Savant PAV-AOMBAL8C User manual

PAV-AOMBAL8C-xx Quick Reference Guide | 009-1605-02
Copyright 2021 Savant Systems, Inc | 210120
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
1 of 2
Box Contents
(1) 16 Channel Balanced Audio Output IP Receiver
(PAV-AOMBAL8C-xx)
(1) Installation Kit (075-0204-xx)
(8) Stereo Connectors (028-9347-xx)
(2) 3-pin Control Connector (028-9351-xx)
(1) 5V 3A Multi-Blade Power Supply (025-0223-xx)
(1) Product Information and Regulatory Insert (009-1950-xx)
Specifications
Environmental
Temperature 32° to 104° F (0° to 40° C)
Humidity 10% to 80% Relative Humidity
(non-condensing)
Dimensions and Weight
Height 1.6in (41.5 mm)
Width 8.5in (215.0 mm)
Depth 3.7in (93.3 mm)
Weight Net: 1.4lb (0.64 kg) Shipping: 2.3lb (1.05 kg)
Power
Power Supply 5V DC 3A Multi-Blade
Maximum Power 15 watts
Power over Ethernet
(PoE) (PAV-AOMBAL8C-10 Only) IEEE 802.3af
Networking
Supported
Standard
IEEE 802.1 AVB/TSN switches
IEEE 802.3 Ethernet
Regulatory
Safety and Emissions
FCC Part 15 CE C-Tick
RoHS Compliant
Front Panel
A B
Power Status
Power LED
Green: System has power and is operating
normally.
O: System is not receiving power.
Status LED
O: Embedded processor is resetting, or is
powered up, and is booting the embedded
firmware.
Green: Host has established communications
with the embedded system.
Green Blinking: Embedded system is ready, but
no communication has been established with the
host.
Red: Host has determined the firmware needs to
be updated, but a problem occurred during the
process that will initiate a reset.
Red Blinking: Embedded firmware is running, but
has not received a DHCP IP Address.
Amber: Host is updating the embedded
firmware.
Amber Blinking: Embedded system has a valid
link-local IP Address and is connecting to the
host.
A
B
1s1s
Repeat
1s1s
Repeat
1s1s
Repeat
Installation
The PAV-AOMBAL8C should be installed on a solid, flat, level surface.
The device will fit on a 1U rack shelf. The location should be dry, well
ventilated, and out of direct sunlight.
IMPORTANT! The PAV-AOMBAL8C must to be connected to a AVB
Switch. Also a Savant AVB audio input device is required.
Network Requirements
For networking guidelines and recommendations, refer to the Savant
Device Networking Guidelines available on the Savant Community
Knowledge Base.
Supported Releases
PAV-AOMBAL8C-00 da Vinci 8.10.2 and higher
PAV-AOMBAL8C-10 da Vinci 8.10.2, 9.3.4 and higher
Savant® ProAV 16 Channel Balanced Audio Output IP Receiver
with Control (PAV-AOMBAL8C)
Quick Reference Guide

PAV-AOMBAL8C-xx Quick Reference Guide | 009-1605-02
Copyright 2021 Savant Systems, Inc | 210120
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
2 of 2
Rear Panel
Reset
Resets the network settings of the device.
Hold Reset Button for 5 seconds while powered
on to clear network settings. Status LED will
rapidly blink red when reset is complete.
USB USB 2.0 Type A (reserved for future use).
GPIO
3-pin Control Connector
See GPIO Wiring for pinouts
GPIO Input: When configured as an input the
processor will look for a low (<0.8V DC) or a high
(>2.4V DC) state.
Minimum 0V DC / Maximum 12V DC.
GPIO Output: When configured as an output, the
port provides a binary output of 0-12V
DC 150mA max.
Balanced
Audio
Outputs
(8) Analog Stereo Balanced Line Output (Left &
Right). Direct Line Level 4.2-VRMS.
Ethernet
8-pin RJ-45 port
10/100/1000 Base-T auto-negotiating port with
Link/Activity LEDs.
Supports Power over Ethernet (PoE).
Supports Audio Video Bridging (AVB).
Ethernet
Activity LED
Green Blinking: Activity (Rx/Tx).
O: No Activity.
Ethernet
Link LED
Green Solid: Ethernet Link is established.
O: Ethernet link is not established.
Power Input 5V DC 3A Multi-Blade
A
B
C
D
E
F
G
H
32
1
G 1 PD1 PIN 1
PIN 2
PIN 3
Ground
GPIO 1
Pull-Down Jumper 1
NOTE: While not shown in the
diagram above, GPIO 2 follows
the same wiring as GPIO 1.
General Purpose Input/Outputs
(GPIO) are binary I/O ports used
on Savant controllers to trigger an
action within the system. Events
can control a device, such as turning
on an amplifier (output) or detecting
a state change for a device (input) to
perform a workflow. Pin 2 is used for
input or output depending on configuration.
GPIO Pull Down Resistor (PD) Usage
GPIO pins are configured as inputs and are pulled high to 12V while the
host is booting up. To make the GPIO signal low during a host reboot
and/or a power cycle, attach the GPIO 1 pin to the PD pin. The PD pin
is a 1K ohm pull down resistor (to signal ground) which keeps the GPIO
output below 0.8V during processor boot times.
GPIO Wiring
Additional Documentation
Refer to the following documents located on the Savant Customer
Community for additional information.
– ProAV IP Audio Deployment Guide (009-1571-xx)
Expansion
Savant AVB devices can be connected in a single system, providing a
virtual audio switch that can be configured to suit almost any need.
The maximum number of devices varies based on the active da Vinci
runtime.
USB
Reset
PD2G 2
2
1
LL
PD1
GPIO
1
G-
Balanced Analog Audio Out
4
R RL
3
+
-
+G G +-+
-
L
68
R
