore be powered from
a PoE compliant switch or hub. For customers requiring AC power, AC to DC adapters can be purchased
separately from Sangoma. Alternatively, if you want to source your own power supply, the specications must
meet the 5V / 1.2A input rating. If the wrong power supply is used and the unit is damaged, the warranty will
be void.

Phone Layout
Phone Assembly and Connections
1. Headset connection
2. Network port to connect a laptop or desktop computer (10/100 Mbps Connection)
3. Handset port
4. LAN Network Connection - Power-Over-Ethernet (PoE).
Note* If your Network provides Power-Over-Ethernet, the Phone Power supply
(labeled #5 ) is not required.
5. Power Supply Connection. *If the Phone is connected to a Power-Over-Ethernet
connection the power supply is not required
6. Stand. Insert the connectors on the stand into the stand slots on the rear of the
phone, then slide to lock in place
Configuration
For a full list of configuration methods please visit:
https://wiki.sangoma.com/display/PHON/Phones+Home
Network Details
Finding IP address:
Press the “Menu” >“Status” >“Information” soft keys to get its IP address (xx.xx.xx.xx).
Setting Network information:
Press “Menu” >”Setting” >”Advanced Settings” (Default password is “admin”)
Power Indicator
Soft keys
Navigation Keys
Volume Keys
Mute
Speaker
Alphanumeric
Keypad
Message
Headset
Transfer
Redial
line keys
Under low angle position Under Anther Position
Notice
When you want to change from the low angle position to another position,
please take out the hookswitch then rotate it 180 degrees then slide it
back into its groove.
1
Internet
23
4
5
6
