The VERSA-LCDM-WRL wireless keypad enables operation and programming of the control panels
of VERSA (firmware version 1.04 or newer), VERSA IP and VERSA Plus series. The device is
designed for work within the ABAX two-way wireless system. It is supported by the ACU-120 /
ACU-270 controller connected to the VERSA / VERSA IP / VERSA Plus control panel.
The VERSA-LCDM-WRL keypad is not supported by the ARU-100 radio signal repeater.
Fig. 1. VERSA-LCDM-WRL keypad.
1. Features
Two-way encrypted radio communication in the 868 MHz frequency band.
Display 2 x 16 characters with backlight.
LEDs indicating the state of partitions and system.
12 keys, bearing designations according to telephone standard and intended for entering data.
4 additional keys for menu navigation and arming/disarming.
Backlit keys.
Built-in proximity card reader.
Built-in sounder.
Tamper contact reacting to the enclosure opening or detaching from the wall.
Power supply: two CR123A 3 V batteries.

2 VERSA-LCDM-WRL SATEL
2. Description
Operating modes
The keypad can work in two modes:
active mode – started by pressing any key. Additionally, the active mode can be started automatically
when an alarm occurs or an entry delay, an exit delay or an auto-arming delay begins (see
description of the
W AKE - UP parameter, section “Settings stored in ABAX system controller” p. 5).
In this mode, the keypad operates in much the same way as the LCD wired keypad. The display is
ON and the backlight, LED signaling and sound signaling are active.
inactive mode – is started:
– after 20 seconds since the last key press,
– after preset time, if the active mode was started automatically (see description of the
W AKE - UP
parameter, section “Settings stored in ABAX system controller” p. 5).
The purpose of the inactive mode is to save energy. The display is off. Backlight, LED indication
and sound signaling are disabled (if a time different from 0 is preset for the
W AKE - UP parameter,
CHIME from zones will be signaled).
Support for proximity cards
The built-in proximity card reader enables the system to be operated by using proximity cards (any
125 kHz passive transponder in the form of a card, tag, etc.). If the alarm system is not to be operated
by using the proximity cards, the reader can be disabled (thus reducing the battery consumption).
Periodic transmissions
Every 15 minutes, the keypad sends a periodic transmission. The purpose of such transmissions is to
monitor presence and condition of the keypad.
Battery status control
The keypad controls the status of the batteries. If the voltage is lower than 2.75 V:
low battery information is sent during each periodic transmission,
on entering the active mode, a low battery message will be displayed (the message will specify
which battery is to be replaced – the battery designation can be found on the electronics board,
after opening the enclosure).
The battery life depends on how the keypad is used. The more frequently the active mode is
entered, the quicker the batteries will be depleted.
3. Installation
There is a danger of battery explosion when using a different battery than
recommended by the manufacturer, or handling the battery improperly.
Be particularly careful during installation and replacement of the batteries. The
manufacturer is not liable for the consequences of incorrect installation of the battery.
The used batteries must not be discarded, but should be disposed of in accordance
with the existing rules for environment protection.
The keypad is designed for indoor installation. The place of installation should be readily accessible to
the system users. When selecting the installation location, take into account the communication range
of the ABAX system.
1. Open the keypad enclosure (Fig. 2).
2. Install the batteries and add the keypad to the wireless system (see: “Adding the keypad to the
wireless system”).
3. Put the cover on the catches and snap the enclosure shut.

SATEL VERSA-LCDM-WRL 3
Fig. 2. Opening the enclosure.
4. Place the keypad in the location intended for its installation.
If you want to hold the keypad in your hand when checking the radio signal level, grab the
device from its left side (on its right side, there is the antenna, which must not be covered).
5. Check the level of signal received from the keypad by the ACU-120 / ACU-270 controller. If the
signal level is lower than 40%, select another place for installation. Sometimes, it is sufficient to
shift the device ten or twenty centimeters to obtain a considerable improvement in the signal
quality. Only after the optimal level of radio signal is achieved can you proceed to the next step.
6. Open the keypad enclosure (Fig. 2).
7. Place the enclosure base against the wall and mark location of the mounting holes.
8. Drill the holes in the wall for wall plugs (screw anchors).
9. Using wall plugs (screw anchors) and screws, secure the enclosure base to the wall. Select wall
plugs and screws specifically intended for the mounting surface (different for concrete or brick
wall, different for plaster wall, etc.). When installed, the device must withstand a pull-off force of at
least 50 N.
10. Put the cover on the catches and snap the enclosure shut.
11. Lock the cover using screws.
3.1 Adding the keypad to the wireless system
Before adding the keypad, make sure that the controller switch 8 is set to ON position.

4 VERSA-LCDM-WRL SATEL
You can add the wireless keypad to the ABAX system by using either a computer with DLOADX
program installed, or an LCD keypad. The controller allows for registering of up to 6
VERSA-LCDM-WRL keypads. If no wired keypad is connected to the control panel, you can only add
the first wireless keypad using the DLOADX program (to establish communication between the
program and the control panel, you must start the service mode “from pins” – refer to the control panel
programming manual).
3.1.1 DLOADX program
You can add wireless keypads in the “VERSA – Structure” window, “Hardware” tab, after clicking on
the name of ABAX system controller on the list of devices, and then on the “LCD-WRL” tab (see:
Fig. 3p. 5).
1. Click on the “Read” button to read the data related to wireless keypads from the controller (these
data are not read after clicking on the button in the main menu).
2. Click on the “New device” button. The “
New wireless dev.” window will open.
3. In the “Serial number” field enter the 7-digit serial number of the added device. The serial number
can be found on the electronics board.
4. In the “Address” field, select which address is to be assigned to the keypad to be added.
5. Press any button on the keypad or open its tamper switch.
6. The message will confirm that a keypad has been added (unless you have entered an invalid
serial number, of which you will be informed by a message). The name assigned to the keypad
will be displayed. You can change it.
7. Click “OK” (to cancel adding the keypad, click on the “Quit” button). The “
New wireless dev.”
window will close. The new keypad will appear in the table, “LCD-WRL” tab, as well as on
the list of expanders .
8. Click on the “Write” button to write the new wireless keypad data to the controller (these data will
not be written after clicking on the button in the main menu). The new keypad data will be
automatically written to the control panel.
3.1.2 LCD keypad
You can add wireless keypads in the service mode by means of the N EW DEVICE function ( S ERVICE
MODE
 2. H ARDWARE  1. K PDS . & EXPS . 3. W IRELESS MOD .  1. N EW DEVICE ).
1. Having started the function, enter the 7-digit serial number of the added keypad and press the
key. The serial number can be found on the electronics board.
2. When the “Open device tamper” message is displayed, press any key on the keypad or open its
tamper switch.
3. Information on the keypad to be added will be displayed (if nothing happens, it can mean that you
have entered an invalid serial number – if this is the case, press to return to the submenu).
Press to confirm your intention to add a keypad.
4. Using the and keys, select the address which is to be assigned to the keypad to be
added, and then press . The wireless keypad will be added.
5. The name assigned to the keypad will be displayed. You can change it. Press to save the
name.
6. In the next step, you can configure the settings stored in the ABAX system controller (see: p. 5).
3.2 Removing the keypad from the wireless system
3.2.1 DLOADX program
You can remove the wireless keypads in the “VERSA – Structure” window, “Hardware” tab, after
clicking on the name of ABAX system controller on the list of devices, and then on the “LCD-WRL” tab
(see: Fig. 3p. 5).
1. Click on the “Read” button to read the data related to wireless keypads from the controller.

SATEL VERSA-LCDM-WRL 5
2. Click on the wireless keypad you want to remove.
3. Click on the “
Delete” button. The “Confirm” window will open.
4. Click on the “Yes” button. The “Confirm” window will close.
5. Click on the “Write” button to save the changes to the controller and control panel.
3.2.2 LCD keypad
You can remove wireless keypads in the service mode by means of the R EMOVE DEVICE function
(
S ERVICE MODE  2. H ARDWARE  1. K PDS . & EXPS . 3. W IRELESS MOD .  3. R EMOVE DEVICE ).
1. Having started the function, use the and keys to select the keypad you want to
remove, and then press .
2. A prompt will appear on the display, whether the keypad is to be deleted (the keypad serial
number will be displayed). Press . The keypad will be deleted.
4. Configuring
You can configure the wireless keypad settings by using a computer with DLOADX program installed,
or an LCD keypad.
4.1 Settings stored in ABAX system controller
The settings can be configured:
DLOADX program: “VERSA – Structure” window “Hardware” tab “Expansion modules”
branch [ABAX system controller name]
“LCD-WRL” tab (see: Fig. 3),
Fig. 3. DLOADX
program: keypad settings stored in the ABAX system controller.
LCD keypad:
S ERVICE MODE  2. H ARDWARE  1. K PDS . & EXPS .  3. W IRELESS DEV .
2.
C ONFIG . DEVICE [wireless keypad name].
4.1.1 Description of parameters and options
Presence contr. – if this option is enabled, the keypad presence is being monitored. If there is no
transmission from the keypad for 1 hour, missing keypad will be reported.

6 VERSA-LCDM-WRL SATEL
Wake-up - maximum length of time for which the active mode can be started automatically. If you
enter a value different from 0:
– the active mode will be started automatically when an alarm occurs or an entry delay or an exit
delay begins,
– the CHIME from zones will also be signaled in the inactive mode.
If you enter 0, the active mode will not be started automatically.
If a value different from 0 is preset for the
W AKE - UP parameter, the keypad will be
awaiting for transmissions with information on events. As a result, the energy
consumption will be growing and the battery life will be considerably reduced.
Card reader – if this option is enabled, the card reader is supported.
4.2 Settings stored in the control panel
These settings are configured in exactly the same way, as for the wired keypad:
DLOADX program: “VERSA – Structure” window “Hardware” tab “Expansion modules”
branch [keypad name] (see: Fig. 4),
LCD
keypad:
S ERVICE MODE  2. H ARDWARE  1. K PDS . & EXPS .  2. S ETTINGS [keypad
name].
4.2.1 Parameters and options
Given in the square brackets are the names of parameters and options presented on the keypad
display.
Name – individual name of the keypad (up to 16 characters).
Tamper signaled in part. [Tamper in p.] – partition in which tamper alarm will be triggered if the
keypad tamper switch is opened or the keypad is not present.
CHIME signal of zones [Zone chime] – the keypad can audibly signal violation of selected zones. If
the zone is armed, violation will not trigger the CHIME signal.
The wireless keypad signals the CHIME from zones not more frequently than once every 30
seconds. In the inactive mode, the CHIME from zones is only signaled if a value different from
0 is preset for the W AKE - UP parameter.
Sign. entry delay [Entry time sign.] – if this option is enabled, the keypad will audibly signal the entry
delay countdown. In the inactive mode, the entry delay is not signaled.
Sign. exit delay [Exit time sign.] – if this option is enabled, the keypad will audibly signal the exit
delay countdown. In the inactive mode, the exit delay is not signaled.
Sign. alarms [Alarm signalling] – if this option is enabled, the keypad will signal the alarms audibly.
The alarm is signaled during the
K EYPAD ’ S ALARM TIME (refer to the control panel programming
manual). In the inactive mode, the alarms are not signaled. The alarms are not signaled, if the
G RADE 2 option is enabled in the control panel.
Quick arming – Partition 1 [Part.1 QuickArm] – if this option is enabled, quick arming (without user
authorization) of the partition 1 is possible. The quick arming is not possible, if the
G RADE 2 option
is enabled in the control panel.
Quick arming – Partition 2 Part.2 QuickArm] – if this option is enabled, quick arming (without user
authorization) of the partition 2 is possible. The quick arming is not possible, if the
G RADE 2 option
is enabled in the control panel.
Keys sound – with this option enabled, pressing the keypad keys is confirmed by beeps.
Sign. trbl in part. arm [Trbl.in part.arm] – if this option is enabled, the LED goes off after both
partitions are fully armed (if the option is disabled, the LED goes off after just one of the partitions
is armed in any mode).
Show code entering [Code entry ind.] – if this option is enabled, entering the code is presented on
the keypad display by asterisks.
Chime on/off – if this option is enabled, the chime signal can be enabled/disabled by means of the
key (the key is to be pressed for about 3 seconds).

SATEL VERSA-LCDM-WRL 7
Fig. 4. DLOADX
program: keypad settings stored in the control panel.
Quick control – if this option is enabled, the users can control the outputs by using the number keys.
When programming the control panel, the
15. C ONTROLLED outputs must be assigned to the keys
(refer to the control panel programming manual).
Sign. new trouble [New trbl.signal.] – if this option is enabled, the keypad will audibly signal
occurrence of any new trouble (additionally, the
T ROUBLE MEMORY UNTIL REVIEW option must be
enabled in the control panel – refer to the control panel programming manual). The signaling will
be turned off after reviewing the trouble with the 7.
S YSTEM STATE user function. In the inactive
mode, new troubles are not signaled. The new troubles will not be signaled, if the
G RADE 2 option
is enabled in the control panel.
Auto-Arm delay countdown [Autoarm signal.] – if this option is enabled, the auto-arm delay
countdown is signaled acoustically. In the inactive mode, the auto-arm delay countdown is not
signaled.
Arm mode review [Arm mode check.] – if this option is enabled, holding down the key for
about 3 seconds will display information on the partition status. The users cannot check the
partition status using the key, if the
G RADE 2 option is enabled in the control panel.
Date/Time format – the way how date and time will be presented on the display.
LCD backlight – the way how the display backlight will work in the active mode:
not present – disabled.
permanent 50% – enabled: brightness 50%.
permanent 100% – enabled: brightness 100%.
auto 0-50% – enabled: brightness 50%.

8 VERSA-LCDM-WRL SATEL
auto 0-100% – enabled: brightness 100%.
auto 50%-100% – enabled: brightness 100%.
Keys backlight – the way how the keys backlight will work in the active mode:
not present – disabled.
auto – enabled.
permanent – enabled.
Alarm messages
Partitions [Part.alarm msg.] – if this option is enabled, messages on partition alarms will be displayed
(they contain the name of partition).
Zones [Zone alarm msg.] – if this option is enabled, messages on alarms from zones will be
displayed (they contain the name of zone). The zone alarm messages have the priority.
The messages will not be displayed, if the
G RADE 2 global option is enabled.
Alarms
PANIC alarm – if this option is enabled, pressing the key for approx. 3 seconds will trigger the
panic alarm.
silent [Silent panic] – if this option is enabled, the panic alarm triggered from the keypad will be a
silent one (without loud signal). The option is available, if the
PANIC ALARM option is enabled.
FIRE alarm – if this option is enabled, pressing the key for approx. 3 seconds will trigger the
fire alarm.
AUX. alarm [Medical alarm] – if this option is enabled, pressing the key for approx. 3 seconds
will trigger the auxiliary (medical) alarm.
Alarm 3 incorrect codes [3 wrong codes] – if this option is enabled, entering invalid code three times
will trigger the alarm.
The auto-backlight parameters do not affect the wireless keypad performance.
4.2.2 Volume
Fig. 5. DLOADX program: keypad volume settings.

SATEL VERSA-LCDM-WRL 9
Volume – volume level of the beeps generated during keypad operation (key pressing, confirmation
of performed operation, etc.).
Chime – volume level of the beeps generated after zone violation (CHIME).
Entry delay – volume level of the entry delay beeps.
Exit delay – volume level of the exit delay beeps.
Fire alarm – volume level of the fire alarm beeps.
Burglary alarm – volume level when signaling burglar, panic and auxiliary (medical) alarms.
Warning alarm – volume level when signaling warning alarms.
Trouble signaling – volume level when signaling troubles.
4.2.3 Proximity cards
Fig. 6. DLOADX program: settings for using the proximity cards.
Arming
Card hold-down – if you select this option, the user will have to bring the card close to the keys and
hold it still for about 3 seconds to arm the system.
Card read – if you select this option, the user will only have to bring the card close to the keys to arm
the system.
When configuring the keypad by using functions available in the service mode, use the
P ROX . CARD - ARMS option to define how to arm the system using the proximity card (option
enabled = C ARD READ ; option disabled = C ARD HOLD - DOWN ).
Card hold-down control outputs
If you have selected the
C ARD READ option, you can permit the users to toggle the 15. C ONTROLLED
type outputs (the output status will change after the card is brought close to the keys and held still for
about 3 seconds). Select the outputs the users will be allowed to control.

10 VERSA-LCDM-WRL SATEL
5. Operation
When in active mode, the wireless keypad enables operation and programming of the alarm system.
In order to enter the active mode, press any key on the keypad.
In addition to starting the active mode, pressing a key will also have other consequences, as
appropriate for the given key. The keypad will treat each key pressing exactly in the same
way.
In the active mode, the LCD wireless keypad works much in the same way as the LCD wired keypad.
Additionally, it enables the alarm system to be operated using a proximity card. For the way of using
the keypad, please refer to the control panel user and programming manuals. The manuals are
available in electronic form on the www.satel.eu website.
6. Specifications
Operating frequency band .................................................................................868.0 MHz ÷ 868.6 MHz
Radio communication range (in open area) ..........................................................................up to 500 m
Batteries .........................................................................................................................2 x CR123A 3 V
Standby current consumption, BT1 battery .............................................................................. 0.005 mA
Maximum current consumption, BT1 battery ................................................................................. 50 mA
Standby current consumption, BT2 battery .............................................................................. 0.001 mA
Maximum current consumption, BT2 battery (card reader disabled)............................................. 45 mA
Maximum current consumption, BT2 battery (card reader enabled) ............................................. 90 mA
Environmental class according to EN50130-5........................................................................................II
Operating temperature range ............................................................................................ -10°C...+55°C
Maximum humidity........................................................................................................................ 93±3%
Enclosure dimensions ...............................................................................................139 x 124 x 22 mm
Weight .............................................................................................................................................280 g
