Saso PA-4510P User manual

1. Parts Description & Coverage and Range
Passive Infrared Detector
PA-4510P
Installation Instructions
Please install the detector in the
desirable detection site.
2. Cautions on Installation
Please avoid installing it where
electric noise and vibration is
prevalent.
Please avoid direct sunlight to the
detector. Avoid installing it at outdoor. (indoor only)
3. Installation
Notice : This detector is designed to detect an intruder and to sound
alarm when detected; it is not to prevent burglary. We are not responsible
for damage or losses from accident, theft, natural calamity, misuse,
abnormal use, improper installation and bad maintenance.
4. Wiring
- TERMINAL
- Protection Range
Top view
1) Separate the cover
from body 4) Close the body cover.2) Fix it where you want to.3) Connect wires correctly to the plate of terminal.
.
84˚
- LED(ON/OFF) - ALARM(CONTACT)
※CAUTION
Do not connect power to alarm terminal
Side view
ALARM - +12VTAMPER
ON
OFF
NC
NO

5. Troubleshooting
6. Specification & Dimension
Model No. PA-4510P (PET Type)
Detection Passive Infrared motion detecting
Detection Range Stereoscopic alert / alert distance : 10m / 84˚
Zone
Composition 37 Pairs (74 Zone)
Voltage DC 8 ~ 18V (Polarity)
Current 20mA (MAX)
Alarm Output Non-voltage contact (N.C / N.O) Contact Volume: AC/DC 30V 0.2A Max
Protection Resistance : 18Ω
Alarm LED (RED) LED On when warming up / LED off when setting /
LED on when detecting
Tamper Output Non-voltage contact output (N.C)
Contact Volume: AC/DC 30V 0.2A Max
Temperature -20℃~ 60℃
Installation Site Indoor
PET Function Under 10kg
Material COVER, BASE: ABS Resin, LENS: PE Resin
Dimension 102 x 64 x 47mm
Weight 68g
Installation Height
(2.5m)
Detection Distance (m)
3m 5m 7m 10m
Angle 20°10°5°0°
※Respective angels and detection distance when using optional bracket (B-4001)
<Sensitivity Adjustment>
▶H (High Sensitivity) : For more sensitive detection
▶L (Low Sensitivity) : For less sensitive detection
※Notice : This sensor is for indoor use only. Please do not install it in outdoor
- Sensitivity Adjustment
Problem0 Cause Solution
When LED is not turned on, Lines of electricity source are cut. Check the lines
Electricity source is not correct. Check it to DC 8 ~ 18V
No contact point although it is set Cutting lines or abnormality of inner circuit Check the lines of connection
No contact point when detected Cutting lines or abnormality of inner circuit Check the lines of connection
LED is not working when detected Cutting lines, LED broken down or
abnormality of inner circuit. Check the lines of connection
When there is abnormal working
There is dirt on the cover Remove dirt with soft cloth
When it is exposed to direct ray of light Install it to another place or block the light
When it can’t detect normally Adjust the scope of alert
HI
LOW
