Instruction Manual of
2-ch. Min-Max Digital Thermometer Model PC-3710
This product is designed to measure temperature. Do not use it for other purposes.
Read this manual thoroughly before use, and keep it for future reference.
Important Notices
Beware of Explosion
PC-3710 is not explosion-proof. Never use it in an atmosphere containing flammable
gases.
Cautions
To use PC-3710 properly, follow the instructions below.
Do not use the device as a clinical thermometer.
Do not drop or give a shock to the device, as it is a sensitive instrument.
Do not forcibly pull, bend, bundle, heat, or put a heavy thing on the cable.
Otherwise, the cable may get damaged.
Do not measure temperature out of the measurable range, or it may result in
malfunction.
Do not keep the device submerged in water.
Do not use the device under direct sunlight or aside a heat source, or it may lead
to a deformation or malfunction.
Do not leave the device in a place like an automobile on a fine summer day, or the
extreme heat may damage it.
Do not wash or wipe the device with alcohol, thinner, or other organic solvents. If
the device becomes dirty, wipe it with a tightly-wrung towel that has been dipped
in warm water with neutral detergent.
Do not use the device in an environment with electrical noise, or the display may
become unstable or the measurement error may increase.
Do not disassemble or customize the device, or it may cause a fatal malfunction.
For repair or calibration, or if the device is broken before use, contact us or a retailer
from which you have purchased.
Cautions Related to Magnets
As PC-3710 contains magnets, do not place it near the followings:
chests of people with pacemakers or other implanted cardiac devices
electronic devices
materials vulnerable to magnetic fields such as magnetic cards
Names of Sections
(i) Temperature of the external probe (OUT)
(ii) Temperature of the internal sensor (IN)
Replacement of Batteries
Replace the battery immediately when the low battery sign is displayed, as described
below to prevent errors in measurement.
1. If the device is wet, wipe it out first.
2. Close the frame stand in the back.
3. Turn the battery lid screw anticlockwise to loosen it and remove the lid. If the
device was wet in the process 1, face the lid down when opening in order to
prevent water from immersing inside the battery box.
Connector cap
External probe
connector
MAX/MIN/Reset key
Cable
Hanging hook
Battery lid
Clasp for
holding
probe
Low battery
sign
Frame stand
Sensor
(i)
(ii)
MAX/MIN sign
Magnets
embedded
here

Be sure that the screw is designed not to drop from the lid.
4. Exchange the batteries according to the description in the battery box.
5. Confirm that the black packing seal is firmly put into the groove, then tighten the
screw until the screw head comes under the body surface.
Maximum and minimum temperatures are initialized after replacing batteries.
Cautions Related to Batteries
Do not dispose of batteries in a fire, or it may explode to hurt you.
For environmental conservation purposes, dispose of batteries in compliance with
local rules and regulations.
Keep batteries out of the reach of children. If they are swallowed accidentally,
consult a doctor immediately.
If battery fluid leaks out, wipe it away immediately without touching it directly.
Remove the battery if not used for a long period, or it may lead to fluid leakage and
malfunction.
Do not use rechargeable batteries, because the sealed structure of PC-3710 can
accumulate gas leaked from the battery to cause a fire or explosion.
Attach the battery lid firmly to the body with the packing seal put into the groove,
and secure the screw. Otherwise, the device may fail to be waterproof and result
in malfunction, short-circuit, battery leakage, extreme heat, or explosion.
How to Use
1. Refer to “Replacement of Batteries” to open the battery lid and remove an
insulation sheet.
The measurement begins immediately, and current temperatures of the internal
sensor (IN) and the external probe (OUT) are shown first. After then two
temperatures are alternately measured every 5 seconds. Each of them is
updated per 10 seconds.
2. Install the device using either the frame stand, hanging hook, or the magnets
embedded in the back. Carefully check if it is placed safely.
3. Let the device adapt to the ambient environment for more than 30 minutes.
Internal Sensor (IN)
The temperature of the internal sensor is displayed with a sign of “IN” in the lower
row. Connector cap must be closed.
As it cannot be used in the environment where temperature falls below −5°C
or exceeds 50°C, place only the external probe in the said environment and
keep the body outside of it in such case.
External Probe (OUT)
The temperature of the external probe is displayed with an indicator of “OUT” in the
upper row when the probe is firmly inserted to the connector. Hooking the clasp
attached to the cable on somewhere helps the probe get fixated.
Close the sensor cap securely if you do not use the external probe.
Cautions When in Use
The device accepts water splashes, but it does not mean that the body and the
probe can be submerged in water.
Do not pull the probe strongly, or it may break.
The sensor part made of stainless steel may get deteriorated when it contacts with
corrosive liquid. Do not measure temperature of such liquid.
The magnet may not work well depending on a surface condition where it takes
place.
Measurement error can be enlarged when your hand touches the cable.
A sign of “HHH” or “LLL” is indicated when the temperature is out of range.
For better management, it is recommended to compare the measured value with
that of a standard thermometer to check accuracy once in a year. We offer
traceable calibration service.
Max/Min Temperatures
PC-3710 logs the maximum (MAX) and minimum (MIN) temperatures. Each press
of the key in the front makes the device show MAX, MIN, and current temperature
in this order.
Their logging is initialized when the key is press for 3 seconds, or the battery is
replaced.

Specifications
Product name
2-ch. Min-Max Digital Thermometer
Model no.
PC-3710
Catalog no.
1850-00
Measuring range
Internal sensor: −5.0 to 50.0°C
External probe: −50.0 to 70.0°C
Accuracy
±1.0°C (0.0 to 40.0°C), ±2.0°C (other)
Resolution
0.1°C
Sampling time
Approx. 10 seconds (5 seconds alternately)
Operating ambient
−5 to 50°C, less than 80%rh without condensing
Power
AAA battery x 1
Battery life
2 years under room temperature, with an alkaline battery
Attached batteries are for test purpose and may last shorter.
Waterproof rating
IPX5 (resists water stream of room temperature)
The rating is valid only when the connector cap is closed, or the external
probe is connected.
Dimensions
Body: 67 (W) x 65 (H) x 22 (D) mm
External probe: sensor part Ø 5.5 mm, cable 3 m long
Materials
Body: ABS resin with antimicrobial, silicone rubber
Sensor part of external probe: SUS304, PE resin
Cable part of external probe: PVC resin
Weight
71 g including a battery
Accessories
AAA battery x1, clasp for holding external probe x1
Specifications and appearance are subject to change for improvement.
Visit our website https://www.sksato.co.jp/en/ for the latest information.
Warranty Policy
Our products are warranted to be free from defects in materials and workmanship
for a period of one year from date of delivery. If repair is necessary and has not been
the result of misuse, force majeure, or transportation arranged by yourself within the
one-year period, please return the products on freight prepaid basis. Correction of
the defect will be made without charges. We alone will determine if the product
problem is due to deviations or customer misuse.
Out-of-warranty products will be repaired for a fee.
Before returning, request for our acknowledgement first.
For details, contact us or a retailer from which you have purchased.
SATO KEIRYOKI MFG. CO., LTD.
3-4, Kanda-kajicho, Chiyoda-ku, Tokyo 101-0045, Japan
https://www.sksato.co.jp/en/
Ver. V.05
As of Nov. 2022
