Santos Lever Juicer Evolution 70 User manual

LEVER JUICER EVOLUTION #70
Ideal appliance to make fresh fruit juices
(lemons, oranges, and grapefruits)
Internationally patented models
www.santos.fr

SINCE 1954
The lever juicer evolution #70 is the ideal product to make fresh juices from lime,lemon,orange and grapefruit.Thanks
to its powerful motor and its high output (50l/h) it is adapted to intensive use.
For use everywhere you need a fresh squeezed citrus juicer: juice bars, health food stores, hotels, bars, restaurants, cafete-
rias, ice cream shops, institutions, hospitals…

• Allows you to make citrus juices either in a glass or in a jug
• Equipped with  lime, lemon, orange or grapefruit
•  when we push the lever (patented clutch system)
•  removable stainless steel bowl, cone and cup

stainless steel cup (1/4 turn)
 stainless steel
bowl and squeezer
 drip tray
220 mm (8.6’’)
For all kinds of glasses and jugs
Ergonomic, sturdy and easy
to clean articulated lever
Stainless steel deector
protects from any juice ejection

for automatic start/stop of the cone
On / off waterproof switch
Heavy duty and quiet


EVOLUTION #70LEVER JUICER
Output: 50 l /h VIDEO 2-YEAR WARRANTY5-YEAR WARRANTY
Glass-raiser available
on demand

THE PROFESSIONAL ART OF JUICING SINCE 1954

• Machinery directive 2006 / 42 / EC
• Electromagnetic compatibility 2004 / 108 / EC
• “Low voltage” directive 2006 / 95 / EC
• Regulation 1935 / 2004 /EC (contact with food)
• RoHS directive 2002 / 95 / EC

• EN ISO 12100-1 and 2: 2004 ; NF EN 60204-1: 2006
• EN 60335 -2-64: 2004 Commercial electric kitchen machines
• CE (Europe), NFS (USA), UL (USA) and cUL (Canada), KC (Korea)
• GS (Germany) checked by the LNE (National Test Laboratory)

• On / Off interlock switch in waterproof
• All mechanical parts are ground connected
• All equipment is 100% tested at the end of assembly
(special electrical testing bay)

Motor protected by internal thermal detector.

The asynchronous motor is particularly silent.

All removable parts can be put in a dishwasher or easily
cleaned with hot soapy water.

Single phase: 100 - 120 V - 50 /60 Hz – 350 W – NSF, UL, CE
220 - 240 V - 50/ 60 Hz – 300 W – CE, GS, KC
Speed: 1 500 rpm (50 Hz)
1 800 rpm (60 Hz)

Net: 13.5 kg (30’’)
Shipping: 14.5 kg (32’’)
TECHNICAL SPECIFICATIONS

EVOLUTION #70LEVER JUICER
APPLIANCE SHIPPING BOX
W : 240 mm (9’’)
D: 400 mm (16’’)
H: 490 mm (19,3’’)
www.santos.fr
15 l /h 30 l /h 30 l /h 40 l /h 30l /h 50 l /h
38 C 10 C
71 C 11 52 G 70

Equipped with powerful and reliable commercial motors, they are the perfect appliances to quickly squeeze any kind of citrus,
from small limes to big grapefruits. All of these juicers are very easy to clean: parts in contact with fruits are removable.
2-YEAR WARRANTY5-YEAR WARRANTY
W: 280 mm (11’’)
D: 440 mm (17’’)
H: 550 mm (22’’)
DW
H

SANTOS
140-150 avenue Roger Salengro – 69120 –Vaulx-en-Velin (Lyon) – FRANCE – Tel. [phone] – Fax [phone]
 www.santos.fr – [email protected]
LEVER JUICER EVOLUTION #70
www.santos.fr
04 / 2013 V6 | cultivescence.com
