GL408/412 e
www.satoamerica.com
• Emulations
• RFID Ready
• SATOnet CONNECTTM with
Ethernet or Wireless IF
• 3-Port Communication (STD):
USB, Parallel, Serial
• Up to 10 ips Print Speed
• Online Barcode Verication
Streamlined Features
• Aerospace
• Automotive
• Distribution
• Manufacturing
• Logistics
• Government
• Health Care
• Transportation
Industry Verticals
• Compliance Labeling
• Service Bureaus
• Shipping/Receiving
• Asset Tracking
• WMS
• Logistic Tracking
• Retail Labeling
• Laboratory
Industry Applications
The Power of Performance
Emulations*
Easy-To-Change
Printhead
Large LCD
Display Panel
RFID Designed
Printer
ZGL
DGL
PGL
TGL
IGL
950110126000000131

PRINTER MODEL GL408eGL412e
PRINT SPECIFICATIONS
Print Method Direct Thermal/Thermal Transfer
Print Resolution 203 dpi (8 dots/mm) 305 dpi (12 dots/mm)
Print Speed Up to 10 ips (254 mm/sec)
Max. Print Area 4.09" (104 mm) W x 98.98" (2514 mm) L
MEDIA SPECIFICATIONS
Sensor Type Adjustable Reflective Sensor (for use with pre-printed marks)
Adjustable See-Through Sensor (for die-cut labels with gap)
Media Type Roll and Fanfold, Paper, Labels, Synthetics
Media Size Width 0.87" (22 mm) - 5.04" (128 mm)
Length (Continuous) 0.24" (6 mm) - 15.63" (397 mm)
Length (Tear-Off) 0.67" (17 mm) - 15.63" (397 mm)
Thickness 0.002" – 0.0106" (0.06 mm – 0.268 mm)
Media Roll
Size
Outer Diameter Max. 10.43" (265 mm)
Inner Diameter 1.5" (38.1 mm) to 4" (101.6 mm)
Wind Orientation Face In or Face Out
Ribbon Width Max. 5.04" (128mm)
Length Up to 1476' (450 m)
Type Coated Side In or Out
FONT / SYMBOLOGIES
Font U, S, M, WB, XS, XU, XM, XB, XL, OUTLINE, OCR-A, OCR-B, WL,
CG Times, CG Triumvirate
Barcode
Symbologies
Linear UPC-A/E, UCC/EAN-128, Interleaved 2 of 5, CODE 39, CODE 128, EAN-8/13,
CODE 93, RSS-14, POSTNET, NW-7, Matrix 2 of 5, MSI, Bookland
2-Dimensional Data Matrix, PDF417, Macro PDF, Maxicode, Micro PDF417,
Composite Symbology, QR Code
COMMUNICATION INTERFACE
Interfaces Standard IEEE1284 (ECP Compatible), RS232C, USB (2.0)
Option Wireless Ethernet (802.11b/g), LAN (10/100BaseT)
MEMORY
Memory 32 MB DRAM, 8 MB Flash ROM, Selectable
extended Flash Memory cartridge 32 MB option
OPERATING CHARACTERISTICS
Power Requirements 100-120/200-240 Volts AC ±10%, 50/60 Hertz ±5%
Environment Operating 41° - 104°F (5° - 40°C), 15 - 85% RH, non-condensing
Storage -4° - 140°F (-20° - 60°C), 15 - 85% RH, non-condensing
Dimensions 10.75" W (271 mm) x 18" D (455 mm) x 12" H (305 mm)
Weight 33 lbs. (15 kg)
OPTIONS
Label Cutter, Label Dispenser, External/Internal Rewinder, Real Time Calendar/Clock, Online Barcode Verification, RFID
General Specications
The Standard for Reliable
Barcode Printing GL408/412e
SATO America, Inc.
10350-A Nations Ford Road, Charlotte, NC 28273
Phone: [phone] Fax: [phone]
E-mail: [email protected] © 2007 SATO America, Inc. All rights reserved. Rev. 09/07
*PGL is a trademark of Printronix, Inc. TGL is a trademark of the Toshiba TEC Corporation. The acronyms used to identify the programming languages
of non-SATO products may be the property of their respective companies and are used here to identify their various programming languages, used only
for explanation without intent to infringe. SATO makes no claims to the authenticity of their command language or functionality. Specifications subject to
change without notice.
