Santos Juicers N10 User manual

AUTOMATIC CITRUS JUICER
WITH LEVER #10
The genuine commercial
citrus juicer since 1954.
Ideal for hotels, bars, restaurants.
Internationally Patented Models
www.santos.fr

EASY TO USE
• The automatic citrus juicer with lever #10 is the ideal product to make juice by glass
• It is equipped with a heavy duty and quiet asynchronous motor
• For use everywhere you need a fresh squeezed citrus juice: juice bars, health food stores,
hotels, bars, restaurants, cafeterias, ice cream shops, institutions, hospitals…
Removable perforated
strainer
stainless steel
Stainless steel deector
Protects from any juice ejection
Stainless steel cup
Special clutch system
when you press.
Instant start and stop.
Stainless steel bowl
Height of the spout:
135 mm (5’’)
Removable drip tray
Heavy duty and quiet
asynchronous motor
High speed
Chromed or painted (grey)
motor base
Articulated lever
AUTOMATIC CITRUS
Output: 30 l /h

THE PROFESSIONAL ART OF JUICING SINCE 1954
In accordance with the following regulations:
Machinery directive 2006/42/EC
Electromagnetic compatibility 2004/108/EC
‘‘Low voltage’’ directive 2006/95/EC
RoHs directive 2002/95/EC
Regulation 1935/2004/EC (contact with food)
Harmonized European standards:
EN ISO 12100 - 1 AND 2: 2004
EN 60204-1: 2006
EN 60335-2-64: 2004: commercial electric kitchen machines
CE (European standards), UL (USA & Canada), NSF (USA)
Thermal safety
Motor protected by internal thermal detector.
Electrical safety
• On / Off interlock switch is waterproof.
• All mechanical parts are ground (earth) connected.
• All equipment is perfectly controlled after assembly
(special electrical testing bay).
Acoustic safety
The asynchronous motor with clutch system is particularly silent.
Hygiene
All removable parts can be put in a dishwasher or easily cleaned
with hot soapy water (NSF approved).
Motor
Single phase: 100-120V - 50 /60 Hz - 260W - NSF, CE, UL
220-240V - 50 / 60 Hz - 230W - CE
Speed: 1 500 rpm (50 Hz)
1 800 rpm (60 Hz)
Weight
Net: 9.2 kg (20.3 lbs)
Shipping: 10 kg (22 lbs)
TECHNICAL SPECIFICATIONS
SAFETY, STANDARDS, HYGIENE
JUICER WITH LEVER #10
APPLIANCE
W : 200 mm (8’’)
D: 300 mm (12’’)
H: 380 mm (15’’)
www.santos.fr
PRODUCT: 2-YEAR WARRANTY | MOTOR: 5-YEAR WARRANTY
15 l /h 30 l /h 30 l /h 40 l /h 30l /h 50 l /h
38 C 10 C
71 C 11 52 G 70
You will nd the citrus juicer of your need to make citrus juices either in a glass or in a jug.
Equipped with powerful asynchronous motors,these appliances allow you to squeeze all types of citrus:lime,lemon,orange or grapefruit.
All of these juicers are easy to use and clean: all the parts which are in contact with the fruits are removable.
SHIPPING BOX
W: 250 mm (10’’)
D: 340 mm (13’’)
H: 440 mm (17’’)
H
WD

SANTOS
140-150 avenue Roger Salengro – 69120 –Vaulx-en-Velin (Lyon) – FRANCE – Tel. [phone] – Fax [phone]
Website: www.santos.fr – Email: [email protected]
AUTOMATIC CITRUS JUICER
WITH LEVER #10
www.santos.fr
03 / 2015 - V8 | cultivescence.com
