Santos 11 Operating instructions

SANTOS: Instruction and Maintenance Manual
98111 US 3.0 - 05 2007 1 / 13 www.santos.fr
SANTOS :
140-150 AVENUE ROGER SALENGRO
69120 VAULX-EN-VELIN (LYON) - FRANCE
TÉL. [phone] - FAX [phone] -
TELECOPIE 33 (0) 478 26 58 21
E-Mail :[email protected] www.santos.fr
CITRUS JUICERS Nos. 11 - 38 - 52
USER AND MAINTENANCE MANUAL
!
IMPORTANT: documents included in this manual to be kept:
•"CE" COMPLIANCE DECLARATION
•WARRANTY CERTIFICATE
ORIGINAL VERSION
N°52
N°38
N°11
Coffee grinders - Fruit juicers - Mixers - Blenders - Drinks dispensers - Planetary mixers
Cheese graters - Ice crushers - Mincers - Vegetable slicers – Dough mixer
Moulins à café - Presse-fruits - Mixers - Blenders - Distributeurs de boissons - Batteurs
mélangeurs - Pétrin - Râpes à fromage - Broyeurs à glaçons - Hache-viande - Coupe-légumes
MODELES DEPOSES FRANCE ET INTERNATIONAL
INTERNATIONALLY PATENTED MODELS

SANTOS: Instruction and Maintenance Manual
CONTENTS
“CE” COMPLIANCE DECLARATION..................................................................................3
IMPORTANT SAFEGUARDS..............................................................................................4
IMPROPER USE..............................................................................................................4
ELECTRICAL CONNECTION:.........................................................................................4
USING FOR THE 1st TIME:.............................................................................................4
RECYCLING THE PRODUCT AT THE END OF ITS SERVICE LIFE .............................5
YOUR CITRUS JUICER Nos. 11- 38 - 52 ...........................................................................6
Using the CITRUS JUICER.................................................................................................6
USING:.............................................................................................................................6
CLEANING:......................................................................................................................6
MAINTENANCE...............................................................................................................7
Spare parts ......................................................................................................................7
TROUBLESHOOTING.........................................................................................................7
The appliance does not start:.......................................................................................7
The appliance stops due to motor overheating.............................................................7
The appliance stops further to an overload: .................................................................7
TECHNICAL SPECIFICATIONS .........................................................................................8
ELECTRICAL WIRING DIAGRAMS.................................................................................9
Wiring diagram 220-240V 50/60Hz..................................................................................9
Wiring diagram 220-240V 50/60Hz................................................................................10
Wiring diagram 100-120V 50/60Hz................................................................................11
FIGURES.......................................................................................................................12
WARRANTY CERTIFICATE ............................................................................................13
APPLIANCE IDENTIFICATION PLATE ..........................................................................13
98111 US 3.0 - 05 2007 2 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
“CE” COMPLIANCE DECLARATION
THE MANUFACTURER:
SANTOS SAS - 140-150, Av. Roger SALENGRO 69120 VAULX-EN-VELIN (LYON)
FRANCE
HEREBY DECLARES THAT THE MACHINE DESIGNATED ON THE IDENTIFICATION
PLATE AFFIXED:
•UNDER THE APPLIANCE,
•ON THE WARRANTY CERTIFICATE ON THE LAST PAGE OF THIS MANUAL,
COMPLIES WITH THE PROVISIONS OF THE "machines" DIRECTIVE AS MODIFIED
(Directive 98/37/CEI)
AND THE NATIONAL LEGISLATION TRANSPOSING IT.
IT ALSO COMPLIES WITH THE PROVISIONS OF THE FOLLOWING EUROPEAN
DIRECTIVES:
No. 73/23 dated 19/02/73 (Low voltage directive)
No. 89/336 (CEM directive)
No. 2002/95/CE (RoHS directive)
No. 2002/96/CE (WEEE directive)
The machine complies with the provisions of the following harmonised European
standards:
EN ISO 12100 -1 and 2: 2004 - Machine safety devices - General design principles
EN 60204-1: 2006: Machine safety devices - Machine electrical equipment -General
regulations
EN 60335-1: 2002 - Safety of household and similar electrical appliances
SIGNED IN VAULX-EN-VELIN ON: 01/05/07
SIGNATORY'S TITLE: CHIEF EXECUTIVE OFFICER
SIGNATORY'S NAME: JACQUES FOUQUET
SIGNATURE
98111 US 3.0 - 05 2007 3 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
IMPORTANT SAFEGUARDS
When using, cleaning or maintaining the machine, always follow these instructions:
Read all instructions
Note: You will find it easier to understand the next few paragraphs if you refer to
the diagrams at the end of this manual.
IMPROPER USE
1. Do not use this appliance to press any food other than limes, lemons, oranges
and grapefruit.
2. The appliance should neither be cleaned in a jet of water nor with a high
pressure spray.
! 3. The base (4) must not be immersed in water.
4. For electrocution risk protection reasons, never plunge the base into water or
any other liquid.
5. Unplug the appliance before carrying out any work on it: cleaning, maintenance
or repair.
6. The use of spare parts other than certified SANTOS original parts is prohibited.
ELECTRICAL CONNECTION:
The appliance is available in with a choice of two voltages for the power supply
•220-240V 50/60 Hz single phase
•110-120V 50/60 Hz single phase
Line protection: the appliance should be connected to a standard 2-pole + earth electric
socket. The installation should be fitted with an RCD and a fuse rated at 16A. The
appliance must be earthed
CARE:
•Before connecting the machine, check that the mains electrical voltage is the
same as the voltage for your appliance. Its value is shown:
¾either on the identification plate under the machine.
¾or on the identification plate on the last page of this manual.
•If the power cable (10) is damaged, it should be replaced by a special
assembly available from approved SANTOS dealers or from SANTOS.
!
CARE: Make sure that the on / off switch (6) is on 0 position before plugging the power
cord (7) into the mains supply socket (Fig.A).
USING FOR THE 1st TIME:
98111 US 3.0 - 05 2007 4 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
Carefully clean all parts of the machine in contact with the food (Fig. A).
•Remove the anti-splash dome (8) {model no 52}.
•Remove the cone (1) by pulling it upwards.
•Remove the bowl (2), the pulp grating (9) {model no 52} and the trim (3) {model nos.
11 and 38}.
•Wash the parts with a standard washing up liquid or in the dishwasher.
RECYCLING THE PRODUCT AT THE END OF ITS SERVICE LIFE
This equipment is marked with the selective sorting symbol relating to
wastes from electrical and electronic equipment. It signifies that this product
should be taken over by a selective collection system conforming to the
Guideline 2002/96/EC (WEEE) – part Professional Equipment – so that it
can be either recycled or dismantled in order to reduce any impact on the
environment.
For more information, please contact your Retailer or the SANTOS.
For eliminating or recycling components of equipment, please contact a specialized
company or contact SANTOS.
The electronic products not undergoing a selective sorting are potentially dangerous for
the environment.
The damaging materials should be eliminated or recycled according to the regulations in
force.
98111 US 3.0 - 05 2007 5 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
YOUR CITRUS JUICER Nos. 11- 38 - 52
•Citrus juicers nos. 11 – 38 – 52 are especially designed for bars, cafés, hotels,
restaurants, cocktail bars, institutions, fresh fruit juice bars, etc.
•The appliances nos. 11 and 38 are comprised of an aluminum motor unit, a juice
bowl and 3 engineered plastic pressing cones (2 pressing cones for model N°38).
•The appliance no. 52 is comprised of an aluminum motor unit, a powerful motor for
intensive use, a stainless steel bowl, 3 plastic pressing cones and a plastic anti-
splash dome.
•Citrus juicers nos. 11 – 38 – 52 are designed to press limes, lemons, oranges or
grapefruit.
•They are ideal for preparing: fresh lemon, orange or grapefruit juice or as a basis for
preparing fruit cocktails.
Using the CITRUS JUICER
USING:
Caution: the fruits used must be washed carefully before being pressed.
Assembly and preparation:
1. Place the trim (3) on the bowl (2) {models nos. 11 and 38}.
2. Place the bowl (2) on the base (4).
3. Place the pulp grating (9) in the bowl.
4. Place the cone (1) on the motor shaft (5).
5. Place the anti-splash dome (8) on the bowl (2) {model no 52}.
6. Cut the citrus fruit in two halves.
7. Place a glass level with the spout on the bowl (2).
8. Start the appliance by putting the On / Off switch (6) on "1".
9. Press the citrus fruit halves one after the other.
10.When you have finished using it, stop the appliance by putting the On / Off switch
(6) on "0".
CLEANING:
IMPORTANT :
•In every case, stop the appliance and unplug the appliance’s power cord
(7).
It is recommended to clean the appliance as soon as you have finished using it.
Cleaning will be easier if you do not wait until the pulp has dried in the bowl (2), on the
anti-splash dome (8), the cone (1) or the pulp grating (9).
The base (4) is to be cleaned with a soft damp sponge, then dried.
98111 US 3.0 - 05 2007 6 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
MAINTENANCE
Before any servicing of the appliance, it is essential to unplug the appliance from the
mains supply (7).
This machine requires no particular maintenance because the bearings are lubricated for
life.
If servicing is necessary to replace any parts such as the electrical components or any
others, refer to the list of components (see the exploded view at the end of the manual).
Spare parts
IMPORTANT:Use of spare parts other than certified original SANTOS
parts is prohibited
!
For all spare part orders (see references in the exploded view at the end of the manual),
state:
¾the type,
¾the machine serial number and
¾the electrical specifications (16)
recorded under the machine.
TROUBLESHOOTING
Identifying the cause of appliance stoppage precisely.
The appliance does not start:
•Check: the mains supply, the condition of the power cord (7).
The appliance stops due to motor overheating:(the motor unit is hot)
The motor is protected by a built-in thermal cutout. In the event of overheating, the motor
stops.
•Set the On / Off switch (6) to 0position, disconnect the plug (7).
•Wait until the motor cools down (20 to 45 minutes), reconnect the plug (7) then press
the On / Off switch (6) (position 1).
If the problem persists, switch off the power supply to the appliance (unplug the cord from
the mains socket (7)) and call in the maintenance service or contact a SANTOS-approved
dealer.
The appliance stops further to an overload:
If the motor stalls (due to excessive pressing), it can heat very quickly and stops by
overload protection.
98111 US 3.0 - 05 2007 7 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
TECHNICAL SPECIFICATIONS
Model N° 11 N° 38 N° 52
Supply voltage .(V) 220-240 100-120 220-240 100-120 220-240 100-120
Frequency (Hz) 50/60 50/60 50/60 50/60 50/60 50/60
Motor: Nominal
Power input (W) 130 155 130 155 230 260
Speed :
(rpm) (rpm) 1450 to 50Hz 1700 to 60Hz 1450 to 50Hz 1700 to 60Hz 1450 to 50Hz 1700 to 60Hz
Dimensions : Height (mm) 350 350 480
Width (mm) 200 200 230
Depth (mm) 300 300 300
Clearance height beneath
the spout (mm) 125 135 200
Weight: Net weight (kg) 5 5 10
Packaged weight (kg) 5.6 5.6 11
Noise:
(
2
)
(
dBA
)
65 65 65
(1) These ratings are provided as a rough guide. The exact electrical specifications can be found
on the rating plate.
(2) Noise level measured in sound pressure appliance in operation 1 m from its axis in accordance
with standard EN 31201.
MARK Description
1 Pressing cone
2 Bowl
3 Trim
4 Base
5 Motor shaft
6 On / off switch
7 Plug / power supply cord
8 Anti-splash dome
9 Pulp grating
98111 US 3.0 - 05 2007 8 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
98111 US 3.0 - 05 2007 9 / 13 www.santos.fr
ELECTRICAL WIRING DIAGRAMS
Models nos. 11 and 38:
Wiring diagram 220-240V 50/60Hz
Blue
On / Of
f
White 180
White 180
4
Green/Yellow
1
2 5
Black
Capacitor
Black
White
MBlue
1x240
1x340
~
Brown

SANTOS: Instruction and Maintenance Manual
Model no 52:
Wiring diagram 220-240V 50/60Hz
Blue
On / Of
f
White 240
White 240
4
Green/Yellow
1
2 5
Black
Grey
White
M
Y
ellow
2x240
~
Brown
98111 US 3.0 - 05 2007 10 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
Models nos. 11, 38 and 52:
Wiring diagram 100-120V 50/60Hz
White
White 240
White 240
Green/Yellow
1
2 5
Black
Capacitor
Red
White
M
Y
ellow
2x240
~
Black
On / Of
f
4
98111 US 3.0 - 05 2007 11 / 13 www.santos.fr

SANTOS: Instruction and Maintenance Manual
98111 US 3.0 - 05 2007 12 / 13 www.santos.fr
FIGURES
4
7
5
2
9
1
6
6
6
4
5
2
3
9
Fig. A
8
7
1
Model N°52
Model N°11
or
Model N°38

SANTOS: Instruction and Maintenance Manual
WARRANTY CERTIFICATE
WARRANTY
This appliance is guaranteed for twelve months from the date of manufacture appearing
on the identification plate.
The guarantee is strictly limited to the free replacement of any original part acknowledged
by us as being defective as a result of a fault or a manufacturing defect and identified as
belonging to the appliance in question.
It does nor apply to damage resulting from an installation or use which does not comply
with the instructions supplied with each appliance (user manual) or in the event of an
obvious lack of maintenance or non-observance of basic electrical safety rules.
All part replacements under warranty are made after return of the defective part to our
workshops carriage paid, accompanied by a copy of this warranty certificate on which the
serial number of the appliance is shown.
All appliances have an identification plate bearing a serial number identical to that on this
warranty certificate.
In the event of serious damage which is deemed only to be repairable in our workshops,
and after agreement from our services, all appliances under warranty are to be dispatched
by the client carriage paid. If the appliance is repaired outside the warranty, the forwarding
and return transport is the responsibility of the client. Parts and labour are invoiced at the
prices in force (spare parts price - hourly labour cost). All repairs will be subject to a prior
estimate which should be agreed before repair.
In the event of a dispute, the Courts for the manufacturer's area (Lyon) alone have
jurisdiction.
APPLIANCE IDENTIFICATION PLATE
SPECIMEN
For all documents not supplied with
the appliance.
Printed, Faxed and Downloaded
98111 US 3.0 - 05 2007 13 / 13 www.santos.fr
