SCAN Andersen 1 User manual

INSTRUCTIONS FOR
INSTALLATION AND USE
SCAN
Andersen 1
This manual is accompanied by a
pamphlet with General Instructions for
Installation. Edition 10.04 - GB
MONTERINGSVEJLEDNING
med brugs- og fyringsanvisning
Indhold:
Generelle råd og anvisninger . . . . . . . . . .2-3
Reklamationsret
Type- og miljøgodkendelse
Udpakning
Tilbehør til din pejs
Montering af kakler og fedtsten
Kvalitetskontrol
Anmeldelsespligt
Skorstenstjek
Skorstensløsninger
Bærende underlag
Brændbar eller ikke brændbar væg
Gulvplade
Varmefordeling
Justerskrue
Typeskilt
Produktionsnr.
Servicepakke
Monteringsvejledning. . . . . . . . . . . . . . . . .4-7
Tilslutning til eksisterende/muret skorsten
Tilslutning topafgang til stålskorsten
Forbrændingsluft udefra
Brugs- og fyringsanvisning . . . . . . . . . . . 8-10
Vedligeholdelse af pejseovnen
Håndtering af brændsel
Optænding og fyring
Fejlsøgning . . . . . . . . . . . . . . . . . . . . . . . . 11
SCAN 3
BRUGSANVISNING
TildenneBrugsanvisninghørerogsåen
generelMonteringsvejledning.Udgave03.03-DK
MONTERINGSVEJLEDNING
medbrug
s-ogfyringsanvisning
Indhold:
Generellerådoganvisninger..........2-3
Reklamationsret
Type-ogmiljøgodkendelse
Udpakning
Tilbehørtildinpejs
Monteringafkaklerogfedtsten
Kvalitetskontrol
Anmeldelsespligt
Skorstenstjek
Skorstensløsninger
Bærendeunderlag
Brændbarellerikkebrændbarvæg
Gulvplade
Varmefordeling
Selvlukkendelåge
Justerskrue
Typeskilt
Produktionsnr.
Servicepakke
Monteringsvejledning.................4-7
Tilslutningtileksisterende/muretskorsten
Tilslutningtopafgangtilstålskorsten
Forbrændingsluftudefra
Brugs-ogfyringsanvisning...........8-10
Vedligeholdelseafpejseovnen
Håndteringafbrændsel
Optændingogfyring
Fejlsøgning........................11
Tildennemonteringsvejledninghørerogsåen
separatbrugsanvisningfordenenkeltepejs.
Udgave02/03-DK
Til dennemonteringsvejledning hørerogsåen
separatbrugsanvisning fordenenkelte pejs.
Udgave 02/03 - DK
Approved according to DIN 18891

a
You have chosen a product from one of Europe's leading manufacturers of wood-burning stoves. We are convin-
ced that your stove will be to your full satisfaction and give you many hours of pleasure if you follow the advice
and instructions of this manual.
Please read this manual as well as the General Instructions for Installation before beginning the installation.
Congratulations on your new SCAN stove!
Ceramic smoke deflector
In order to dismount the ceramic smoke deflec-
tor, you should first remove the log guard (a)
and one of the steel fittings on which the plate
rests. Lift up the fitting, where after the rear
part of the plate can be released from the
rear firebrick. Then lift up the ceramic smoke
deflector until this is also released from the
rear firebrick.
Mounting of the heat shields
You have to mount separate heat shields under
the SCAN Andersen 1. Place the stove care-
fully on the back and mount the heat shields as
shown on the sketch.
SCAN Andersen 1
Steel fitting Ceramic smoke deflector

1 Regulation for primary air. Turn the air valve
in order to open. The primary air is used when
lighting and refuelling the stove. It can be clo-
sed during continuous firing.
2 Regulation for combustion air. Push the but-
ton sideways. Left position is closed and right
position is open. The air is used for the combu-
stion and regulates the output of the stove.
Attention! Be careful when you empty
ashes from the stove. There may be embers
left for up to 24 hours after the stove was
last used.
Mounting of the convection plates
Mount the convection plates as shown on the sketch.
The screws and fittings are delivered together with the
convection plates.
Mounting of the legs
Mount the legs according to the same procedure als the
convection sides.
2
1
SCAN Andersen 1
Wood / briquettes Fuel kg/h (beechwood
max. 20% humidity)
SCAN Andersen 1 1,8 kg
Combustion air % 100
Primary air % 100
You should read this manual as well as the General Instructions for Installation before beginning the installation.
Adjustment of the air

Krog Iversen & Co. A/S - DK-5492 Vissenbjerg
Technical info
Rated output: 6 kW
Min./max.: 2 - 8 kW
Weight of radiation stove: 70 kg
Weight of convection stove: 92 kg
Connection piece diameter: int. 120 mm/ext. 128 mm
Warranty conditions
All SCAN wood-burning stoves and inserts are made of first-class material and are subject to a strict quality control,
before they leave the factory. However, if an error should occur, we back all SCAN wood-burning stoves and inserts with
an extensive, five-year limited warranty.
See also the General Instructions for Installation delivered with your stove for more details.
Distances to flammable
materials (mm)
710
385 570
126
SCAN Andersen 1
Data for calculation of the chimney
Stove with convection
You should observe the following mini-
mum distances from the sides of the
stove:
D
C
D
Floor
plate
500
300
Radiation area
Corner
Wall
B
A
C
500
Radiation area
Floor
plate
For radiation stoves, the distance to the side
walls is as follows:
CORNER: 300 mm
WALL: 450 mm
Stove
model
SCAN
Connecting
adaptor
mm
1
Density of
flue gas
flow
g/s
2
Flue gas
tempera-
ture
oC
3
Minimum
draft
Pa
4
Density of
flue gas
flow
g/s
5
Flue gas
temperature
oC
6
Minimum
draft
Pa
7
0,8
Minimum
draft
Pa
A1 130 - - - 7,3 270 13 11
With closed doorsWith open doors
Column 5 shows the flue gas temperature in the connecting adaptor
Column 6 shows the lowest/minimum draft in Pa by rated value
Column 7 shows the lowest/minimum draft in Pa by 0.8 x rated value
