Sauder Registry Row 412922 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-31
Français pg 32-35
Español pg 36-39
Lot # 376390 08/17/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Entertainment Credenza
Registry Row Collection | Model 412922
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Entertaining what
entertains you.

Table of Contents Assembly Tools Required
3
4-5
6-31
32-35
36-39
40-42
43
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Use of a TV that is too heavy or large is hazardous. A TV that is too heavy will create a risk of a tip-over that can cause severe injury or
death. A TV that is too large for the available space might be accidentally pushed or bumped o the furniture, or subject to tip-over.
• Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly!
• This Sauder unit is designed for use with televisions weighing less than 95 pounds. Never use with a TV that weighs more.
• The size of the television, front-to-back and side-to-side, must fit within the space defined in the diagram.
• Never place the front edge of the TV past the front edge of the TV support shelf (or stop molding – if equipped)
• Never allow the sides of the TV to extend past the side edges of the TV support surface.
• If the TV has a CRT picture tube, the picture tube cone may extend past the rear of the support shelf.
• Be sure to apply the warning label as instructed in the last assembly step. The label provides important safety related information.
WARNING
!
Skip the power trip.
This time.
412922 www.sauder.com/servicesPage 2
60-3/4"
15-1/2"
95 lbs.

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C RIGHT UPRIGHT (1)
D LEFT UPRIGHT (1)
E TOP (1)
F FLIP TOP (1)
G2 BOTTOM (1)
H SMALL BOTTOM (1)
I SHELF (1)
J SMALL BACK (1)
K DOOR (2)
L BACK (1)
M ADJUSTABLE SHELF (4)
N SMALL ADJUSTABLE SHELF (1)
O LEFT FRONT LEG (1)
P RIGHT FRONT LEG (1)
Q REAR LEG (2)
R DRAWER FRONT (1)
V SKIRT (1)
X TOP MOLDING (1)
Y2 EXTENSION BLOCK (1)
Z FOOT SPACER (2)
D44 RIGHT DRAWER SIDE (1)
D45 LEFT DRAWER SIDE (1)
D62 DRAWER BACK (1)
D701 DRAWER BOTTOM (1)
M75 END MOLDING (4)
Now you know
our ABCs.
412922www.sauder.com/services Page 3
A
B
C
D
E
F
G2
H
I
J
K
K
LM
M
M
M
N
O
P
Q
R
V
Z
X
Y2
Q
D44
D62
D701
D45
M75
M75
M75
M75

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
412922 www.sauder.com/servicesPage 4
FELT DISC CARD - 1
MM
METAL BRACKET - 2
HH
ANGLE BRACKET - 5
GG
GROMMET CAP - 2
QQ
RUBBER SLEEVE - 20
SS METAL PIN - 20 TT
BUMPER - 4
OO
UU HINGE - 4 VV SW HINGE - 3
RR GROMMET - 2
DRAWER FRONT
BRACKET - 1
II
PULL - 1
PP
NN CORNER ACCENT - 2
FOOT - 4
JJ
40CB CABINET LEFT - 1 40CA CABINET RIGHT - 1 40CC DRAWER RIGHT - 1 40CD DRAWER LEFT - 1
CAM SCREW - 6
8F
HIDDEN CAM - 31
1F CAM DOWEL - 25 2F
FOOT - 1
3E

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
412922www.sauder.com/services Page 5
GGG BLACK 9/16" LARGE HEAD SCREW - 18
EEE SILVER 5/8" MACHINE SCREW - 2
BBB BLACK 1-7/8" FLAT HEAD SCREW - 7
AAA BLACK 2-1/4" FLAT HEAD SCREW - 6
CORD CLIP - 4
YY
KNOB - 2
WW XX BACKPLATE - 2
DDD BLACK 1-1/8" MACHINE SCREW - 2
HHH SILVER 1/2" MACHINE SCREW - 2
LLL NAIL - 60
JJJ BLACK 1/2" FLAT HEAD SCREW - 14
FFF BLACK 9/16" FLAT HEAD SCREW - 8
GOLD 5/16" FLAT HEAD SCREW - 8
3S
30S BLACK 1-9/16" FLAT HEAD SCREW - 4
SILVER 1-1/8" FLAT HEAD SCREW - 4
10S
SILVER 2" FLAT HEAD SCREW - 2
57S
(Refer to step 25 for proper location and application)
WARNING LABEL - 1
3L
WARNING
Never use this furniture with a TV that is too
large or too heavy. Severe injury or death
can occur.The TV and furniture will be
unstable and may tip.
-The TV must less than 95 lbs.
-The base of the TV must be able to sit
completely on this shelf.
-Refer to instruction book for complete
safety information.
Note: This is a permanent label. Do not try
to remove. Surface will be damaged.
02/ 02 269227

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push thirty-one HIDDEN CAMS (1F) into the ENDS (A and B),
UPRIGHTS (C and D), BOTTOM (G2), SMALL BOTTOM (H),
SHELF (I), and SMALL BACK (J). Then, insert the metal end
of a CAM DOWEL (2F) into each HIDDEN CAM, except in
the long edges of the ENDS (A and B).
412922 www.sauder.com/servicesPage 6
A
B
C
D
I
G2
J
H
Arrow
1F
2F
Arrow
1F
2F
(31 used)
(25 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not tighten the HIDDEN CAMS in this step.
Do not insert
CAM DOWELS
into these edges.
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1267
to watch a video on how to assemble your unit.

å Turn six CAM SCREWS (8F) into the FRONT LEGS (O and P).
å Fasten a CORNER ACCENT (NN) to each FRONT LEG (O
and P). Use two SILVER 5/8" MACHINE SCREWS (EEE).
Step 2
412922www.sauder.com/services Page 7
P
O
NN
NN
8F
8F
SILVER 5/8" MACHINE SCREW
(2 used in this step)
EEE
Angled edge
Angled edge
Remember:
Righty tighty.
Lefty loosey.

Step 3
å Fasten the FRONT LEGS (O and P) to the ENDS (A and B).
Tighten six HIDDEN CAMS
412922 www.sauder.com/servicesPage 8
A
B
O
PAngled edge
Angled edge
12
Surface without
HIDDEN CAMS
Surface with
HIDDEN CAMS

å Turn eight BLACK 9/16" FLAT HEAD SCREWS (FFF) into
the ENDS (A and B) until the shoulders of the SCREWS
rest on the surfaces of the ENDS.
å Slide the END MOLDINGS (M75) onto the ENDS (A and B).
Line up the grooves in the MOLDINGS over the heads of the
SCREWS in the ENDS and slide them until they are against
the RIGHT FRONT LEGS (O and P).
å Fasten the RIGHT REAR LEGS (Q) to the ENDS (A and B).
Use six BLACK 2 1/4" FLAT HEAD SCREWS (AAA).
Step 4
412922www.sauder.com/services Page 9
A
B
AAA
P
O
Q
Q
Angled edge
Angled edge
Shoulder
Apply pressure with your hands
as you guide the MOLDINGS over
the SCREWS and onto the END.
BLACK 9/16" FLAT HEAD SCREW
(8 used in this step)
FFF
BLACK 2-1/4" FLAT HEAD SCREW
(6 used in this step)
AAA
M75
M75
M75
M75
M75

Step 5
å Fasten the CABINET RIGHT (40CA) and CABINET LEFT (40CB)
to the UPRIGHTS (C and D). Use four GOLD 5/16" FLAT HEAD
SCREWS (3S) through holes #1 and #4.
412922 www.sauder.com/servicesPage 10
Surface with
HIDDEN CAM
4
3
2
1
C
D
Roller end
4
3
2
1
Surface with
HIDDEN CAM
Curved edge
Curved edge
Roller end
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S

å Fasten the UPRIGHTS (C and D) to the SHELF (I). Tighten
four HIDDEN CAMS.
Step 6
412922www.sauder.com/services Page 11
C
D
I
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Curved edge
Finished edge
Surface with
HIDDEN CAMS
Curved edge
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution

Step 7
å Fasten the UPRIGHTS (C and D) to the BOTTOM (G2).
Use four BLACK 1-7/8" FLAT HEAD SCREWS (BBB).
å Fasten the ENDS (A and B) to the BOTTOM (G2). Tighten
four HIDDEN CAMS.
412922 www.sauder.com/servicesPage 12
A
B
C
D
G2
Arrow
Minimum
190 degrees
Maximum
210 degrees
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
BBB

å Fasten the SMALL BACK (J) to the SMALL BOTTOM (H).
Use three BLACK 1-7/8" FLAT HEAD SCREWS (BBB).
å Push the GROMMETS (RR) and GROMMET CAPS (QQ)
into the large holes in the SMALL BACK (J).
Step 8
412922www.sauder.com/services Page 13
Surface without
HIDDEN CAMS
J
H
QQ
RR
BLACK 1-7/8" FLAT HEAD SCREW
(3 used in this step)
BBB
Edge with CAM DOWELS

Step 9
å Fasten the SMALL BACK (J) and SMALL BOTTOM (H) to
the ENDS (A and B). Tighten four HIDDEN CAMS.
412922 www.sauder.com/servicesPage 14
A
B
H
Surface with
HIDDEN CAMS
J
Arrow
Minimum
190 degrees
Maximum
210 degrees

å Push four CORD CLIPS (YY) into the holes in the TOP (E).
å Fasten the TOP (E) to the ENDS (A and B) UPRIGHTS (C
and D), and SMALL BACK (J). Tighten nine HIDDEN CAMS.
Step 10
412922www.sauder.com/services Page 15
YY
E
A
B
C
D
J
Arrow
Minimum
190 degrees
Maximum
210 degrees

Step 11
å Fasten five ANGLE BRACKETS (GG) to the SKIRT (V). Use
five BLACK 9/16" LARGE HEAD SCREWS (GGG).
å NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edges of the SKIRT.
å Now, fasten the SKIRT to the ENDS (A and B) and
BOTTOM (G2). Use five BLACK 9/16" LARGE
HEAD SCREWS (GGG).
412922 www.sauder.com/servicesPage 16
V
GG
GG
GG
A
B
G2
BLACK 9/16" LARGE HEAD SCREW
(10 used in this step)
GGG

å Turn your unit onto its top.
å Push a FOOT (JJ) over the bottom edge of
each LEG (O, P and Q).
Step 12
412922www.sauder.com/services Page 17
JJ
JJ
P
Q
Q
O
Don't worry. It isn't
Rome. This can be built
in a day.

Step 13
å Carefully turn your unit over onto its front edges. Unfold the
BACK (L) and lay it over your unit.
å Make equal margins along the short edges of the BACK (F).
The BACK should be even with the TOP (E) and will overhang
the BOTTOM (G) slightly. Push on opposite corners of your
unit if needed to make it "square".
å Fasten the BACK (L) to your unit using the NAILS (LLL).
å NOTE: Be sure to tap NAILS into the holes that line up over
the UPRIGHTS (C and D).
å NOTE: Perforations have been provided for access through
the BACK. Carefully cut out the holes needed.
412922 www.sauder.com/servicesPage 18
These holes must line up over
the UPRIGHTS (C and D).
L
E
These holes
must be here.
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Unfinished surface
NAIL
(60 used in this step)
LLL
Th BACK will overhang
the BOTTOM slightly.
Th BACK should be even
with the TOP.

Step 14
412922www.sauder.com/services Page 19
å Fasten the EXTENSION BLOCK (Y2) to the BOTTOM (G2).
Use four SILVER 1-1/8" FLAT HEAD SCREWS (10S).
å Fasten two FOOT SPACERS (Z) to the EXTENSION BLOCK (Y2).
Use two SILVER 2" FLAT HEAD SCREWS (57S).
å Push the FOOT (3E) into the center hole of the FOOT
SPACER (Z).
Y2
Z
Z
3E
G2
SILVER 1-1/8" FLAT HEAD SCREW
(4 used in this step)
10S
SILVER 2" FLAT HEAD SCREW
(2 used in this step)
57S

Step 15
412922 www.sauder.com/servicesPage 20
VV
VV
F
OO
Mounting screw
(vertical)
Adjusting screw (depth)
(horizontal adjustment screws)
SW is stamped into this hinge for identification.
å Fasten the SW HINGES (VV) to the FLIP TOP (F). Use six
BLACK 1/2" FLAT HEAD SCREWS (JJJ).
å Push four BUMPERS (OO) into the FLIP TOP (F).
BLACK 1/2" FLAT HEAD SCREW
(6 used in this step)
JJJ
