CT Series Printers
www.satolabeling.com
Performance in a Compact Package
The CT printers pack the power of a high performance printer in a
compact design. With a 32-bit RISC CPU, 6 ips print speed, and
high-speed interface the CT’s offer outstanding performance in a
desktop design.
High Print Quality and Print Resolution
The CT printers offer superior print quality in direct thermal or thermal
transfer applications at 203 and 305 dots-per-inch.
Feature Rich To Satisfy Demanding Applications
With internal Ethernet and 802.11b wireless interfaces, the CT’s offer
great integration flexibility. For broad media handling the CT’s are
available with dispenser or cutter. The CT printers’ enclosure offers
high antimicrobial, and high-heat resistance.
HIGH PERFORMANCE DESKTOP THERMAL SOLUTION
CT high performance desktop
printers are ideal for a range of
applications, including:
Pharmacy Labeling
Wristband Printing
Asset Labeling
Retail Marking
Shipping/Receiving
Compliance Labeling
Healthcare
Performs best with
Labels & Ribbons

Printing Method
Print Resolution
Print Speed
Media Width
Max. Print Width
Min. Print Length
Max. Print Length
Max. Ribbon Size
Dimensions
Weight
Memory:
8 MB SRAM
2 MB Flash ROM
Processor:
32-BIT RISC
Media:
Roll-fed or fan-fold, die-cut or continuous
direct thermal (thermal transfer) labels, synthet-
ics, and tag stock with or without black mark,
gap, or notch.
Max. Caliper: 0.0075" (0.19 mm)
Max. Roll Diameter: 4.4" (110 mm)
Wind: Face-Out
Ribbon:
Max. Roll Diameter: 1.5" (39 mm)
Min. Core Diameter: 0.5" (12.7 mm)
Wind: Face-Out
Sensing:
Adjustable transmissive sensor for gap.
Reflective sensor for black mark. Automatic,
programmable setting of top of form. Label
present sensor - optional with label dispenser.
Ribbon-out sensor
Interface:
• IEEE1284, High-Speed, Bi-directional
• Serial RS232 (up to 57.6k bps)
• Ethernet - 10/100BaseT (internal)
• Wi-Fi - 802.11b (internal)
• USB adapter
Barcode Symbologies:
EElleemmeennttaarryy::
UPC-A, UPC-E, EAN-8, EAN-
13, Code 39, Code 93, Code 128, Codabar,
MSI, Bookland, Industrial 2/5, Interleaved
2/5, Matrix 2/5, Postnet, UCC/EAN 128,
RSS Composite Code
22--DDiimmeennssiioonnaall::
PDF417, Micro PDF417,
Truncated PDF417, Maxicode, Data Matrix,
QR Code
Fonts:
Bitmap - 12 proportional, mono-spaced and
outline fonts (Code table 858). Scalable
Internal CG Triumvirate®& CG Times®fonts.
Optional Downloaded TrueType®fonts, scala-
ble from 8 to 72 points.
Barcode & Font Formatting:
360° rotation of barcodes and text, charac-
ter expansion horizontally and vertically,
sequential numbering, form overlay for high-
speed editing of complex formats.
Graphic Support:
Printing & storage of .PCX, .BMP format,
SATO Hex/binary
Software:
Windows®Drivers (Windows®95, 98, ME,
NT4.0, 2000, XP)
“Label Gallery Free” - Label Software
Printer Utilities
Electrical Requirements:
115V/220V (± 10%), 50/60 Hz (± 1%)
Agency Certifications: CE, UL, CSA, TÜV
Environmental Requirements:
Operating: 41° to 104°F (5° to 40°C)
15-85% RH, non-condensing
Storage: 0° to 104°F (-20° to 40°C)
Max. 90% RH, non-condensing
EDS: 8kV
Optional Features:
Label Cutter (factory installed), Label
Dispenser (factory installed), Ethernet,
802.11b Wireless, Label Gallery Software,
Rewinder, External Keyboard
SATO Labeling Solutions America, Inc.
1440 Windham Parkway, Romeoville, IL 60446
Phone: [phone] Fax: [phone]
E-mail: [e-mail]
www.satolabeling.com
Network I/F Keyboard
© 2006SATO America, Inc. All rights reserved. Specifications subject to change without notice. Rev. 6/06Reorder #THM-002
THE BEST PERFORMING
COMPACT SPECIFICATIONS
Rewinder
Software
CT400 CT410
Direct Thermal/Thermal Transfer or Direct Thermal only
203 dpi (8 dpmm) 305 dpi (12 dpmm)
6 ips (150 mm/second) 4 ips (100 mm/second)
Max. 4.6” (118 mm) /Min. 1” (25 mm)
4.1” (104 mm)
0.6” (15 mm)
15.7” (400 mm)
4.33" (110 mm) x 325 ft. (100 m) - Face-Out
7.8” W x 9.1” D x 7.1” H
(198 mm W x 230 mm D x 181 mm H)
6.6 lbs (3 kg)
