Saxby Lighting 40655 Manual

• Thissystemcontainsnon-replaceablepartsand
cannotbeserviced.Ifdamageoccursthepartshould
bescrapped.
Instructionleaflet
Uma Brick Light
40655
www.saxbylighting.com
Foryoursafety,alwaysswitchoffthesupplybeforecleaning.
Wasteelectricalproductsshouldnotbedisposedofwithhouseholdwaste.Pleaserecyclewherefacilities
exist.CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
SaxbyLightingLtd.BH233PE
Werecommendcleaningwithasoftdrycloth.
Donotusesolventsorabrasivecleanersasthesecould
damagethefinish.
The LED's are protected by a shade. This part must be replaced immediately should the shade
become cracked or damaged. This fitting must not be used without the shade in place.
ReplaceCracked
Shade
Fitting/replacing bulbs
Iss.130042012
Check that...
• Youhavecorrectlyidentifiedthewires.
• Theconnectionsaretight.
• Noloosestrandshavebeenleftoutoftheconnection
block.
• Ensure that the gland is fitted properly around the
cabletomaintaintheIPrating.
• Reassmbletheunit,takingcarenottotrapanyofthe
internalwiring.
• Push the unit into the plastic housing and fix in
position.
• Replacefuse orcircuit breaker and switchon. Your
lightisnowreadyforuse.
Commissioning

Thankyouforpurchasingthislightfitting.Pleasereadtheinstructionscarefullybeforeusetoensuresafeand
satisfactoryoperationofthisproduct.Pleaseretaintheseinstructionsforfuturereference.
Warning
Specification
Voltage: 240V~50hz
Lamp: 3.2W(39LED's)
IPrating: 68
Layout
• Planthedesiredlayoutofthisfittingcarefully,
ensuringthecableswillreachthedistancebetween
thejunctionboxandthelightfitting.
• Avoidlocatinganycablesinpositionsthatwould
causeahazard.Positioncablesandoutdoorrated
junctionboxes(notsupplied)awayfromareas
wheretheymaybeatriskfrombeingcut,trappedor
damaged.
• WerecommendthatyouuseH05RN-Fspecification
cable(notsupplied)whichisanoutdoorgrade,
rubbersheathedcable.Themainssupplycablemust
haveaminimumcrosssectionalareaof1.0mm².
• Cablesmustbeprotectedusingsuitableconduitor
plastictrunking.
Existingfittingsmustbecompletelyremovedbefore
installationofanewproduct.Beforeremovingthe
existingfitting,carefully note the position of each set
of wires.
• Undothetwofrontscrewsandremovethefront
panel.removethesealedLEDunitandsetaside.
• Cutthemountingholefortheunittakingcarenot
todamageanypipesormainscablesbeneaththe
mountingsurface.
 190mmx65mmcutout : 75mmvoiddepth.
• Pullthepowersupplycablethroughtherearplastic
moulding.Fittherearmouldingintoposition.Seal
thecablewhereitcomesthroughfromthewall.
Installation
NEUTRAL
SWITCHEDLIVE
BLUE(N)
BROWN(L)
SUPPLYLIGHTFITTING
Thisunitisdoubleinsulatedandmustnotbeearthed.If
thereareanyincomingearthcables,theymustbejoined
togetherandwellinsulatedwithgoodqualityinsulation
tape.Thisistoensureearthcontinuitythroughoutyour
property.
Havingcorrectlyidentifiedthewiringfromyourexisting
lightfittingconnecttotheconnectionblockinsidethe
productinthefollowingway:
Wiring
This product is Double Insulated and does
not require connection to an Earth circuit.
Pleasereadtheseinstructionscarefullybefore
commencinganywork.
Thisunitmustbefittedbyacompetentandqualified
electrician.
InstallinaccordancewithIEEWiringregulationsand
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
beforeinstallingormaintainingthisfitting.Ensure
otherpersonscannotrestoretheelectricalsupply
withoutyourknowledge.Ifyouareinanydoubt,
pleaseconsultaqualifiedelectrician.
Thislightfittingshouldbeconnectedtoafusedcircuit.
Ifreplacinganexistingfitting,makeacarefulnoteof
theconnections.
Thissystemcontainsnon-replaceablepartsand
cannotbeserviced.Ifdamageoccursthepartshould
bescrapped.
Wasteelectricalproductsshouldnotbedisposedof
withhouseholdwaste.Pleaserecyclewherefacilities
exist.Checkwithyourlocalauthorityorretailerfor
recyclingadvice.
ThisproductisratedatIP54.
Thisproductisnotsuitableforlocationinorneara
marineenvironment.
Thisproductisnotsuitablefordimming.
