SCAN SCAN 4 User manual

SCAN 4
INSTRUCTIONS FOR
INSTALLATION AND USE
This manual is accompanied by a
pamphlet with General Instructions for
Installation. Edition 10.04 - GB
MONTERINGSVEJLEDNING
med brugs- og fyringsanvisning
Indhold:
Generelle råd og anvisninger . . . . . . . . . .2-3
Reklamationsret
Type- og miljøgodkendelse
Udpakning
Tilbehør til din pejs
Montering af kakler og fedtsten
Kvalitetskontrol
Anmeldelsespligt
Skorstenstjek
Skorstensløsninger
Bærende underlag
Brændbar eller ikke brændbar væg
Gulvplade
Varmefordeling
Justerskrue
Typeskilt
Produktionsnr.
Servicepakke
Monteringsvejledning. . . . . . . . . . . . . . . . .4-7
Tilslutning til eksisterende/muret skorsten
Tilslutning topafgang til stålskorsten
Forbrændingsluft udefra
Brugs- og fyringsanvisning . . . . . . . . . . . 8-10
Vedligeholdelse af pejseovnen
Håndtering af brændsel
Optænding og fyring
Fejlsøgning . . . . . . . . . . . . . . . . . . . . . . . . 11
SCAN 3
BRUGSANVISNING
TildenneBrugsanvisninghørerogsåen
generelMonteringsvejledning. Udgave03.03-DK
MONTERINGSVEJLEDNING
medbrugs-ogfyringsanvisning
Indhold:
Generellerådoganvisninger..........2-3
Reklamationsret
Type-ogmiljøgodkendelse
Udpakning
Tilbehørtildinpejs
Monteringafkaklerogfedtsten
Kvalitetskontrol
Anmeldelsespligt
Skorstenstjek
Skorstensløsninger
Bærendeunderlag
Brændbarellerikkebrændbarvæg
Gulvplade
Varmefordeling
Selvlukkendelåge
Justerskrue
Typeskilt
Produktionsnr.
Servicepakke
Monteringsvejledning.................4-7
Tilslutningtileksisterende/muretskorsten
Tilslutningtopafgangtilstålskorsten
Forbrændingsluftudefra
Brugs-ogfyringsanvisning...........8-10
Vedligeholdelseafpejseovnen
Håndteringafbrændsel
Optændingogfyring
Fejlsøgning........................11
Tildennemonteringsvejledninghørerogsåen
separatbrugsanvisningfordenenkeltepejs.
Udgave02/03-DK
Til dennemonteringsvejledning hørerogsåen
separatbrugsanvisning fordenenkelte pejs.
Udgave 02/03 - DK
Approved according to DIN 18891

1 Ashtray. The ashtray is placed below the com-
bustion chamber. Attention! Be careful when you
empty ashes from the stove. There may be embers
left for up to 24 hours after the stove was last
used.
2 Handle for shaking grate. The stove is equipped
with a shaking grate. When you activate the grate
handle, the ashes from the combustion chamber
are emptied into the ashtray.
3 Regulation for primary air. Turn the air valve
in order to open. The primary air is used when
lighting and refuelling the stove. It should always
be closed during continuous firing.
4 Regulation for combustion air. Turn the air valve
to the right for opening and to the left for closing.
The air is used for the combustion and regulates
the output of the stove.
The ashtray, shaking grate, and primary air should
always be closed during continuous firing.
Ceramic smoke deflector
In order to dismount the ceramic smoke
deflector, lift up the plate at the front edge.
Lower it at the back and take it out.
You have chosen a product from one of Europe's lea-
ding manufacturers of wood-burning stoves. We are
convinced that your stove will be to your full satisfaction
and give you many hours of pleasure if you follow the
advice and instructions of this manual.
Please read this manual as well as the General
Instructions for Installation before beginning the
installation.
Congratulations on your new SCAN stove!
2
3
4
1
4
SCAN 4
Adjustment of the air
Wood / briquettes Fuel kg/h (beechwood
max. 20% humidity)
SCAN 4 2 kg
Combustion air % 100
Primary air % 0-50

Adjustment of the handle
If the handle is not in the vertical position, you
can adjust as follows: loosen the screw (see
illustration), put the handle in the vertical posi-
tion and tighten the screw.
Handle
The door is opened by turning the handle
counter-clockwise.
Self-closing door (BA 1)
The door is prepared with a self-closing function at the fac-
tory. If you tighten the spring with the hexagon spanner, the
door will close automatically when you let go of it.
Accessories
For this model you can have the following accessories:
• Large grill
• Steel floor plate
SCAN 4
Stove
model
SCAN
Connecting
adaptor
mm
1
Density of
flue gas
flow
g/s
2
Flue gas
tempera-
ture
oC
3
Minimum
draft
Pa
4
Density of
flue gas
flow
g/s
5
Flue gas
temperature
oC
6
Minimum
draft
Pa
7
0,8
Minimum
draft
Pa
4150 - - - 6 320 14 11
With closed doorsWith open doors
Data for calculation of the chimney
Column 2 and 5 show the flue gas temperature in the connecting adaptor
Column 3 and 6 show the lowest/minimum draft in Pa by rated value
Column 7 shows the lowest/minimum draft in Pa by 0.8 x rated value

Krog Iversen & Co. A/S - DK-5492 Vissenbjerg
Warranty conditions
All SCAN wood-burning stoves and inserts are made of first-class material and
are subject to a strict quality control before they leave the factory. However, if
an error should occur, we back all SCAN wood-burning stoves and inserts with
an extensive, five-year limited warranty.
See also the General Instructions for Installation delivered with your stove
for more details.
Technical info
Rated output: 7 kW
Min./max.: 3 - 9 kW
Weight: 115 kg
Connection piece, diameter: int. 135 mm / ext. 148 mm
*
*To the middle of the rear outlet
Distances to flammable
materials (mm)
Production number
Write the production number of your
stove here so that you have it at hand
in case you need to contact us.
You can choose between several floor plates in
different shapes and dimensions for your stove.
Please contact your local authorities concer-
ning the security distances needed.
SCAN 4
Base plate
Base plate
Radiation area
Radiation area
You should read this manual as well as the General Instructions for Installation before beginning the installation.
