Saxby Lighting Solaris 76925 Manual

We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could damage the finish.
Instruction leaflet
For your safety, the internal batteries in these products are non replaceable. Do not attempt to disassemble
the products.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.
Recycling advice
Safety information
Care and Cleaning
Iss3 24/01/2019
Solaris Wall Light
76925, 76926, 76927
WWW.saxbylighting.com Saxby lighting. BH23 3PE

Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and
satisfactory operation of this product. Please retain these instructions for future reference.
Battery Care Warnings (for remote supplied with 76927)
Please note: the internal batteries in these products are non replaceable. Do not attempt to disassemble
the products.
Do not recharge non-rechargeable batteries.
Do not mix old and new batteries.
Do not mix batteries of different types.
Always insert the batteries with the correct polarity.
Always remove exhausted batteries from the product.
Do not short circuit the supply terminals.
Do not use rechargeable batteries
This product is suitable for use by adults only.
Specification
Lamp: 76925: 1.8W LED Module & 0.2W LED
76926: 5W LED Module
76927: 8W LED Module
IP rating: IP44
• Decide on the optimum location for the product. The recommended installation height is 1.8-4m, depending
on preference and environment.
• 76925 has one keyhole-shaped hole on the back of the product. Using the product as a template, mark the
position of the hole. Drill the hole, taking care to avoid damaging any concealed wiring or pipes.
• 76926 and 76927 have two keyhole-shaped holes in the back of the product Measure the distance between
these and then mark the position of the fixing holes on the wall. Drill the holes, taking care to avoid damaging
any concealed wiring or pipes.
• Fit the supplied wall plug(s) and screw(s). Make sure the screw(s) are protruding slightly from the wall - for
76926 and 76927, ensure the screw holes are horizontal so the product hangs level.
• Place the keyhole-shaped hole(s) on the back of the product over the screw(s) to hang the product in place.
• For 76925, tighten the screw to secure.
Installation
• The sensors in these products have 3 settings, as detailed below. To move between each setting, it is
necessary to initially hold the button down on the products until the light flashes twice (usually <3 seconds).
• N.B. 76927 is fitted with a microwave sensor and works in the same way as detailed below but it is first
switched on with the button on the rear of the product and then operated via the supplied remote control
(remote can only be used in the dark).
• 1st Setting: The light remains dim and becomes bright when motion is detected.
• 2nd Setting: The light remains unlit and becomes bright once motion is detected.
• 3rd Setting:The light stays in constant bright mode and has no sensing.
• 4th Setting: OFF.
• To restart to 1st Setting, hold the button until it flashes twice (not applicable for 76927).
Sensor Operation
• Read the battery care warnings overleaf.
• To access the battery, slide the battery cover off of the back of the remote and keep safe for refitting later.
• Remove the old batteries and replace. Ensure the correct polarity is observed.
• Refit the battery cover set aside earlier.
Battery Replacement - (for remote supplied with 76927)
Commissioning
• Once desired setting of Sensor has been set, your light is now ready for use.
76925/76926 76927
• 10 lux on, 10 lux off • 10 lux on, 10 lux off
• 120˚detection angle • 120˚detection angle
• 5 - 8m range • 8 - 10m range
• 10 sec duration • 15 sec duration
Sensor Parameters
• This system contains non-replaceable parts and cannot be serviced. If damage occurs the part should
be scrapped.
Fitting/replacing bulbs
