Sauder Palladia 411835 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-19
Français pg 20-22
Español pg 23-25
Lot # 366058 11/04/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Night Stand
Palladia Collection | Model 411835
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
3
4
5-19
20-22
23-25
26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
411835 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A2 RIGHT END (1)
B2 LEFT END (1)
C TOP (1)
D BOTTOM (1)
D40 RIGHT DRAWER SIDE (1)
D41 LEFT DRAWER SIDE (1)
D69 DRAWER BACK (1)
D621 DRAWER BOTTOM (1)
E BACK (1)
F BRACE (1)
G BASE (1)
H DRAWER FRONT (1)
L FRONT MOLDING (1)
M RIGHT MOLDING (1)
N LEFT MOLDING (1)
O END MOLDING (2)
P MOLDING (1)
Q BOTTOM MOLDING (1)
R2 PLINTH (2)
Now you know
our ABCs.
411835www.sauder.com/services Page 3
A2
B2
C
D
E
F
G
L
M
N
O
P
QR2
O
H
R2
D41
D40
D69
D621

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
411835 www.sauder.com/servicesPage 4
TWIST-LOCK® FASTENER - 10
WANGLE BRACKET - 6
Y
METAL BRACKET - 5
ZMOLDING CONNECTOR - 2
AA KNOB - 1 BB
BLACK 1-1/4" FLAT HEAD SCREW - 6
CC
BLACK 1-1/8" PAN HEAD SCREW - 8
DD EE BLACK 9/16" LARGE HEAD SCREW - 16
SILVER 1/2" MACHINE SCREW - 1
FF BROWN 7/16" LARGE HEAD SCREW - 8 GG
GOLD 5/16" FLAT HEAD SCREW - 8
HH NAIL - 24 II
35AA UNIVERSAL CABINET RAIL - 235AC DRAWER RIGHT - 135AD DRAWER LEFT - 1
DRAWER FRONT BRACKET - 1
X
30S BLACK 1-9/16" FLAT HEAD SCREW - 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (W) into the large holes in the ENDS (A2 and B2).
å Repeat this step for the BOTTOM (D).
411835www.sauder.com/services Page 5
W
A2
B2
W
W
(10 used)
Do not tighten the TWIST-LOCK® FASTENERS in this step.
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1607
to watch a video on how to assemble your unit.

Step 2
å Tap two MOLDING CONNECTORS (AA) into the notches
in the MOLDINGS (L, M, and N).
411835 www.sauder.com/servicesPage 6
Use your hammer to tap the MOLDING CONNECTORS (AA) into the notches in the MOLDINGS.
M
N
L
AA
AA
Flat end
Flat end
Unfinished surface
Unfinished surface
Unfinished surface

å Flip the MOLDINGS (L, M, and N) over and fasten the
MOLDINGS to the TOP (C). Use six BLACK 1-1/4" FLAT
HEAD SCREWS (CC).
å NOTE: Do not overtighten the SCREWS into the TOP.
Step 3
411835www.sauder.com/services Page 7
L
M
N
C
Rounded edge
BLACK 1-1/4" FLAT HEAD SCREW
(6 used in this step)
CC
Finished surface
Finished surface
Finished surface
Remember:
Righty tighty.
Lefty loosey.
Surface with holes

Step 4
411835 www.sauder.com/servicesPage 8
3
2
1
1
2
3
A2
B2
Edge with
TWIST-LOCK®
FASTENER
Y
Y
GOLD 5/16" FLAT HEAD SCREW
(4 used for the CABINET RAILS)
HH
(6 used)
Edge with
TWIST-LOCK®
FASTENER
å Fasten the UNIVERSAL CABINET RAILS* (35AA) to the
ENDS (A2 and B2). Use four GOLD 5/16" FLAT
HEAD SCREWS (HH).
å Fasten six ANGLE BRACKETS (Y) to the ENDS (A2 and B2).
Use two BLACK 9/16" LARGE HEAD SCREWS (EE) and
four BROWN 7/16" LARGE HEAD SCREWS (GG). Follow the
diagram closely.
å *patent pending glide system
Glide end
Glide end
BLACK 9/16" LARGE HEAD SCREW
(2 used in this step)
EE
BROWN 7/16" LARGE HEAD SCREW
(4 used in this step)
GG
VIEW THE DRAWER GLIDE VIDEO

å Fasten the BOTTOM (D) to the ENDS (A2 and B2).
Tighten four TWIST-LOCK® FASTENERS.
Step 5
411835www.sauder.com/services Page 9
A2
B2
D
Finished edge
Edge with
TWIST-LOCK®
FASTENER
Edge with
TWIST-LOCK®
FASTENER
Dowel end
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Surface with
TWIST-LOCK®
FASTENERS
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution

Step 6
å Fasten the ENDS (A2 and B2) to the MOLDINGS (M and N)
on the TOP (C). Tighten four TWIST-LOCK® FASTENERS.
å Fasten the PLINTHS (R2) to the ENDS (A2 and B2). Tighten
two TWIST-LOCK® FASTENERS.
411835 www.sauder.com/servicesPage 10
A2
B2
R2
R2
C
M
N
Curved edge
Rounded edge
These surfaces should be even.

å Carefully turn your unit onto its top.
å Fasten the END MOLDINGS (O) to the ANGLE
BRACKETS on the ENDS (A2 and B2). Use four BROWN
7/16" LARGE HEAD SCREWS (GG).
å Fasten the MOLDING (P) to the ANGLE BRACKETS
on the ENDS (A2 and B2). Use two BLACK 9/16"
LARGE HEAD SCREWS (EE).
Step 7
411835www.sauder.com/services Page 11
A2
B2
O
O
P
O
A2
BLACK 9/16" LARGE HEAD SCREW
(2 used for the MOLDING)
EE
Locator hole
Locator hole
BROWN 7/16" LARGE HEAD SCREW
(4 used for the END MOLDINGS)
GG
The END MOLDINGS
will set in from the edge.

Step 8
å Fasten five METAL BRACKETS (Z) to the BRACE (F). Use
five BLACK 9/16" LARGE HEAD SCREWS (EE).
å NOTE: Be sure the three BRACKETS are even with the
long edges of the BRACE. The BRACKETS on the short
edges will overhang the BRACE.
411835 www.sauder.com/servicesPage 12
F
Z
Z
Z
BLACK 9/16" LARGE HEAD SCREW
(5 used in this step)
EE
Surface with
more holes
Side Step: Make
nachos. (Optional, but
recommended.)

å Fasten the BRACE (F) to the ENDS (A2 and B2) and
BOTTOM (D). Use five BLACK 9/16" LARGE
HEAD SCREWS (EE).
Step 9
411835www.sauder.com/services Page 13
A2
B2
D
F
BLACK 9/16" LARGE HEAD SCREW
(5 used in this step)
EE

Step 10
å Fasten the BASE (G) and BOTTOM MOLDING (Q) to the
BRACE (F). Use four BLACK 1-1/8" PAN HEAD SCREWS (DD).
å Fasten the PLINTHS (R2) to the BRACE (F). Use four BLACK
1-1/8" PAN HEAD SCREWS (DD).
411835 www.sauder.com/servicesPage 14
F
G
Q
R2
R2
BLACK 1-1/8" PAN HEAD SCREW
(8 used in this step)
DD
The holes are closer
to this long edge.

å Carefully turn your unit over onto its front edges. Unfold the
BACK (E) and lay it over your unit.
å Make equal margins along all four edges of the BACK (E). Push
on opposite corners of your unit if needed to make it "square".
å Fasten the BACK (E) to your unit using the NAILS (II).
Step 11
411835www.sauder.com/services Page 15
E
Printed information
must be facing up.
NAIL
(24 used in this step)
II
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
These holes are farther
from the corner.

Step 12
411835 www.sauder.com/servicesPage 16
D41
D41
D40
D40
H
H
1
2
Push down
å Pull the DRAWER FRONT BRACKETS (X) apart and slide them into the
grooves in the DRAWER SIDES (D40 and D41). You may need to gently tap
them in with a hammer.
å NOTE: The DRAWER FRONT BRACKETS are marked "RH" and "LH" for
easy identification.
å Fasten the DRAWER FRONT (H) to the DRAWER FRONT BRACKETS (X).
Use two BLACK 9/16" LARGE HEAD SCREWS (EE).
å Slide the DRAWER BOTTOM (D621) into the grooves in the DRAWER
SIDES (D40 and D41) and DRAWER FRONT (H).
D621
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT groove.
With the palm of your hand,
tap the DRAWER BOTTOM
down into the groove.
X
BLACK 9/16" LARGE HEAD SCREW
(2 used in this step)
EE
VIEW THE T-SLOT BOX VIDEO
Unfinished surface

Step 13
411835www.sauder.com/services Page 17
D41
D40
D69
å Fasten the DRAWER BACK (D69) to the DRAWER
SIDES (D40 and D41). Use four BLACK 1-9/16" FLAT
HEAD SCREWS (30S).
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK groove.
VIEW THE T-SLOT BOX VIDEO
30S
Start each screw a few turns before
completely tightening any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(4 used in this step)

Step 14
H
BB
1
2
411835 www.sauder.com/servicesPage 18
1
2
SILVER 1/2" MACHINE SCREW
(1 used for the KNOB)
FF
GOLD 5/16" FLAT HEAD SCREW
(4 used for the DRAWER SLIDES)
HH
å Fasten the DRAWER RIGHT (35AC) to the RIGHT
DRAWER SIDE (D40) and the DRAWER LEFT (35AD)
to the LEFT DRAWER SIDE (D41). Use four GOLD 5/16"
FLAT HEAD SCREWS (HH) through holes #1 and #2.
å NOTE: The glides are not intended to rotate.
å Fasten the KNOB (BB) to the DRAWER FRONT (H). Use a
SILVER 1/2" MACHINE SCREW (FF).
Glide end
Glide end
D41
D40
Hey! It's starting to look
like something!
VIEW THE DRAWER GLIDE VIDEO

å Carefully stand your unit upright.
å To insert the drawer into your unit, tip the front of the drawer down and drop the glides on the drawer behind the glides on
the unit. Lift the front of the drawer up and slide it into the unit.
å To make adjustments to the drawer, loosen the SCREWS in the DRAWER FRONT BRACKETS, make needed adjustments,
and tighten the SCREWS.
å NOTE: Please read the back pages of the instruction booklet for important safety information.
å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry.
Step 15
411835www.sauder.com/services Page 19
40 lbs.
40 lbs.
15 lbs.
And to celebrate, why not share your success story?

411835 www.sauder.com/servicesPage 20
A l’usage exclusif du
Canada Noter la date
d’achat de cet élément
et conserver le livret
pour future référence.
Pour contacter Sauder
en ce qui concerne cet
élément, faire référence
au numéro de lot et
numéro de modèle en
appelant notre numéro
sans frais.
Lot nº : ____________
Date de
l’achat: ____________
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
NOUS SOMMES LA POUR VOUS AIDER!
Nous faisons de notre mieux pour nous assurer que votre meuble
arrive dans d’excellentes conditions. Nos représentants du service
Clientèle sont aimables et prêts à vous aider au cas où une pièce
aurait été endommagée ou manquerait (ou si vous aviez besoin
d’aide pour l’assemblage). NE RAMENEZ PAS LE MEUBLE AU
MAGASIN. Au Canada, composez ce numéro d’appel gratuit:
1-800-523-3987
Du lundi au vendredi, de 9 heures du matin à
5:30 heures du soir (horaire Côte Est)
(sauf jours fériés)
Si une pièce a besoin d’être remplacée, la pièce de remplacement
sera envoyée dans les 48 heures. (Sauf week-ends et jours fériés)
Utilisez les instructions d’assemblage en français avec les
schémas étape par étape du manuel d’instruction en anglais.
Chaque étape en français correspond à la même étape
en anglais. La pièce devant être attachée à l’élément est
représentée en gris sur les schémas de chaque étape pour plus
de précision. Comparer la “Liste de pièces” ci-dessous avec
la “PART IDENTIFICATION” du manuel en anglais pour vous
familiariser avec les pièces avant l’assemblage.
REMARQUE : CE MANUEL D’INSTRUCTIONS CONTIENT
D’IMPORTANTES INFORMATIONS RELATIVES À LA SÉCURITÉ.
À LIRE ET CONSERVER POUR TOUTE RÉFÉRENCE FUTURE.
ChevetModèle 411835
35AA GLISSIÈRE D'ÉLÉMENT UNIVERSELLE ......2
35AC COULISSE DROITE DE TIROIR.........................1
35AD COULISSE GAUCHE DE TIROIR......................1
W FIXATION TWIST-LOCK®....................................10
X CONSOLE DE DEVANT DE TIROIR...............1
Y CONSOLE À ÉQUERRE.........................................6
Z CONSOLE EN MÉTAL.............................................5
AA CONNECTEUR DE MOULURE..........................2
BB BOUTON.............................................................................1
30S VIS TÊTE PLATE 40 mm NOIRE...................4
CC VIS NOIRE TÊTE PLATE 32 mm.....................6
DD VIS NOIRE TÊTE GOUTTE
DE SUIF 28 mm...........................................................8
EE VIS NOIRE TÊTE LARGE 14 mm..................16
FF VIS ARGENTÉE À MÉTAUX 13 mm...............1
GG VIS MARRON TÊTE LARGE 11 mm ..............8
HH VIS DORÉE TÊTE PLATE 8 mm......................8
II CLOU .................................................................................24
A2 EXTRÉMITÉ DROITE................................................1
B2 EXTRÉMITÉ GAUCHE ............................................1
C DESSUS.............................................................................1
D DESSOUS........................................................................1
D40 CÔTÉ DROIT DE TIROIR......................................1
D41 CÔTÉ GAUCHE DE TIROIR...............................1
D69 ARRIÈRE DE TIROIR ................................................1
D621 FOND DE TIROIR.......................................................1
E ARRIÈRE............................................................................1
F ENTRETOISE.................................................................1
G SOCLE................................................................................1
H DEVANT DE TIROIR.................................................1
L MOULURE AVANT....................................................1
M MOULURE DROITE..................................................1
N MOULURE GAUCHE...............................................1
O MOULURE D’EXTRÉMITÉ...................................2
P MOULURE.......................................................................1
Q MOULURE DE DESSOUS...................................1
R2 PLINTHE...........................................................................2
